OβXON BS1 QUICK START GUIDE PACKGE CONTENTS z Speaker z USB Cable z 3.5mm Stereo (Wired Audio) z Quick Start Guide FUNCTION 3.5mm Audio Input / Power Input(Micro USB Port) / Power Button / LED Volume Down(Previous) / Volume UP(Next) / NFC / Play/Pause/Talk/Pairing Button BATTERY CHARGING z Plug BS1 into your wall charger or computer via micro USB cable. z Full charge takes 3 hours The LED will turn off when fully charged. BLUETOOTH z When turned on for the first time, BS1 willautometically enter pairing mode. z Press it to connect your phone with the wireless speaker, you will find the <BS1> character on the menu of your smart phone. z To enter pairing mode thereafter, press down this button to enable the bluetooth. *It needs around 20 seconds when connecting the bluetooth in the first time. SPECIFICATIONS Speaker Power--------------------------2W x 2 Speaker Size----------------------------40mm x 2 Frequency---------------------------160Hz-15kHz SNR β₯80dB Audio Input------------Bluetooth, 3.5mm Audio P ower Input-----------------------------Micro USB Built-in Microphone------------------------Yes Battery Capacity--------------------1000mAh Working Hours------------------------------10h Dimensions--------------------177x56x58mm Material--------------------------------------ABS Net Weight--------------------------------- 360g SAFETY INFORMATION NST ALL RIGHTS RESERVED. REV 1406 SAFETY INFORMATION CE DECLARATION We Beijing Natural Smart-Tech Co., Ltd. declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EU. FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tuning the equipment off and on, the user is encouraged to try correct the interference by one or more of the receiving measures: Reorient or replace relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless user could lose the authority to operate this equipment if an unauthorized change or modification is made. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.
Report No.: TB-FCC141136 Page: 3 of 10 TB-RF-075-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Report No.: TB-FCC141136 Page: 4 of 10 TB-RF-075-1.0 Photo 3 Appearance of EUT
Report No.: TB-FCC141136 Page: 5 of 10 TB-RF-075-1.0 Appendix IV EUT Internal Photographs Photo 4 Internal of EUT Photo 5 Appearance of PCB Report No.: TB-FCC141136 Page: 6 of 10 TB-RF-075-1.0 Photo 6 Appearance of PCB Photo 7 Appearance of PCB BT(2.4G) Antenna Report No.: TB-FCC141136 Page: 7 of 10 TB-RF-075-1.0 Photo 8 Appearance of PCB (NFC Module) Photo 9 Appearance of PCB (NFC Module) Report No.: TB-FCC141136 Page: 8 of 10 TB-RF-075-1.0 Photo 10 Appearance of Battery
Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC141138 Page: 1 of 28 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Baoβan, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: 2ACSPNST-BS1 Original Grant Report No. : TB-FCC141138 Applicant : Beijing Natural Smart-Tech Co., Ltd. Equipment Under Test (EUT) EUT Name : Bluetooth Speaker Model No. : NST-BS1 Series Model No. : N/A Brand Name : Oβxon Receipt Date : 2014-07-04 Test Date : 2014-07-05 to 2014-07-23 Issue Date : 2014-09-02 Standards : FCC Part 15, Subpart C (15.225/15.215) Test Method : ANSI C63.4:2003 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC and IC requirements Test/Witness Engineer : Approved& Authorized : This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC141138 Page: 2 of 28 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 4 1.4 Description of Support Units .............................................................................................. 5 1.5 Description of Test Mode .................................................................................................... 6 1.6 Description of Test Software Setting ................................................................................ 6 1.7 Test Facility ........................................................................................................................... 7 2. TEST SUMMARY ....................................................................................................................... 8 3. CONDUCTED EMISSION TEST ............................................................................................. 9 3.1 Test Standard and Limit ...................................................................................................... 9 3.2 Test Setup ............................................................................................................................. 9 3.3 Test Procedure ..................................................................................................................... 9 3.4 Test Equipment Used ........................................................................................................ 10 3.5 EUT Operating Mode ........................................................................................................ 10 3.6 Test Data ............................................................................................................................. 10 4. RADIATED EMISSION TEST ................................................................................................ 13 4.1 Test Standard and Limit .................................................................................................... 13 4.2 Test Setup ........................................................................................................................... 14 4.3 Test Procedure ................................................................................................................... 16 4.4 EUT Operating Condition ................................................................................................. 16 4.5 Test Equipment .................................................................................................................. 16 4.6 Test Data ............................................................................................................................. 17 5. FREQUENCY STABILITY ...................................................................................................... 23 5.1 Test Standard and Limit .................................................................................................... 23 5.2 Test Setup ........................................................................................................................... 23 5.3 Test Procedure ................................................................................................................... 23 5.4 EUT Operating Condition ................................................................................................. 23 5.5 Test Equipment .................................................................................................................. 23 5.6 Test Data ............................................................................................................................. 24 6. BANDWIDTH TEST ................................................................................................................. 26 6.1 Test Standard and Limit .................................................................................................... 26 6.2 Test Setup ........................................................................................................................... 26 6.3 Test Procedure ................................................................................................................... 26 6.4 EUT Operating Condition .........................................................β¦
