2ACLKPS-M0095Wireless mouse

3. Now you can use it and enjoy it. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

2015-04-15 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ACLKPS-M0095_ Product Name: Wireless mouse Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Name Mei Tang Position Product Specialist Company Name Manger Address Room702,ZhangShubu Business Bldg,NO 78 BuSha Road,NanWan ,LongGang，Shenzhen ,China Tel 0755-28245892 Fax 0755-28245892 Email [email protected]

2015-04-15 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Alpha Product Testing Laboratory, Address: Building B, East Area of Nanchang Second, Industrial Zone, Gushu 2nd Road, Bao'an, Shenzhen, China Person: Mark Zhu (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. FCC ID: 2ACLKPS- M0095 For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with Shenzhen Sicily Technology Co.,Ltd Address: Room702,ZhangShubu Business Bldg,NO 78 BuSha Road,NanWan ,LongGang，Shenzhen ,China ( applicant name and address). Signature: Name Mei Tang Position Product Specialist Company Name Manger Address Room702,ZhangShubu Business Bldg,NO 78 BuSha Road,NanWan ,LongGang，Shenzhen ,China Tel 0755-28245892 Fax 0755-28245892 Email [email protected]

30mm 20mm FCC ID: 2ACLKPS-M0095 Shenzhen Sicily Technology Co.,Ltd Model name: Wireless mouse Model No.: PS-M0095 Label Location

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 86.87 dBuV/m @3m Ant gain -1 dBi; so Ant numeric gain=0.794 So pt={[10 (86.87/20) /10 6 x3] 2 /30x0.794 }x1000 mW =0.184 mW So ( 0.184 mW/5mm)x √2.409 GHz = 0.053 <3 Then SAR evaluation is not required

Page 1 of 28 Report No.: T1850250 01 TEST REPORT FCC ID: 2ACLKPS-M0095 Applicant : Shenzhen Sicily Technology Co.,Ltd Address : Room702,ZhangShubu Business Bldg,NO 78 BuSha Road,NanWan ,LongGangˈ ˈShenzhen ,China Equipment Under Test (EUT): Name : Wireless mouse Model : PS-M0095 In Accordance with: FCC PART 15, SUBPART C : 2014 (Section 15.249) Report No : T1850250 01 Date of Test : March 30, 2015 to April 15, 2015 Date of Issue : April 15, 2015 Test Result : PA S S In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Alpha Product Testing Co., Ltd Or test done by Shenzhen Alpha Product Testing Co., Ltd Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Alpha Product Testing Co., Ltd Approvals in writing . Page 2 of 28 Report No.: T1850250 01 TABLE OF CONTENT 1 General Information ------------------------------------------------------------------------------------ 3 1.1 Description of Device (EUT) --------------------------------------------------------------------- 3 1.2 Description of Test Facility ----------------------------------------------------------------------- 4 2 EMC Equipment List ------------------------------------------------------------------------------------ 4 3 Test Procedure ------------------------------------------------------------------------------------------- 5 4 Summary of Measurement ---------------------------------------------------------------------------- 6 4.1 Summary of test result ---------------------------------------------------------------------------- 6 4.2 Test connection ------------------------------------------------------------------------------------- 6 4.3 Assistant equipment used for test ---------------------------------------------------------------- 6 4.4 Test mode ------------------------------------------------------------------------------------------- 6 4.5 Test Conditions ------------------------------------------------------------------------------------- 7 4.6 Measurement Uncertainty (95% confidence levels, k=2)------------------------------------- 7 5 Spurious Emission ----------------------------------------------------------------------------------- 8 5.1 Radiation Emission -------------------------------------------------------------------------------- 8 5.1.1 Radiation Emission Limits(15.209) ------------------------------------------------------------- 8 5.1.2 Test Setup ------------------------------------------------------------------------------------------- 8 5.1.3 Test Procedure ------------------------------------------------------------------------------------ 10 5.1.4 Test Equipment Setting For emission test Result. ------------------------------------------- 10 5.1.5 Test Condition ------------------------------------------------------------------------------------ 10 5.1.6 Test Result ---------------------------------------------------------------------------------------- 10 6 POWER LINE CONDUCTED EMISSION ------------------------------------------------------- 16 6.1 Conducted Emission Limits(15.207) ---------------------------------------------------------- 16 6.2 Test Setup ----------------------------------------------------------------------------------------- 16 6.3 Test Procedure ------------------------------------------------------------------------------------ 17 6.4 Test Results --------------------------------------------------------------------------------------- 17 7 Bandwidth ---------------------------------------------------------------------------------------------- 18 7.1 Test limit ------------------------------------------------------------------------------------------ 18 7.2 Method of measurement ------------------------------------------------------------------------ 18 7.3 Test Setup ----------------------------------------------------------------------------------------- 18 7.4 Test Results --------------------------------------------------------------------------------------- 18 8 Antenna Requirement ------------------------------------------------------------------------------ 21 8.1 Standard Requirement --------------------------------------------------------------------------- 21 8.2 Antenna Connected Construction -------------------------------------------------------------- 21 8.3 Result ---------------------------------------------------------------------------------------------- 21 9 Photographs of Test Setup ----------------------------------------------------------------------- 22 4.7 Photos of Radiated emission ------------------------------------------------------------------- 22 10 Photographs of EUT--------------------------------------------------------------------------------- 23 Page 3 of 28 Report No.: T1850250 01 1 General Information 1.1 Description of Device (EUT) EUT : Wireless mouse Model No. : PS-M0095 DIFF N/A Trade mark : N/A Power supply : DC 3V from battery, 2*1.5V AAA battery Radio Technology : MSK Operation frequency : 2409-2476MHz Channel No. 8 Channels Modulation : MSK Antenna Type : Reversed Dipole Antenna, max gain -1dBi. Applicant : Shenzhen Sicily Technology Co.,Ltd Address : Room702,ZhangShubu Business Bldg,NO 78 BuSha Road,NanWan ,LongGang ˈShenzhen ,China Manufacturer : Shenzhen Sicily Technology Co.,Ltd Address : Room702,ZhangShubu Business Bldg,NO 78 BuSha Road,NanWan ,LongGangˈShenzhen ,China Page 4 of 28 Report No.: T1850250 01 1.2 Description of Test Facility Shenzhen Alpha Product Testing Co., Ltd Building B, East Area of Nanchang Second, Industrial Zone, Gushu 2nd…
