2ACHBMERCURYGNSS Receiver

Mercury Laser RTK User Guide 1 Mercury Laser RTK User Guide Mercury Laser RTK User Guide 2 Corporate office ComNav Technology Ltd. Building 2, No.618 Chengliu Middle Road, 201801 Shanghai, China Tel: +86 21 64056796 Fax: +86 21 54309582 Website:http://www.comnavtech.com E-mail:[email protected] Trademark notice © 2025 ComNav Technology Ltd. All rights reserved. SinoGNSS is the official trade mark of ComNav Technology Ltd., registered in People’s Republic of China, EU, USA and Canada. Copyright Notice This is the V1.0 (January, 2026) revision of the Mercury User Guide. It cannot be copied or translated into any language without the written permission of ComNav Technology Ltd. Technical Assistance If you have any question and can't find the answer in this manual, please contact your local dealer from which you purchased the Mercury. Alternatively, request technical support from ComNav Technology Website:www.comnavtech.comor technical support email: [email protected] feedback about this Guide will help us to improve it with future revisions. Safety Information Before using the receiver, please make sure that you have read and understood this User Guide, as well as the safety requirements. ⚫ Connect your devices strictly based on this User Guide ⚫Install the GNSS receiver in a location that minimizes vibration and moisture ⚫Avoid falling to ground, or colliding with other items MercuryLaserUser Guide 3 ⚫ Keep a sound ventilation environment ⚫ Change the cable if damaged Related Regulations The receiver contains integral Bluetooth® wireless technology. Regulations regarding the use of the datalink vary greatly from country to country. In some countries, the unit can be used without obtaining an end-user license. But in some countries the administrative permissions are required. For license information, please consult your local dealer. Use and Care The receiver can withstand the rough treatment that typically occurs in the field. However, the receiver is high-precision electronic equipment and should be treated with reasonable care. Warning and Caution An absence of specific alerts does not mean that there are no safety risks involved. A Warning or Caution information is intended to minimize the risk of personal injury and/or damage to the equipment. WARNING-A Warning alerts you to a potential risk of serious injury to your person and/or damage to the equipment, because of improper operations or wrong settings of the equipment. CAUTION- A Caution alerts you to a possible risk of damage to the equipment and/or data loss. Warranty Notice ComNav Technology does not warranty devices damage because of force majeure (lighting, high voltage or collision). ComNav Technology does not warranty the disassembled devices. MercuryLaserUser Guide 4 FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help RF Exposure Information (SAR) : This device meets the government's requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard for wireless devices employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg for body and 4.0W/kg for Limbs. *Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the poser required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this device is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/ oet/fccid after searching on FCC ID: 2ACHBMERCURY For body worn operation, this device has been tested and meets the FCC RF exposure guidelines for use with an accessory that contains no metal and the positions the device minimum of 5mm from the body . MercuryLaserUser Guide 5 Contents 1.Introduction ........................................................…

Text truncated - open the document above for the full version.

APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：17 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：18 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：19 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：20 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：21 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：22 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：23 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：24 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：25 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：26 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：27 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：28 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：29 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：30 / 53 APPENDIX D CALIBRATION CERTIFICATES Report No.: RKSA260302001-20B Page：31 / 53

Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260302001 1 / 3 EXHIBIT E - TEST SETUP PHOTOGRAPHS Conducted Emissions (Front View) Conducted Emissions (Left View) Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260302001 2 / 3 Radiated Emissions (Below 30 MHz) Radiated Emissions (30MHz-1GHz) Bay Area Compliance Laboratories Corp. (Kunshan) Project No.: RKSA260302001 3 / 3 Radiated Spurious Emissions (1-18 GHz) Radiated Spurious Emissions (18-40 GHz)

Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 75 of 83 802.11ac20_5745MHz 802.11ac20_5785MHz 802.11ac20_5825MHz 802.11ac40_5755MHz 802.11ac40_5795MHz 802.11ac80_5775MHz Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 76 of 83 CONDUCTED TRANSMITTER OUTPUT POWER Environmental Conditions & Test Information Test Date: 2026-04-15 Temperature: 21.2°C Relative Humidity: 50 % ATM Pressure: 100.5 kPa Test Result: Pass Test Engineer: Neil Zhou Test Mode: Transmitting Band Mode Channel Frequency (MHz) Conducted Average Power (dBm) Limit (dBm) 5150-5250 MHz 802.11a Low 5180 10.47 24 Middle 5200 9.97 High 5240 10.29 802.11ac20 Low 5180 10.76 Middle 5200 10.55 High 5240 10.79 802.11ac40 Low 5190 9.36 High 5230 9.64 802.11ac80 Middle 5210 7.17 Note: The EUT is a client device Band Mode Channel Frequency (MHz) Conducted Average Power (dBm) Limit (dBm) 5725-5850 MHz 802.11a Low 5745 11.69 30 Middle 5785 11.76 High 5825 11.65 802.11ac20 Low 5745 11.37 Middle 5785 11.53 High 5825 11.40 802.11ac40 Low 5755 11.24 High 5795 11.24 802.11ac80 Middle 5775 11.54 Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 77 of 83 POWER SPECTRAL DENSITY Environmental Conditions & Test Information Test Date: 2026-04-15 Temperature: 21.2°C Relative Humidity: 50 % ATM Pressure: 100.5 kPa Test Result: Pass Test Engineer: Neil Zhou Test Mode: Transmitting Band Mode Channel Frequency (MHz) Reading (dBm/MHz) Duty Cycle Factor (dB) Result (dBm/MHz) Limit (dBm/MHz) 5150-5250 MHz 802.11a Low 5180 0.11 0.20 0.31 11 Middle 5200 -1.15 0.20 -0.95 High 5240 -0.80 0.20 -0.6 802.11ac20 Low 5180 -0.72 0.19 -0.53 Middle 5200 -0.77 0.19 -0.58 High 5240 -0.54 0.19 -0.35 802.11ac40 Low 5190 -5.04 0.39 -4.65 High 5230 -4.74 0.39 -4.35 802.11ac80 Middle 5210 -10.14 0.71 -9.43 Band Mode Channel Frequency (MHz) Reading (dBm/500kHz) Duty Cycle Factor (dB) Result (dBm/500kHz) Limit (dBm/500kHz) 5725-5850 MHz 802.11a Low 5745 -2.75 0.17 -2.58 30 Middle 5785 -2.60 0.17 -2.43 High 5825 -2.80 0.17 -2.63 802.11ac20 Low 5745 -3.24 0.19 -3.05 Middle 5785 -3.05 0.19 -2.86 High 5825 -3.17 0.19 -2.98 802.11ac40 Low 5755 -6.30 0.39 -5.91 High 5795 -6.22 0.39 -5.83 802.11ac80 Middle 5775 -9.45 0.69 -8.76 Note： Result=Reading+ Duty Cycle Factor Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 78 of 83 5150-5250MHz 802.11a_5180MHz 802.11a_5200MHz 802.11a_5240MHz 802.11ac20_5180MHz 802.11ac20_5200MHz 802.11ac20_5240MHz Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 79 of 83 802.11ac40_5190MHz 802.11ac40_5230MHz 5725-5850MHz 802.11ac80_5210MHz 802.11a_5745MHz 802.11a_5785MHz 802.11a_5825MHz Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 80 of 83 802.11ac20_5745MHz 802.11ac20_5785MHz 802.11ac20_5825MHz 802.11ac40_5755MHz 802.11ac40_5795MHz 802.11ac80_5775MHz Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 81 of 83 EUT PHOTOGRAPHS Please refer to the attachment EXHIBIT A - EUT EXTERNAL PHOTOGRAPHS and EXHIBIT B - INTERNAL PHOTOGRAPHS. Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 82 of 83 TEST SETUP PHOTOGRAPHS Please refer to the attachment EXHIBIT E - TEST SETUP PHOTOGRAPHS. Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 83 of 83 Declarations 1. The laboratory is not responsible for the authenticity of any information provided by the applicant. Information from the applicant that may affect test results is marked with “★”. 2. The test data was only valid for the test sample(s). 3. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. 4. Otherwise required by the applicant or Product Regulations, Decision Rule in this report did not consider the uncertainty. 5. The extended uncertainty given in this report is obtained by combining the standard uncertainty times the coverage factor k=2 with the 95.45% confidence interval. *****END OF REPORT*****

Page 1 of 83 FCC PART 15.407 TEST REPORT For ComNav Technology Ltd. Building 2, No.618 Chengliu Middle Rd. shanghai, China FCC ID: 2ACHBMERCURY Report Type: Original Report Product Name: GNSS Receiver Report Number: RKSA260302001-00D Report Date: 2026-06-03 Reviewed By: Winnie Yang Approved By: Kyle Xu Test Laboratory: Bay Area Compliance Laboratories Corp. (Kunshan) No.248 Chenghu Road, Kunshan, Jiangsu Province, China Tel: +86-512-86175000 Fax: +86-512-88934268 www.baclcorp.com.cn Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Kunshan). This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, or any agency of the U.S. Government. Bay Area Compliance Laboratories Corp. (Kunshan) Report No.: RKSA260302001-00D Page 2 of 83 TABLE OF CONTENTS REPORT REVISION HISTORY................................................................................................................................. 4 GENERAL INFORMATION ....................................................................................................................................... 5 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 5 OBJECTIVE ................................................................................................................................................................... 5 TEST METHODOLOGY .................................................................................................................................................. 5 MEASUREMENT UNCERTAINTY .................................................................................................................................... 6 TEST FACILITY ............................................................................................................................................................. 6 SYSTEM TEST CONFIGURATION .......................................................................................................................... 7 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 7 EUT EXERCISE SOFTWARE .......................................................................................................................................... 8 EQUIPMENT MODIFICATIONS ..................................................................................................................................... 12 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................. 12 EXTERNAL I/O CABLE................................................................................................................................................ 12 BLOCK DIAGRAM OF TEST SETUP .............................................................................................................................. 12 SUMMARY OF TEST RESULTS ............................................................................................................................. 14 TEST EQUIPMENT LIST ......................................................................................................................................... 15 FCC §1.1307(b) & §2.1093 - RF EXPOSURE ........................................................................................................... 17 APPLICABLE STANDARD ............................................................................................................................................ 17 FCC §15.203 – ANTENNA REQUIREMENT .......................................................................................................... 18 APPLICABLE STANDARD ............................................................................................................................................ 18 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 18 FCC §15.407 (b) (9) §15.207 (a) – AC POWER LINE CONDUCTED EMISSIONS ............................................ 19 APPLICABLE STANDARD ............................................................................................................................................ 19 TEST SYSTEM SETUP .................................................................................................................................................. 19 EMI TEST RECEIVER SETUP ....................................................................................................................................... 19 TEST PROCEDURE ...................................................................................................................................................... 20 TEST RESULTS SUMMARY .......................................................................................................................................... 20 FCC §15.205 & §15.209 & §15.407(B) – UNDESIRABLE EMISSION & RESTRICTED BANDS .................... 21 APPLICABLE STANDARD ............................................................................................................................................ 21 TEST SYSTEM SETUP .................................................................................................................................................. 21 EMI TEST RECEIVER & SPECTRUM ANALYZER SETUP .............................................................................................. 24 TEST PROCEDURE ...................................................................................................................................................... 24 FCC §15.407(a) &§…

Text truncated - open the document above for the full version.

HX-CSX352A InternalSurveyAntenna HX-CSX352A HX-CSX352A ProductInformation ProductNameHelixAntenna ModelNumberHX-CSX352A RevisionHistory RevisionDatePreparedbyDescription A2026-04-24XinkaiGeInitialrelease AboutHarxon Address Room501,Han'sLaserTechnologyCentre, ShennanAveNo.9988,NanshanDistrict, Shenzhen,GuangdongProvince,China Tel+86-18902450568 Fax+86-755-26989994 [email protected] Websiteen.harxon.com ProprietaryNotice TheinformationcontainedhereinisproprietarytoHarxonCorporation.HarxonCorporationmakesnorepresentationsor warrantiesregardingtheaccuracyorcompletenessofthisdocumentandreservestherighttomakechangesto specificationsandproductdescriptionsatanytimewithoutpriornotice. Nopartofthisdocumentmaybereproduced,transmitted,ordisclosedtoanythirdpartywithoutpriorwrittenpermission fromHarxonCorporation. ©HarxonCorporation.Allrightsreserved. HX-CSX352A 1.Introduction TheHX-CSX352Aisafour-systemfull-frequencybuilt-inmeasurementantennathatcoversGPS, GLONASS,BDS,andGALILEO.ItisalsocompatiblewiththeWIFIworkingfrequencyband.Theantenna unithashighgain,widecoveragefrequencyband,stablesatellitereception,andfeaturesanelegant appearanceandhighenvironmentalreliability.ItcanbeusedinconjunctionwithvariousGPS,Beidou andotherreceivers,andiswidelyappliedinfieldssuchasgeodeticsurveying,marinesurveying,channel surveying,dredgingsurveying,earthquakemonitoring,bridgedeformationmonitoring,landslide monitoring,andcontaineroperationsatdocks. Thephasecenterisstable.Theantennaadoptsamulti-feed-pointdesigntoachievethecoincidenceof thephasecenterandthegeometriccenter,therebyminimizingtheimpactofantennaalignmenterrors onthemeasurementresults. TheantennaLNAhasexcellentout-of-bandsuppressionperformance,whichcansuppressunwanted electromagneticwavesignalsandpreventthereceiverfrombeinginterferedbyotherwireless communicationsystems.Thiseffectivelyreducestheriskofsystemlockout,suchasinpowergrids, communicationbasestations,radiostations,etc,wherethereareelectromagneticwaveinterferences. Theantennaunitfeatureshighgainandawidedirectionalbeampattern,ensuringthattheantennacan stillreceivestrongsignalsatlowelevationangles,andenablingittoquicklylockontosatellitesand stablyoutputGNSSnavigationsignalsevenincomplexenvironmentssuchasundertreecoveror buildingobstructions. KeyFeatures: ●Supportsfull-bandsignalsoffourGNSSsystems ●Supportsdual-bandWi-Ficommunication ●Stronganti-interferenceability,capableofwithstandingharshworkingenvironments ●Goodelectromagneticcompatibility,smallantennasize,facilitatingproductintegration. HX-CSX352A 2.Specifications FrequencyBandsandSupportedFunctions GPS L1L2L5  GLONASS G1G2G3  Galileo E1E5aE5bE6  BeiDou B1IB1CB2aB2bB3I  QZSS L1L2L5L6  IRNSS L1L5  SBAS L1(WAAS/EGNOS/MSAS) L5(EGNOSv3,etc.) G2   Additional Functions L-BandSatelliteCommunicationWi-Fi/BluetoothCellular(4G/5G)  RadioCommunicationLoRa/LPWANCommunication GNSSFrequencyBandsandConstellations HX-CSX352A Performance NominalImpedance50Ω PolarizationRHCP AxialRatio(@zenith)≤3dB GainRHCP(maximum) 1166~1278MHz4.0dBi 1559~1612MHz3.5dBi L-Band3.6dBi LNAGain 1166~1278MHz：34±2dB 1559~1612MHz：32±2dB VSWR≤2 NoiseFigure≤2dB OperationVoltage+3.3～12VDC OperationCurrent25mA(Typical)@5VDC PhaseCentreOffset±3mm Mechanical DimensionsΦ70*28.7mm(Cableandconnectornotincluded) Weight≈50g ConnectorIPEX-1 Mounting4×M2.5ScrewsFixed Environmental OperatingTemperature-40°C～+85°C StorageTemperature-55°C～+85°C RegulatoryComplianceFCC,CE,RoHS,REACH HX-CSX352A 3.StructureDrawing Undeclaredtolerance:±0.3mm 4.GNSSAntennaTestMeasurement 4.1AnechoicChamberTestSetup HX-CSX352A 4.2GNSSAntennaRadiationPerformance GNSS Gainat Zenith(dBi) AxialRatio atZenith(dB) Gainat20° Elevation(dBi) AxialRatioat 20°Elevation (dB) GPS/QZSS L13.332.61-2.278.53 L23.521.75-3.006.66 L51.041.13-6.378.71 GLONASS G12.982.70-2.228.42 G24.092.09-3.516.90 G32.281.26-3.866.81 BeiDou B1I3.512.33-3.399.29 B2I2.281.26-3.866.81 B3I3.722.61-3.887.18 B1C3.332.61-2.278.53 B2a1.041.13-6.378.71 B2b2.281.26-3.866.81 Galileo E12.982.70-2.228.42 E5a1.041.13-6.378.71 E5b2.281.26-3.866.81 E63.722.61-3.887.18 L-band3.622.69-4.179.40 HX-CSX352A 4.3GNSSAntennaGainRadiationPatterns 4.4Wi-FiAntennaRadiationEfficiencyandGain RadiationEfficiencyandGain Frequency(MHz)Gain(dBi)Efficiency(%) 2400-0.0627.9 2450-0.7823.6 2485-1.7421.6 5100-3.6013.1 5200-1.5322.1 5300-0.0531.0 5400 1.34 34 31.0 55001.6528.3 56002.0226.4 5700-0.1115.1 5800-2.618.5 4.5Wi-FiAntennaGainRadiationPatterns HX-CSX352A HX-CSX352A 5.LabelandPackaging 6.ModelNumberBuilder LabelandPackaging LabelSize:15*10mm Seethefigureontheleftforlabeldetails. PackingQuantity:20GNSSantennaspercarton CartonSize:330×290×270mm HX-CSX352A i.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Kunshan). This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, or any agency of the U.S.Govemment. This report contains data not covered by NVLAP accreditation. SAR Evaluation Report 1 of 116 SAR EVALUATION REPORT For ComNav Technology Ltd. Building 2, No.618 Chengliu Middle Rd. shanghai, China FCC ID: 2ACHBMERCURY Report Type: Original Report Product Name: GNSS Receiver Report Number: RKSA260302001-20B Re port Date: 2026-05-28 Reviewed By: Bard Liu Approved By: Kyle Xu Prepared By: Bay Area Compliance Laboratories Corp. (Kunshan) No.248 Chenghu Road, Kunshan, Jiangsu Province, China Tel: +86-512-86175000 Fax: +86-512-88934268 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Kunshan) No.: RKSA260302001-20B SAR Evaluation Report 2 of 116 TABLE OF CONTENTS REPORT REVISION HISTORY ................................................................................................................................ 3 REFERENCE, STANDARDS, AND GUIDELINES .................................................................................................. 6 SAR LIMITS ................................................................................................................................................................. 6 FACILITIES .................................................................................................................................................................. 7 DESCRIPTION OF TEST SYSTEM .......................................................................................................................... 8 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 17 EQUIPMENTS LIST & CALIBRATION INFORMATION .................................................................................................... 17 SAR MEASUREMENT SYSTEM VERIFICATION .............................................................................................. 18 LIQUID VERIFICATION ............................................................................................................................................... 18 SYSTEM ACCURACY VERIFICATION ........................................................................................................................... 26 SAR SYSTEM VALIDATION DATA ..................................................................................................................... 28 EUT TEST STRATEGY AND METHODOLOGY ................................................................................................. 36 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS .............................................................................. 36 TEST DISTANCE FOR SAR EVALUATION .................................................................................................................... 36 SAR EVALUATION PROCEDURE ................................................................................................................................. 37 CONDUCTED OUTPUT POWER MEASUREMENT ........................................................................................... 38 TEST PROCEDURE ...................................................................................................................................................... 38 RADIO CONFIGURATION ............................................................................................................................................ 38 MAXIMUM TARGET OUTPUT POWER ......................................................................................................................... 41 TEST RESULTS: .......................................................................................................................................................... 43 STANDALONE SAR TEST EXCLUSION CONSIDERATIONS ......................................................................... 70 STANDALONE SAR TEST EXCLUSION CONSIDERATIONS ........................................................................................... 72 STANDALONE SAR ESTIMATION: ............................................................................................................................... 72 SAR TEST EXCLUSION FOR THE EUT EDGE CONSIDERATIONS RESULT ...................................................................... 73 SAR MEASUREMENT RESULTS ........................................................................................................................... 76 SAR TEST DATA ........................................................................................................................................................ 76 SAR MEASUREMENT VARIABILITY .................................................................................................................. 85 SAR SIMULTANEOUS TRANSMISSION DESCRIPTION ................................................................................. 86 APPENDIX A SAR PLOTS OF SAR MEASUREMENT ....................................................................................... 87 APPENDIX B MEASUREMENT UNCERTAINTY ............................................................................................. 107 APPENDIX C EUT TEST POSITION PHOTOS .................................................................................................. 108 APPENDIX D CALIBRATION CERTIFICATES ................................................................................................ 114 APPENDIX E DIPOLE INTERMEDIATE CHECK ............................................................................................ 115 Bay Area Compliance Laboratories Corp. (Kunshan) No.: RKSA260302001…

Text truncated - open the document above for the full version.

APPENDIX E DIPOLE INTERMEDIATE CHECK Report No.: RKSA260302001-20B Page: 1 / 8 Dipole antenna information： Dipole： D750V3 Serial Number: 1166 Manufacturer: Speag Calibration Date: 2025/06/14 Calibrated by: Reciewed by: Note： All Calibration have been conducted in the closed laboratory facility: Lab Temperature 18°C-25°C and humidity < 70% Calibration Equipment used: Equipment Model S/N Calibration Date Calibration Due Date Twin-SAM Phantom QD 000 P41 Ax 1963 N/A N/A Simulated Tissue LiquidHead HBBL600-6000V6 180611-3 Each Time Network Analyzer E5071B SG42400155 2025/04/08 2026/04/07 Network Analyzer Calibration Kit 50Ω N/A N/A N/A Test Data: Frequency (MHz) Simulated Liquid Parameter Measured Va l u e Target Va l u e Deviation 750 Head Return Loss -27.232 dB -26.546 dB 2.584% Real Impedance 53.708 Ω 50.953 Ω 2.755 Ω Imaginary Impedance -2.5298 Ω -4.6599 Ω 2.1301 Ω Note: The return loss is <-20dB, within 20% of prior calibration; the impedance is within 5 ohm of prior calibration. Therefore the verification result should support extended calibration. APPENDIX E DIPOLE INTERMEDIATE CHECK Report No.: RKSA260302001-20B Page: 2 / 8 D750V3 - SN: 1166 (Date of Measurement: 2025/06/14) APPENDIX E DIPOLE INTERMEDIATE CHECK Report No.: RKSA260302001-20B Page: 3 / 8 Dipole antenna information： Dipole： D1750V2 Serial Number: 1140 Manufacturer: Speag Calibration Date: 2025/06/14 Calibrated by: Reciewed by: Note： All Calibration have been conducted in the closed laboratory facility: Lab Temperature 18°C…

Text truncated - open the document above for the full version.
