2ACM3TCB723smartphone

1 User Manual Contents Let’s get started Getting to know your phone Key definitions Screen control Open and switch applications Home Screen Switch to sleep mode Wake up your phone Make and answer calls Make a call Answer a call Reject a call End a call Adjust the volume Turn the speaker on or off 2 Add one call Open the dialing keypad Contacts Add new contact Delete contacts Edit contact details Search contacts Add a contact to Favorites Create a group of contacts Accounts Import/Export contacts Share a contact Messaging Send messages Receive messages Message thread Settings Email 3 Set up Email account Send Emails Check Emails Gmail Set up an Gmail account for the first time Send Gmails Replying to or forwarding email messages in Gmail Network Applications Network connection Browser Settings Airplane mode Device Accounts and sync Language Date & time About phone 4 Experiencing Multimedia Camera Music Player Videos Player Gallery Sound Recorder FM radio More Applications File manager Clock Calculator Calendar Downloads Maps Navigation Manage applications Install new applications Uninstall applications 5 Let’s get started Thanks for choosing the V765M. It’s a WCDMA Digital Mobile Phone, which we’ll simply call ‘phone’ from now on. Powered by Android TM , the phone supports 3G high-speed internet access, which brings you brand new experiences. To ensure proper phone operation and longevity, please read this guide carefully. And don’t worry if the pictures we use to demonstrate your phone’s functions look a little different from what you see on its screen. It’s the functions they show that matter. This user manual is to introduce the phone’s functions. For detailed precautions, installation descriptions, authentication information, please refer to the Quick Start Guide. Back to top 6 Getting to know your phone Key definitions Menu key Touch it to open a menu with items that affect the current screen or application. Home key Touch it to open the home screen. If you’re viewing the left or right extended home screen, Press it to open the central home screen. Back key Touch it to open the previous screen you were working in. If the onscreen keyboard is open, touch it to close the keyboard. Power key Press it to turn on/off the display. Long press it to open a menu with options for Airplane mode, for Silent mode, for Vibration mode, and for powering off and for rebooting the phone. Volume keys Adjust the volume. Long press it to quickly adjust the ring tone volume to maximum or minimum. Back to top 7 Screen control You can control your phone through a series of operations on the screen. - Touch: You can touch the items on the screen to select, to open the applications or to use the keyboard to input characters. - Swipe or slide: Quickly move your finger across the surface of the screen, without pausing when you first touch (so you don't drag something instead). - Touch & hold: You can touch & hold some items to get the item’s available menu. - Drag: You can drag some items on the screen to realize some operations. - Switch between landscape mode and portrait mode: You can switch to the landscape mode by rotating your phone. The landscape mode is only valid under some interfaces, such as the text input interface, the message viewing interface, etc. - Pinch: In some apps (such as Maps and Gallery), you can zoom in and out by placing two fingers on the screen at once and pinching them together (to zoom out) or spreading them apart (to zoom in). Back to top Open and switch applications Open and close the All Apps screen On the home screen, touch the icon to open the All Apps screen. You can slide the All Apps screen left or right to view more applications. After opening the All Apps screen, touch an icon to enter the corresponding application. Touch the Back key to return to the previous screen. Touch the Home key to return to the home screen. Switch to a recently used application 8 On the home screen, touch & hold the Home key, opens a list of thumbnail images of apps you've worked with recently. To open an app, touch it. To remove a thumbnail from the list, swipe it left or right. Back to top Home Screen Arrange & work with apps From All Apps, you can: - Explore your widgets: Touch the widgets tab at the top of any All Apps screen. - Get more apps: Touch the Play Store icon at the top of any All Apps screen. Manage notifications - Open notifications panel: When a new notification appears on the notification bar, you can drag the notification bar down from the top of the screen to open notifications panel when your phone has been in idle mode or lock the screen. - Respond to a notification: Touch it. - Dismiss a notification: Swipe it sideways. - Close notifications panel: Drag the tab at the bottom of the notification panel to the top of the screen. Display area The home screen can be extended to exceed the screen’s width in order to provide more space for newly added shortcuts, widgets, etc. On the home screen, slide your finger on the screen to extend to the left or right. Place an app icon on a Home screen Touch & hold the app icon, slide your finger, and lift your finger to drop the icon in place. Delete items on the homepage 9 Touch & hold the app icon, slide your finger toward the top of the screen, and drop the app over the Remove icon. Use folders You can combine several app icons in a folder. Drop one app icon over another on a Home screen, and the two icons will be combined. From any Home screen, you can - Open a folder: Touch it. The folder opens: - Rename a folder: Touch its name. - Move icons around your Home screens: Touch, hold and slide. Favorites tray The app icons you keep in the favorites tray remain visible on every Home screen. - Place an app icon in the Favorites tray: Touch, hold, & slide to move one of the Favorites icons out of the tray. Then use the same technique to move another one into the same position. The All Apps icon in the center is permanent, you can't move it. …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 Networking Group SAS Tr. 19A No. 98-28 Of. 204, Bogota, Colombia 2014-6-23 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Networking Group SAS hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2ACM3TCB723 Model:Live Era, TCB-723 Product:Smartphone Sincerely, signature : name / title: ROSSANA PALACIOS RODRIGUEZ / General Manger address: Tr. 19A No. 98-28 Of. 204, Bogota, Colombia SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0 Networking Group SAS Tr. 19A No. 98-28 Of. 204, Bogota, Colombia 2014-6-23 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Networking Group SAS hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): FCC ID: 2ACM3TCB723 Model:LIVE ERA, TCB-723 Product: smartphone We affirm that between SIEMIC, Inc. and Networking Group SAS , any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, signature : name / title: ROSSANA PALACIOS RODRIGUEZ / General Manger address: Tr. 19A No. 98-28 Of. 204, Bogota, Colombia

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 NETWORKING GROUP SAS Tr. 19A No. 98-28 Of. 204, Bogota, Colombia 2014-6-23 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACM3TCB723 We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description BOM Tune up Procedurer The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: ROSSANA PALACIOS RODRIGUEZ / General Manger address: Tr. 19A No. 98-28 Of. 204, Bogota, Colombia

Networking Group SAS Tr. 19A No. 98-28 Of. 204, Bogota, Colombia FCC ID: 2ACM3TCB723 To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC FCC DOC is applying and FCC DOC approval will be got prior to marketing the device Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Sincerely, signature : name / title: ROSSANA PALACIOS RODRIGUEZ / General Manger address: Tr. 19A No. 98-28 Of. 204, Bogota, Colombia

Networking Group SAS Tr. 19A No. 98-28 Of. 204, Bogota, Colombia Jul 11, 2014 To: FCC From: Networking Group SAS RE: Supersede request for FCC ID: 2ACM3TCB723 , granted on Jul. 11 2014. Request for supersede of RFTest report , SAR report , Family Letter . Grantee has requested to add trade name from the original test report. Sincerely, signature : name / title: ROSSANA PALACIOS RODRIGUEZ / General Manger address: Tr. 19A No. 98-28 Of. 204, Bogota, Colombia

Updated on 2005/02/07 by Kally Chan DECLARATION OF IDENTITY FCC ID：2ACM3TCB723 Hereby we: Networking Group SAS (Name of Manufacturer) Basic Model Number: TCB-723 Basic Brand Name: NWG Basic Product Name: Smartphone Declare the Circuit, PCB Layout, shape of enclosure and Electrical Parts of the following product(s) are identical to the basic model: New / Additional Model Number(s): Live Era New / Additional Brand Name(s): / Except the following(s) : Model numbers，outlook color Signature with Company Chop : Printed Name : ROSSANA PALACIOS RODRIGUEZ DATE:2014-06-28

Label location Smartphone Model: Live Era FCC ID: 2ACM3TCB723

GSM Antenna

SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 1 / 106 FCC SAR EVALUATION REPORT For Networking Group SAS Tr. 19A No. 98-28 Of. 204, Bogota, Colombia Product Name: Smartphone Model No. : Live Era, TCB-723 Date of Receipt: 24 th June. 2014 Date of Test: 26 th ~28 th June. 2014 Issued Date: 28 th June. 2014 Report No.:TS201406020 Report Version:V1.0 Issue By Shenzhen Sunway Communication CO.,LTD Testing Center 1/F,BuildingA，SDG Info Port, KefengRoad，Hi-Tech Park, Nanshan District, Shenzhen , Guangdong, China 518104, Note: The test results relate only to the samples tested. This report shall not be reproduced in full, without the written approval of SUNWAY Testing Center. SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 2 / 106 SAR Evaluation compliance Product Name: Smartphone Brand Name: NWG Model Name: Live Era, TCB-723 Applicant: Networking Group SAS Address: Tr. 19A No. 98-28 Of. 204, Bogota, Colombia Manufacturer: Tecomax Electronics Technology Co., Ltd Address: Units 2202-2203, 22/F, Changxing Building, Futian , Shenzhen, Guangdong 518000, China. Applicable Standard: IEEE Std. 1528-2013,FCC 47 CFR§2.1093 KDB 865664 D01 SAR measurement 100 MHz to 6 GHz v01r03 KDB 447498 D01 General RF Exposure Guidance v05r02 Test Result: Max. SAR Report: Body (1g): 1.205W/kg Head(1g): 1.353W/kg Performed Date: 26 th ~28 th June. 2014 Test Engineer: 28 th June. 2014 Reviewed By 28 th June. 2014 Performed Location: Shenzhen Sunway Communication CO.,LTD Testing Center 1/F,BuildingA，SDG Info Port, KefengRoad，Hi-Tech Park, Nanshan District,Shenzhen , Guangdong, China 518104 Tel: +86-755- 36615880 Fax: +86-755- 86525532 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 3 / 106 TABLE OF CONTENS 1. General Information: .......................................................................................................... 4 2. SAR Measurement System: ............................................................................................... 7 3. System Components:......................................................................................................... 8 4. Tissue Simulating Liquid ................................................................................................. 10 5. SAR System Validation .................................................................................................... 12 6. SAR Evaluation Procedures: ........................................................................................... 14 7. SAR Exposure Limits ....................................................................................................... 15 8. Measurement Uncertainty:............................................................................................... 16 9. Conducted Power Measurement: .................................................................................... 18 10. Test photos and results: ................................................................................................ 21 11. Equipment List:............................................................................................................... 30 Appendix A. System validation plots:................................................................................. 31 Appendix D. DAE Calibration Data:..................................................................................... 85 Appendix E. Dipole Calibration Data: ................................................................................. 90 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 4 / 106 1. General Information: 1.1 EUT Description: EUT Information Product Name Smartphone Brand Name NWG Model Name Live Era, TCB-723 Device Category MobilePhone Antenna Type Integral Antenna Headset / Battery T ype: Rechargeable lithium-ion battery 3.7V Dimensions (L*W*H): 145mm (L)× 75mm (W)×10mm (H) Weight: - Power Source: Rechargeable lithium-ion battery 3.7V Normal Operation: Head & Body GSM-2G Support Band GSM850/PCS1900 GPRS Type GPRS850/GPRS1900 GPRS Class 12 Frequency Bands: GSM 850: UL: 824-850 MHz DL: 869-894 MHz PCS 1900: UL: 1850-1910 MHz DL: 1930-1990 MHz Release Version R99 Type of modulation GMSK for GSM Antenna locations GSM antenna is located on the top of the mobile phone (page 22) Antenna Gain 1.5dBi SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 5 / 106 Note: the device can't support DTM/Hotspot mode WCDMA-3G Support Band WCDMA Band II Frequency Bands: WCDMA Band II: UL: 1850 ~ 1910MHz DL: 1930 ~ 1988MHz Release Version Rel-5 Type of modulation QPSK Antenna Gain 1.5dBi Max. Output Power (Conducted) GSM850: 32.30 dBm PCS1900: 29.30 dBm WCDMA Band II 24.50 dBm SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 6 / 106 1.2 Test Environment: Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 21~23 Humidity (%RH) 30-70 50~65 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 7 / 106 2. SAR Measurement System: 2.1 Dasy4 System Description: The DASY4 system for performing compliance tests consists of the following items: ¾ A standard high precision 6-axis robot with controller, teach pendant and software. An arm extension for accommodating the data acquisition electronics (DAE). ¾ A dosimetric probe, i.e., an isotropic E-field probe optimized and calibrated for usage in tissue simulating liquid. The probe is equipped with an optical surface detector system. ¾ A data acquisition electronics (DAE) which performs the signal amplification, signal multiplexing, AD-conversion, offset measurements, mechanical surface detection, collision detection, etc. ¾ The Electro-optical converter (EOC) performs the conversion between optical and electrical of the signals for the digital communication to the DAE and for the analog signal from the optical surface detection. ¾ A probe alignment unit which improves the (absolute) accuracy of the probe positioning. ¾ A computer …

Text truncated - open the document above for the full version.

SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 82 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 83 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 84 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 85 / 106 Appendix D. DAE Calibration Data: SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 86 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 87 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 88 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 89 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 90 / 106 Appendix E. Dipole Calibration Data: SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 91 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 92 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 93 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 94 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 95 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 96 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 97 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 98 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 99 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 100 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 101 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 102 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 103 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 104 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 105 / 106 SHENZHEN SUNWAY COMMUNICATION CO.,LTD Report NO.: TS201406020 Page 106 / 106 *****END OF REPORT*****

FCC ID: 2ACM3TCB723 Keyway Testing Technology Co., Ltd. Report No. 14KWE061251R Page 1 of 45 FCC TEST REPORT(Mobile Phone) for Networking Group SAS Smartphone Model Number: Live Era, TCB-723 FCC ID: 2ACM3TCB723 Prepared for : Networking Group SAS Address : Tr. 19A No. 98-28 Of. 204, Bogota, Colombia Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 14KWE061251R Date of Test : Jun. 19~25, 2014 Date of Report : Jun. 25, 2014 FCC ID: 2ACM3TCB723 Keyway Testing Technology Co., Ltd. Report No. 14KWE061251R Page 2 of 45 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .......................................................................................................................... 4 2. GENERAL PRODUCT INFORMATION......................................................................................... 5 2.1. Product Function.................................................................................................................... 5 2.2. Description of Device (EUT) .................................................................................................. 5 2.3. Difference between Model Numbers...................................................................................... 5 2.4. Test Supporting System......................................................................................................... 5 2.5. Independent Operation Modes .............................................................................................. 6 3. TEST SITES .................................................................................................................................. 7 3.1. Test Facilities ......................................................................................................................... 7 3.2. List of Test and Measurement Instruments............................................................................ 8 4. TEST SET-UP AND OPERATION MODES .................................................................................. 9 4.1. Principle of Configuration Selection .......................................................................................9 4.2. Block Diagram of Test Set-up ................................................................................................ 9 4.3. Test Operation Mode and Test Software ............................................................................... 9 4.4. Special Accessories and Auxiliary Equipment ....................................................................... 9 4.5. Countermeasures to Achieve EMC Compliance.................................................................... 9 5. EMISSION TEST RESULTS .......................................................................................................10 5.1. Conducted RF Output Power............................................................................................... 10 5.2. 99% & -26 dB Occupied Bandwidth..................................................................................... 12 5.3. Frequency Stability .............................................................................................................. 18 5.4. Conducted Out of Band Emissions ...................................................................................... 21 5.5. Conducted Out of Band Emissions ...................................................................................... 27 5.6. Transmitter Radiated Power (EIRP/ERP) .............................................................................. 29 5.7. Radiated Out of Band Emissions ........................................................................................... 36 5.8. Conducted Emission at the Mains Terminals Test............................................................... 41 6. PHOTOGRAPHS OF TEST SET-UP .......................................................................................... 44 7. PHOTOGRAPHS OF THE EUT .................................................................................................. 45 FCC ID: 2ACM3TCB723 Keyway Testing Technology Co., Ltd. Report No. 14KWE061251R Page 3 of 45 Keyway Testing Technology Co., Ltd. Applicant: Address: Networking Group SAS Tr. 19A No. 98-28 Of. 204, Bogota, Colombia Manufacturer: Address: Tecomax Electronics Technology Co., Ltd Units 2202-2203, 22/F, Changxing Building, Futian , Shenzhen, Guangdong 518000, China. E.U.T: Smartphone Model Number: Live Era, TCB-723 Trade Name: NWG Serial No.: ------ Date of Receipt: Jun. 19, 2014 Date of Test: Jun. 19~25, 2014 Test Specification: FCC CFR Title 47 Part 2: 2013 FCC CFR Title 47 Part22 Subpart H: 2013 FCC CFR Title 47 Part24 Subpart E: 2013 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Jun. 25, 2014 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: 2ACM3TCB723 Keyway Testing Technology Co., Ltd. Report No. 14KWE061251R Page 4 of 45 1. TEST SUMMARY Test Items Test Requirement Result RF Exposure (SAR) Part 1.1307 Part 2.1093 Passed* (Please refer to SAR Report) Conducted RF Output Power 2.1046 PASS 99% & -26 dB Occupied Bandwidth 2.1049, 22.917 24.238, PASS Frequency Stability 2.1055, 22.355 24.235, PASS Conducted Out of Band Emissions 2.1051,2.1057 22.917, 24.238 PASS Band Edge 2.1051,2.1057 22.917, 24.238 PASS Transmitter Radiated Power (EIPR/ERP) 22.913, 24.232 PASS Radiated Out of Band Emissions 2.1053,2.1057 22.917, 24.238 PASS Con…

Text truncated - open the document above for the full version.

Conducted Emission Radiated Emission
