2ACCJB246T-Pen Pro Active Stylus

Quick Start Guide Active Stylus 1 EN Write and draw with T-Pen Pro on compatible TCL tablets just like you would on paper. T-Pen Pro will automatically enter Sleep Mode after 1 minute of inactivity and wake up immediately once you start using it. Paring and Charging Before first use, charge the pen for pairing. After use, attach the pen to the charging area for charging and storage. Replacing the tip Five replacement tips (3 hard tips and 2 soft tips) are included. (1) 1. Rotate the tip counterclockwise to remove it. 2. Rotate the new tip clockwise to secure it. Note: This product is compatible with TCL NOTE A1 NXTPAPER. For more compatibility information, visit our official website: https:// www.tcl.com/global/en/support-mobile Safety and Use WARNING: This product contains removable parts. Keep away from small children. Swallowing by children may cause suffocation or other hazards. (1) Depending on country. Tip Eraser Inspiration key 2 EN - Do not throw the T-Pen Pro into fire or expose it to high temperature. Battery may explode if thrown into fire. - Do not throw or crush the T-Pen Pro. Battery may explode if severely impacted. - Do not keep the device connected to the charger with battery fully charged for a long period of time. - Keep the tip of the T-Pen Pro clean and void of debris, moisture, and other small particles. - To clean the T-Pen Pro exterior, use a lint-free cloth the exterior. Do not use sprays, solvents, or abrasives. Specification ItemDescription Dimensions Length: 166mm Diameter: 8.5-9.0mm Weight About 15.0g Pressure sensitivity levels 8192 Charging modeWireless Contents T-Pen Pro, Quick Start Guide, 5 Replacement tips Warning! CHOCKING HAZARD – small parts. Not suitable for use by children under 3 years. Certification Hereby, TCL Communication Ltd. declares that this equipment of type AS9566X is in compliance with Electromagnetic Compatibility (EMC)Directive 2014/30/EU. This symbol on your device, the battery, and the accessories means that these products must be taken to: - Municipal waste disposal centres with specific bins. - Collection bins at points of sale. 3 EN They will then be recycled, preventing substances being disposed of in the environment. In European Union countries: These collection points are accessible free of charge. All products with this sign must be brought to these collection points. In non-European Union jurisdictions: Items of equipment with this symbol are not to be thrown into ordinary bins if your jurisdiction or your region has suitable recycling and collection facilities; instead they are to be taken to collection points for them to be recycled. FCC Radiation Exposure Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. 4 EN - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/ TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. FCC ID: 2ACCJB246 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF exposure statement: The device was evaluated to meet general RF exposure requirements. The device can be used in portable exposure condition without restriction. Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS) d'Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes: (1) Cet appareil ne doit pas causer d'interférences. (2) Cet appareil doit accepter toutes les interférences, y compris celles susceptibles de provoquer un fonctionnement indésirable de l'appareil. Tout changement ou modification non expressément approuvé par la partie responsable de la conformité pourrait annuler l'autorité de l'utilisateur à utiliser l'équipement. 5 EN Déclaration d'exposition RF: L’appareil a été évalué pour répondre aux exigences générales en matière d’exposition aux RF. L’appareil peut être utilisé en condition d’exposition portable sans restriction. IC: 9238A-0135 CAN ICES-3 (B)/NMB-3(B) Disclaimer There may be certain differences between the user manual description and the device's operation, depending on the sof…

Text truncated - open the document above for the full version.

Rev 1/26/2023 TCL Communication Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Nov. 25, 2025 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2ACCJB246 [TCL Communication Ltd] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [TCL Communication Ltd] certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Ting Wang Rev 1/26/2023 TCL Communication Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Nov. 25, 2025 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2ACCJB246 [TCL Communication Ltd] certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Ting Wang

Summary Antenna Specification ITEM ANT SPEC Antenna type PCB Antenna Center Frequency Horizontal Vertical 2402MHz 2440MHz 2480MHz 2402MHz 2440MHz 2480MHz -1.26-0.76-0.58-5.25-2.46-1.86 MAX. Gain -0.58dBi Polarization Horizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance 50Ohm Antenna Length 9.194mm Manufacture Yingke Song Pen Industry Technology Research and Development Center Shenzhen Co., LTD Address Building 1, Hengda Metropolis Plaza, No. 15, Huancheng South Road, Ma 'antang Community, Bantian Subdistrict, Longgang District, Shenzhen City Horizontal: 2402 MHz 2440 MHz 2480 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Frequency (MHz) Gain(dBi) Max Min Avg 2402 -1.26174-30.0801-7.18716 2440 -0.765802-36.5604-7.48023 2480 -0.585582-22.0315-6.59127 Vertical: 2402 MHz 2440 MH; 2480 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Frequency (MHz) Gain(dBi) Max Min Avg 2402 -5.2537-22.1424-12.4294 2440 -2.4652-24.5837-10.4702 2480 -1.86120-29.5214-9.20432 ANT Test Labs： Attestation of Global Compliance Co., Ltd.

TCL Communication Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: November 26, 2025 Subject; Request for Confidentiality FCC ID: 2ACCJB246 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Ting Wang Title: Manager

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 TCL Communication Ltd Date: Nov. 25, 2025 Product Model Number: AS9566X FCC ID: 2ACCJB246 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following:  Testing  Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: +8613502294537 On behalf of: TCL Communication Ltd

Ext Photos Model: AS9566X Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

Note：Due to the product structure, the size is too small, so the label is printed on the packaging box.

Int Photos Model: AS9566X Photo 1 Photo 2 Photo 3 Photo 4 RX ANT Photo 5 Photo 6 PCB ANT Photo 6

- Page 1 of 9 - Report No.: HB20251124055E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com RF EXPOSURE Test Report Product: T-Pen Pro Active Stylus Trade Mark: TCL Model Number: AS9566X FCC ID: 2ACCJB246 Prepared for TCL Communication Ltd 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong Prepared by Shenzhen HongBiao Certification& Testing Co., Ltd Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen, China Tel.: +86-755-2998 9321 Fax.: +86-755-2998 5110 Website: http://www.sz-hongbiao.com - Page 2 of 9 - Report No.: HB20251124055E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Table of Contents 1 GENERAL DESCRIPTION ................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................ 5 1.2 TEST MODE .............................................................................................................................................................. 5 1.3 TEST SETUP .............................................................................................................................................................. 5 1.4 ANCILLARY EQUIPMENT .............................................................................................................................................. 5 2 TEST FACILITIES AND ACCREDITATIONS ............................................................................................................ 6 2.1 TEST LABORATORY ..................................................................................................................................................... 6 2.2 ENVIRONMENTAL CONDITIONS ..................................................................................................................................... 6 2.3 MEASUREMENT UNCERTAINTY ..................................................................................................................................... 6 2.4 TEST SOFTWARE ........................................................................................................................................................ 6 3 LIST OF TEST EQUIPMENT ................................................................................................................................ 7 4 RF EXPOSURE .................................................................................................................................................. 8 4.1 STANDALONE SAR TEST EXCLUSION CONSIDERATIONS........................................................................................................ 8 4.1.1. Limit ............................................................................................................................................................ 8 4.1.2. Test Procedures ........................................................................................................................................... 8 4.1.3. Test Result ................................................................................................................................................... 9 - Page 3 of 9 - Report No.: HB20251124055E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com TEST RESULT CERTIFICATION Applicant’s Name ................. : TCL Communication Ltd Address ................................. : 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong Manufacturer's Name .......... : TCL Communication Ltd Address ................................. : 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong Product description Product name ........................ : T-Pen Pro Active Stylus Model Number ....................... : AS9566X Standards ............................. : FCC CFR 47 PART 1 , 1.1310 Test procedure ....................... : KDB 447498 D01 General RF Exposure Guidance v06 This device described above has been tested by Shenzhen HongBiao Certification& Testing Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the EMC requirements. And it is applicable only to the tested sample identified in the report. Date of Test ............................................ : Date (s) of performance of tests ............. : Nov. 11, 2025~Nov. 25, 2025 Test Result ............................................... : Pass Testing Engineer : (Zoe Su) Technical Manager : ( G a r y Lu) Authorized Signatory : (L e o S u) - Page 4 of 9 - Report No.: HB20251124055E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Revision History Revised No. Date of Issue Description 01 Nov. 25, 2025 Original - Page 5 of 9 - Report No.: HB20251124055E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com 1 General Description 1.1 Description of EUT Product name: T-Pen Pro Active Stylus Model name: AS9566X Series Mo…
