2ACWZ21000Automated drywall corner system.

User Manual Safety Guidelines This manual contains information that is very important to know and understand. This information is provided for SAFETY and to PREVENT EQUIPMENT PROBLEMS. To help recognize this information, observe the following symbols. Indicates an imminently hazardous situation which, if not avoided, WILL RESULT in death or serious injury. Indicates a potentially hazardous situation, which if not avoided, COULD RESULT in death or serious injury. Indicates a potentially hazardous situation! If not avoided, MAY RESULT in minor or moderate injury. It may also be used to alert against unsafe practices. DANGER WARNING CAUTION NOTICE Indicates important information , that if not followed, may cause damage to machine. Automated Drywall Corner Trim System 2. AutoPRO User Manual Safety Guidelines General Safety and Warnings for AutoPRO machine operation Read manual carefully. Be thoroughly familiar with the controls and the proper use of the machine. Follow all local electrical and safety codes, as well as the U.S.A., National Electrical Codes (NEC) and Occupational Safety and Health Act (OSHA). Only persons well acquainted with these rules should be allowed to use the machine. Wear safety glasses and approved hearing protection when operating the machine. Operate machine on dry, level surface. DO NOT lay machine on side. Turn off machine when not in use. Do not operate machine if it is wet. Use only well-maintained equipment. Repair or replace damaged parts at once. Maintain unit according to this manual. Keep all panels and covers securely in place. All visitors (especially children) should be kept at a safe distance from the machine. DO NOT use setting-type compounds in AutoPRO as they will damage the machine. Structus recommends ready-mix All-Purpose joint compound ONLY for use in the AUTOPRO machine when running corners. DO NOT modify this machine with non-Structus products, as modification could affect performance, safety or durability. In addition, damage or performance problems resulting from modification may not be covered under warranty. AUTOPRO is engineered to be used with the LevellinePRO roll product ONLY. AutoPRO is engineered to be used with the LevellinePRO roll product ONLY. DO NOT store the AutoPRO machine in temperatures below 32 ̊ F. Do not use a grounding adapter with this machine! Improper use of grounding plug can result in a possible risk of electric shock! All wiring and electrical connections should be performed by a qualified electrician. Installation must be in accordance with local codes and national electrical codes. Motors, electrical equipment and controls can cause electrical arcs that will ignite a flammable gas or vapor. Never operate or repair in or near a flammable gas or vapor. Never store flammable liquids or gases in the vicinity of the compressor. Do not wear loose fitting clothing while operating machine. Keep hands and loose fitting clothing away from moving parts. Do Not attempt to move AutoPRO with Hopper Assembly in place. To move or transport AutoPRO, remove Hopper Assembly. CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER CAUTION NOTICE WARNING DANGER AutoPRO User Manual 3. FCC statement: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Structus Building Technologies, Inc. could void the user’s authority to operate the equipment. Industry Canada notice: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. FOREWORD Welcome to the growing number of drywall contractors who are using the AutoPRO Automated Drywall Corner Trim System. We are proud of the innovative engineering and quality construction of each AutoPRO machine that we build. This instruction manual explains the operation of the AutoPRO system. Please read it thoroughly and follow the instructions carefully. All information and specifications in this manual are current at the time of printing. However, because of our commitment to cont…

Text truncated - open the document above for the full version.

Model: AutoPRO 21000 FCC ID: 2ACWZ21000 IC: 12255A-21000 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in USA L - 2.75 x 1.35 0.063 Corner Radius No Holes

This report contains a total of 31 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Structus Building Technologies TEST REPORT FOR AutoPRO Model: 21000 Tested To The Following Standards: FCC Part 15 Subpart C Section(s) 15.207 and 15.225 Report No.: 96012-6 Date of issue: August 29, 2014 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 31 Report No.: 96012-6 TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Modifications/Conditions During Testing .................................................................................................................. 5 Equipment Under Test ............................................................................................................................................... 6 Peripheral Devices ..................................................................................................................................................... 6 FCC Part 15 Subpart C ................................................................................................................................... 7 15.207 AC Conducted Emissions ................................................................................................................................ 7 15.215(c) Occupied Bandwidth ............................................................................................................................... 14 15.225(a)(b)(c) Fundamental Field Strength Emissions ........................................................................................... 17 15.225(d) Field Strength of Spurious Emissions ...................................................................................................... 21 15.225(e) Frequency Tolerance & Voltage Variation .............................................................................................. 27 Supplemental Information .......................................................................................................................... 30 Measurement Uncertainty ...................................................................................................................................... 30 Emissions Test Details .............................................................................................................................................. 30 Page 3 of 31 Report No.: 96012-6 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: Structus Building Technologies 20870 Redside Court Bend, OR 97701 Morgan Tramontin CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 REPRESENTATIVE: Mike House Project Number: 96012 Customer Reference Number: MH000131 DATE OF EQUIPMENT RECEIPT: August 5, 2014 DATE(S) OF TESTING: August 5, 2014 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 31 Report No.: 96012-6 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 22116 23rd Drive S.E., Suite A Bothell, WA 98021-4413 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.00.14 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Bothell US0081 SL2-IN-E-1145R 3082C-1 318736 A-0148 Page 5 of 31 Report No.: 96012-6 SUMMARY OF RESULTS Standard / Specification: FCC Part 15 Subpart C Test Procedure/Method Description Modifications* Results 15.207 / ANSI C63.4 Conducted Emissions NA Pass 15.215(c) Occupied Bandwidth NA Pass 15.225(a)(b)(c) / ANSI C63.4 Fundamental Field Strength Emissions NA Pass 15.225(d) / ANSI C63.4 Field Strength of Spurious Emi…

Text truncated - open the document above for the full version.
