Safety and Regulatory Information EN-1 Safety and use ����������������������������� We recommend that you read this chapter carefully before using your device. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. TRAFFIC SAFETY: Given that studies show that using a device while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their device when the vehicle is not parked. Check the laws and regulations on the use of wireless devices and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas. CONDITIONS OF USE: • You are advised to switch off the device from time to time to optimize its performance; • Remember to abide by local authority rules of device use on aircrafts; • If your device is a unibody device, where the back cover and battery are not removable, dissembling the device will void your warranty. Disassembling the device can cause bodily injury if the battery is punctured; • Always handle your device with care and keep it in a clean and dust-free place; • Do not allow your device to be exposed to adverse weather or environmental conditions, such as moisture, humidity, rain, infiltration of liquids, dust, sea air, etc. The manufacturer’s recommended operating temperature range is 0°C (32°F) to +40°C (104°F). At over 40°C (104°F), the legibility of the device’s display may be impaired, though this is temporary and not serious; • Do not open, dismantle, or attempt to repair your device yourself; • Do not drop, throw, or bend your device; • Use only batteries, battery chargers, and accessories which are compatible with your device model. • Your device should not be disposed of in a municipal waste. Please check local regulations for disposal of electronic products; • Remember to make backup copies or keep a written record of all important information stored on your device; • Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or EN-2 if you have a family history of such occurrences, please consult your doctor before playing video games on your device or enabling a flashing-lights feature on your device; • Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the devices. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, orientation, or movements. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. PRIVACY: Please note that you must respect the laws and regulations of your jurisdiction or other jurisdiction(s) where you will use your mobile device regarding taking photographs and recording sounds with your mobile device. Pursuant to such laws and regulations, it may be strictly forbidden to take photographs and/or to record the voices of other people or any of their personal attributes, and reproduce or distribute them, as this may be considered to be an invasion of privacy. It is the user’s sole responsibility to ensure that prior authorization be obtained, if necessary, in order to record private or confidential conversations or take a photograph of another person; the manufacturer, the seller or vendor of your mobile device (including the operator) disclaim any liability which may result from the improper use of the mobile device. Legal Information In order to provide you with better access to this important information, we've made the materials accessible from the tablet's Settings menu. Review these materials prior to using your mobile device. To access the materials on your mobile device, swipe up from the home screen, and tap Settings > My device > Legal information , and select a topic. Regulatory Information (e-label) Your device uses an electronic label (e-label) that provides regulatory information about your device. To view the regulatory information (such as FCC ID) for this device, on the device, swipe up from the Home screen, then tap Settings > System > Regulatory & safety . BATTERY: Observe the following precautions: • Do not attempt to open the back cover; EN-3 • Do not attempt to eject, replace, or open battery; • Do not puncture the back cover of your device; • Do not burn or dispose of your device in household rubbish or store it at temperature above 60°C (140°F); • Do not disassemble or open, crush, bend or deform, puncture or shred. • Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, expose to fire, explosion or other hazard. • Only use the battery with a charging system that has been qualified with the system per CTIA Certification Requirements for Battery System Compliance to IEEE 1725. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard. • Improper battery use may result in a fire, explosion or other hazard. • Do not replace an embedded battery pack. Improper replacement may present a risk of fire, explosion, leakage or other hazard. Contact the manufacturer for replacement. • This device shall only be connected to CTIA Certification certified adapters, products that bear the USB-IF logo or products that have completed the USB-IF compliance program. Device and battery as a unibody device must be disposed of in accordance with locally applicable environmental regulations. This symbol on your device, the battery, and the accessories means that…

Text truncated - open the document above for the full version.

ANTportinfo ANT0 ANT2 ANT1 ANT4 ANT5 ANT3 ANT6

15B CE 15B RE BT&WIFI Cellular DFS

ANT6 ANT3 ANT2 ANT1 ANT5ANT4 12.5mm 100mm 40.5mm 14mm 26.5mm 7.0mm 86.6mm 35.2mm 51.65mm 79mm 15.85mm12.50mm Ant0: TRX (G4+W2/4/5+B1/2/3/4/5/8/12/20/25/26/28/66/71+N25/66/71) Ant1: PM(B2/4/25/66) Ant2: TRX(B7/38/41+N41) Ant3: PM(B&N2/4/25/66/41) Ant4: DRX(B5/8/12/20/26/28/71), DM(B&N2/4/25/66/41) Ant5: DRX(B1/2/3/4/7/25/38/41/66) Ant6: WIFI(2.4+5G)+BT+GPS ANT0 ANT2 BandGain (dBi) FDD Band 7-0.8 TDD Band 38-1.2 TDD Band 41-1.2 n41-1.2 Gain ANT6 BandGain (dBi) Wi-Fi 2.4G/BT-1.8 Wi-Fi 5G-2.7 ANT0 BandGain (dBi) GSM850-1.6 GSM1900-1 UMTS II-1 UMTS IV-1 UMTS V-1.6 FDD Band 2-1 FDD Band 4-1 FDD Band 5-1.6 FDD Band 12-2.2 FDD Band 25-1 FDD Band 26-1.6 FDD Band 66-1 FDD Band 71-2.5 n25 -1 n66-1 n71-2.5

Project name：Diana 10.1 Date：2025.03.06 Material: FPC Manufacturer: Shenzhen Haitong Manufacturer Address: Southern District, Phoenix Tower, 15 Nanshan District science and Technology North Road, Shenzhen, Guangdong. ANT0 Band Gain (dBi) GSM850 -1.6 GSM1900 -1 UMTS II -1 UMTS IV -1 UMTS V -1.6 FDD Band 2 -1 FDD Band 4 -1 FDD Band 5 -1.6 FDD Band 12 -2.2 FDD Band 25 -1 FDD Band 26 -1.6 FDD Band 66 -1 FDD Band 71 -2.5 n25 -1 n66 -1 n71 -2.5 ANT2 Band Gain (dBi) FDD Band 7 -0.8 TDD Band 38 -1.2 TDD Band 41 -1.2 n41 -1.2 ANT6 Band Gain (dBi) Wi-Fi 2.4G/BT -1.8 Wi-Fi 5G -2.7 3.2 Radiation Pattern Antenna 0 (Frequency Band) 830MHz 710MHz 3D Radiation Pattern (Frequency Band) 680MHz 1880MHz 3D Radiation Pattern (Frequency Band) 1750MHz 1900MHz 3D Radiation Pattern Antenna 2 (Frequency Band) 2600MHz 3D Radiation Pattern Antenna 6 (Frequency Band) 2440MHz 5200MHz 3D Radiation Pattern

©Copyright. All rights reserved by CTTL. FCC PART 15 TEST REPORT No.24T04Z103031-009 for TCL Communication Ltd. Tablet PC 9185W FCC ID: 2ACCJB229 with Hardware Version: 05 Software Version: 4J3M Issued Date: 2025-03-06 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: CTTL-Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.24T04Z103031-009 ©Copyright. All rights reserved by CTTL. Page 2 of 16 REPORT HISTORY Report Number Revision Description Issue Date 24T04Z103031-009 Rev.0 1st edition 2025-03-06 Note: the latest revision of the test report supersedes all previous version. No.24T04Z103031-009 ©Copyright. All rights reserved by CTTL. Page 3 of 16 CONTENTS CONTENTS .................................................................................................................................................. 3 1. TEST LABORATORY ................................................................................................................. 4 1.1. INTRODUCTION & ACCREDITATION ................................................................................................. 4 1.2. TESTING LOCATION ......................................................................................................................... 4 1.3. TESTING ENVIRONMENT .................................................................................................................. 4 1.4. PROJECT DATE ................................................................................................................................. 4 1.5. SIGNATURE ...................................................................................................................................... 4 2. CLIENT INFORMATION ........................................................................................................... 5 2.1. APPLICANT INFORMATION ............................................................................................................... 5 2.2. MANUFACTURER INFORMATION ...................................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ..................... 6 3.1. ABOUT EUT .................................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .......................................................... 6 3.3. GENERAL DESCRIPTION ................................................................................................................... 6 4. REFERENCE DOCUMENTS ..................................................................................................... 7 4.1. DOCUMENTS SUPPLIED BY APPLICANT ............................................................................................ 7 4.2. REFERENCE DOCUMENTS FOR TESTING ........................................................................................... 7 5. LABORATORY ENVIRONMENT ............................................................................................. 7 6. TEST RESULTS............................................................................................................................ 7 6.1. SUMMARY OF TEST RESULTS ........................................................................................................... 7 6.2. STATEMENTS .................................................................................................................................... 7 6.3. TEST CONDITIONS ........................................................................................................................... 8 7. TEST FACILITIES UTILIZED .................................................................................................. 8 ANNEX A: DETAILED TEST RESULTS .................................................................................................. 9 A.1. MEASUREMENT METHOD .................................................................................................................... 9 A.2. CHANNEL MOVE TIME AND CHANNEL CLOSING TRANSMISSION TIME ................................................. 11 A.3.NON-OCCUPANCY PERIOD .................................................................................................................. 14 A3.1 ASSOCIATED TEST ............................................................................................................................. 14 A.8. ANTENNA REQUIREMENT ............................................................................................................ 15 ANNEX B: EUT PARAMETERS .............................................................................................................. 15 ANNEX C: ACCREDITATION CERTIFICATE .................................................................................... 16 No.24T04Z103031-009 ©Copyright. All rights reserved by CTTL. Page 4 of 16 1. Test Laboratory 1.1. Introduction & Accreditation Telecommunication Technology Labs, CAICT is an ISO/IEC 17025:2017 accredited test laboratory under American Association for Laboratory Accreditation (A2LA) with lab code 7049.01, and is also an FCC accredited test laboratory (CN1349), and ISED accredited test laboratory (CAB identifier:CN0066). The detail accreditation scope can be found on A2LA website. 1.2. Testing Location Location 1:CTTL(Gaolizhang Road) Address: Cuihu Cloud Center, No.1, Gaolizhang Road, Wenquan, Haidian District, Beijing, China 1.3. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.4. Project date Testing Start Date: 2024-12-31 Testing End Date: 202…
