2ACPR-W4301smartphone

0 smartphone W4301 User’s Guide 1 1 THE BASICS ............................................................. 3 1.1 OVERVIEW ............................................................. 3 1.2 SAFETY GUIDE ....................................................... 4 1.3 SAFETY WARNINGS AND NOTICES ........................ 6 1.3.1 General attention ................................................ 6 1.3.2 Notices when using your phone .......................... 7 1.3.3 Notices when using the battery ......................... 10 1.3.4 Charging your phone ........................................ 12 1.3.5 Cleaning and maintenance ............................... 16 2 GETTING STARTED ................................................... 17 2.1 COMPONENT NAME AND EXPLANATION.................. 17 2.1.1 Technical parameters ................................. 17 2.1.2 Icons ............................................................. 17 2.2 KEY EXPLANATIONS ............................................. 19 2.3 USING THE TOUCHSCREEN ................................. 21 2.4 CONNECTING TO THE NETWORK......................... 21 2.4.1 Inserting and removing the SIM card ................ 21 2.4.2 Turning your phone on and off .......................... 22 2.4.3 Unlocking the SIM card .................................... 23 2.4.4 Unlocking your phone ....................................... 24 2.4.5 Connecting to the network ................................ 24 2.4.6 Making a call .................................................... 25 2.4.7 Making a domestic call ..................................... 25 2 2.4.8 Making an international call ............................ 26 2.4.9 Making a call from the list ................................ 26 2.4.10 Making an emergency call .............................. 27 2.4.11 Call menu ........................................................ 27 3 FUNCTIONAL MENU ................................................. 29 3.1 FILE MANAGEMENT ............................................ 29 3.2 SENDING AN EMAIL ............................................. 30 3.3 DIALING ............................................................... 31 3.4 3G VIDEO CALL ................................................... 32 3.5 CALCULATOR ...................................................... 33 3.6 BROWSER............................................................ 34 3.7 VOICE RECORDER .............................................. 36 3.8 CALENDAR .......................................................... 37 3.9 SETTINGS ............................................................ 39 3.10 CLOCK ............................................................... 41 3.11 RADIO ................................................................ 42 3.12 GOOGLE SEARCH ............................................. 44 3.13 CONTACTS ........................................................ 45 3.14 GALLERY ........................................................... 47 3.15 CAMERA ............................................................ 48 3.16 MESSAGING ...................................................... 49 3.17 NOTIFICATION MENU ........................................ 51 3.18 DOWNLOAD CONTENT ...................................... 52 3 3.19 MUSIC ................................................................ 53 3.20 CALL RECORDS ................................................ 54 3.21 WIDGET ............................................................. 55 3.22 SELECTING WALLPAPER SOURCE ................... 56 3.23 LOCAL SEARCH ................................................. 57 3.24 MAP ................................................................... 58 3.25 NAVIGATION ...................................................... 59 3.26 VOICE SEARCH ................................................. 61 3.27 VIEW PALYER .................................................... 62 4. TEXT INPUT ......................................................... 63 5 SD CARD INTRODUCTION ................................. 66 6 FAQS AND SOLUTIONS ...................................... 70 1 The Basics 1.1 Overview Thank you for choosing the GSM/GPRS digital mobile phone. After reading this guide you will be able to fully master the use of your phone and appreciate all its functions and ease of use. Not only does the smartphone provide you with 4 basic call functions such as call Register, but also with many practical functions and services, to improve the time you spend working and playing. The c olor s creen m obile p hone c omplies wi th t he GSM/GPRS tec hnology a nd has b een a pproved by certification authorities both domestically and abroad. The availability of some services and features described in this manual depends on the network and your subscription. Therefore, some menu items may not be available in your phone. The shortcuts to menus and features may also vary from phone to phone. Our company reserves the right to revise this manual content without prior notice. 1.2 Safety guide  If your mobile phone is lost or stolen, please contact the telecommunications authorities or a sales agent immediately to have a hold on the phone and the SIM card. This will prevent economic loss caused by unauthorized calls made from your mobile phone.  When you contact the telecommunications authorities or a sales agent, they will need to 5 know the IMEI number of our mobile phone (remove battery to expose number located on the label on back of phone). Please copy this number and keep in a safe place for future use.  In order to avoid the misuse of your mobile phone please take the following preventative measures: - Set the PIN number of your mobile phone’s SIM card and change this number immediately if it becomes known to a third party. - Please keep the phone out of sight when leaving it in a vehicle. It is best to carry the phone with you, or lock it in the trunk. - Set call barring. 6 1.3 Safety warnings and notices Before using y…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenzhen Bmorn Technology Co., Ltd. 2015/08/18 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ___ Shenzhen Bmorn Technology Co., Ltd._ _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： smartphone Trade Name： N/A Model Name： W4301 Serial Model： N/A FCC ID： 2ACPR-W4301 Sincerely, Client’s name / title : Tang shaofeng / Manager Contact information / address : 5/F, Hengfang Veteran Industrial Park, Xingye Road, Xixiang, Bao'an, Shenzhen, China.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Shenzhen Bmorn Technology Co., Ltd. 2015/08/18 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACPR-W4301 We hereby request confidential treatment of information accompanying this application as outlined below: - . Block Diagram - Schematics - Operational Description - BOM - - tune up procedure - The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s name / title : Tang shaofeng / Manager Contact information / address : 5/F, Hengfang Veteran Industrial Park, Xingye Road, Xixiang, Bao'an, Shenzhen, China.

Shenzhen Bmorn Technology Co.,Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2015-08-18 SUBJECT: FCC Application for ( FCC ID: 2ACPR-W4301) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Client’s name / title : Tang shaofeng / Manager Contact information / address : 5/F, Hengfang Veteran Industrial Park, Xingye Road, Xixiang, Bao'an, Shenzhen, China.

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID LABELING AND LOCATION FCC ID Label smartphone Model NO.: W4301 FCC ID: 2ACPR-W4301 Shenzhen Bmorn Technology Co.,Ltd. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 WIFI/BT Ant 2G/3G Ant Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC RADIO TEST REPORT-BT FCC ID: 2ACPR-W4301 Product： smartphone Trade Name： N/A Model Name： W4301 Serial Model： N/A Report No.： NTEK-2015NT07172298F2 Prepared for Shenzhen Bmorn Technology Co.,Ltd. 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 69 Report No.:NTEK-2015NT07172298F2 TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Bmorn Technology Co.,Ltd. Address ................................. : 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Manufacture's Name ............ : Shenzhen Bmorn Technology Co.,Ltd. Address ................................. : 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Product description Product name ........................... : smartphone Model and/or type reference : W4301 Serial Model： N/A Standards ............................. : FCC Part15.247: 01 Oct. 2014 Test procedure .............................. ANSI C63.10-2013 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 16 Jul. 2015 ~11 Aug. 2015 Date of Issue ........................................... : 11 Aug. 2015 Test Result ............................................... : Pass Testing Engineer : (Jason Chen) Technical Manager : (Brown Lu) Authorized Signatory : (Sam Chen) Page 3 of 69 Report No.:NTEK-2015NT07172298F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 19 3.2.1 RADIATED EMISSION LIMITS 19 3.2.2 TEST PROCEDURE 20 3.2.3 DEVIATION FROM TEST STANDARD 20 3.2.4 TEST SETUP 21 3.2.5 EUT OPERATING CONDITIONS 22 3.2.6 TEST RESULTS (BELOW 30 MHZ) 23 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 24 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 26 4 . NUMBER OF HOPPING CHANNEL 27 4.1 APPLIED PROCEDURES / LIMIT 27 4.1.1 TEST PROCEDURE 27 4.1.2 DEVIATION FROM STANDARD 27 4.1.3 TEST SETUP 27 4.1.4 EUT OPERATION CONDITIONS 27 4.1.5 TEST RESULTS 28 5 . AVERAGE TIME OF OCCUPANCY 29 5.1 APPLIED PROCEDURES / LIMIT 29 Page 4 of 69 Report No.:NTEK-2015NT07172298F2 Table of Contents Page 5.1.1 TEST PROCEDURE 29 5.1.2 DEVIATION FROM STANDARD 29 5.1.3 TEST SETUP 30 5.1.4 EUT OPERATION CONDITIONS 30 5.1.5 TEST RESULTS 31 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 37 6.1 APPLIED PROCEDURES / LIMIT 37 6.1.1 TEST PROCEDURE 37 6.1.2 DEVIATION FROM STANDARD 37 6.1.3 TEST SETUP 37 6.1.4 EUT OPERATION CONDITIONS 37 6.1.5 TEST RESULTS 38 7 . BANDWIDTH TEST 44 7.1 APPLIED PROCEDURES / LIMIT 44 7.1.1 TEST PROCEDURE 44 7.1.2 DEVIATION FROM STANDARD 44 7.1.3 TEST SETUP 44 7.1.4 EUT OPERATION CONDITIONS 44 7.1.5 TEST RESULTS 45 8 . PEAK OUTPUT POWER TEST 51 8.1 APPLIED PROCEDURES / LIMIT 51 8.1.1 TEST PROCEDURE 51 8.1.2 DEVIATION FROM STANDARD 51 8.1.3 TEST SETUP 51 8.1.4 EUT OPERATION CONDITIONS 51 8.1.5 TEST RESULTS 52 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 58 9.1 DEVIATION FROM STANDARD 58 9.2 TEST SETUP 58 9.3 EUT OPERATION CONDITIONS 58 9.4 TEST RESULTS 59 10 . ANTENNA REQUIREMENT 67 10.1 STANDARD REQUIREMENT 67 10.2 EUT ANTENNA 67 11 . EUT TEST PHOTO 68 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 69 Report No.:NTEK-2015NT07172298F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 69 Report No.:NTEK-2015NT07172298F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 69 Report No.:NTEK-2015NT07172298F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment smartphone Trade Name N/A Model Name W4301 Serial Model N/A Model Diff…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
