2ACCJH132GSM/UMTS/LTE Mobile phone

1 Safety and use Please read before using your phone THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE BOX. DO NOT REMOVE THE BATTERY PACK WHEN THE PHONE IS CHARGING. Privacy restrictions Some countries require full disclosure of recorded telephone conversations, and stipulate that you must inform the person with whom you are speaking that the conversation is being recorded. Always obey the relevant laws and regulations of your country when using the recording feature of your phone. Disclaimers ANY WEATHER, STOCK, OR OTHER INFORMATION, DATA, OR DOCUMENTATION (“ACCESSED INFORMATION”) ARE PROVIDED “AS IS” AND WITHOUT ANY WARRANTY OR ANY TECHNICAL SUPPORT. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, TCL MOBILE AND ITS AFFILIATES expressly disclaim any and all representations and warranties, arising by law or otherwise, related to the Accessed Information, including without limitation any express or implied representation or warranty of merchantability, fitness for a particular purpose, non-infringement, quality, accuracy, completeness, effectiveness, reliability, or usefulness. Without limiting the foregoing, it is further understood that TCL Mobile and its Affiliates are not responsible for any use of the Accessed Information or the results arising from such use, and that you use such information at your own risk. Limitation of damages TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL TCL MOBILE OR ITS AFFILIATES BE LIABLE TO YOU, ANY USER, OR THIRD PARTY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES OF ANY KIND, ARISING IN CONTRACT, TORT, OR OTHERWISE, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF REVENUE, LOSS OF GOODWILL, LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS, REGARDLESS OF THE FORESEEABILITY THEREOF OR WHETHER TCL MOBILE OR ITS AFFILIATES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. AND IN NO EVENT SHALL THE TOTAL LIABILITY OF TCL MOBILE OR ITS AFFILIATES EXCEED THE AMOUNT RECEIVED FROM YOU, REGARDLESS OF THE LEGAL THEORY UNDER WHICH THE CAUSE OF ACTION IS BROUGHT. THE FOREGOING DOES NOT AFFECT ANY STATUTORY RIGHTS WHICH MAY NOT BE DISCLAIMED. 2 Important health information and safety precautions When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages. Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product. To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions. WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov Electrical safety This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product. Safety precautions for proper grounding installation CAUTION: Connecting to improperly grounded equipment can result in an electric shock to your device. Safety precautions for power supply unit  Use the correct external power source A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product. This product should be operated only with the following designated power supply unit(s). Travel charger: Input: 100-240 V, 50/60 Hz, 0.2A Output: 5 V, 1A Battery: Lithium 3500mAh  Take extra precautions • Do not attempt to open the back cover; • Do not attempt to eject, replace, or open the battery; • Do not puncture the back cover of your phone; • Do not burn or dispose of your phone in household garbage or store it at temperature above 60°C (140°F); Phone and battery as a unibody device must be disposed of in accordance with locally applicable environmental regulations. 3 This symbol on your phone, the battery, and the accessories mean that these products must be taken to collection points at the end of their life: • Municipal waste disposal centers with specific bins for these types of equipment; • Collection bins at points of sale. They will then be recycled, preventing substances from being disposed of in the environment, so that their components can be reused. Safety precautions for direct sunlight Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 140 ̊F (60 ̊C), such as on a car dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your device near your ear while the loudspeaker is in use. Safety in aircraft Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an airplane is against the law in most countries. If you want to use this device when on board an aircraft, remember to turn off your phone by switching to Airplane Mode. Environment restrictions Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fueling areas, fuel storehouses, below deck on boats, chemical plants, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or fire resulting in bodily injury or…

Text truncated - open the document above for the full version.

English - CJB2G80KFAAA Printed in China Quick Start Guide Thank you for choosing TCL. This booklet helps you get started with your new device. For more information about your phone or to download the complete user manual version, please visit tcl.com/us Phone Setup Installing or removing the SIM card and microSD TM card Your phone already has a SIM card installed. If you need to change or remove your SIM card, follow the steps below.  Use the provided SIM pin to open the SIM tray.  To install SIM/microSD TM card, place the SIM/microSD TM card with the chip facing down into the SIM card tray and then slide it into its slot.  To remove SIM/microSD TM card, push up on the chip side of the cards inside the SIM tray.   Charging the battery It is advised that you fully charge your battery ( ). Connect the charger to your phone and an outlet. Charging status is indicated by the percentage on screen while the phone is powered off. The percentage increases as the phone is charged. Power on your phone Hold down the Power key until the phone powers on, unlock your phone (screen lock, face unlock, password, etc.) if necessary and confirm. The Home screen is displayed. If you do not know your PIN/password or pattern, or if you have forgotten it, contact your service provider. Do not leave your PIN/password or pattern, with your phone. Store this information in a safe place when not in use. Set up your phone for the first time The first time you power on the phone, you'd better to set the following options: language, mobile data, Google service, and date & time, etc. Power off your phone Hold down the Power key from any screen until the phone options appear, select Power off. Personalize your Home screen Add You can touch and hold a folder, an application or a widget to activate the Move mode and drag the item to any Home screen as you prefer. Reposition Touch and hold the item to be repositioned to activate the Move mode, drag the item to the desired position and then release. You can move items both on the Home screen and the favorite tray. Hold the icon on the left or right edge of the screen to drag the item to another Home screen. Remove Touch and hold the item to be removed to activate the Move mode, drag the item up to the top of the Remove icon, and release after the item turns grey. Create folders To improve the organization of items (shortcuts or applications) on the Home screen and the favorite tray, you can add them to a folder by stacking one item on top of another. To rename a folder, open it and touch the folder’s title bar to input the new name. Wallpaper customization Touch and hold the Home screen then touch Wallpapers to customize wallpaper. Messages You can create, edit, and receive SMS and MMS with this phone. To access this feature, touch Messages from the Home screen. Touch to take a photo/video or attach a photo/video. Touch to give access to your location, send a voice message or attach files. Touch to enter voice input. Touch to switch to "abc/Abc" mode; Touch and hold to switch to "ABC" mode. Sending a message Enter the mobile phone number of the recipient in the To bar or select a contact, then touch the Tex t message bar to type the text of the message. When finished, touch to send the text message. An SMS of more than 160 characters will be charged as several SMS. A counter will be displayed on the right of the text box to remind you of how many characters can be entered in one message. Specific letters (accent) will also increase the size of the SMS, this may cause multiple SMS to be sent to your recipient. Sending a multimedia message MMS enables you to send video clips, images, photos, animations, slides and sounds to other compatible phones and e-mail addresses. An SMS will be converted to MMS automatically when media files (image, video, audio, slides, etc.) are attached or subject or email addresses are added. Gmail In addition to your Gmail account, your phone supports external POP3, IMAP or Exchange email accounts. To access this feature, swipe up on Home screen then select Gmail. To create and send emails • Touch from the Inbox screen. • Enter recipient(s) email address(es) in the To: field. • If necessary, tap next to the To: field to add Cc/Bcc to the message. • Enter the subject and the content of the message. • Ta p to add an attachment. • Ta p to send. Camera & Video Your mobile phone is equipped with a camera and a camcorder for taking photos and shooting videos, touch from the Home screen to access this function. To take a picture: The screen acts as the viewfinder. First, position the object or landscape in the viewfinder, touch the screen to focus if necessary. Touch to capture, the photo will be automatically saved. You can also touch and hold to take burst shots, the maximum number is 20. To take a video: Touch VIDEO to change the camera mode to video. Touch to start video recording. Touch the left part of this icon to take a picture during video recording. Touch the right part of this icon to pause video recording and touch to continue. Touch to stop recording. The video will be automatically saved. Phone Placing a call Touch Phone from the Home screen. Show the dial pad Enter the desired number from the keyboard directly, or select one of the following: • Choose frequently called or favorite contacts in Favorites . • Choose recently called numbers and contacts in Recents . • Choose a saved contact in Contacts . Touch to place the call. To hang up a call, touch . Answering or rejecting a call When you receive a call: • Swipe up to answer. • Swipe down to reject. • Swipe to reject the call by sending a preset message. To mute the ringtone volume of an incoming call, press the Volume up/down key. Contacts Contacts enables quick and easy access to the people you want to reach. You can view and create contacts on your phone. To access this feature, swipe up on the Home screen, then select Contacts . Adding a contact Touch to add a new contact • Touc…

Text truncated - open the document above for the full version.

TCL Communication Ltd. 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong Tel: 0086-755-36611722 http://tclcom.tcl.com Date 2021-01-04 To: Federal Communications Commission, Authorization & Evaluation Division, 7345 Oakland Mills Road Columbia, MD 21046 And American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: CTTL (Telecommunication Technology Labs,Academy of Telecommunication Research,MIIT) is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, which includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong TEL: 0086-755-36611722 2021-01-04 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Permanent Confidentiality request for FCC ID: 2ACCJH132 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, the applicant requests permanent confidential treatment of the following information accompanying this application: - Block Diagram - Schematics - Operational Description - BOM list/Tune-Up-Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

TCL Communication Ltd. 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong TEL: 0086-755-36611722 http://tclcom.tcl.com 2021-01-04 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality request for FCC ID: 2ACCJH132 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days: - External Photos - Internal Photos - Test Setup Photos - User manual The applicant also acknowledges that they will also provide appropriate notice to ACB should either of the following occur: a) if the applicant requires additional 45 days extension periods they will notify ACB with a new request letter at least 7 days prior to the short-term confidentiality expiration date – [Note: up to a maximum of 3 extensions only are allowed], or b) Immediately notify ACB in the event the information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

Company letterhead Declaration of pre-install of OTT voice service We, [TCL Communication Ltd.], as the manufacturer of FCC ID: 2ACCJH132 （Model: A600DL）, declares that this model supports Wi-Fi Calling and only pre-installs Google DUO of OTT service with Android OS，and doesn’t support any other OTT services. We tested DUO using the software from Google according to KDB 285076 D02v03 Guidance for performing T-Coil tests for air interfaces supporting VOIP to support CMRS based telephone services. APPROVED BY: Projects Manager: Wenli Wang Signature: Company name: TCL Communication Ltd. Date: 2021-1-6

Internal Photo

TEST REPORT No.I20N03110-SAR For TCL Communication Ltd. GSM/UMTS/LTE Mobile phone Model Name: A600DL With Hardware Version: PIO Software Version: vA3D FCC ID: 2ACCJH132 Issued Date: 2020-12-31 Designation Number: CN1210 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of SAICT. Test Laboratory: SAICT, Shenzhen Academy of Information and Communications Technology Building G, Shenzhen International Innovation Center, No.1006 Shennan Road, Futian District, Shenzhen, Guangdong, P. R. China 518000. Tel:+86(0)755-33322000, Fax:+86(0)755-33322001 Email: [email protected]. www.saict.ac.cn No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 2 of 245 REPORT HISTORY Report Number Revision Description Issue Date I20N03110-SAR Rev.0 1st edition 2020-12-31 No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 3 of 245 TCONTENTS 1. SUMMARY OF TEST REPORT ................................................................................................... 5 1.1. TEST ITEMS .................................................................................................................................... 5 1.2. TEST STANDARDS ........................................................................................................................... 5 1.3. TEST RESULT .................................................................................................................................. 5 1.4. TESTING LOCATION ......................................................................................................................... 5 1.5. PROJECT DATA ............................................................................................................................... 5 1.6. SIGNATURE ..................................................................................................................................... 5 2. STATEMENT OF COMPLIANCE ................................................................................................. 6 3. CLIENT INFORMATION ............................................................................................................... 9 3.1. APPLICANT INFORMATION ................................................................................................................. 9 3.2. MANUFACTURER INFORMATION ........................................................................................................ 9 4. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) .............................. 10 4.1. ABOUT EUT .................................................................................................................................. 10 4.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST .............................................................. 11 4.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ................................................................. 11 5. TEST METHODOLOGY ............................................................................................................. 12 5.1. APPLICABLE LIMIT REGULATIONS.................................................................................................... 12 5.2. APPLICABLE MEASUREMENT STANDARDS ....................................................................................... 12 6. SPECIFIC ABSORPTION RATE (SAR) ..................................................................................... 13 6.1. INTRODUCTION .............................................................................................................................. 13 6.2. SAR DEFINITION ........................................................................................................................... 13 7. TISSUE SIMULATING LIQUIDS ................................................................................................ 14 7.1. TARGETS FOR TISSUE SIMULATING LIQUID ....................................................................................... 14 7.2. DIELECTRIC PERFORMANCE .......................................................................................................... 14 8. SYSTEM VERIFICATION ........................................................................................................... 18 8.1. SYSTEM SETUP ............................................................................................................................. 18 8.2. SYSTEM VERIFICATION .................................................................................................................. 19 9. MEASUREMENT PROCEDURES ............................................................................................. 20 9.1. TESTS TO BE PERFORMED .............................................................................................................. 20 9.2. GENERAL MEASUREMENT PROCEDURE .......................................................................................... 22 9.3. WCDMA MEASUREMENT PROCEDURES FOR SAR ......................................................................... 23 9.4. SAR MEASUREMENT FOR LTE ....................................................................................................... 24 9.5. LTE (TDD) CONSIDERATIONS ........................................................................................................ 24 9.6. BLUETOOTH & WLAN MEASUREMENT PROCEDURES FOR SAR ....................................................... 26 9.7. POWER DRIFT ............................................................................................................................... 26 10. CONDUCTED OUTPUT POWER ............................................................................................ 27 10.1. GSM MEASUREMENT RESULT ...................................................................................................... 27 10.2. WCDMA MEASUREMENT RESU…

Text truncated - open the document above for the full version.

No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 56 of 245 Reduced power level 3 LTE Band 25 Actual output Power (dBm) Tune up Band -width RB No. / RB offset Frequency (MHz) Modulation Modulation QPSK 16QAM 64QAM QPSK 16QAM 64QAM 5 MHz 1RB_24 1912.5 22.15 22.35 21.77 23.0 23.0 22.5 1882.5 22.31 22.61 21.89 23.0 23.0 22.5 1852.5 22.18 22.41 21.80 23.0 23.0 22.5 1RB_12 1912.5 22.19 22.43 21.81 23.0 23.0 22.5 1882.5 22.43 22.68 21.88 23.0 23.0 22.5 1852.5 22.50 22.50 22.05 23.0 23.0 22.5 1RB_0 1912.5 22.34 22.56 21.98 23.0 23.0 22.5 1882.5 22.47 22.62 21.99 23.0 23.0 22.5 1852.5 22.42 22.59 22.04 23.0 23.0 22.5 12RB_13 1912.5 22.17 21.60 20.63 23.0 22.5 21.5 1882.5 22.26 21.77 20.77 23.0 22.5 21.5 1852.5 22.22 21.79 20.76 23.0 22.5 21.5 12RB_6 1912.5 22.18 21.66 20.70 23.0 22.5 21.5 1882.5 22.29 21.78 20.73 23.0 22.5 21.5 1852.5 22.23 21.78 20.81 23.0 22.5 21.5 12RB_0 1912.5 22.23 21.62 20.71 23.0 22.5 21.5 1882.5 22.41 21.86 20.84 23.0 22.5 21.5 1852.5 22.30 21.79 20.85 23.0 22.5 21.5 25RB_0 1912.5 22.18 21.60 20.70 23.0 22.5 21.5 1882.5 22.23 21.73 20.72 23.0 22.5 21.5 1852.5 22.25 21.75 20.74 23.0 22.5 21.5 No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 57 of 245 Reduced power level 3 LTE Band 25 Actual output Power (dBm) Tune up Band -width RB No. / RB offset Frequency (MHz) Modulation Modulation QPSK 16QAM 64QAM QPSK 16QAM 64QAM 10 MHz 1RB_49 1910.0 22.38 22.63 22.14 23.0 23.0 22.5 1882.5 22.59 22.71 22.20 23.0 23.0 22.5 1855.0 22.58 22.71 22.17 23.0 23.0 22.5 1RB_24 1910.0 22.29 22.38 21.91 23.0 23.0 22.5 1882.5 22.26 22.42 21.94 23.0 23.0 22.5 1855.0 22.39 22.34 21.94 23.0 23.0 22.5 1RB_0 1910.0 22.48 22.56 22.12 23.0 23.0 22.5 1882.5 22.48 22.72 22.26 23.0 23.0 22.5 1855.0 22.52 22.65 22.12 23.0 23.0 22.5 25RB_25 1910.0 22.22 21.79 20.80 23.0 22.5 21.5 1882.5 22.36 21.89 20.86 23.0 22.5 21.5 1855.0 22.35 21.87 20.88 23.0 22.5 21.5 25RB_12 1910.0 22.32 21.78 20.82 23.0 22.5 21.5 1882.5 22.27 21.77 20.74 23.0 22.5 21.5 1855.0 22.25 21.76 20.78 23.0 22.5 21.5 25RB_0 1910.0 22.28 21.67 20.72 23.0 22.5 21.5 1882.5 22.32 21.81 20.75 23.0 22.5 21.5 1855.0 22.28 21.78 20.73 23.0 22.5 21.5 50RB_0 1910.0 22.43 21.71 20.77 23.0 22.5 21.5 1882.5 22.28 21.84 20.74 23.0 22.5 21.5 1855.0 22.34 21.79 20.76 23.0 22.5 21.5 No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 58 of 245 Reduced power level 3 LTE Band 25 Actual output Power (dBm) Tune up Band -width RB No. / RB offset Frequency (MHz) Modulation Modulation QPSK 16QAM 64QAM QPSK 16QAM 64QAM 15 MHz 1RB_74 1907.5 22.38 22.68 22.03 23.0 23.0 22.5 1882.5 22.51 22.71 22.02 23.0 23.0 22.5 1857.5 22.33 22.69 21.92 23.0 23.0 22.5 1RB_37 1907.5 22.30 22.51 21.77 23.0 23.0 22.5 1882.5 22.33 22.62 21.88 23.0 23.0 22.5 1857.5 22.28 22.46 21.86 23.0 23.0 22.5 1RB_0 1907.5 22.61 22.88 21.93 23.0 23.0 22.5 1882.5 22.42 22.86 22.12 23.0 23.0 22.5 1857.5 22.37 22.58 22.01 23.0 23.0 22.5 36RB_38 1907.5 22.36 21.95 20.86 23.0 22.5 21.5 1882.5 22.52 21.98 20.98 23.0 22.5 21.5 1857.5 22.46 21.95 20.90 23.0 22.5 21.5 36RB_19 1907.5 22.40 21.90 20.93 23.0 22.5 21.5 1882.5 22.45 21.91 20.92 23.0 22.5 21.5 1857.5 22.33 21.89 20.82 23.0 22.5 21.5 36RB_0 1907.5 22.40 21.93 20.93 23.0 22.5 21.5 1882.5 22.46 21.95 20.95 23.0 22.5 21.5 1857.5 22.29 21.78 20.76 23.0 22.5 21.5 75RB_0 1907.5 22.52 21.95 20.91 23.0 22.5 21.5 1882.5 22.44 21.96 20.90 23.0 22.5 21.5 1857.5 22.43 21.91 20.90 23.0 22.5 21.5 No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 59 of 245 Reduced power level 3 LTE Band 25 Actual output Power (dBm) Tune up Band -width RB No. / RB offset Frequency (MHz) Modulation Modulation QPSK 16QAM 64QAM QPSK 16QAM 64QAM 20 MHz 1RB_99 1905.0 22.23 22.42 21.75 23.0 23.0 22.5 1882.5 22.21 22.40 21.81 23.0 23.0 22.5 1860.0 22.11 22.39 21.82 23.0 23.0 22.5 1RB_50 1905.0 22.33 22.67 21.93 23.0 23.0 22.5 1882.5 22.30 22.63 22.02 23.0 23.0 22.5 1860.0 22.31 22.53 21.93 23.0 23.0 22.5 1RB_0 1905.0 22.53 22.78 22.24 23.0 23.0 22.5 1882.5 22.36 22.80 22.18 23.0 23.0 22.5 1860.0 22.37 22.63 21.96 23.0 23.0 22.5 50RB_50 1905.0 22.34 21.94 20.81 23.0 22.5 21.5 1882.5 22.40 21.98 20.94 23.0 22.5 21.5 1860.0 22.33 21.79 20.72 23.0 22.5 21.5 50RB_25 1905.0 22.39 21.92 20.85 23.0 22.5 21.5 1882.5 22.35 21.84 20.81 23.0 22.5 21.5 1860.0 22.30 21.83 20.80 23.0 22.5 21.5 50RB_0 1905.0 22.44 21.93 20.86 23.0 22.5 21.5 1882.5 22.43 21.97 20.88 23.0 22.5 21.5 1860.0 22.26 21.79 20.75 23.0 22.5 21.5 100RB_0 1905.0 22.51 21.95 20.91 23.0 22.5 21.5 1882.5 22.39 21.86 20.79 23.0 22.5 21.5 1860.0 22.30 21.87 20.79 23.0 22.5 21.5 No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 60 of 245 Full Power LTE Band 26 Actual output Power (dBm) Tune up Band -width RB No. / RB offset Frequency (MHz) Modulation Modulation QPSK 16QAM 64QAM QPSK 16QAM 64QAM 1.4 MHz 1RB_5 848.3 23.24 22.96 21.61 25.0 24.0 23.0 831.5 23.94 23.50 22.09 25.0 24.0 23.0 814.7 24.18 23.48 22.31 25.0 24.0 23.0 1RB_3 848.3 23.53 22.98 21.71 25.0 24.0 23.0 831.5 24.08 23.29 22.15 25.0 24.0 23.0 814.7 24.23 23.59 22.38 25.0 24.0 23.0 1RB_0 848.3 23.47 22.99 21.76 25.0 24.0 23.0 831.5 23.97 23.24 21.94 25.0 24.0 23.0 814.7 24.02 23.62 22.37 25.0 24.0 23.0 3RB_3 848.3 23.56 22.49 21.59 25.0 24.0 23.0 831.5 24.05 23.06 22.10 25.0 24.0 23.0 814.7 24.23 23.25 22.33 25.0 24.0 23.0 3RB_1 848.3 23.56 22.63 21.52 25.0 24.0 23.0 831.5 24.07 23.00 22.02 25.0 24.0 23.0 814.7 24.28 23.25 22.28 25.0 24.0 23.0 3RB_0 848.3 23.50 22.61 21.59 25.0 24.0 23.0 831.5 24.07 23.02 22.06 25.0 24.0 23.0 814.7 24.20 23.17 22.22 25.0 24.0 23.0 6RB_0 848.3 22.55 21.68 20.49 24.0 23.0 22.0 831.5 22.94 22.01 21.02 24.0 23.0 22.0 814.7 23.18 22.21 21.16 24.0 23.0 22.0 No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 61 of 245 Full Power LTE Band 26 Actual output Power (dBm) Tune up Band -width RB No. / RB offset Frequency (MHz) Modulation Modulation QPSK 16QAM 64QAM QPSK 16QAM 64QAM 3 MHz 1RB_14 847.5 23.54 22.89 21.77 25.0 24.0 23.0 831.5 23.91 23.32 22.25 25.0 24.0 23.0 815.5…

Text truncated - open the document above for the full version.

No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 101 of 245 Reduced power level 2/3 LTE Band 41 PC3 Actual output Power (dBm) Tune up Band -width RB No. / RB offset Frequency (MHz) Modulation Modulation QPSK 16QAM 64QAM QPSK 16QAM 64QAM 10 MHz 1RB_49 2685.0 22.27 21.95 21.70 23.0 23.0 22.5 2639.0 22.11 21.61 21.38 23.0 23.0 22.5 2593.0 22.07 21.62 21.34 23.0 23.0 22.5 2547.0 22.01 21.53 21.19 23.0 23.0 22.5 2501.0 21.86 21.33 20.95 23.0 23.0 22.5 1RB_24 2685.0 22.19 21.98 21.70 23.0 23.0 22.5 2639.0 22.03 21.64 21.38 23.0 23.0 22.5 2593.0 22.12 21.86 21.48 23.0 23.0 22.5 2547.0 21.92 21.48 21.16 23.0 23.0 22.5 2501.0 21.82 21.42 21.19 23.0 23.0 22.5 1RB_0 2685.0 22.04 21.86 21.59 23.0 23.0 22.5 2639.0 22.02 21.66 21.34 23.0 23.0 22.5 2593.0 22.11 21.73 21.44 23.0 23.0 22.5 2547.0 21.98 21.50 21.23 23.0 23.0 22.5 2501.0 21.89 21.49 21.11 23.0 23.0 22.5 25RB_25 2685.0 22.35 21.94 21.84 23.0 22.5 21.5 2639.0 22.05 21.47 21.44 23.0 22.5 21.5 2593.0 21.98 21.64 21.48 23.0 22.5 21.5 2547.0 21.84 21.38 21.39 23.0 22.5 21.5 2501.0 21.80 21.22 21.31 23.0 22.5 21.5 25RB_12 2685.0 22.28 21.94 20.88 23.0 22.5 21.5 2639.0 22.08 21.61 20.62 23.0 22.5 21.5 2593.0 22.16 21.68 20.63 23.0 22.5 21.5 2547.0 22.01 21.42 20.48 23.0 22.5 21.5 2501.0 21.87 21.41 20.28 23.0 22.5 21.5 25RB_0 2685.0 22.20 21.72 20.67 23.0 22.5 21.5 2639.0 22.04 21.44 20.39 23.0 22.5 21.5 2593.0 22.14 21.77 20.60 23.0 22.5 21.5 2547.0 21.91 21.40 20.42 23.0 22.5 21.5 2501.0 21.74 21.21 20.22 23.0 22.5 21.5 50RB_0 2685.0 22.17 21.84 20.77 23.0 22.5 21.5 2639.0 22.04 21.55 20.58 23.0 22.5 21.5 2593.0 22.13 21.63 20.58 23.0 22.5 21.5 2547.0 21.96 21.38 20.35 23.0 22.5 21.5 2501.0 21.87 21.37 20.26 23.0 22.5 21.5 No. I20N03110-SAR ©Copyright. All rights reserved by SAICT Page 102 of 245 Reduced power level 2/3 LTE Band 41 PC3 Actual output Power (dBm) Tune up Band -width RB No. / RB offset Frequency (MHz) Modulation Modulati…

Text truncated - open the document above for the full version.
