2ACCJH021HSUPA/HSDPA/UMTS Tri band/GSM Quad band mobile phone

12 English - CJB287CALAAA Quick Start Guide For more information about how to use your mobile phone, please visit www.alcatelonetouch.us to consult the FAQ, perform software upgrades, etc. www.sar-tick.com This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found in the RADIOWAVES section of this user guide. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 10 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. 1 Your mobile ����������������� 1�1 Keys and connectors Headset connector Micro-USB connector Back key Home key Menu key Touch screen Front Camera


 5HORRN Pixi3-4 Relook 4014A_4014E USA QG_Eng_EN_02_150714.indd 1-22015/7/14 10:10:58 34 Volume up Volume down Camera Flash/Flashlight Power key Menu key • Option menu. Touch to access Manage Home- screen, Add widgets, Manage applications, Wallpaper and Settings. • Recent apps. Touch and hold to open a list of thumbnail images of apps you've worked with recently. Touch it to open an app. Swipe it up or down to remove a thumbnail from the list. Home key • While on any application or screen, touch to return to the Home screen. Back key • Touch to go back to the previous screen, to close a dialog box, options menu, the notification panel, etc. Power key • Press: Lock the screen/Light up the screen. • Press and hold: Power on or generate a pop up menu selecting from Power off/Restart/Airplane mode or Ringer mode icons. • Press to mute the ringtone when there’s an incoming call. • Press and hold for more than 10 seconds to restart the phone if it has become unresponsive. • Press and hold the Power key and Volume down key to capture a screenshot. • Press and hold the Power key and Volume up key under power off mode to restore factory settings. Volume keys • Under call mode, adjust the earpiece or headset volume. • In Music/Video/Streaming mode, adjust the media volume. • In general mode, adjust the ringtone volume. • Mute the ringtone of an incoming call. • In Camera mode, using it as the capture key allows you to take a photo. Pixi3-4 Relook 4014A_4014E USA QG_Eng_EN_02_150714.indd 3-42015/7/14 10:10:58 56 1�2 Getting started 1�2�1 Set up Installing or removing the back cover Inserting or removing the SIM card You must insert your SIM card to make phone calls. Please power off your phone before inserting or removing the SIM card. 4014A 4014E Place the SIM card with the chip facing down and slide it into its housing. Make sure that it is correctly inserted. To remove the card, press and slide it out. Both SIM1 and SIM2 can support 2G and 3G networks. If both of them are 3G SIM cards, only one card can support 3G network (1) . Your phone only supports mini-SIM cards. Do not attempt to insert other SIM types, such as micro and nano cards, otherwise you may damage your phone. (1) 4014E only. Installing or removing the battery Please power off your phone before removing the battery. • Insert and click the battery into place, then close the cover. • Unclip the cover, then remove the battery. Installing or removing the microSD card To install, please open the microSD card lock first, then place the external microSD card into the slot with the gold contact facing down. To remove the external microSD card, please open the microSD card lock and take it out from the slot. Charging the battery Connect the battery charger to your phone and plug it into the socket. If the battery is very low, there will be no indication that power is being received until the charge is sufficient to show the charging status bar. To reduce power consumption and energy waste, once the battery is fully charged, disconnect your charger from the plug; switch off Wi-Fi, GPS, Bluetooth or background-running applications when not in use; reduce the backlight time, etc. Pixi3-4 Relook 4014A_4014E USA QG_Eng_EN_02_150714.indd 5-62015/7/14 10:11:06 78 1�2�2 Power on your phone Hold down the Power key until the phone powers on. It will take a few seconds before the screen lights up. Set up your phone for the first time The first time you power on the phone, you should set the following options: language, input method, Google account, etc. If you power on your phone with no SIM card inserted, you can connect to a Wi-Fi network to sign into your Google account to use some features. For dual SIM mode, you should select a SIM card or choose Always ask for voice call, messaging, etc (1) . 1�2�3 Power off your phone Hold down the Power key until the Phone options appear, select Power off. 1�3 Home screen You can bring all of the items (applications, shortcuts, folders and widgets) you love or use most frequently to your Home screen for quick access. Touch the Home key to switch to Home screen. Status bar • Status/Notification indicators • Touch and drag down to open the notification panel. Application tab • Touch to open main menu. Search bar • Touch  to enter text search screen. • Touch  to enter voice search screen. Favorite applications tray • Touch to enter the application. • Touch and hold to move or change applications. Add a location to display local weather. (1) 4014E only. Home screen is provided in an extended format to allow more space for adding applications, shortcuts etc. Slide the Home screen horizontally left and right to get a complete view of the Home screen. The row of small squares at the lower part of the screen indicates which screen you are viewing. 1�3�1 Using the touchscreen Touch To access an application, touch it with your finger. Touch and Hold Touch and hold the home screen to access the available options for sett…

Text truncated - open the document above for the full version.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com Date 2015-01-19 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL-Terminals Test Lab of China Academy of Telecommunication Research of MIIT is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Te l : +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com 2015-06-29 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2ACCJH021 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

EUT photograph Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone Mobile Phone

EUT Interior photograph Mobile Phone Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly Mobile Phone Disassembly

©Copyright. All rights reserved by CTTL. TEST REPORT No. I15Z41460-EMC01 for TCL Communication Ltd HSUPA/HSDPA/UMTS Tri band/GSM Quad band mobile phone Model Name: 4014A FCC ID: 2ACCJH021 with Hardware Version: PIO Software Version: v5B60 Issued Date: 2015-06-23 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. Test Laboratory: FCC 2.948 Listed: No. 525429 CTTL, Telecommunication Technology Labs, Academy of Telecommunication Research, MIIT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel: +86(0)10-62304633-2512, Fax: +86(0)10-62304633-2504 Email: [email protected], website: www.chinattl.com No.I15Z41460-EMC01 Page 2 of 27 ©Copyright. All rights reserved by CTTL. REPORT HISTORY Report Number Revision Description Issue Date I15Z41460-EMC01 Rev.0 1st edition 2015-06-23 No.I15Z41460-EMC01 Page 3 of 27 ©Copyright. All rights reserved by CTTL. CONTENTS 1. TEST LABORATORY .............................................................................................................. 4 1.1. TESTING LOCATION .......................................................................................................... 4 1.2. TESTING ENVIRONMENT .................................................................................................. 4 1.3. PROJECT DATA .................................................................................................................. 4 1.4. SIGNATURE ........................................................................................................................ 4 2. CLIENT INFORMATION .......................................................................................................... 5 2.1. APPLICANT INFORMATION............................................................................................... 5 2.2. MANUFACTURER INFORMATION ..................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT ........................................................................................................................ 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 6 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 6 3.4. EUT SET-UPS ..................................................................................................................... 7 4. REFERENCE DOCUMENTS .................................................................................................. 9 4.1. REFERENCE DOCUMENTS FOR TESTING ...................................................................... 9 5. LABORATORY ENVIRONMENT .......................................................................................... 10 6. SUMMARY OF TEST RESULTS ........................................................................................... 11 7. TEST EQUIPMENTS UTILIZED ............................................................................................ 12 ANNEX A: MEASUREMENT RESULTS ...................................................................................... 13 No.I15Z41460-EMC01 Page 4 of 27 ©Copyright. All rights reserved by CTTL. 1. Test Laboratory 1.1. Testing Location Location 1: CTTL(huayuan North Road) Address: No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191 1.2. Testing Environment Normal Temperature: 15-35°C Relative Humidity: 20-75% 1.3. Project data Testing Start Date: 2014-11-26 Testing End Date: 2014-12-10 1.4. Signature Zhang Ying (Prepared this test report) Qu Pengfei (Reviewed this test report) Liu Baodian (Approved this test report) No.I15Z41460-EMC01 Page 5 of 27 ©Copyright. All rights reserved by CTTL. 2. Client Information 2.1. Applicant Information Company Name: TCL Communication Ltd Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. 201203 City: Shanghai Postal Code: 201203 Country: China Contact Person: Gong Zhizhou Contact Email [email protected] Telephone: 0086-21-51798260 Fax: 0086-21-61460602 2.2. Manufacturer Information Company Name: TCL Communication Ltd Address /Post: 5F, C building, No. 232, Liang Jing Road ZhangJiang High-Tech Park, Pudong Area Shanghai, P.R. China. City: Shanghai Postal Code: 201203 Country: China Telephone: 0086-21-51798260 Fax: 0086-21-61460602 No.I15Z41460-EMC01 Page 6 of 27 ©Copyright. All rights reserved by CTTL. 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description HSUPA/HSDPA/UMTS Tri band/GSM Quad band mobile phone Model Name 4014A FCC ID 2ACCJH021 Extreme vol. Limits 3.5VDC to 4.2VDC (nominal: 3.8VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Telecommunication Metrology Center of MIIT of People’s Republic of China. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 / PIO v5B60 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN Remarks AE2 Battery / / AE3 Battery / 14TCT-BA-0092 AE4 Battery / 14TCT-BA-0231 AE5 Battery / 14TCT-BA-0123 AE6 Battery / 14TCT-BA-0097 AE7 Battery / 14TCT-BA-0113 AE8 Travel charger / 14TCT-CH-1231 AE10 Travel charger / 14TCT-CH-2119 AE11 Travel charger / 14TCT-CH-2208 AE12 Travel charger / 14TCT-CH-2186 AE13 USB cable / 14TCT-DC-0619 AE14 USB cable / 14TCT-DC-0316 AE16 USB cable / / AE17 USB cable / / AE2 Model CAB1300015C2 Manufacturer SCUD Capacitance 1300mAh Nominal voltage 3.7V AE3, AE4, AE5, AE6, AE7 Model CAB31P0000C1 Manufacturer BYD Capacitance 1300mAh Nominal voltage 3.7V No.I15Z41460-EMC01 Page 7 of 27 ©Copyright. All rights reser…

Text truncated - open the document above for the full version.

FDD Con D ID 2ACCJ nducted em JH021 mission RE Rad diated Spurrious Emisssion
