2ACUE19230223Remote control transmitter

1 RJ DUNKIN CO. LLC STRUTT’N 360 XDR INSTRUCTION MANUAL 2 CONTENTS IMPORTANT USAGE INSTRUCTIONS ............................................................................................................................ 3 About this Manual .............................................................................................................................................................. 5 AA Batteries Not Included .................................................................................................................................................. 8 AA Battery Installation....................................................................................................................................................... 8 STRUTT’N 360 XDR Start-up .......................................................................................................................................... 10 Getting Your Decoy Ready ............................................................................................................................................... 13 HUNTING Set-up for the STRUTT’N 360 XDR ............................................................................................................... 14 Frequently asked questions .............................................................................................................................................. 15 1. Is the STRUTT’N 360 XDR Waterproof? .......................................................................................................... 15 2. Can I use real mounted decoys with the STRUTT’N 360 XDR? ....................................................................... 15 3. How far out will the STRUTT’N 360 XDR work? ............................................................................................. 16 4. Can I use more than one STRUTT’N 360 XDR with one STRUTT’N Transmitter? ........................................ 16 5. Does the STRUTT’N 360 XDR come with a Warranty? ................................................................................... 16 6. Does RJ DUNKN Co, LLC have a Field, Pro or Elite Staff Team that I might join? ......................................... 17 Contact Information ......................................................................................................................................................... 20 3 IMPORTANT USAGE INSTRUCTIONS Important Usage Instructions: COPYRIGHT WARNING: Unauthorized recording of copyrighted materials may infringe on the rights of copyright owners and be contrary to copyright laws. STRUTT’N 360 XDR™: THIS DEVICE HAS BEEN TESTED AND COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO TH E FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS EQUIPMENT GENERATES, USES AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT USED IN ACCORDANCE WITH THE INSTRUCTIONS CONTAINED HEREIN, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. NOTE: DO NOT MAKE ANY MODIFICATIONS TO THE EQUIPMENT UNLESS OTHERWISE SPECIFIED TO DO SO IN THIS MANUAL. THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. RJ DUNKIN COMPANY, LLC 424 STONECREST DRIVE, BIRMINGHAM, ALABAMA 35242 PHONE (205) 405-7223 FCC ID: 2ACUE19230223 RJ DUNKIN CO. LLC 424 STONECREST DRIVE BIRMINGHAM, ALABAMA 35242 4 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS: 1. Read the Instructions: All operating instructions should be read before operating the equipment. 2. Retain the Instructions: The safety and operating instructions should be retained for future use. 3. Heed Warnings: All warnings on the product and in the operating instructions should be adhered to at all times. 4. Follow Instructions: All operating and maintenance instructions should be followed. 5. Disassembly: Do not disassemble the product unless instructed to do so by an authorized factory representative. 6. Cleaning: Do not use liquid or aerosol cleaners. The product should be cleaned only as recommended in this manual or by an authorized factory representative. 7. Accessories: Do not use accessories not recommended in this manual as they may be hazardous to either the operator or the product. 8. Servicing: Do not try to service this product yourself. Refer service to the factory. In some instances, a factory authorized representative may walk you through trouble shooting steps which may entail some disassembly. 5 About this Manual Thank you for purchasing the STRUTT’N 360 XDR™. Please read the manual in its entirety before you use the 360. Retain this manual for future use. Should your 360 fail to operate properly, refer to the troubleshooting section of this manual. For additional help, phone the factory at (205) 405-7223. ANY USE OF THIS PRODUCT OTHER THAN CONSUMER PERSONAL USE FOR WHICH IT IS INTENDED IS EXPRESSLY PROHIBITED WITHOUT A LICENSE WITH THE MANUFACTURER. THIS PRODUCT IS PATENTED AND PROTECTED ACCORDING TO THE PATENT LAWS OF THE UNITED STATES OF AMERICA. U.S. PATENT NUMBER: 8245436 B2 ISSUED: AUGUST 21, 2012 6 Supplied Components Your STRUTT’N 360 XDR shipping box should contain the following components (see Figure 1): Item # Quantity Description 1. (1) Styrofoam Bottom 2. (1) The STRUTT’N 360 XDR 3. (1) STRUTT’N Transmitter 4. Omitted 5. (1) STRUTT’N Post – 2 Pieces 6. (4) STRUTT’N Stakes 7. (1) Styrofoam Top 8. (1) Instructional DVD 9. (1) Instruction Manual 10. (1) ¼-20 Plastic Thumb Nuts (Not Shown) 11. (2) ¼ I.D. Plastic Washers (Not Shown) 12. (1) STRUTT’N 360 XDR Window Decal (Not Shown) This container has been packed by: ____________________________ If you find that items are missing from your package, phone RJ DUNKIN Co. LLC at (205) 405-7223. 7 F…

Text truncated - open the document above for the full version.

APPLICANT: RJ DUNKIN CO., LLC. FCC ID: 2ACUE19230223 INTERNAL PHOTOS

FCC PART 15.231 TEST REPORT LOW POWER UNLICENSED TRANSMITTER Applicant RJ DUNKIN COMPANY, LLC Address 424 STONECREST DRIVE BIRMINGHAM ALABAMA 35242 FCC ID 2ACUE19230223 Product Description REMOTE CONTROL TRANSMITTER Date Sample Received 10/23/2014 Date Tested 11 /3/2014 Tested By Sid Sanders Approved By Cory Leverett Test Results Pass Fail THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP://WWW.TIMCOENGR.COM APPLICANT: RJ DUNKIN COMPANY, LLC FCC ID: 2ACUE19230223 REPORT: R\RJ DUNKIN\1585ZUT14\1585ZUT14TestReport.docx Page 2 of 16 TABLE OF CONTENTS Contents GENERAL REMARKS ...........................................................................................3 REPORT SUMMARY.............................................................................................4 TEST ENVIRONMENT ..........................................................................................4 TEST SETUP ......................................................................................................4 EUT SPECIFICATION ..........................................................................................5 MANUFACTURE DECLARATION OF COMPLIANCE WITH PART 15.231(A) ....................6 TEST PROCEDURES ............................................................................................7 CALCULATION OF DUTY CYCLE ............................................................................8 RADIATION INTERFERENCE .............................................................................. 12 RADIATION INTERFERENCE(Cont.) .................................................................... 13 OCCUPIED BANDWIDTH ................................................................................... 14 POWER LINE CONDUCTED INTERFERENCE .......................................................... 15 TEST EQUIPMENT LIST ..................................................................................... 16 APPLICANT: RJ DUNKIN COMPANY, LLC FCC ID: 2ACUE19230223 REPORT: R\RJ DUNKIN\1585ZUT14\1585ZUT14TestReport.docx Page 3 of 16 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Project Manager Date: 11/5/2014 Table of Contents APPLICANT: RJ DUNKIN COMPANY, LLC FCC ID: 2ACUE19230223 REPORT: R\RJ DUNKIN\1585ZUT14\1585ZUT14TestReport.docx Page 4 of 16 REPORT SUMMARY Disclaimer The test results only relate to the item tested. Applicable Rule(s) FCC Pt 15.231, Pt 15.209, Pt 15.207, ANSI C63.4: 2009 Related Report(s) or Approval(s) NA TEST ENVIRONMENT Test Facility The test sites are located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition: Temperature: 24 -26ºC Relative humidity: 50-65 % TEST SETUP Test Exercise (e.g software description, test signal, etc.): The EUT was operated in a normal mode to determine the duty cycle and then placed in continuous transmit mode of operation for the radiated emissions. Deviation from the standard(s) No deviation from the standard(s) Modification to the EUT: No modification was made to the EUT. Supporting Peripheral Equipment Not applicable. The device is a stand-alone remote control radio. Table of Contents APPLICANT: RJ DUNKIN COMPANY, LLC FCC ID: 2ACUE19230223 REPORT: R\RJ DUNKIN\1585ZUT14\1585ZUT14TestReport.docx Page 5 of 16 EUT SPECIFICATION Applicant RJ DUNKIN COMPANY, LLC Description REMOTE CONTROL TRANSMITTER FCC ID 2ACUE19230223 Frequency Range 433.95MHz EUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Table of Contents APPLICANT: RJ DUNKIN COMPANY, LLC FCC ID: 2ACUE19230223 REPORT: R\RJ DUNKIN\1585ZUT14\1585ZUT14TestReport.docx Page 6 of 16 MANUFACTURE DECLARATION OF COMPLIANCE WITH PART 15.231(A) Item Description Yes No 1 Does this device transmit a signal that is only used to control another device? X 2 Does this device send data with this control signal? X 3 Does this device send data? Data is, things like: temperature, wind direction, fluid amount, rate of flow, etc. X 4 Does this device transmit continuously or automatically? X 5 If manually operated does this device stop transmitting within 5 seconds of releasing the button? X 6 If automatically operated does it deactivate 5 seconds after activation? X 7 Does it transmit at regular predetermined intervals? X 8 Does it poll or send supervisory information? X If yes does it do a system integrity check? How often? X 9 Is this a fire, security or safety of life device? X If YES does the device stop transmitting after the alarm condition is satisfied? X 10 DUTy cycle: Maximum on-time IS 9.26mSeconds. If YES, on-time in 100 ms? If Other, please specify here On time in 11 Modulation technique: Please specify the modulation of the test sample, FM, or AFSK, or FSK, or on-off keying, or others? P Table of Contents APPLICANT: RJ DUNKIN COMPANY, LLC FCC ID: 2ACUE19230223 REPORT: R\RJ DUNKIN\1585ZUT14\1585ZUT14TestReport.docx Page 7 of 16 TEST PROCEDURES Power line conducted E…

Text truncated - open the document above for the full version.

APPLICANT: RJ DUNKIN COMPANY, LLC FCC ID: 2ACUE19230223 TEST SET UP PHOTOS RADIATED EMISSIONS TEST SET UP PHOTOS
