TRF No.: FCC SAR/A Page 1 of 61 Report No.: ES150530365E Ver.1.0 Access to the World SAR TEST REPORT For Smartphone Model No.: W5302,W4301,W4302,W4303,W5303,W5305,W5306,W6301 W5402,W4401,W4402,W4403,W5403,W5404,W5405,W5406,W6401 FCC ID: 2ACPR-W5302 Trademark: BMORN REPORT NO.: ES150530365E ISSUE DATE: August 10, 2015 Prepared for Shenzhen Bmorn Technology Co.,Ltd 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.: FCC SAR/A Page 2 of 61 Report No.: ES150530365E Ver.1.0 Access to the World Table of Contents 1 TEST RESULT CERTIFICATION .......................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION ........................................................................................................................ 4 3 STATEMENT OF COMPLIANCE .......................................................................................................................... 6 4 AUXILIARY EQUIPMENT DETAILS ................................................................................................................... 6 5 TEST FACILITY ..................................................................................................................................................... 6 6 EUT ANTENNA LOCATIONS ............................................................................................................................... 7 7 GUIDANCE STANDARD ...................................................................................................................................... 8 8 RF EXPOSURE ....................................................................................................................................................... 9 8.1 LIMITS ......................................................................................................................................................... 9 8.2 EVALUATION ............................................................................................................................................. 9 8.3 SAR TESTING FOR TABLET .................................................................................................................. 10 8.4 MAXIMUM TUNE-UP LIMIT .................................................................................................................. 10 9 SPECIFIC ABSORPTION RATE (SAR) ............................................................................................................... 12 9.1 INTRODUCTION ...................................................................................................................................... 12 9.2 SAR DEFINITION ..................................................................................................................................... 12 10 SAR MEASUREMENTS SYSTEM CONFIGURATION ..................................................................................... 13 10.1 SAR MEASUREMENT SET-UP ............................................................................................................... 13 10.2 DASY5 E-FIELD PROBE SYSTEM ......................................................................................................... 14 10.3 E-FIELD PROBE CALIBRATION ............................................................................................................ 15 10.4 OTHER TEST EQUIPMENT ..................................................................................................................... 15 10.5 SCANNING PROCEDURE ....................................................................................................................... 18 10.6 DATA STORAGE AND EVALUATION .................................................................................................... 20 10.7 TISSUE-EQUIVALENT LIQUID .............................................................................................................. 22 10.8 SYSTEM CHECK ...................................................................................................................................... 24 11 MEASUREMENT PROCEDURES ....................................................................................................................... 32 11.1 GENERAL DESCRIPTION OF TEST PROCEDURES ............................................................................ 32 11.2 MEASUREMENT VARIABILITY ............................................................................................................ 35 11.3 TEST POSITIONS REQUIREMENTS ................................................................................................................. 35 11.4 TEST RESULTS ......................................................................................................................................... 39 GRAPH RESULTS ......................................................................................................................................................... 47 12 700MHZ TO 3GHZ MEASUREMENT UNCERTAINTY .................................................................................... 59 13 MAIN TEST INSTRUMENTS .............................................................................................................................. 61 TRF No.: FCC SAR/A Page 3 of 61 Report No.: ES150530365E Ver.1.0 Access to the World 1 TEST RESULT CERTIFICATION Applicant: Shenzhen Bmorn Technology Co.,Ltd 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Manufacturer: Shenzhen Bmorn Technology Co.,Ltd 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Product Description: Smartphone Model Number: W5302,W4301,W4302,W4303,W5303,W5305,W5306,W6301 …

Text truncated - open the document above for the full version.

TRF No.: FCC SAR/A Page 33 of 61 Report No.: ES150530365E Ver.1.0 Access to the World using the highest body SAR configuration in 12.2 kbps RMC without HSDPA. HSDPA should be configured according to the UE category of a test device.The number of HSDSCH/ HS-PDSCHs, HARQ processes, minimum inter-TTI interval, transport block sizes and RV coding sequence are defined by the H-set. To maintain a consistent test configuration and stable transmission conditions, QPSK is used in the H-set for SAR testing. HS-DPCCH should be configured with a CQI feedback cycle of 4 ms with a CQI repetition factor of 2 to maintain a constant rate of active CQI slots. DPCCH and DPDCH gain factors(βc, βd), and HS-DPCCH power offset parameters (∆ACK, ∆NACK, ∆CQI) should be set according to values indicated in the Table below. The CQI value is determined by the UE category, transport block size, number of HS-PDSCHs and modulation used in the H-set. Table 8: Subtests for UMTS Release 5 HSDPA Table 9: Settings of required H-Set 1 QPSK in HSDPA mode For the HSDPA Test configuration: Body SAR is also measured for HSPA when the maximum average output of each RF channel with HSPA TRF No.: FCC SAR/A Page 34 of 61 Report No.: ES150530365E Ver.1.0 Access to the World active is at least ¼ dB higher than that measured without HSPA using 12.2 kbps RMC or the maximum SAR for 12.2 kbps RMC is above 75% of the SAR limit. Body SAR for HSPA is measured with E-DCH Sub-test 5, using H-Set 1 and QPSK for FRC and a 12.2 kbps RMC configured in Test Loop Mode 1 with power control algorithm 2, according to the highest body SAR configuration in 12.2 kbps RMC without HSPA. Due to inner loop power control requirements in HSPA, a commercial communication test set should be used for the output power and SAR tests. The 12.2 kbps RMC, FRC H-set 1 and E- DCH configurations for HSPA should be configured according to the β values indicated below as well as other applicable procedures described in the ‘WCDMA Handset’ and ‘Release 5 HSDPA Data Devices’ sections of 3 G device. Table 10: Sub-Test 5 Setup for Release 6 HSUPA Table 11: HSUPA UE category TRF No.: FCC SAR/A Page 35 of 61 Report No.: ES150530365E Ver.1.0 Access to the World 11.2 MEASUREMENT VARIABILITY Per FCC KDB Publication 865664 D01, SAR measurement variability was assessed for each frequency band, which was determined by the SAR probe calibration point and tissue-equivalent medium used for the device measurements. When both head and body tissue-equivalent media were required for SAR measurements in a frequency band, the variability measurement procedures were applied to the tissue medium with the highest measured SAR, using the highest measured SAR configuration for that tissue-equivalent medium. These additional measurements were repeated after the completion of all measurements requiring the same head or body tissue-equivalent medium in a frequency band. The test device was returned to ambient conditions (normal room temperature) with the battery fully charged before it was re-mounted on the device holder for the repeated measurement(s) to minimize any unexpected variations in the repeated results. SAR Measurement Variability was assessed using the following procedures for each frequency band: 1) When the original highest measured SAR is ≥ 0.80 W/kg, the measurement was repeated once. 2) A second repeated measurement was preformed only if the ratio of largest to smallest SAR for the original and first repeated measurements was > 1.20 or when the original or repeated measurement was ≥ 1.45 W/kg (~ 10% from the 1-g SAR limit). 3) A third repeated measurement was performed only if the original, first or second repeated measurement was ≥ 1.5 W/kg and the ratio of largest to smallest SAR for the original, first and second repeated measurements is > 1.20. 4) Repeated measurements are not required when the original highest measured SAR is < 0.80 W/kg. 11.3 TEST POSITIONS REQUIREMENTS (1) Ear and handset reference point Picture11 shows the front, back, and side views of the SAM phantom. The center-of-mouth reference point is labeled “M,” the left ear reference point (ERP) is marked “LE,” and the right ERP is marked “RE.” Each ERP is 15 mm along the B-M (back-mouth) line behind the entrance-to-ear-canal (EEC) point, as shown in Picture12.The Reference Plane is defined as passing through the two ear reference points and point M. The line N-F (neck-front), also called the reference pivoting line, is normal to the Reference Plane and perpendicular to both a line passing through RE and LE and the B-M line (see Picture13). Both N-F and B-M lines should be marked on the exterior of the phantom shell to facilitate handset positioning. Posterior to the N-F line the ear shape is a flat surface with 6 mm thickness at each ERP, and forward of the N-F line the ear is truncated, as illustrated in Picture12. The ear truncation is introduced to preclude the ear lobe from interfering with handset tilt, which could lead to unstable positioning at the cheek. Picture11 Front, back, and side views of SAM twin phantom TRF No.: FCC SAR/A Page 36 of 61 Report No.: ES150530365E Ver.1.0 Access to the World Picture12 Close-up side view of phantom showing the ear region. Picture13 Side view of the phantom showing relevant markings and seven cross-sectional plane locations (2) Definition of the cheek position 1. Ready the handset for talk operation, if necessary. For example, for handsets with a cover piece (flip cover), open the cover. If the handset can transmit with the cover closed, both configurations must be tested. 2. Define two imaginary lines on the handset—the vertical centerline and the horizontal line. The vertical centerline passes through two points on the front side of the handset—the midpoint of the width wt of the handset at the level of the acoustic output (point A in Picture 14 and Picture 15 ), and the midpoint of the width wb of the bottom of the handset (point B). The horizontal line is perpendicular…

Text truncated - open the document above for the full version.

TRF No.: FCC Part22H Page 1 of 52 Report No.: ES150530365E4 Ver.1.0 Access to the World FCC 47 CFR PART 22 SUBPART H CERTIFICATION TEST REPORT For Smartphone Model No.: W5302,W4301,W4302,W4303,W5303,W5305,W5306,W6301 W5402,W4401,W4402,W4403,W5403,W5404,W5405,W5406 W6401 Trademark: BMORN REPORT NO: ES150530365E4 ISSUE DATE: August 10, 2015 Prepared for Shenzhen Bmorn Technology Co.,Ltd. 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.: FCC Part22H Page 2 of 52 Report No.: ES150530365E4 Ver.1.0 Access to the World TEST RESULT CERTIFICATION Applicant: Shenzhen Bmorn Technology Co.,Ltd. 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Manufacturer: Shenzhen Bmorn Technology Co.,Ltd. 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Product Description: Smartphone Model Number: W5302,W4301,W4302,W4303,W5303,W5305,W5306,W6301 W5402,W4401,W4402,W4403,W5403,W5404,W5405,W5406,W6401 (Note: all the model numbers are identical in circuitry and electrical, mechanical and physical construction, PCB layout, External dimension; the only differences are the model no., appearance and colour. for trading purpose. We take W5302 to test.) File Number: ES150530365E4 Date of Test: July 17, 2015 to August 10, 2015 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 22, Subpart H PASS The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 22 The test results of this report relate only to the tested sample identified in this report. Date of Test : July 17, 2015 to August 10, 2015 Prepared by : Andy Wei/Editor Reviewer : Joe Xia/Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No.: FCC Part22H Page 3 of 52 Report No.: ES150530365E4 Ver.1.0 Access to the World TABLE OF CONTENTS 1 EUT TECHNICAL DESCRIPTION .................................................................................................................... 4 2 SUMMARY OF TEST RESULT ........................................................................................................................... 5 3 TEST METHODOLOGY ...................................................................................................................................... 7 3.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................................. 7 3.2 MEASUREMENT EQUIPMENT USED ............................................................................................................ 7 3.3 DESCRIPTION OF TEST MODES ..................................................................................................................... 8 4 FACILITIES AND ACCREDITATIONS ........................................................................................................... 12 4.1 FACILITIES ...................................................................................................................................................... 12 4.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................... 12 5 TEST SYSTEM UNCERTAINTY ...................................................................................................................... 13 6 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 14 6.1 RADIO FREQUENCY TEST SETUP 1 ............................................................................................................ 14 6.2 RADIO FREQUENCY TEST SETUP 2 ............................................................................................................ 14 6.3 CONDUCTED EMISSION TEST SETUP ........................................................................................................ 15 6.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ......................................................................... 16 6.5 SUPPORT EQUIPMENT .................................................................................................................................. 16 7 TEST REQUIREMENTS .................................................................................................................................... 17 7.1 RF OUTPUT POWER ....................................................................................................................................... 17 7.2 MODULATION CHARACTERISTICS ............................................................................................................ 19 7.3 OCCUPIED BANDWIDTH .............................................................................................................................. 20 7.4 EFFECTIVE ISOTROPIC RADIATED POWER .............................................................................................. 28 7.5 SPURIOUS EMISSION AT ANTENNA TERMINAL ...................................................................................... 30 7.6 PEAK TO AV E R A G E RATIO ........................................................................................................................... 42 7.7 FREQUENCY STABILITY ............................................................................................................................... 43 7.8 POWER LINE CONDUCTED EMISSIONS ...............................................................................…

Text truncated - open the document above for the full version.

TRF No.: FCC Part24E Page 1 of 55 Report No.: ES150530365E5 Ver.1.0 Access to the World FCC 47 CFR PART 24 SUBPART H CERTIFICATION TEST REPORT For Smartphone Model Name: W5302,W4301,W4302,W4303,W5303,W5305,W5306,W6301 W5402,W4401,W4402,W4403,W5403,W5404,W5405,W5406 W6401 Trademark: BMORN REPORT NO: ES150530365E5 ISSUE DATE: August 10, 2015 Prepared for Shenzhen Bmorn Technology Co.,Ltd. 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.: FCC Part24E Page 2 of 55 Report No.: ES150530365E5 Ver.1.0 Access to the World TEST RESULT CERTIFICATION Applicant: Shenzhen Bmorn Technology Co.,Ltd. 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China Manufacturer: Shenzhen Bmorn Technology Co.,Ltd. 5/F, Hengfang Verteran Industrial Park,Xingye Road, Xixiang, Bao'an,Shenzhen, Guangdong,China EUT Description: Smartphone Model Number: W5302,W4301,W4302,W4303,W5303,W5305,W5306,W6301 W5402,W4401,W4402,W4403,W5403,W5404,W5405,W5406,W6401 (Note: all the model numbers are identical in circuitry and electrical, mechanical and physical construction, PCB layout, External dimension; the only differences are the model no., appearance and colour. for trading purpose. We take W5302 to test.) File Number: ES150530365E5 Date of Test: July 17, 2015 to August 10, 2015 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J, June 11, 2014 FCC 47 CFR Part 24, Subpart H, , May 9, 2014 PASS The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 24 The test results of this report relate only to the tested sample identified in this report. Date of Test : July 17, 2015 to August 10, 2015 Prepared by : Andy Wei/Editor Reviewer : Joe Xia/Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No.: FCC Part24E Page 3 of 55 Report No.: ES150530365E5 Ver.1.0 Access to the World Table of Contents 1 EUT TECHNICAL DESCRIPTION .................................................................................................................... 4 2 SUMMARY OF TEST RESULT ........................................................................................................................... 5 3 TEST METHODOLOGY ...................................................................................................................................... 6 3.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................................. 6 3.2 MEASUREMENT EQUIPMENT USED ............................................................................................................ 6 3.3 DESCRIPTION OF TEST MODES ..................................................................................................................... 7 4 FACILITIES AND ACCREDITATIONS ........................................................................................................... 11 4.1 FACILITIES ...................................................................................................................................................... 11 4.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................... 11 5 TEST SYSTEM UNCERTAINTY ...................................................................................................................... 12 6 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 13 6.1 RA…

Text truncated - open the document above for the full version.
