2ACDGS1-P125K proximity card reader

Regulatory Information CE Mark The reader has passed all relevant tests and obtained CE approval. C Tick The reader has passed all relevant requirements for application of C Tick. FCC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna - Increase the separation between the equipment and receiver - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV technician for help Any changes or modifications to this product not expressly approved in this document could void the user's authority to operate this equipment. Designed & Manufactured in Australia. Mifare ® is a registered trademark of Philips Electronics. Reader Specifications Reader Output Wiegand Power requirements +12Vdc Current Consumption (+/- 5%) Normal Activated Read range Operating temperature Relative humidity 90% max, operating non-condensing Reader dimensions (Facia) 67 x 50 x 16mm Status LED’s Green/Red controlled by access controller Audible tone Colour Charcoal IP rating Cable distances 0.22mm 2 cable 0.33mm 2 cable 100m max 250m max 30 - 50mm Wiring Connect the wiring as indicated in the table to the control panel. Connect the 0V reference and 0V (if provided in the power supply) to the ground (GND) Wire. Connect the W0, W1, LED and Buzzer Connect the +Vdc last. Handling Handle the reader with care. Do not drop or damage before installation. Mounting If necessary, drill holes for the mounting screws in the wall on which the reader will be placed. Alternately a back box can be used. Note magnet location for position of tamper reed switch (refer overleaf). Place the reader on the wall or back box, make sure wires are not crushed. Insert and hand tighten the screws. Check that the reader is level before tightening screws. Power up reade r Troubleshooting If the reader doesn’t respond when a valid smart card is presented, check the following: SymptomPossible Cause Check LED is not lit LED is orange/indeterminate or buzzer sounds low Reader doesn’t respond No power to the reader Voltage to the reader is below minimum required level Invalid card or card is faulty or wiring to the controller is faulty Check power supply to the reader Check power supply to the reader Check reader with another valid smart card; if problem persists check wiring External Use Mount the reader on a single gang box or suitable surface. Make sure the wire bundle to the reader has an IP rating of at least IP65. red Cable Colours black yellow orange green white +5 to +12Vdc ground buzzer green led W0 W1 Warranty Each reader comes with a 3 year warranty from the date of dispatch. The warranty is void if the instructions contained within this document have not been adhered to. INS Global Pty Ltd Suite 8 166a The Entrance Road Erina NSW 2250 www.insglobal.com Ph: 1300 203 373 Product of Australia S1-P INSTALLATION GUIDE Model INS - IG - B1 - R01 M A GN E T CUT OUT IN WALL REQUIRED :52 x 70mm (2.05 x 2.76”) FACIA WALL APPLY DOUBLESIDED TAPE LED ORIENTATION TAMPER REED SWITCHLOCATION IF FITTED FRONT VIEW SIDE VIEW NOT TO SCALE

INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EUT View 3 EUT View 4 INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EUT View 5 EUT View 6 INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EUT View 7 (Adding Model: S1-P) EUT View 8 (Adding Model: S2-P) INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EUT View 9 (Adding Model: B1-P) EUT View 10 (Adding Model: F1-125) INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EUT View 11 (Adding Model: F1-P) EUT View 12 (Adding Model: F2-P)

INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2ACDGS1-P This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: 2ACDGS1-P This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. Proposed Label Location on EUT FCC ID Label Location

INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS Solder Board-Component View 1 Solder Board-Component View 2 Loop Antenna

INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I PAGE 1 OF 16 FCC PART 15.209 FCC Part 15C Measurement and Test Report For INS Global Pty Ltd Suite 8, 166A The Entrance Rd, Erina NSW 2250 FCC ID: 2ACDGS1-P Test Rule(s): FCC Part 15.209 Product Description: 125K proximity card reader Tested Model: S3-P Report No.: STR14058060I Tested Date: 2014-05-08 to 2014-05-12 Issued Date: 2014-05-19 Tested By: Susan Su / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy so / PSQ Manager Prepared By: Shenzhen SEM.Test Technology Co., Ltd. 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, P.R.C.（518101） Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen SEM.Test Technology Co., Ltd. INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I PAGE 2 OF 16 FCC PART 15.209 TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 3 1.2 TEST STANDARDS ................................................................................................................................................... 4 1.3 TEST METHODOLOGY ............................................................................................................................................. 4 1.4 TEST FACILITY ....................................................................................................................................................... 4 1.5 EUT SETUP AND OPERATION MODE ...................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 6 3. §15.203 - ANTENNA REQUIREMENT .................................................................................................................. 7 3.1 STANDARD APPLICABLE ......................................................................................................................................... 7 3.2 TEST RESULT.......................................................................................................................................................... 7 4. RADIATED EMISSIONS ......................................................................................................................................... 8 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................................. 8 4.2 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 8 4.3 TEST PROCEDURE ................................................................................................................................................... 8 4.4 TEST RECEIVER SETUP ........................................................................................................................................... 9 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION .............................................................................................. 9 4.6 ENVIRONMENTAL CONDITIONS .............................................................................................................................. 9 4.7 SUMMARY OF TEST RESULTS/PLOTS ...................................................................................................................... 9 5. CONDUCTED EMISSIONS .................................................................................................................................. 13 5.1 MEASUREMENT UNCERTAINTY ............................................................................................................................ 13 5.2 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 13 5.3 TEST PROCEDURE ................................................................................................................................................. 13 5.4 BASIC TEST SETUP BLOCK DIAGRAM ................................................................................................................... 13 5.5 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 14 5.6 TEST RECEIVER SETUP ......................................................................................................................................... 14 5.7 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 14 5.8 CONDUCTED EMISSIONS TEST DATA .................................................................................................................... 14 INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I PAGE 3 OF 16 FCC PART 15.209 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: INS Global Pty Ltd Address of applicant: Suite 8, 166A The Entrance Rd, Erina NSW 2250 Manufacturer: INS Global Pty Ltd Address of manufacturer: Suite 8, 166A The Entrance Rd, Erina NSW 2250 General Description of EUT Product Name: 125K proximity card reader Trade Name: Model No.: S3-P Adding Model(s): S1-P,S2-P, B1-P, F1-125, F1-P, F2-P Rated Voltage: DC 12V Rated Current: 100mA Rated Power: 1.2W Note: The test data is gathered from a production sample, provided by the manufacturer. The enclosure …

Text truncated - open the document above for the full version.

INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test Setup (Below 30MHz) INS Global Pty Ltd Model: S3-P REPORT NO.: STR14058060I FCC PART 15.209 Radiation Emission Test Setup (30MHz to 1GHz)
