V1.0 | www.tcl.com TW241-TW18 What’s in the box English First time pairing ① Open the charging case and place the earbuds in the charging case for at least 5 seconds. ② The earbud LED indicators flash in blinking blue, close the charging case, the LED indicator will turn off. Open the case to complete the activation. ③ On your device, open Bluetooth ® settings and select TCL MOVEAUDIO Neo to pair. S M L Charging Case & Earbuds USB-C cable Alt. earbud tip sizesQuick start guide Controls Press and hold either earbud for 2 seconds Reject an incoming call / Mute mic on / off * Double tap either earbud Play or pause / Answer or end a call Press and hold left earbud for 2 seconds Previous song Press and hold right earbud for 2 seconds Next song Triple tap right earbud Switch EQ mode: Music, Bass, Podcast and Treble. Triple tap left earbudActivate Siri ® or Google Assistant™ Press and hold right earbud for 5 seconds Turn on Low latency mode Press and hold the left and right earbuds at the same time for 3 seconds Activate ANC * Mute mic on/off is only available during phone calls. Charging the case The LED indicator turns orange when charging, and turns green when charging is complete. Check case battery Open or close the charging case to check the battery level for the case from the case LED indicator lights. If the case battery is 20% or greater the light will be green. If the case battery is lower than 20% the light will be orange. Charging your earbuds The case LED indicator light will turn green for 3 seconds when charging starts. Earbuds will fully charge in 1.5 hours. Charging your headphones and case Reset the headphones ① Place earbud in the charging case with the lid open. ② Press and hold left or right earbud for 8 seconds. The earbud LED indicator flash in blue when earbuds enter reset process. After reset process, the earbuds will enter pairing mode automatically and earbuds LED indicator flashes in blue in cycle. Note: All pairing information is deleted when the earbuds are reset to factory settings. Elementos incluidos Español Primera vez vinculando ① Abra el estuche de carga y coloque los auriculares dentro durante, al menos, 5 segundos. ② Los indicadores LED del auricular parpadearán en azul. Cierre el estuche de carga y se apagará el indicador LED. Abra el estuche para completar la activación. ③ En su dispositivo, abra los ajustes de Bluetooth ® y seleccione TCL MOVEAUDIO Neo para iniciar el emparejamiento. S M L Estuche de carga y auricularesCable USB tipo C Tamaños de almohadilla del auricular Instructivo de uso Controles Mantenga pulsado cualquier auricular durante 2 segundos Rechazar una llamada / Activar/Desactivar micro * Toque dos veces cualquier auricular Reproducir o pausar / Contestar o finalizar una llamada Mantenga pulsado el auricular izquierdo durante 2 segundos Canción anterior Mantenga pulsado el auricular derecho durante 2 segundos Siguiente canción Toque tres veces el auricular derecho Cambiar modo Ecualizador: Modo Música (predeterminado), modo Bajo, modo Pódcast Toque tres veces el auricular izquierdo Activar Siri ® o el Asistente de Google™. Mantenga pulsado el auricular derecho durante 5 segundos Activar el modo Baja latencia Mantenga pulsados los auriculares derecho e izquierdo a la vez durante 3 segundos Activar ANC * Activar o desactivar el micro sólo está disponible durante las llamadas telefónicas. Cargar el estuche El indicador LED se vuelve naranja durante la carga y verde cuando termina de cargar. Comprobar la batería del estuche Abra o cierre el estuche de carga para comprobar su nivel de batería mediante las luces del indicador LED del estuche. Si la batería del estuche es del 20 % o más, la luz será verde. Si la batería del estuche es menos del 20 %, la luz será naranja. Cargar los auriculares La luz del indicador LED del estuche se volverá verde durante 3 segundos cuando comience la carga. Los auriculares se habrán cargado por completo en una hora y media. Cargar los auriculares y el estuche Reiniciar los auriculares ① Coloque los auriculares en el estuche de carga con la tapa abierta. ② Mantenga pulsado el auricular izquierdo o el derecho durante 8 segundos. Los indicadores LED de los auriculares parpadean en azul cuando los auriculares están en proceso de reiniciarse. Después de este proceso, los auriculares entran en el modo de emparejamiento de forma automática y el indicador LED de los auriculares parpadea en azul. Importante: Toda la información del emparejamiento se elimina cuando los auriculares restablecen sus valores predeterminados. English Safety and Precautions Hearing safety Caution: To prevent possible hearing damage, do not listen at high volume levels for long periods. Set the volume to a safe level. Electric-, Magnetic- and Electromagnetic Fields (EMF) This product complies with all applicable standards and regulations regarding exposure to electromagnetic fields. To prevent fire or shock hazard: Always keep this product dry. Do not expose it to excessive heat by heating equipment or direct sunlight. 1 YEAR LIMITED WARRANTY TCL Technology Holding Limited, offers a 1 year limited warranty on selected Head Phones and Audio Products that are found to be defective in materials or workmanship upon submission of the following items: 1. Proof of purchase – consisting of original invoice or sales slip indicating the date of purchase, dealer’s name, model number and serial number of the product is required for warranty support. General Terms and Conditions This warranty is confined to the first purchaser of the product only and is not applicable to cases other than defects in material, design and workmanship. Items and Conditions Not Covered: • Periodic checks, maintenance, repair and replacement of parts due to normal wear and tear. • Abuse or misuses, including but not solely limited to the failure to use this product for its normal purposes or in accordance with TCL’s instructions on usage and maintenance. • Defects resulting from u…
