2ACT9ES-KZ5005Flash controller

FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Zhe Jiang Eastsun Autocar Things Co., Ltd. No. 97 North Chezhan Road, Jiashan County, Zhejiang, China Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACT9ES-KZ5005 We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: XINWAN QIAN / Manager address: No. 97 North Chezhan Road, Jiashan County, Zhejiang, China

Label location Model No.: ES-KZ5005 FCC ID: 2ACT9ES-KZ5005

RX Antenna location

FCC ID: 2ACT9ES-KZ5005 Keyway Testing Technology Co., Ltd. Report No. 14KWE081763F Page 1 of 19 FCC TEST REPORT(15B) for ZHE JIANG EASTSUN AUTOCAR THINGS CO, LTD. Flash controller Model Number: ES-KZ5005 FCC ID: 2ACT9ES-KZ5005 Prepared for : ZHE JIANG EASTSUN AUTOCAR THINGS CO, LTD. Address : No. 97 North Chezhan Road, Jiashan County, Zhejiang, China Prepared by : Keyway Testing Technology Co., Ltd. Address : Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 14KWE081763F Date of Test : Aug. 8~14, 2014 Date of Report : Aug. 14, 2014 FCC ID: 2ACT9ES-KZ5005 Keyway Testing Technology Co., Ltd. Report No. 14KWE081763F Page 2 of 19 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY .............................................................................................................4 2. GENERAL PRODUCT INFORMATION ............................................................................4 2.1. Product Function .......................................................................................................4 2.2. Description of Device (EUT) ......................................................................................4 2.3. Difference between Model Numbers..........................................................................4 2.4. Independent Operation Modes ..................................................................................4 2.5. Test Supporting System ............................................................................................5 2.6. Test Facilities.............................................................................................................5 2.7. List of Test and Measurement Instruments................................................................6 3. TEST SET-UP AND OPERATION MODES......................................................................7 3.1. Principle of Configuration Selection ...........................................................................7 3.2. Block Diagram of Test Set-up ....................................................................................7 3.3. Test Operation Mode and Test Software ...................................................................7 3.4. Special Accessories and Auxiliary Equipment ...........................................................7 3.5. Countermeasures to Achieve EMC Compliance........................................................7 3.6. Test Environment:......................................................................................................7 4. EMISSION TEST RESULTS.............................................................................................8 4.1. Radiated Emission Test.............................................................................................8 5. PHOTOGRAPHS OF TEST SET-UP..............................................................................14 6. PHOTOGRAPHS OF THE EUT......................................................................................15 FCC ID: 2ACT9ES-KZ5005 Keyway Testing Technology Co., Ltd. Report No. 14KWE081763F Page 3 of 19 Keyway Testing Technology Co., Ltd. Applicant: Address: ZHE JIANG EASTSUN AUTOCAR THINGS CO, LTD. No. 97 North Chezhan Road, Jiashan County, Zhejiang, China Manufacturer: Address: ZHE JIANG EASTSUN AUTOCAR THINGS CO, LTD. No. 97 North Chezhan Road, Jiashan County, Zhejiang, China E.U.T: Flash controller Model Number: ES-KZ5005 Trade Name: EASTSUN Serial No.: ------ Date of Receipt: Aug. 8, 2014 Date of Test: Aug. 8~14, 2014 Test Specification: FCC Part 15, Subpart B: Oct. 1, 2013 ANSI C63.4:2009 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Aug. 15, 2014 Tested by: Reviewed by: Approved by: Andy Gao / Engineer Jade Yang/ Supervisor Chris Du / Manager Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: 2ACT9ES-KZ5005 Keyway Testing Technology Co., Ltd. Report No. 14KWE081763F Page 4 of 19 1. TEST SUMMARY Test Items Test Requirement Result Radiated Emissions 15.109 PASS Conducted Emissions 15.107 N/A Note: "N/A" means due to this EUT is powered by the battery only, this test item is not applicable. 2. GENERAL PRODUCT INFORMATION 2.1. Product Function Refer to Technical Construction Form and User Manual. 2.2. Description of Device (EUT) Product Name: Flash controller Model No.: ES-KZ5005 Operation Frequency: RX 433.92MHz Modulation technology: FSK Antenna Type: Internal Power supply: DC12~24V 2.3. Difference between Model Numbers None. 2.4. Independent Operation Modes The basic operation modes are: 1 RX 433.92MHz FCC ID: 2ACT9ES-KZ5005 Keyway Testing Technology Co., Ltd. Report No. 14KWE081763F Page 5 of 19 2.5. Test Supporting System None. 2.6. Test Facilities Lab Qualifications : Certificated by Industry Canada Registration No.: 9868A Date of registration: December 8, 2011 Certificated by FCC, USA Registration No.: 370994 Date of registration: February 21, 2012 Certificated by CNAS China Registration No.: CNAS L5783 Date of registration: August 8, 2012 FCC ID: 2ACT9ES-KZ5005 Keyway Testing Technology Co., Ltd. Report No. 14KWE081763F Page 6 of 19 2.7. List of Test and Measurement Instruments 2.7.1. For radiated emission test Equipment Manufacturer Model No. Serial No. Last Cal.Next Cal. EMI Test Receiver Rohde&SchwarzESCI 101156 Apr. 27,14 Apr. 26,15 System Simulator Agilent E5515C GB43130245 Apr. 30,14 Apr. 29,15 Power Splitter Weinschel 1506A NW425 Apr. 30,14 Apr. 29,15 Bilog Antenna ETS-LINDGREEN3142D 135452 Apr. 27,14 Apr. 26,15 Loop antenna teseq HLA6120 22032 Apr. 30,14 Apr. 29,15 Spectrum Analyzer Agilent …

Text truncated - open the document above for the full version.

Radiated Emission
