2ACCJH180GSM/UMTS/LTE Mobile phone

12 10.3 Mobile network ....................................................................................................51 10.4 Connections .........................................................................................................51 10.5 Home screen & lock screen .................................................................................53 10.6 Display .................................................................................................................53 10.7 NXTVISION ...........................................................................................................53 10.8 Sound & vibration ................................................................................................54 10.9 Notifications .........................................................................................................54 10.10 Buttons & Gestures ..............................................................................................54 10.11 Advanced features ...............................................................................................54 10.12 Location ...............................................................................................................54 10.13 Security & privacy ................................................................................................54 10.14 Safety & emergency .............................................................................................55 10.15 Apps ....................................................................................................................55 10.16 Storage ................................................................................................................56 10.17 Accounts ..............................................................................................................56 10.18 Digital Wellbeing & parental controls ....................................................................56 10.19 Google .................................................................................................................56 10.20 Smart Manager ....................................................................................................56 10.21 Accessibility .........................................................................................................56 10.22 System ................................................................................................................57 11 FOTA Upgrade ��������������������������������������������������������������������������������������������������������������������58 12 Safety and use ������������������������������������������������������������������������������������������������������������������59 Table of contents 1 Your mobile �������������������������������������������������������������������������������������������������������������������������4 1.1 Keys and connectors ..............................................................................................4 1.2 Getting started .......................................................................................................6 1.3 Home screen .........................................................................................................8 2 Text input���������������������������������������������������������������������������������������������������������������������������16 2.1 Using the Onscreen Keyboard ..............................................................................16 2.2 Text editing ..........................................................................................................17 3 Phone call, Call log and Contacts ������������������������������������������������������������������������������������18 3.1 Phone ..................................................................................................................18 3.2 Contacts ..............................................................................................................24 4 Messages ��������������������������������������������������������������������������������������������������������������������������28 4.1 Writing a new message .......................................................................................28 4.2 Manage messages ...............................................................................................29 5 Camera ������������������������������������������������������������������������������������������������������������������������������30 6 Gmail ���������������������������������������������������������������������������������������������������������������������������������33 7 Calendar & Alarm clock ����������������������������������������������������������������������������������������������������39 7.1 Calendar ..............................................................................................................39 7.2 Clock ...................................................................................................................40 8 Getting connected �������������������������������������������������������������������������������������������������������������42 8.1 Connecting to the Internet ....................................................................................42 8.2 Connecting to Bluetooth devices .........................................................................43 8.3 Connecting to a computer ....................................................................................45 8.4 Sharing your phone's mobile data connection ......................................................45 8.5 Connecting to virtual private networks .................................................................46 9 Google applications ���������������������������������������������������������������������������������������������������������48 10 Settings �������������������������������������������������������������������������������������������…

Text truncated - open the document above for the full version.

TCL Communication Ltd. Federal Communications Commission Date: 11/16/2023 7435 Oakland Mills Road Columbia, MD 21046 Subject: Attestation to FCC HAC Waiver DA 23-914 FCC ID: 2ACCJH180, Model No: T434D To Whom It May Concern, We are certifying the HAC Compliance of FCC ID: 2ACCJH180 under the ANSI C63.19-2019, and the Volume Control performance is assessed under the condition of the limited-term waiver DA 23-914. We attest that, the package label is compliance with 47 CFR 20.19(f)(1) and states the actual conversational gain obtained under the waiver for the passing codecs demonstrated in section 2.a. and 2.b. of KDB 285076 D05 HAC Wavier and for the lowest conversational gain achieved for each 2N and 8N. Sincerely, Annie Jiang [email protected]

TCL Communication Ltd. Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: November 24, 2023 Subject: Certifications concerning “covered” equipment pursuant to Part 2.911(d)(5)(i) and (ii) To whom it may concern, TCL Communication Ltd. certifies that the equipment FCC ID: 2ACCJH180 for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. TCL Communication Ltd. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List ( as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, ___________________ Annie Jiang [email protected]

TCT Mobile, Inc. 189 Technology Drive, Irvine, California USA 92618 TO: Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046, USA ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: TCT Mobile (US) Inc. Contact Name: Yao Dai Street Address: 189 Technology Drive City/Province/Zip: Irvine, CA 92618 Telephone No: 1-855-368-0829 Email: [email protected] FRN #: 0033429465 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: October 9, 2023 Signed by (Printed Name/Title): Yao Dai / Technical Acceptance Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: TCL Communication Ltd. Grantee Code: 2ACCJ FRN: 0031833205 Contact Name: Annie Jiang Street Address: 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong City/Province/Zip: Hongkong Telephone No: +86 755 36611621 Email: [email protected] Applicant Signature: Date: 2023-10-9 Signed by (Printed Name/Title): Annie Jiang / Product Certification Manager DocuSign Envelope ID: A2138C4A-C1E1-43B4-92EB-9546E9F565AC

Federal Communications CommissionDA 23-914 Before the Federal Communications Commission Washington, D.C. 20554 In the Matter of Amendment of the Commission’s Rules Governing Standards for Hearing Aid-Compatible Handsets ) ) ) ) WT Docket No. 20-3 ORDER Adopted: September 29, 2023Released: September 29, 2023 By the Chief, Wireless Telecommunications Bureau: I.INTRODUCTION 1.Today we grant a limited waiver of section 20.19(b)(1) and (b)(3) of the Commission’s wireless hearing aid compatibility rules with respect to the volume control technical standard that handset manufacturers use in part to certify handsets as hearing aid-compatible under the 2019 ANSI Standard. 1 Our action is prompted by a request filed by the Alliance for Telecommunications Industry Solutions (ATIS) seeking waiver of certain aspects of these rules. 2 Under the terms of the time-limited waiver we grant today, a handset may be certified as hearing aid-compatible under the 2019 ANSI Standard if it meets the volume control testing requirements described in this Order as well as all other aspects of the 2019 ANSI Standard. 2.Consistent with ATIS’s September 12, 2023, ex parte letter (ATIS Ex Parte Letter) and as a condition of this waiver, we require a handset to pass the conversational gain test at the 2 Newton (N) force level on all available narrowband and wideband codecs and air interface combinations. 3 With respect to the 8N force level test, we agree with the ATIS Ex Parte Letter that this test should be performed, and we waive the requirement that a handset achieve at least an 18 dB conversational gain. 4 This waiver is conditioned on manufacturers performing the 8N force level test using the same testing parameters that we are requiring for the 2N force level test and to place on the handset’s package label the resulting conversational gain (even if it is below 18 dB) in a manner consistent with our existing hearing aid compatibility labeling rules. 3.With respect to the related receive distortion and noise performance (distortion/noise) and receive acoustic frequency response performance (frequency response) tests, we agree with the ATIS Ex Parte Letter that handsets must pass testing using at least one narrowband and one wideband codec of the 1 The 2019 ANSI Standard refers to the technical document entitled Accredited Standards Committee C63®– Electromagnetic Compatibility, American National Standard Methods of Measurement of Compatibility Between Wireless Communications Devices and Hearing Aids, ANSI C63.19-2019 (approved Aug. 19, 2019) (2019 ANSI Standard). 2 Petition of ATIS on Behalf of the Covered Entities of the Hearing Aid Compatibility Task Force for Limited, Interim Waiver, WT Docket Nos. 15-285 and 20-3 (filed Dec. 16, 2022) (ATIS Waiver Petition). ATIS filed its waiver petition on behalf of all manufacturers and service providers subject to section 20.19(b)(1) and (b)(3) of the Commission’s wireless hearing aid compatibility rules. Id. at 1, 4. 3 Letter from Thomas Goode, General Counsel, ATIS, to Marlene H. Dortch, Secretary, FCC, WT Docket Nos. 15- 285 and 20-3, at 2 (filed Sept. 12, 2023) (ATIS Ex Parte Letter); see also ATIS Waiver Petition at 4, 12-13. Below we explain the conversational gain test. See infra para. 9. 4 ATIS Ex Parte Letter at 2. Originally, ATIS had proposed to waive the entire 8N force level test. ATIS Waiver Petition at 10-11, 13. Federal Communications CommissionDA 23-914 2 manufacturer’s choosing. 5 We also accept ATIS’s suggestion that at least one narrowband and one wideband codec must pass testing for distortion/noise and frequency response and tests will be limited to one bit rate and only with those air interfaces associated with the chosen codecs and that the other codecs used for conversational gain at the 2N and 8N force levels are not required to undergo the distortion/noise and frequency response tests. 6 Further, as detailed below, we accept ATIS’s suggested method to set the volume control setting for testing these other codecs for conversational gain. 7 4.By taking these steps, we ensure that when the exclusive use transition period ends on December 5, 2023, new handset models can be certified as hearing aid-compatible using the 2019 ANSI Standard as modified by the conditions established in this Order. 8 Our actions allow consumers with hearing loss who use hearing aids or cochlear implants to benefit from wider availability of handsets offering improved hearing aid compatibility under the 2019 ANSI Standard’s radio frequency (RF) interference and inductive coupling requirements. In addition, our approach gives consumers assurance that a handset’s amplifier/speaker combination will provide improved volume control functionality over narrowband and wideband modes of voice communications, and that consumers have the information that they need to make informed purchasing decisions. Our actions today will move us closer to the Commission’s goal of reaching 100% hearing aid compatibility for wireless handsets, while also creating a path forward for testing to ensure that handsets have volume control capabilities. 9 5.This waiver is effective immediately upon release of this Order so that manufacturers may afford the benefits of this relief to consumers with hearing loss as soon as feasible. In reliance upon ATIS’s representations that efforts are underway to expeditiously develop a new volume control standard through the TIA standards setting process, we limit this waiver to a two-year period. 10 During this waiver period, we will evaluate the effectiveness of the waiver standard in meeting the needs of consumers with hearing loss and take action where appropriate. We expect that a two-year time limitation for the waiver will encourage all interested parties to work together to rapidly develop an improved volume control standard that we can incorporate into our rules in the future. To ensure this outcome, we condition this waiver in part on ATIS filing a status lett…

Text truncated - open the document above for the full version.

TCL Communication Ltd. Declaration - MIF for HAC RF Interference Evaluation To whom it may concern: This device, with FCC ID: 2ACCJH180, Hearing Aid Compatibility Requirement is going to be certified under ANSI C63.19 2011 version per Part 20.19. For Radio Frequency Interference, Speag’s Audio Interference Analyzer (AIA) or other indirect or direct measurement was not used to determine the M rating. The M rating was determined by measuring the maximum steady state average E-field values in dB (V/m) or average antenna input power as documented in HAC test report exhibit, and adding the MIF value in dB. The MIF values below for the worst-case operation mode for all air interfaces are pre-determined values provided by Speag. UID Communication System Name MIF(dB) 10021 GSM-FDD(TDMA,GMSK) 3.63 10025 EDGE-FDD (TDMA, 8PSK, TN 0) 3.75 10460 UMTS-FDD(WCDMA, AMR) -25.43 10225 UMTS-FDD (HSPA+) -20.39 10170 LTE-FDD(SC-FDMA,1RB,20MHz,16-QAM) -9.76 10173 LTE-TDD (SC-FDMA, 1 RB, 20 MHz, 16-QAM) -1.44 10769 5G NR (CP-OFDM, 1 RB, 15 MHz, QPSK, 15 kHz) -12.08 10973 5G NR (DFT-s-OFDM, 1 RB, 100 MHz, QPSK, 30 kHz) -1.64 10061 IEEE 802.11b WiFi 2.4 GHz (DSSS, 11 Mbps) -2.02 10077 IEEE 802.11g WiFi 2.4 GHz (DSSS/OFDM, 54 Mbps) 0.12 10427 IEEE 802.11n (HT Greeneld, 150 Mbps, 64-QAM) -13.44 10069 IEEE 802.11a/h WiFi 5 GHz (OFDM, 54 Mbps) -3.15 10616 IEEE 802.11ac WiFi (40MHz, MCS0, 90pc duty cycle) -5.57 10671 IEEE 802.11ax (20MHz, MCS0, 90pc duty cycle) -5.58 We confirmed that the Speag simulation provided represents all the air interface modes applicable for a HAC rating for this handset. Sincerely, Annie Jiang [email protected]

Rev. 1/1/03 TCL Communication Ltd. Date: October 31, 2023 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ACCJH180 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics Block Diagram Parts List Operation Description Tune up Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ________________________ Contact Person: Annie Jiang E-mail: [email protected]

TCL Communication Ltd. Date: October 31, 2023 Power of Attorney To whom it may concern, Please be notified that I, Annie Jiang, have designated Jim Tsai in Sporton International Inc. as the person being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out by Jim Tsai in Sporton International Inc., on the matters of relating to all processes required in the FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C 862. This authorization is limited to the product of as following: FCC ID: 2ACCJH180 If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely yours, ____ Contact Person: Annie Jiang E-mail: [email protected]

1/1 TCL Communication Ltd. Date: October 31, 2023 Federal Communications Commission Authorization and Evaluation Division RE : Certification Application FCC ID: 2ACCJH180 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47, Public Notice DA 04-1705 of the Commission’s policy and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days:  External Photos  Internal Photos  Test set-up photos  Users Manual The application contains technical information, which TCL Communication Ltd. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, ____ Contact Person: Annie Jiang E-mail: [email protected]

Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 17 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 720510 3. Internal Photograph of EUT Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 18 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 19 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 20 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Ant 0 Ant 1 Ant 2 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 21 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 22 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 23 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 24 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 25 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 26 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 27 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 28 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 29 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 30 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 31 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 32 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 33 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 34 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 35 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 36 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 37 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 38 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 39 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Ve…

Text truncated - open the document above for the full version.

Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 51 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 52 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 53 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 54 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 55 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 56 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Ant 0 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 57 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Ant 1 Photographs of EUT Report No.: EP3O1004 Brand Name: TCL; Model Name: T434D Sporton International Inc.(Shenzhen) Page Number : 58 of 58 TEL : 86-755-8637-9589 Report Issued Date : Nov. 22, 2023 FAX : 86-755-8637-9595 Report Version : Rev. 01 FCC ID : 2ACCJH180 Ant 2

D2600V2, Serial No. 1070 Extended Dipole Calibrations Referring to KDB 865664 D01, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. D2600V2 – serial no. 1070 2600 Head Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) 2021.12.20 -23.6 50.5 -6.6 2022.12.19 -24.0 1.6% 51.2 -0.7 -6.3 -0.3 <Justification of the extended calibration> The return loss is < -20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. Dipole Verification Data> D2600V2, serial no. 1070 2600MHz – Head----2022.12.19 D5GHzV2, Serial No. 1341 Extended Dipole Calibrations Referring to KDB 865664 D01, if dipoles are verified in return loss (<-20dB, within 20% of prior calibration), and in impedance (within 5 ohm of prior calibration), the annual calibration is not necessary and the calibration interval can be extended. 5250MHz D5GV2 – serial no. 1341 5250 Head Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) 2021.12.13 -35.7 48.4 0.1 2022.12.12 -35.7 0.0 50.1 -1.7 -1.6 1.7 5600MHz D5GV2 – serial no. 1341 5600 Head Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) 2021.12.13 -22.2 53.8 7.2 2022.12.12 -22.4 0.9 52.9 0.9 7.3 -0.1 5750MHz D5GV2 – serial no. 1341 5750 Head Date of Measurement Return-Loss (dB) Delta (%) Real Impedance (ohm) Delta (ohm) Imaginary Impedance (ohm) Delta (ohm) 2021.12.13 -25.8 51.4 5 …
