2ACUH-SMARTAGLost and Found Tag

Congratulations on your purchase of this SMARTAG. You can enjoy freedom on the go as that device will help you in preventing from lost of your valuable belongings. To get the most from your tag function, please take a few minutes to read these instructions. Safety instruction * Heed all warnings. * Follow all instructions. * Do not use this device near water; clean only using a dry or slightly moist cloth. * The appliance shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed near the tag. * Do not place tag on any wet surface. * D o not allow children to play with the tag. * Do not cover the unit with any table-cloths, curtains, etc. Place the unit where there is good air circulation. * No naked flames sources, such as candles, should be placed on the product. * Press the buttons gently. Pressing them too hard can damage the tag. * Do not use the tag in an extremely dry environment, as this can lead to static discharge which can damage the tag. * Do not expose the tag to temperatures above 35C; keep it out of direct sunlight. * This tag has no user-serviceable parts. Do not attempt to repair this product yourself. Only qualified service personnel should perform servicing. * Care required with the use of this apparatus in tropical and/or moderate climates. * Do not subject the tag to harsh impacts. Do not drop the appliance. This may result in damage to the tag. * Use a slightly damp, lint-free cloth to clean this appliance. * Do not place unit near TV, speakers, wireless telephones and other objects that generate strong magnetic fields. * Do not use this tag inside hospital or next to any medical instrument. * Only use attachments/accessories specified by the manufacturer. Install APP - SMARTAG Unpack the unit carefully. We recommend that you save the box and packing materials, in case you wish to store the unit. Before setting up the unit, please have your smartphone ready with installed APP - SMARTAG, which is available in Apple APP store and Google play store. Syncing ‘SMARTAG’ with smartphone 1. Pull out the battery insulator from the tag and long press the button until a ‘bitbit’ sound on. 2. Put the tag you wish to be synced next to your smartphone. 3 Open the ‘SMARTAG’ APP and turn on Bluetooth connection on your smartphone. 4. Click the ‘ + ‘ on the top left corner of the APP for adding new tag. 5. Wait for few second and you will find a new tag. 6. You can add a related photo and rename it if needed. 7. You can pair up to 8 SMARTAG on your smartphone. 12 3 4 Instruction Manual Read this instruction manual before operating the appliance; and save it for further reference. MULTI FUNCTION BUTTON BATTERY INSULATOR Set up 1. Select the synced tag for function set up. 2. Select photo or take a tag related photo. 3. Rename the tag description. 4. Select different function as you needed ( shown as below ). RING TONE 1 2 3 RING VOLUME LOW MED HIGH RANGE SHORT MED LONG FUNCTION OFF ON PETPET DELETE BACK PHOTO SELECT TAKE NEW PHOTO TAG DESCRIPTION DIFFERENT FUNCTION SELECTION CALL TAG FUNCTION RANGE RANGE TONE RING VOLUME - function ON/OFF selection - range to activate the tag selection - alarm sound ringing selection - volume HIGH/MED/LOW selection 5 67 PETPET AUTO GPS LOCKGPS HISTORY OFF ONOFF ON HISTORY 4 GPS HISTORY SHOW PREVIOUS SHOW NEXT RECORD GPS GPS function ( location checking ) By keeping the GPS record, you can trace your valuable belongings in at once. Also can use it as a car finder with GPS record. In total, it can save up to 10 GPS record. RADAR function The radar feature provided in the APP gives you a visual image on your smartphone showing the distance and movement of the object that you want to keep track of. Find the tag By simply click the button on the APP to make your tag alarm on, can find your tag (valuable belongings) back... easy ! Two way tracking By simply click the button on the tag to make your phone alarm on, can find your phone back... easy ! Remote shutter (SELFIE) function Enter Remote Shutter function, you can use the ‘smartag’ button for photo taking. Model : SMARTAG DC power : DC 3V (CR 2016 ) Bluetooth smart connecttion Working Distance in open air : < 20M Technical Specifications Care and maintenance Instructions: When cleaning the unit, use only a dry soft cloth to wipe the unit. Never allow water or any other liquids to get inside the unit while cleaning. Do not use any cleaning agents containing alcohol, ammonia, benzene, or abrasives as this may harm the set. SymptomPossible problem and solution Cannot pair successfully Check whether the tag is in power on and searching mode. Check whether there are too many Bluetooth receivers around your Bluetooth device. Turn them off to avoid any disturbance. And pair again. The sound is small or distorted Check the battery in your tag. Trouble Shooting No sound from the tag when pressing the search button on the APP. Check the bluetooth is connected and the battery is in good condition. Please reset the tag and pair again. Changing Battery It is using CR 2016 standard battery. Pull out the battery door, remove the old battery and replace it with a new one. Please make sure the pole is correct. Slide in the battery door carefully and press/hold the button for 2 seconds to turn on the tag. PETPET KEYCHAIN HANDBAG LONG RANGE SHORT RANGE MEDIUM RANGE ADD NEW TAGSETTING GPS LOCK CONNECTION TAG DISTANCE FCC ID : 2ACUH-SMARTAG THIS DEVICE COMPLIECS WITH PART 15 OF FCC RULES, OPERATION I S SUBJECT TO THE FOLLOWING TWO CONDITIONS: 1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment.

2ACUH-SMARTAG

FCC ID:2ACUH-SMARTAG The device has a standalone transmission. According to KDB 447498 section 4.3.1, the 1-g SAR test exclusion thresholds at test separation distances 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[f(GHz)]  3.0 The maximum tune-up limit power is 2.78dBm(1.897mW) @ 2.402GHz For the head and body SAR, use 5mm as the conservative minimum test separation distance, [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[f(GHz)] =0.588 3.0 So standalone SAR measurements are not required for both head and body. 2.81dBm(1.90mW) @ 2.402GHz

Global United Technology Services Co., Ltd. Report No.: GTSE14070128401 Authorized Signature: Robinson Lo Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the GTS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of GTS or testing done by GTS in connection with, distribution or use of the product described in this report must be approved by GTS in writing. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. FCC REPORT Applicant: NEXI LIMITED Address of Applicant: Unit 2101-2, 21/F, New Trend Centre 704, Prince Edward Road East, San Po Kong, Kowloon Equipment Under Test (EUT) Product Name: Lost and Found Tag Model No.: Smartag 1, Smartag 2 Trade Mark: NEXI FCC ID: 2ACUH-SMARTAG Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247:2013 Date of sample receipt: July 24, 2014 Date of Test: July 24-30, 2014 Date of report issued: August 6, 2014 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Global United Technology Services Co., Ltd. Project No.: GTSE140701284RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 33 2 Version Version No. Date Description 00 August 6, 2014 Original Prepared By: Date: August 6, 2014 Project Engineer Check By: Date: August 6, 2014 Reviewer Global United Technology Services Co., Ltd. Project No.: GTSE140701284RF 2nd Floor, Block No.2, Laodong Industrial Zone, Xixiang Road Baoan District, Shenzhen, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 33 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 CLIENT INFORMATION ......................................................................................................................... 5 5.2 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.3 TEST MODE ........................................................................................................................................ 7 5.4 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.5 TEST FACILITY ................................................................................................................................... 7 5.6 TEST LOCATION ................................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA ...................................................................................... 9 7.1 ANTENNA REQUIREMENT ..................................................................................................................... 9 7.2 CONDUCTED PEAK OUTPUT POWER .................................................................................................. 10 7.3 CHANNEL BANDWIDTH ...................................................................................................................... 12 7.4 POWER SPECTRAL DENSITY ............................................................................................................. 14 7.5 BAND EDGES .................................................................................................................................... 16 7.5.1 Conducted Emission Method ..................................................................................................... 16 7.5.2 Radiated Emission Method ........................................................................................................ 17 7.6 SPURIOUS EMISSION ........................................................................................................................ 20 7.6.1 Conducted Emission Method ..................................................................................................... 20 7.6.2 Radiated Emission Method ........................................................................................................ 22 8 TEST SETUP PHOTO ..............................................................................................................…
