2ACIA-TTBT004915 Mhz Wireless IR repeater system

Wireless IR Repeater System User Guide FEATURES: 1. Connect wired IR Repeater devices wirelessly. 2. Easy to control all home entertainment in this system over 200 meters. 3. No extra wire need. SPECIFICATIONS IR: 1. Compatible with all Universal full band carrier frequency infrared Remote 2. Better IR receive sensitivity(distance),over 7 meter RF: 1. Long range transmission over 200 meter (open space) 2. 915MHz RF technology to ignore current 433MHz RF-interference 3. FSK modulation:  Better signal sensitivity than ASK modulation  Better Anti RF-interference than ASK modulation  Better noise suppression 4. Digital technology with frequency hopping technology to minimizes RF-interference 5. Digital encrypted function ensures safety and reliability Power:5VDC/500mA Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from thatto which the receiver is connected. Wireless IR Repeater System User Guide  Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. Wireless IR Repeater System User Guide

RF_160, Issue 03 Declaration of Authorization We Name: Ten-Tronics Co., Ltd. Address: No.33, Lane 347, Chung-San S. Road, Young-Kang City, Tainan, Taiwan City: Tainan Country: Taiwan Declare that: Name Representative of agent : Gloria Chang Agent Company name : Compliance Certification Services Inc. Address : No. 989-1 Wenshan Rd., Shang Shan Village, Qionglin Shiang, Hsinchu County 30741, Taiwan City : Hsinchu County 30741 Country : Taiwan R.O.C is authorized to apply for Certification of the following product(s): Product description: 915 Mhz Wireless IR repeater system Type designation: A-1369 Trademark: on our behalf. Date: July 24, 2015 City: Tainan Name: Jason Wen Function: Manager Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 16-Jul-10 RF_501, Issue 6 Page 1 of 1 Company Name: TEN-TRONICS Address : No.33, Lane 347, Chung-San S. Road, Young-Kang District, Tainan City, Taiwan City: Tainan City Country: ROC To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: 2ACIA-TTBT004 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: Jan. 28, 2016 (notes 2, 3, 4, 5) Date: July.22,2015 Name and signature of applicant: Jason Wen Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Report No.T150702L04 Page 1 of 8 External Photo (TX) Report No.T150702L04 Page 2 of 8 Report No.T150702L04 Page 3 of 8 External Photo (RX) Report No.T150702L04 Page 4 of 8 Report No.T150702L04 Page 5 of 8 Power Adapter Report No.T150702L04 Page 6 of 8 TX Cable Report No.T150702L04 Page 7 of 8 RX Cable Report No.T150702L04 Page 8 of 8 RX Cable

FCCIDLabel mm Back View SCALE:

Report No.T150702L04 Page 1 of 8 Internal Photo (TX) Report No.T150702L04 Page 2 of 8 Report No.T150702L04 Page 3 of 8 Report No.T150702L04 Page 4 of 8 Internal Photo (RX) Report No.T150702L04 Page 5 of 8 Report No.T150702L04 Page 6 of 8 Report No.T150702L04 Page 7 of 8 Antenna (TX) Report No.T150702L04 Page 8 of 8 Antenna (RX)

Compliance Certification Services Inc. FCC ID : 2ACIA-TTBT004 Report No.T150702L04-RP1 Page 1 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. FCC 47 CFR PART 15 SUBPART C AND ANSI C63.10:2013 TEST REPORT For 915 Mhz Wireless IR repeater system Model : A-1369 Issued for Ten-Tronics Co., Ltd. No.33, Lane 347, Chung-San S. Road, Young-Kang City, Tainan, Taiwan Issued by Compliance Certification Services Inc. Hsinchu Lab. No.989-1, Wenshan Rd., Shangshan Village, Qionglin Township, Hsinchu County 30741, Taiwan (R.O.C.) TEL: +886-3-5921698 FAX: +886-3-5921108 http://www.ccsrf.com E-Mail : [email protected] Issued Date: July 22, 2015 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results of this report relate only to the tested sample identified in this report. Compliance Certification Services Inc. FCC ID : 2ACIA-TTBT004 Report No.T150702L04-RP1 Page 2 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 07/22/2015 Initial Issue All Page 27 Michelle Chiu Compliance Certification Services Inc. FCC ID : 2ACIA-TTBT004 Report No.T150702L04-RP1 Page 3 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION ................................................................................ 4 2. EUT DESCRIPTION ..................................................................................................... 5 3. DESCRIPTION OF TEST MODES ............................................................................... 6 4. TEST METHODOLOGY ............................................................................................... 7 5. FACILITIES AND ACCREDITATION ........................................................................... 7 5.1 FACILITIES ............................................................................................................ 7 5.2 ACCREDITATIONS ................................................................................................ 7 5.3 MEASUREMENT UNCERTAINTY ......................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST ...................................................................... 9 7. FCC PART 15.249 REQUIREMENTS .......................................................................... 10 7.1 20 dB BANDWIDTH ............................................................................................... 10 7.2 RADIATED EMISSION ........................................................................................... 13 7.3 CONDUCTED EMISSION ...................................................................................... 20 APPENDIX SETUP PHOTOS .......................................................................................... 25 Compliance Certification Services Inc. FCC ID : 2ACIA-TTBT004 Report No.T150702L04-RP1 Page 4 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 1. TEST REPORT CERTIFICATION Applicant Ten-Tronics Co., Ltd. Address No.33, Lane 347, Chung-San S. Road, Young-Kang City, Tainan, Taiwan Equipment Under Test 915 Mhz Wireless IR repeater system Model A-1369 Tested Date July 02 ~ 17, 2015 APPLICABLE STANDARD Standard Test Result FCC Part 15 Subpart C AND ANSI C63.10:2013 & ANSI C63.4:2014 PASS WE HEREBY CERTIFY THAT: The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Sb. Lu Gundam Lin Sr. Engineer Sr. Engineer Compliance Certification Services Inc. FCC ID : 2ACIA-TTBT004 Report No.T150702L04-RP1 Page 5 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 2. EUT DESCRIPTION Product Name 915 Mhz Wireless IR repeater system Model Number A-1369 Identify Number T150702L04 Received Date July 02, 2015 Frequency Range 915MHz Transmit Power 57.68 dBuV/m Channel Number 1 Channels Type of Modulation FSK Antenna Type Spring Antenna, Antenna Gain : 2 dBi Power Rating 5Vdc Test Voltage 120Vac, 60Hz DC Power Cable Type Non-shielded cable, 1.8m × 2 (Non-detachable) I/O Port EUT 1(TX) : Power Port × 1, IR Port × 1 EUT 2(RX) : Power Port × 1, IR Port × 1 Signal Cable Non-shielded IR cable, 2.9m × 3 (Detachable) Power Adapter : No. Manufacturer Model No. Power Input Power Output Remark 1 HON-KWANG HK-S-050A050- US 100-240Vac, 50/60Hz, 0.2A 5V, 0.5A For EUT 1, 2 Remark : 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. For more details, please refer to the User’s manual of the EUT. 3. This submittal(s) (test report) is intended for FCC ID: 2ACIA-TTBT004 filing to comply with Section 15.207, 15.209 and 15.249 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. FCC ID : 2ACIA-TTBT004 Report No.T150702L04-RP1 Page 6 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 3. DESCRIPTION OF TEST MODES The …

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID : 2ACIA-TTBT004 Report No.T150702L04-RP1 Page 25 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. APPENDIX SETUP PHOTOS RADIATED EMISSION SETUP Below 1 GHz Compliance Certification Services Inc. FCC ID : 2ACIA-TTBT004 Report No.T150702L04-RP1 Page 26 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Above 1 GHz Compliance Certification Services Inc. FCC ID : 2ACIA-TTBT004 Report No.T150702L04-RP1 Page 27 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. CONDUCTED EMISSION SETUP
