1 QUICK START GUIDE Your Mobile Keys and connectors Front camera Power key Volume up/down Headset connector Back button Recent button Home button Micro-USB connector The Google Assistant Button English - CJB2EM102AAA Printed in China PLEASE CONSIDER THE ENVIRONMENT BEFORE PRINTING us.alcatelmobile.com SAVE PAPER SAVE TREES 23 Back camera Back flash Fingerprint sensor Getting started 1 Charge the battery 2 Insert or remove the microSD card. 3 Insert or remove the SIM card. Home screen You can bring all of the items (applications, shortcuts, folders) that you use most frequently to your Home screen for quick access. Touching the Home button always takes you back to the main Home screen. 2 1 1 : Open Settings, to view the full list of settings. 2 : Touch and drag down to open the Notification panel. 45 Phone call Making a call Enter the desired number from the keyboard and touch to make a call. Answering a call When you receive a call, swipe to the right to answer or swipe to the left to reject. 1 2 3 4 1 : Reject by SMS 2 : Reject by Alarm 3 : Answer the call 4 : Reject the call Contacts You can view and create contacts on your phone and synchronize these with your Gmail contacts or other applications on the web or on your phone. 1 2 3 1 : Search in Contacts 2 : Open the Quick contact panel Long press to share or delete the selected contact 3 : Add new contact 67 Messaging You can create, edit, and receive SMS and MMS. An SMS will be converted to MMS automatically when media files (image, video, audio, slides, etc.) are attached or subject or email addresses are added. 1 2 1 : Send the text message 2 : Insert emoticons Gmail The first time you set up your phone, you can select to use an existing Gmail account or to create a new one. 1 2 3 4 1 : Account information 2 : See options and settings 3 : Swipe right or left to archive the email 4 : Create an email 89 Help To get help: • View user manual and FAQ www.alcatelmobile.com • Update your phone's software Go to Settings > System > System Update to check software updates. • Back up your personal data Go to Settings > System > Backup > Back up to Google Drive and turn it on. • Reset your phone Go to Settings > System > Reset > Factory data reset, and then touch to reset you Phone. Support 1. Enter from your Smartphone / Tablet to the application: Support centre 2. Check our frequently asked questions or chat with us through https://www. alcatelmobile.com in the Support section. 3. Call the Call Center Locate your number, below: Argentina: 8004447361 Australia: 1800218730 Canada: 8558446058 Chile: 12300209025 Colombia: 18005183882 Ecuador: 800000635 Mexico: 8001124682 New Zealand: 0800451708 Peru: 80055639 Dominican Republic: 18002039552 Uruguay: 40190752 USA: 18553680829 Venezuela: 8001362017

Safety and Precautions This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found in the Radio waves section. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 15 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your phone near your ear while the loudspeaker is in use. www.sar-tick.com English - CQF2EG2ALAAA Printed in China 1 Safety and use ������������������������������������������������������������������������������������������������ We recommend that you read this chapter carefully before using your phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. TRAFFIC SAFETY: Given that studies show that using a phone while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset, etc.), drivers are requested to refrain from using their phone when the vehicle is not parked. Check the laws and regulations on the use of wireless phones and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas. CONDITIONS OF USE: • You are advised to switch off the phone from time to time to optimize its performance. • Remember to abide by local authority rules of mobile phone use on aircrafts. • If your phone is a unibody device, where the back cover and battery are not removable, disassembling the phone will void your warranty. Disassembling the phone can cause bodily injury if the battery is punctured. • Always handle your phone with care and keep it in a clean and dust-free place. • Do not allow your phone to be exposed to adverse weather or environmental conditions, such as moisture, humidity, rain, infiltration of liquids, dust, sea air, etc. The manufacturer’s recommended operating temperature range is -10°C (14°F) to +45°C (113°F). At over 45°C (113°F), the legibility of the phone’s display may be temporarily impaired. • Do not open, dismantle, or attempt to repair your phone yourself. • Do not drop, throw, or bend your phone. • Use only batteries, battery chargers, and accessories which are recommended by TCL Communication Ltd. and its affiliates and which are compatible with your phone model. TCL Communication Ltd. and its affiliates disclaim any liability for damage caused by the use of other chargers or batteries. 2 • Your phone should not be disposed of in a municipal waste. Please check local regulations for disposal of electronic products. • Remember to make backup copies or keep a written record of all important information stored on your phone. • Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when playing video games. These seizures or blackouts may occur even if a person has never experienced them before. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing-lights feature on your phone. • Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, orientation, or movements. PRIVACY: Please note that you must respect the laws and regulations in force in your jurisdiction or other jurisdiction(s) where you will use your phone regarding taking photographs and recording sounds with your phone. Pursuant to such laws and regulations, it may be strictly forbidden to take photographs and/or to record the voices of other people or any of their personal attributes, and reproduce or distribute them, as this may be considered to be an invasion of privacy. It is the user's sole responsibility to ensure that prior authorization has been obtained, if necessary, in order to record private or confidential conversations or take a photograph of another person; the manufacturer, the seller or vendor of your phone (including the carrier) disclaim any liability which may result from improper use of the phone. BATTERY: For a non-unibody device: Observe the following precautions: • Do not attempt to open the battery (due to the risk of toxic fumes and burns). • Do not puncture, disassemble, or cause a short circuit in the battery. • Do not burn or dispose of a used battery in household garbage or store it at temperatures above 60°C (140°F). 3 Batteries must be disposed of in accordance with locally applicable environmental regulations. Only use the battery for the purpose for which it was designed. Never use damaged batteries or those not recommended by TCL Communication Ltd. and/or its affiliates. For a non-unibody device with a non-removable battery: Observe the following precautions: • Do not attempt to eject, replace, or open the battery. • Do not puncture, disassemble, or cause a short circuit in the battery. • Do not burn or dispose of your phone in household garbage or store it at temperature above 60°C (140°F). Phone and battery must be disposed of in accordance with locally applicable environmental regulations. For a unibody device: Observe the following precautions: • Do not attempt to open the back cover. • Do not attempt to eject, replace, or open the battery. • Do not puncture the back cover of your phone. • Do not burn or dispose of your phone in household rubbish or store it at temperature above 60°C (140°F). Phone and battery as a unibody device must be disposed of in accordance with locally …
