2ACCJN0435G NR/LTE/WCDMA/GSM Mobile Phone

TCL Communication Ltd.

Click to zoom

Application Details

Equipment Class: CXX - Communications Rcvr for use w/ licensed Tx and CBs
Date of Grant: Jun 11, 2020
Application Purpose: Original Equipment
Date of Application: Jun 10, 2020
Equipment Note: 5G NR/LTE/WCDMA/GSM Mobile Phone
Frequency Range: 869.00000000 - 894.00000000
Company: TCL Communication Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Safety and Precautions CQF66L102AAA 12 Safety and use �� We recommend that you read this chapter carefully before using your phone. The manufacturer disclaims any liability for damage, which may result as a consequence of improper use or use contrary to the instructions contained herein. TRAFFIC SAFETY: Given that studies show that using a phone while driving a vehicle constitutes a real risk, even when the hands-free kit is used (car kit, headset...), drivers are requested to refrain from using their phone when the vehicle is not parked. Check the laws and regulations on the use of wireless phones and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas. CONDITIONS OF USE: • You are advised to switch off the phone from time to time to optimize its performance; • Remember to abide by local authority rules of mobile phone use on aircrafts; • If your phone is a unibody device, where the back cover and battery are not removable, disassembling the phone will void your warranty. Disassembling the phone can cause bodily injury if the battery is punctured; • Always handle your phone with care and keep it in a clean and dust-free place; • Do not allow your phone to be exposed to adverse weather or environmental conditions, such as moisture, humidity, rain, infiltration of liquids, dust, sea air, etc. The manufacturer’s recommended operating temperature range is 0°C (32°F) to 55°C (131°F). At over 55°C (131°F), the legibility of the phone’s display may be temporarily impaired; • Do not open, dismantle, or attempt to repair your phone yourself; • Do not drop, throw, or bend your phone; • Use only batteries, battery chargers, and accessories which are recommended by TCL Communication Ltd. and its affiliates and are compatible with your phone model. TCL Communication Ltd. and its affiliates disclaim any liability for damage caused by the use of other chargers or batteries; • Your phone should not be disposed of in a municipal waste. Please check local regulations for disposal of electronic products; • Remember to make backup copies or keep a written record of all important information stored on your phone; • Some people may suffer epileptic seizures or blackouts when exposed to flashing lights, or when playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult your doctor before playing video games on your phone or enabling a flashing-lights feature on your phone; • Parents should monitor their children’s use of video games or other features that incorporate flashing lights on the phones. All persons should discontinue use and consult a doctor if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, orientation, or movements. Printed in China This product meets applicable national SAR limits of 1.6 W/kg. The specific maximum SAR values can be found in the Radio waves section. When carrying the product or using it while worn on your body, either use an approved accessory such as a holster or otherwise maintain a distance of 15 mm from the body to ensure compliance with RF exposure requirements. Note that the product may be transmitting even if you are not making a phone call. PROTECT YOUR HEARING To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise caution when holding your phone near your ear while the loudspeaker is in use. www.sar-tick.com 34 Input 100~240V 50/60Hz 0.5A Output: 5V, 2.0A Battery: 4500mAh typ Radio waves �� THIS PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio-frequency (RF) energy. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. These guidelines include a substantial safety margin designed to ensure the safety of all persons, regardless of age and health. The exposure standard for phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by public authorities such as the Federal Communications Commission of the US Government (FCC), or by Innovation, Science and Economic Development Canada (ISEDC), is 1.6 W/kg averaged over 1 gram of body tissue. Tests for SAR are conducted using standard operating positions with the phone transmitting at its highest certified power level in all tested frequency bands. This device is complied with SAR for general population / uncontrolled exposure limits in ANSI/IEEE C95.1-1992 and had been tested in accordance with the measurement methods and procedures specified in IEEE1528. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: 2ACCJN043. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output of the phone. Before a phone model is available for sale to the public, compliance with national regulations and standards must be shown. The highest SA…

Text truncated - open the document above for the full version.

Users Manual

Cover Letter(s)

TCL Communication Ltd. 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong Tel: 0086-755-36611722; Fax: 0086-755-36612000-81722 Statement We, TCL Communication Ltd., states that our device with FCC ID: 2ACCJN043 is a multi-band mobile phone which supports GSM850/900/1800/1900, WCDMA Band 1/2/4/5/8, LTE Band1/3/5/7/8/20/28/32/38/40/41, 5G NR n1/3/8/28/77/78 for cellular network. For connectivity functions, it is capable of 2.4GHz WiFi 11b/11g/11n-HT20/11n-HT40, 5GHz WiFi 11a/11n-HT20/11n-HT40, 11ac-VHT20/11ac-VHT40/11ac-VHT80 (5.725 GHz – 5.825 GHz frequency range disabled in EU countries’ area based on geo-information), and Bluetooth 5.0 LE (downward compatible and only LE 1M supported in BLE 5.0) , along with FM and NFC. However, LTE band 40 and 5G NR n77, n78 is not available in US market and Canada market, and will be disabled by software. Contact Person: Zhizhou Gong E-mail: [email protected]

Cover Letter(s)

TCL Communication Ltd. 5F, C building, No. 232, Liang Jing Road, ZhangJiang High-Tech Park, Pudong Shanghai, P.R. China. 201203 Tel: +86 21 6146 0666 Fax: +86 21 6146 0602 http://tclcom.tcl.com 2020-06-03 Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: SHORT-TERM Confidentiality request for FCC ID: 2ACCJN043 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days: - External Photos - Internal Photos - Test Setup Photos - User manual The applicant also acknowledges that they will also provide appropriate notice to ACB should either of the following occur: a) if the applicant requires additional 45 days extension periods they will notify ACB with a new request letter at least 7 days prior to the short-term confidentiality expiration date – [Note: up to a maximum of 3 extensions only are allowed], or b) Immediately notify ACB in the event the information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Yours Sincerely, Zhizhou GONG Product Certification Manager TCL Communication Ltd.

External Photos

T790Y TLp043E7 TLp043E7 UC13EU UC13EU-label QC13UK QC13UK-label QC13AU QC13AU-label QC13US QC13US-label CDA0000139C1 CDA0000139C2 SOCL110WTT1-EU

ID Label/Location Info

Label Design Label Location Packaging Design

Internal Photos

T790Y

Test Report

©Copyright. All rights reserved by CTTL. TEST REPORT No. I20Z60563-EMC04 for TCL Communication Ltd. 5G NR/ LTE/WCDMA/GSM Mobile Phone Model Name: T790Y FCC ID: 2ACCJN043 with Hardware Version: 03 Software Version: v2.0.1A.H.6 Issued Date: 2020-06-10 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL-Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.I20Z60563-EMC04 ©Copyright. All rights reserved by CTTL. Page 2 of 30 REPORT HISTORY Report Number Revision Description Issue Date I20Z60563-EMC04 Rev.0 1 st edition 2020-06-01 I20Z60563-EMC04 Rev.1 Renew A.1.2 description in Page 12 2020-06-10 Note: the latest revision of the test report supersedes all previous version. No.I20Z60563-EMC04 ©Copyright. All rights reserved by CTTL. Page 3 of 30 CONTENTS 1. TEST LABORATORY ............................................................................................................... 4 1.1. INTRODUCTION & ACCREDITATION ................................................................................. 4 1.2. TESTING LOCATION ........................................................................................................... 4 1.3. TESTING ENVIRONMENT ................................................................................................... 4 1.4. PROJECT DATA ................................................................................................................... 4 1.5. SIGNATURE .......................................................................................................................... 4 2. CLIENT INFORMATION ........................................................................................................... 5 2.1. APPLICANT INFORMATION ................................................................................................ 5 2.2. MANUFACTURER INFORMATION ...................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT .......................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 6 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 6 3.4. EUT SET-UPS ....................................................................................................................... 7 4. REFERENCE DOCUMENTS .................................................................................................... 8 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 8 5. LABORATORY ENVIRONMENT .............................................................................................. 9 6. SUMMARY OF TEST RESULTS ............................................................................................ 10 7. TEST EQUIPMENTS UTILIZED ............................................................................................. 11 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 12 ANNEX B: PERSONS INVOLVED IN THIS TESTING ................................................................. 30 No.I20Z60563-EMC04 ©Copyright. All rights reserved by CTTL. Page 4 of 30 1. Test Laboratory 1.1. Introduction & Accreditation Telecommunication Technology Labs, CAICT is an ISO/IEC 17025:2005 accredited test laboratory under NATIONAL VOLUNTARY LABORATORY ACCREDITATION PROGRAM (NVLAP) with lab code 600118-0, and is also an FCC accredited test laboratory (CN5017), and ISED accredited test laboratory (CN0066). The detail accreditation scope can be found on NVLAP website. 1.2. Testing Location CTTL (BDA) Address: No.18A, Kangding Street, Beijing Economic-Technology Development Area, Beijing, P. R. China 100176 1.3. Testing Environment Normal Temperature: 15-35ºC Relative Humidity: 20-75% 1.4. Project data Testing Start Date: 2020-04-26 Testing End Date: 2020-05-29 1.5. Signature Wang Junqing (Prepared this test report) Zhang Ying (Reviewed this test report) Liu Baodian Deputy Director of the laboratory (Approved this test report) No.I20Z60563-EMC04 ©Copyright. All rights reserved by CTTL. Page 5 of 30 2. Client Information 2.1. Applicant Information Company Name: TCL Communication Ltd. Address: 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong Contact Person Gong Zhizhou Contact Email [email protected] Telephone: 0086-755-36611722 Fax: 0086-755-36612000-81722 2.2. Manufacturer Information Company Name: TCL Communication Ltd. Address: 5/F, Building 22E, 22 Science Park East Avenue, Hong Kong Science Park, Shatin, NT, Hong Kong Contact Person Gong Zhizhou Contact Email [email protected] Telephone: 0086-755-36611722 Fax: 0086-755-36612000-81722 No.I20Z60563-EMC04 ©Copyright. All rights reserved by CTTL. Page 6 of 30 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description 5G NR/ LTE/WCDMA/GSM Mobile Phone Model Name T790Y FCC ID 2ACCJN043 Extreme vol. Limits 3.5VDC to 4.4VDC (nominal: 3.85VDC) Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of CTTL, Telecommunication Technology Labs, CAICT. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version 38a 354926110009808 03 v2.…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC ID 2ACCJN043 15B RE CE 15C RE CE Radiated Spurious Emission and Output Power
