2ACI8ASA97ASA97 Air Mouse

江苏爱仕达电子有限公司 ASDElectronicsCo.,Ltd. 江苏爱仕达电子有限公司工程部编制第9页 ASD-ST-G-04(05-01)5 操作使用说明GUDIE 一.供电规格：Thepowersupplyspecifications 使用AAA1.5V×2干电池按极性装入遥控器 UsetheAAA1.5Vx2drycell 二．对码操作方法Theoperationmethod 方法一，打开M310盒子，待界面出现对码界面窗口，按住OK键和音量+键，直到对码提示 OK成功字样，对码完成。 Methoda,opentheboxofM310,appeartocodeinterfacewindow,presstheOKkeyand volume+key,untilthecodepromptOK,thecodeiscomplete. 方法二，打开M310盒子，将USB鼠标插到盒子USB接口，操作鼠标，打开设置菜单-蓝牙 设置-点击查找设备，同时按住OK键和音量+键,直到显示蓝牙设备已连接，对码成功。 Method2,opentheM310box,puttheUSBmouseUSBinterfacebox,mouseoperation, opentheSettingsmenu-bluetoothSettings-clicktofindequipment,pressOKkeyand volume+keyatthesametime,indicatingabluetoothdeviceisconnected,thecode successfully 注意：若蓝牙列表有过多设备连接，需重置清除功能盒子，重新上电后按步骤1，2，重新对 码操作。 Mark：Ifthereistoomuchequipmentlistofbluetoothconnection,needtoresetthecleared boxfunction,afterpoweronagainaccordingtothestep1,2,backtomanipulatecode 三．休眠功能HibernateMode 上电无任何按键操作30Min进入休眠，支持任意键唤醒。 30minelectricitywithoutanykeystrokesintodormancy,supportanykey. Federal Communications Commission (FCC) Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications made to this device not expressly approved by JIANGSU ASTARTE ELECTRONICS CO.,LTD may void the FCC authorization to operate this device. Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.

JIANGSU ASTARTE ELECTRONICS CO., LTD FuYong Town, Bao’an District, Shenzhen, and love the new Homestead Idustrial Park TEL: 86-755-23492765 FAX: 86-755-23493364 Rev 11/20/07 Confidentiality Letter Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ACI8ASA97. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operation Description Operation Description.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Yang Hong/ Quality Manager

JIANGSU ASTARTE ELECTRONICS CO., LTD FuYong Town, Bao’an District, Shenzhen, and love the new Homestead Idustrial Park TEL: 86-755-23492765 FAX: 86-755-23493364 AGENCY AUTHORIZATION LETTER FCC ID:2ACI8ASA97 Date: May 30, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize Shenzhen CTL Testing Technology Co., Ltd.(MR. Tracy Qi) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen CTL Testing Technology Co., Ltd. (MR. Tracy Qi) on our behalf shall have the same effect as acts of our own. This authorization expires on May 29, 2015. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, JIANGSU ASTARTE ELECTRONICS CO., LTD are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Yang Hong/ Quality Manager

FCC ID Label Information 1. Label location: 2. FCC ID Label: ASA97 Air Mouse Model: ASA97 FCC ID: 2ACI8ASA97

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT FCC Part 15.249 Report Reference No......................: CTL1405271183-WF Compiled by ( position+printed name+signature)..: File administrators Jacky Chen Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Tracy Qi Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: June 04, 2014 Test Firm..........................................: Shenzhen CTL Testing Technology Co., Ltd. Address.............................................: Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China. Applicant’s name............................: JIANGSU ASTARTE ELECTRONICS CO.,LTD Address.............................................: FuYong Town, Baoan District, Shenzhen, and love the new Homestead Idustrial Park Test specification: Standard ...........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. TRF Originator ..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : ASA97 Air Mouse Trade Mark .......................................: N/A Models/Type reference.....................: ASA97 Modulation .......................................: GFSK Work Frequency...........................: 2402 MHz~2480 MHz Antenna Type..............................: internal FCC ID .............................................: 2ACI8ASA97 Result................................................: Positive V1.0 Page 2 of 29 Report No.: CTL1405271183-WF T E S T R E P O R T Test Report No. : CTL1405271183-WF June 04, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : ASA97 Air Mouse Model /Type : ASA97 Applicant : JIANGSU ASTARTE ELECTRONICS CO.,LTD Address : FuYong Town, Baoan District, Shenzhen, and love the new Homestead Idustrial Park Manufacturer JIANGSU ASTARTE ELECTRONICS CO.,LTD Address FuYong Town, Baoan District, Shenzhen, and love the new Homestead Idustrial Park Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 29 Report No.: CTL1405271183-WF Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 6 2.5. EUT configuration 6 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Configuration of Tested System 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 12 4.3. Band Edge Measurement 17 4.4. Occupied Bandwidth Measurement 21 5. ANTENNA REQUIREMENT ....................................................... 23 6. TEST SETUP PHOTOS OF THE EUT .......................................... 24 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 25 V1.0 Page 4 of 29 Report No.: CTL1405271183-WF 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.4-2009 V1.0 Page 5 of 29 Report No.: CTL1405271183-WF 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : May 27, 2014 Testing commenced on : May 27, 2014 Testing concluded on : June 04, 2014 2.2. Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ● Other (specified in blank below) DC 3.0V from battery（2*AAA） 2.3. Short description of the Equipment under Test (EUT) The EUT is an Air Mouse work at 2402~2480 MHz. Channel List: Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 20 2442 01 2404 21 2444 02 2406 22 2446 03 2408 23 2448 04 2410 24 2450 05 2412 25 2452 06 2414 26 2454 07 2416 27 2456 08 2418 28 2458 09 2420 29 2460 10 2422 30 2462 11 2424 31 2464 12 2426 32 2466 13 2428 33 2468 14 2430 34 2470 15 2432 35 2472 16 2434 36 2474 17 2436 37 2476 18 2438 38 2478 19 2440 39 2480 Power Range: -5dBm~0dBm Modulation: GFSK V1.0 Page 6 of 29 Report No.: CTL1405271183-WF 2.4. EUT operation mode Test Mode(TM) Description Remark TM1 Bottom Channel Transmitting / TM2 Middle Channel Transmitting / TM3 Top Channel Transmitting / The field strength of radiation emission was measured in the following position: EUT stand-up position (Y axis), lie-down position (X, Z axis). The following data show only with the worst case setup. The worst case of Y axis was reported. Based on client request, all normal using modes of the normal function were tested but only the worst test data of the worst mo…
