FCC ID: 2ACH9HM-7517M RF EXPOSURE EVALUATION METHOD FCC ID: 2ACH9HM-7517M SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Maximum measured transmitter power. WIFI: TX 802.11b Mode Frequency Maximum Conducted Output Power（PK） Maximum Conducted Output Power（AV） Maximum Conducted Output Power（AV） Te s t Channe (MHz) (dBm) (dBm) (mW) CH01 2412 14.66 9.31 8.531 CH06 2437 14.98 9.51 8.933 CH11 2462 14.20 9.23 8.375 TX 802.11g Mode CH01 2412 12.23 8.14 6.516 CH06 2437 12.45 8.33 6.808 CH11 2462 12.89 8.26 6.699 TX 802.11n(20) Mode CH01 2412 10.52 7.08 5.105 CH06 2437 10.43 7.13 5.164 CH11 2462 10.66 7.02 5.035 TX 802.11n(40) Mode CH03 2422 9.29 6.93 4.932 CH06 2437 9.32 6.29 4.256 CH09 2452 9.25 6.47 4.436 FCC ID: 2ACH9HM-7517M BT3.0: 1Mbps Test Channel Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) CH00 2402 -2.12 0.614 CH39 2441 -1.48 0.711 CH78 2480 -1.42 0.721 2Mbps CH00 2402 -2.39 0.577 CH39 2441 -1.79 0.662 CH78 2480 -1.78 0.664 3Mbps CH00 2402 -2.10 0.617 CH39 2441 -1.49 0.710 CH78 2480 -1.40 0.724 Remark: The best case gain of the antenna is 1.0dBi. 1.0 dBi logarithmic terms convert to numeric result is nearly 1.26 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] FCC ID: 2ACH9HM-7517M WIFI: Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [f(GHz)] Result Limit 802.11b CH01 8.531 5 2.412 2.65 3 CH06 8.933 5 2.437 2.79 3 CH11 8.375 5 2.462 2.63 3 802.11g CH01 6.516 5 2.412 2.02 3 CH06 6.808 5 2.437 2.13 3 CH11 6.699 5 2.462 2.10 3 802.11n(20) CH01 5.105 5 2.412 1.59 3 CH06 5.164 5 2.437 1.61 3 CH11 5.035 5 2.462 1.58 3 802.11n(40) CH03 4.932 5 2.422 1.54 3 CH06 4.256 5 2.437 1.33 3 CH09 4.436 5 2.452 1.39 3 BT3.0: Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [f(GHz)] Result Limit 1Mbps CH00 0.614 5 2.402 0.190 3 CH39 0.711 5 2.441 0.222 3 CH78 0.721 5 2.480 0.227 3 2Mbps CH00 0.577 5 2.402 0.179 3 CH39 0.662 5 2.441 0.207 3 CH78 0.664 5 2.480 0.209 3 3Mbps CH00 0.617 5 2.402 0.191 3 CH39 0.710 5 2.441 0.222 3 CH78 0.724 5 2.480 0.228 3 The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion: No SAR is required.

FCC RADIO TEST REPORT-WIFI FCC ID: 2ACH9HM-7517M Product： MID Trade Name： N/A Model Name： HM-7517M Serial Model： HM-75XXM (XX = 0-9) Report No.： NTEK-2014NT09231607F1 Prepared for WeiHeng Digital Company Limited. Rm732, 3rd session, Build B, Mingyou Industrial, Products Exhibitionand Purchasing Center,Baoyuan Road, Bao'an District,Shenzhen, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 54 Report No.: NTEK-2014NT09231607F1 TEST RESULT CERTIFICATION Applicant’s name........ WeiHeng Digital Company Limited. Address ........................ Rm732, 3rd session, Build B, Mingyou Industrial, Products Exhibitionand Purchasing Center,Baoyuan Road, Bao'an District,Shenzhen, China Manufacture's Name... WeiHeng Digital Company Limited Address ........................ Build 3,Fengquan Industry Area YaoShan, XieGang Town DongGuan GuangDong, China Product description Product name .................MID Model and/or type reference ..................... HM-7517M Serial Model .................... HM-75XXM (XX = 0-9) Standards.................... FCC Part15.247 01 Oct. 2013 Test procedure ................ ANSI C63.4-2003 and KDB 558074 June 5, 2014 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: 23 Sep. 2014 ~13 Oct. 2014 Date of Issue...........................................: 13 Oct. 2014 Test Result...............................................: Pass Testing Engineer : (Kyle Xu) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 54 Report No.: NTEK-2014NT09231607F1 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 4 . POWER SPECTRAL DENSITY TEST 25 4.1 APPLIED PROCEDURES / LIMIT 25 4.1.1 TEST PROCEDURE 25 4.1.2 DEVIATION FROM STANDARD 25 4.1.3 TEST SETUP 25 4.1.4 EUT OPERATION CONDITIONS 25 4.1.5 TEST RESULTS 26 5 . BANDWIDTH TEST 34 5.1 APPLIED PROCEDURES / LIMIT 34 5.1.1 TEST PROCEDURE 34 Page 4 of 54 Report No.: NTEK-2014NT09231607F1 Table of Contents Page TEST SETUP 34 5.1.2 EUT OPERATION CONDITIONS 34 5.1.3 TEST RESULTS 35 6 . PEAK OUTPUT POWER TEST 43 6.1 APPLIED PROCEDURES / LIMIT 43 6.1.1 TEST PROCEDURE 43 6.1.2 DEVIATION FROM STANDARD 43 6.1.3 TEST SETUP 43 6.1.4 EUT OPERATION CONDITIONS 43 6.1.5 TEST RESULTS 44 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 45 7.1 DEVIATION FROM STANDARD 45 7.2 TEST SETUP 45 7.3 EUT OPERATION CONDITIONS 45 7.4 TEST RESULTS 46 8 . ANTENNA REQUIREMENT 52 8.1 STANDARD REQUIREMENT 52 8.2 EUT ANTENNA 52 9 . EUT TEST PHOTO 53 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 54 Report No.: NTEK-2014NT09231607F1 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 54 Report No.: NTEK-2014NT09231607F1 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 54 Report No.: NTEK-2014NT09231607F1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment MID Trade Name N/A Model Name HM-7517M Serial Model HM-75XXM (XX = 0-9) Model Difference All the model are the same circuit and RF module, except the model name and colour and shell technology. Product Description The EUT is a MID Operation Frequency: 802.11b/g/n(20MHz): 2412~2462MHz 802.11n(40MHz):2422~2452MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz/40MHz):150/144.44/1 30/117/115.56/104/86.67/78/52/6.5Mb ps Number Of Channel 802.11b/g/n20MHz:11CH 802.11n40MHz:7CH Antenna Designation: …
