2ACCJH130GSM/UMTS/LTE Mobile phone

Safety and Precautions This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found on Radio waves section. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 15 mm from the body to ensure compliance with radiofrequency (RF) exposure requirements. Note that the product may be transmitting even if you are not making a phone call. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your phone near your ear while the loudspeaker is in use. www.sartick.com Printed in China 1 Safety and use ������������������������������������������������������������������������������������������������ You are recommended to carefully read this chapter before using your phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. TRAFFIC SAFETY Given that studies show that using a phone while driving a vehicle constitutes a real risk, even when a hands-free device is used (such as Bluetooth car kit or headset), drivers are recommended to refrain from using their phone when the vehicle is not parked. Check the laws and regulations on the use of wireless phones and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas. CONDITIONS OF USE • You are advised to restart the phone from time to time to optimize its performance. • Remember to abide by local authority rules of mobile phone use on aircrafts. • If your phone is a unibody device (meaning the back cover and battery are not removable), disassembling the phone can cause bodily injury if the battery is punctured, and will void your warranty. • Always handle your phone with care and keep it in a clean and dust-free place. • Do not allow your phone to be exposed to adverse weather or environmental conditions, such as moisture, humidity, rain, infiltration of liquids, dust, sea air, etc. The manufacturer’s recommended operating temperature range is between -10°C (14°F) and 55°C (131°F). At over 55°C (131°F), the legibility of the phone’s display may be impaired, though this is temporary and not serious. • Do not open, dismantle, or attempt to repair your phone yourself. 2 • Do not drop, throw, or bend your phone. • Use only batteries, battery chargers, and accessories which are recommended by TCL Communication Ltd. and its affiliates and are compatible with your phone model. TCL Communication Ltd. and its affiliates disclaim any liability for damage caused by the use of other chargers or batteries. • Your phone should not be disposed of in a municipal waste. Please check local regulations for disposal of electronic products. • Remember to make backup copies or keep a written record of all important information stored on your phone. • Some people may suffer epileptic seizures or blackouts when exposed to flashing lights or when playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing-lights feature on your phone. • Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, orientation, or movements. US Information Concerning the Federal Communications Commission (“FCC”) Requirements for Hearing Aid Compatibility with Wireless Devices When wireless devices are used near hearing devices (such as hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference, and wireless devices also vary in the amount of interference that they generate. The wireless telephone industry has developed ratings to assist hearing device users in finding wireless devices that may be compatible with their hearing devices. Not all wireless devices have been rated. Wireless devices that are rated will have the rating displayed on the box together with other relevant approval markings. 3 The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device is vulnerable to interference, you may not be able to use a rated wireless device successfully. Consulting with your hearing health professional and testing the wireless device with your hearing device is the best way to evaluate it for your personal needs. This smartphone has been tested and rated for use with hearing aids for some of the wireless technologies that the smartphone uses. However, other wireless technologies may be used in this smartphone that have not been tested for use with hearing aids. It is important to try the different features of your smartphone thoroughly and in different locations to determine if you hear any interfering noise when using this smartphone with your hearing aid or cochlear implant. Consult your wireless service provider about its return and exchange policies, and for information about hearing aid compatibility. Hearing aid compatibility rating for this smartphone: M4/T4 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may caus…

Text truncated - open the document above for the full version.

TCLCommunicationLtd. 5F,Cbuilding,No.232,LiangJingRoad, ZhangJiangHigh-TechPark,Pudong Shanghai,P.R.China.201203 Tel:+862161460666Fax:+862161460602http://tclcom.tcl.com Date2020-10-21 To:FederalCommunicationsCommission, Authorization&EvaluationDivision, 7345OaklandMillsRoad Columbia,MD21046 AndAmericanCertificationBody,Inc. 6731WhittierAvenue SuiteC110 McLean,VA22101 ToWhomItMayConcern: ShenzhenAcademyofInformationandCommunicationTechnologyisauthorizedto actonourbehalf,untilotherwisenotified,forapplicationstoAmericanCertification Body,Inc.(ACB). Wecertifythatwearenotsubjecttodenialoffederalbenefits,whichincludesFCC benefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,U.S.C.862. Further,noparty,asdefinedin47CFR1.2002(b)totheapplicationissubjectto denialoffederalbenefits,thatincludesFCCbenefits. Thankyou. Regards, ZhizhouGONG ProductCertificationManager TCLCommunicationLtd.

5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong TEL: 0086-755-36611722 2020-09-29 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2ACCJH130 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong TEL: 0086-755-36611722 2020-09-29 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality request for FCC ID: 2ACCJH130 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days: - External Photos - Internal Photos - Test Setup Photos - User manual The applicant also acknowledges that they will also provide appropriate notice to ACB should either of the following occur: a) if the applicant requires additional 45 days extension periods they will notify ACB with a new request letter at least 7 days prior to the short-term confidentiality expiration date – [Note: up to a maximum of 3 extensions only are allowed], or b) immediately notify ACB in the event the information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

TLp034G1‐1 TLp034G1‐2 QC13US QC13US label CDA0000134C2

TEST REPORT No.I20N02478-EMC for TCL Communication Ltd. GSM/UMTS/LTE Mobile phone Model Name：5007S With Hardware Version: 03 Software Version: v2D23UZ31 FCC ID: 2ACCJH130 Issued Date: 2020-10-16 Designation Number: CN1210 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of SAICT. Test Laboratory: SAICT, Shenzhen Academy of Information and Communications Technology Building G, Shenzhen International Innovation Center, No.1006 Shennan Road, Futian District, Shenzhen, Guangdong, P. R. China 518026. Tel:+86(0)755-33322000, Fax:+86(0)755-33322001 Email: [email protected]. www.saict.ac.cn No.I20N02478-EMC ©Copyright. All rights reserved by SAICT. Page 2 of 28 REPORT HISTORY Report Number Revision Description Issue Date I20N02478-EMC Rev.0 1st edition 2020-10-16 Note: the latest revision of the test report supersedes all previous version. No.I20N02478-EMC ©Copyright. All rights reserved by SAICT. Page 3 of 28 CONTENTS 1. SUMMARY OF TEST REPORT ........................................................................................................ 4 1.1. TEST ITEMS ......................................................................................................................................... 4 1.2. TEST STANDARDS ............................................................................................................................ 4 1.3. TEST RESULT ..................................................................................................................................... 4 1.4. TESTING LOCATION.......................................................................................................................... 4 1.5. PROJECT DATA .................................................................................................................................. 4 1.6. SIGNATURE ......................................................................................................................................... 4 2. CLIENTINFORMATION ...................................................................................................................... 5 2.1. APPLICANT INFORMATION ............................................................................................................. 5 2.2. MANUFACTURER INFORMATION .................................................................................................. 5 3. EQUIPMENT UNDERTEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................ 6 3.1. ABOUT EUT ......................................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT ............................................................................................ 6 3.3. INTERNAL IDENTIFICATION OF AE ............................................................................................... 6 3.4. EUT SET-UPS ...................................................................................................................................... 7 3.5. GENERAL DESCRIPTION ................................................................................................................. 8 4. REFERENCE DOCUMENTS ............................................................................................................. 9 4.1. REFERENCE DOCUMENTS FOR TESTING ................................................................................. 9 5. LABORATORY ENVIRONMENT .................................................................................................... 10 6. SUMMARY OF TEST RESULTS ...................................................................................................... 11 6.1. TESTING ENVIRONMENT ................................................................................................................ 11 6.2. SUMMARY OF MEASUREMENT RESULTS ................................................................................. 11 6.3. STATEMENT ........................................................................................................................................ 11 7. MEASUREMENT UNCERTAINTY .................................................................................................. 12 8. TEST FACILITIES UTILIZED ........................................................................................................... 12 ANNEX A: MEASUREMENT RESULTS ................................................................................................ 13 A.1 RADIATED EMISSION (§15.109(A))............................................................................................... 13 A.2 CONDUCTED EMISSION (§15.107(A)) ......................................................................................... 24 No.I20N02478-EMC ©Copyright. All rights reserved by SAICT. Page 5 of 28 2. ClientInformation 2.1. Applicant Information Company Name: TCL Communication Ltd. Address /Post: 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong City: Hong Kong Postal Code: / Country: China Telephone: 0086-755-36611722 2.2. Manufacturer Information Company Name: TCL Communication Ltd. Address /Post: 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong City: Hong Kong Postal Code: / Country: China Telephone: 0086-755-36611722 No.I20N02478-EMC ©Copyright. All rights reserved by SAICT. Page 6 of 28 3. Equipment UnderTest (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description GSM/UMTS/LTE Mobile phone Model Name 5007S FCC ID 2ACCJH130 Antenna Type Internal Antenna Condition of EUT as received No obvious damage in appearance Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of Shenzhen Academy of Information and Communications Technology. 3.2. Inter…

Text truncated - open the document above for the full version.

Test Setup Photos 1. Radiated Emissions (Part 15B,USB mode +FM+ LTE idle,30MHz- 1GHz) 2. Radiated Emissions (Part 15B USB mode +FM+ LTE idle,1GHz- 18GHz) 3. Radiated Emissions (Part 15B，Charger+MP4/GNSS/ Camera /GSM idle/WCDMA idle/LTE idle,30MHz-1GHz) 4. Radiated Emissions (Part 15B，Charger+MP4/GNSS/ Camera /GSM idle/WCDMA idle/LTE idle,1GHz-18GHz) 5. Radiated Emissions (Part 22/24/27,30MHz-18GHz) 6. Radiated Emissions (Part 22/24/27, 18GHz -26.5GHz) 7. Radiated Emissions (Part 22/24/27, 26.5GHz -40GHz) 8. Conducted Emission (Part 15B，Charger+MP4/GNSS/ Camera /GSM idle/WCDMA idle/LTE idle) 9. Conducted Emission (Part 15B，USB mode +FM/LTE idle)
