2ACPA97186MINI-CUBE WIRELESS SPEAKER BLUE

Federal Communications Commission (FCC) Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient or relocate the receiving antenna. z Increase the separation between the equipment and receiver. z Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. z Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications made to this device not expressly approved by PAYA TOYS INTERNATIONAL LIMITED may void the FCC authorization to operate this device. Note: The manufacturer is not responsible for any radio or tv interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.

PAYA TOYS INTERNATIONAL LIMITED 2-3/F, Chang An Business Building, Xinxi Section, JinHong Highroad, Shantou City, Guangdong Province, China TEL: +86-754-86204818 FAX: +86-754-85769308 AGENCY AUTHORIZATION LETTER FCC ID: 2ACPA97186 Date: July 2, 2014 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: We, the undersigned, hereby authorize Shenzhen CTL Testing Technology Co., Ltd.(MR. Tracy Qi) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen CTL Testing Technology Co., Ltd. (MR. Tracy Qi) on our behalf shall have the same effect as acts of our own. This authorization expires on July 1, 2015. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, PAYA TOYS INTERNATIONAL LIMITED are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, ___ Selina /Manager

PAYA TOYS INTERNATIONAL LIMITED 2-3/F, Changan Business Building, Xinxi Section, JinHong Highroad, Shantou City, Guangdong Province, China TEL: +86-754-86204818 FAX: +86-754-85765308 USB Port Statement FCC ID: 2ACPA97186 Date: July 01, 2014 To whom it may concern: We, the undersigned, state that the device's (Model: 97186 ) USB port only used for charge, no any data transfer to PC. Sincerely, __ Selina /Manager

FCC ID Label Information 1. Label location: 2. FCC ID Label: Mini-Cube Wireless Speaker blue Model: 97186 FCC ID: 2ACPA97186

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 Fax: +86-755-26636041 FCC PART 15 SUBPART C TEST REPORT FCC Part 15.249 Report Reference No......................: CTL1406241435-WF Compiled by ( position+printed name+signature)..: File administrators Jacky Chen Name of the organization performing the tests ( position+printed name+signature)..: Test Engineer Tracy Qi Approved by ( position+printed name+signature)..: Manager Tracy Qi Date of issue.....................................: Sept. 29, 2014 Test Firm..........................................: Shenzhen CTL Testing Technology Co., Ltd. Address.............................................: Floor 1-A, Baisha Technology Park, No. 3011, Shahexi Road, Nanshan, Shenzhen 518055 China. Applicant’s name............................: PAYA TOYS INTERNATIONAL LIMITED Address.............................................: 2-3/F, Changan Business Building, Xinxi Section, JinHong Highroad, Shantou City, Guangdong Province, China Test specification: Standard ...........................................: FCC Part 15.249: Operation within the bands 920-928 MHz, 2400- 2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. TRF Originator ..................................: Shenzhen CTL Testing Technology Co., Ltd. Master TRF.......................................: Dated 2011-01 Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Mini-Cube Wireless Speaker blue Trade Mark .......................................: N/A Models/Type reference.....................: 97186 Modulation .......................................: FHSS Work Frequency...........................: 2402 MHz~2480 MHz Antenna Type..............................: internal FCC ID .............................................: 2ACPA97186 Result................................................: Positive V1.0 Page 2 of 34 Report No.: CTL1406241435-WF T E S T R E P O R T Test Report No. : CTL1406241435-WF Sept. 29, 2014 ______________________________________________________________________________________________ Date of issue Equipment under Test : Mini-Cube Wireless Speaker blue Model /Type : 97186 Applicant : PAYA TOYS INTERNATIONAL LIMITED Address : 2-3/F, Changan Business Building, Xinxi Section, JinHong Highroad, Shantou City, Guangdong Province, China Manufacturer Shenzhenshi Junengtong Electronics Co., Ltd Address 6/F, Building 5, Xifa Industrial Area A, Xixiang Yintian Industrial, Bao'an District, Shenzhen, Guangdong, China Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. V1.0 Page 3 of 34 Report No.: CTL1406241435-WF Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 6 2.5. EUT configuration 6 2.6. Related Submittal(s) / Grant (s) 6 2.7. Modifications 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 7 3.4. Configuration of Tested System 7 3.5. Statement of the measurement uncertainty 8 3.6. Equipments Used during the Test 9 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 14 4.3. Band Edge Measurement 19 4.4. Occupied Bandwidth Measurement 24 5. ANTENNA REQUIREMENT ....................................................... 26 6. TEST SETUP PHOTOS OF THE EUT .......................................... 27 7. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 30 V1.0 Page 4 of 34 Report No.: CTL1406241435-WF 1. TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.249: Operation within the bands 902 - 928 MHz, 2400 - 2483.5 MHz, 5725 - 5875 MHz, and 24.0 - 24.25 GHz. ANSI C63.4-2009 V1.0 Page 5 of 34 Report No.: CTL1406241435-WF 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Sept. 17, 2014 Testing commenced on : Sept. 17, 2014 Testing concluded on : Sept. 26, 2014 2.2. Equipment Under Test Power supply system utilised Power supply voltage : o 120V / 60 Hz o 115V / 60Hz o 12 V DC o 24 V DC ● Other (specified in blank below) DC 3.7V from battery 2.3. Short description of the Equipment under Test (EUT) The EUT is a Mini-Cube Wireless Speaker blue work at 2402~2480 MHz. Channel List: Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 00 2402 27 2429 54 2456 01 2403 28 2430 55 2457 02 2404 29 2431 56 2458 03 2405 30 2432 57 2459 04 2406 31 2433 58 2460 05 2407 32 2434 59 2461 06 2408 33 2435 60 2462 07 2409 34 2436 61 2463 08 2410 35 2437 62 2464 09 2411 36 2438 63 2465 10 2412 37 2439 64 2466 11 2413 38 2440 65 2467 12 2414 39 2441 66 2468 13 2415 40 2442 67 2469 14 2416 41 2443 68 2470 15 2417 42 2444 69 2471 16 2418 43 2445 70 2472 17 2419 44 2446 71 2473 18 2420 45 2447 72 2474 19 2421 46 2448 73 2475 20 2422 47 2449 74 2476 21 2423 48 2450 75 2477 22 2424 49 2451 76 2478 23 2425 50 2452 77 2479 24 2426 51 2453 78 2480 25 2427 52 2454 26 2428 53 2455 Modulation: 1Mbps(GFSK), 2Mbps(Pi/4 DQPSK), 3Mbps(8DPSK) For more details, refer to the user’s manual of the EUT. Serial number: Prototyp…
