2ACJ6RD100Roadie

It’s time to get your Roadie on the Road. User’s Manual: This manual is a quick start guide for Roadie Tuner. For a more comprehensive overview on how to operate Roadie with our mobile app please check our online tutorial: www.roadietuner.com/tutorial Model Number: RD100 A- Warranty Band Industries One-Year Limited Warranty — Band Industries warrants the included hardware product and accessories against defects in materials and workmanship for one year from the date of original retail purchase. Band Industries does not warrant against normal wear and tear, nor damage caused by accident or abuse. To obtain service, please email us at [email protected]. B- Inside this box C- Getting Started (6) Charging LED (7) Reset Pin (5) Micro USB Charging Port (4) Restring Buttons (3) Peg Connector (2) RGB LED (A)(B)(C) (1) Power Button Installing the App Roadie app is available for the latest iOS devices and Android 4.3 and newer. Roadie communicates via Bluetooth low energy with the mobile app, please refer to the online tutorial to ensure that your phone is compatible. 1. Go to the AppStore or Playstore on your mobile device and install the Roadie Tuner app 2. Open the app and follow the on-screen instructions Using Roadie for the first time 1. Turn Roadie on by pressing the On/Off power button (1). 2. The RGB LED (2) light will start blinking blue. For more info about what the different colors and patterns of light mean, please refer to the RGB LED light section below. 3. With the app open on your mobile device, create a new instrument. 4. If bluetooth is switched off on your mobile phone, you will be prompted to turn it on. 5. When accepted, the prompt will disappear and the light on Roadie will turn solid blue indicating a successful bluetooth connection. Tuning your instrument 1. Open the Roadie Tuner app 2. Select the instrument that you want to tune, or if it is a new instrument select that instrument 3. Select the string you want to tune and follow the instructions on the screen. 4. The first time you tune a string and sometimes when you restring your guitar, Roadie will ask you to calibrate this string. Just follow the basic instructions on the screen. 5. Connect the peg connector (3) to the proper peg of the string to be tuned. Roadie’s peg connector (3) is designed to fit into most standard peg designs. 6. Pluck the string being tuned while firmly holding Roadie on the tuning peg at all time. 7. Roadie's peg connector will start rotating the string's peg in order to tune it. Note: if you are tuning an electric guitar, you can plug it directly to your mobile device using the Roadie Jack (B). This allows for a silent tuning and removes any possibility of outside noise affecting your tuning. Power and Recharging - Roadie operates on a 3.7V 1000mAh Lithium Polymer battery. - When the battery is low you should charge it through the micro USB charging port (5). - When charging, the LED indicator (6) turns red. - When the battery is fully charged, the charging LED indicator (6) turns green. In that case you should unplug the micro USB cable. - To ensure maximum battery life and protection, Roadie will not work when charging. (6) Charging LED (5) Micro USB Charging Port (6) Charging LED (5) Micro USB Charging Port (7) Reset Pin Re-stringing using Roadie You can use Roadie as a string winder/unwinder either using the mobile app or standalone using the wind/unwind buttons (4). (4) Restring Buttons (3) Peg Connector Left ButtonRight Button counter- clockwise rotation clockwise rotation Power and Recharging - Roadie operates on a 3.7V 1000mAh Lithium Polymer battery. - When the battery is low you should charge it through the micro USB charging port (5). - When charging, the LED indicator (6) turns red. - When the battery is fully charged, the charging LED indicator (6) turns green. In that case you should unplug the micro USB cable. - To ensure maximum battery life and protection, Roadie will not work when charging. D- warnings - Roadie is designed and tested to work with stringed instruments equipped with geared tuning pegs similar to those of the guitar. If your tuning pegs are different, we cannot ensure proper operation of Roadie. Use at your own risk. - If you notice that Roadie’s motor is struggling to rotate the pegs, this is probably because your pegs are rusty. If that is the case, we highly advise you to clean or change your pegs before you use Roadie. RGB LED light This is how Roadie communicates with the external world: - When looking for a Bluetooth connection, the RGB LED blinks blue - When battery is low, the RGB LED blinks red - When Roadie is connected to your smartphone, the RGB LED lights solid blue - When tuning or calibrating a string, the RGB LED lights solid green - When there is an error, the RGB LED lights solid red. Roadie's hard reset If Roadie is not responsive anymore then a hard reset is required. Simply insert a pin inside the Reset Pin (7), in order to turn off Roadie completely. For more info, troubleshooting, and other options, please check the online tutorial at www.roadietuner.com/tutorial E- Compliance - This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interf…

Text truncated - open the document above for the full version.

EIN# 42-1777377 [email protected] Jalgha Bldg. Rachdan St. Furn El Chebak, 622 Beirut, Lebanon FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Band Industries Inc. Addresss Jalgha Bldg. Rachdan St. City Furn El Chebak, 622 Country Lebanon request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: 2ACJ6 RD100 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) √ Operational Description √ Block Diagrams √ Schematics Diagrams √ Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Furn El Chebbak, Lebanon Jul 2, 2014 Bassam Jalgha Chief Technology Officer

EIN# 42-1777377 [email protected] Jalgha Bldg. Rachdan St. Furn El Chebak, 622 Lebanon Power of Attorney To: Phoenix Testlab GmbH Name or model type of the Specified Radio Equipment: Roadie FCC ID: 2ACJ6RD100 Applicant’s company name: Band Industries, Inc. Applicant’s company address: Jalgha bldg. Rachdan St. Furn E1 Chebak, 622, Lebanon Applicant’s name: Bassam Jalgha Date and Applicant’s Signature: Jul 2, 2014 Job Title and Department: Chief Technology Officer I hereby authorize the following person as a representative and all rights regarding the application to obtain Type Certification for the Specified Radio Equipment (mentioned above) are delegated. Attorney’s Company name: Dongguan EMTEK Co., Ltd Attorney’s Company address: No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China. Attorney’s Name: Sam, Lv Date and Attorney’s Signature: Jul 2, 2014 Job Title and Department: EMC Manager

Antenna

TRF No. FCC Part 15.247/A Page 1 of 44 Report No. KAD140627152E Ver.1.0 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Roadie Model No.: RD100 Brand Name: roadie FCC ID: 2ACJ6RD100 Report No.: KAD140627152E Issue Date: July 29, 2014 Prepared for Band Industries Inc. Jalgha Bldg. Rachdan St. Furn El Chebak, 622 Lebanon Prepared by DONGGUAN EMTEK CO., LTD. No.281, Guantai Road, Nancheng District, Dongguan, Guangdong, China TEL: 86-769-22807078 FAX: 86-769-22807079 TRF No. FCC Part 15.247/A Page 2 of 44 Report No. KAD140627152E Ver.1.0 VERIFICATION OF COMPLIANCE Applicant: Band Industries Inc. Jalgha Bldg. Rachdan St. Furn El Chebak, 622 Lebanon Manufacturer: Wing For Electronic Co., No. 9, He Dong Yi Ru, Jin Xia, Chang an, Dongguan City, China. Product Description: Roadie Brand Name: roadie Model Number: RD100 File Number: KAD140627152E Date of Test: June 27, 2014 to July 24, 2014 We hereby certify that: The above equipment was tested by DONGGUAN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2009) and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2013). The test results of this report relate only to the tested sample identified in this report. Approved By Sam.Lv / Q.A. Manager DONGGUAN EMTEK CO., LTD. TRF No. FCC Part 15.247/A Page 3 of 44 Report No. KAD140627152E Ver.1.0 Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / KAD140627152E TRF No. FCC Part 15.247/A Page 4 of 44 Report No. KAD140627152E Ver.1.0 Table of Contents 1. GENERAL INFORMATION ................................................................................................... 6 1.1 PRODUCT DESCRIPTION............................................................................................................... 6 1.2 TEST METHODOLOGY .................................................................................................................. 7 1.3 SPECIAL ACCESSORIES ................................................................................................................ 7 1.4 EQUIPMENT MODIFICATIONS ........................................................................................................ 7 1.5 TEST FACILITY ............................................................................................................................. 7 2. SYSTEM TEST CONFIGURATION ..................................................................................... 8 2.1 EUT CONFIGURATION .................................................................................................................. 8 2.2 EUT EXERCISE ............................................................................................................................ 8 2.3 TEST PROCEDURE ....................................................................................................................... 8 2.4 CONFIGURATION OF TESTED SYSTEM .......................................................................................... 9 3. DESCRIPTION OF TEST MODES..................................................................................... 10 4. CONDUCTED EMISSIONS TEST ..................................................................................... 11 4.1 MEASUREMENT PROCEDURE: .................................................................................................... 11 4.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................... 11 4.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 11 4.4 CONDUCTED EMISSION LIMIT ...................................................................................................... 11 4.5 MEASUREMENT RESULT: ............................................................................................................ 11 4.6 CONDUCTED MEASUREMENT PHOTOS: ....................................................................................... 14 5. RADIATED EMISSION TEST ............................................................................................. 15 5.1 MEASUREMENT PROCEDURE ..................................................................................................... 15 5.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................... 16 5.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 17 5.4 RADIATED EMISSION LIMIT .......................................................................................................... 18 5.5 MEASUREMENT RESULT ............................................................................................................... 19 5.6 RADIATED MEASUREMENT PHOTOS: .............................................................................................. 25 6. 6DB BANDWIDTH MEASUREMENT ............................................................................... 26 6.1 MEASUREMENT PROCEDURE ..................................................................................................... 26 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................... 26 6.3 MEASUREMENT EQUIPMENT USED: ............................................................................................ 26 6.4 LIMIT .......................................................................................................................................... 26 6.5 MEASUREMENT RESULTS: .......................................................................................................... 27 7. MAX IMUM PEAK OUTPUT PO…

Text truncated - open the document above for the full version.
