2ACXFRB-T1REMAX Bluetooth Headset

BLUETOOTH HEADSET OPERATING MANUAL A.Mini USB charging socket B.Earbud C.Talk Button/LEDIndicator D. Microphone SPECIFICATION: Model: RB-T1 Bluetooth Version: 4.0 Operation frequeny: 2402-2480 MHz Talk time: ≤Up to 5hours Standby time: ≤100hours Charge time: 2 hours Wireless range: 10m Connection: Support multipoint connection, can connection two sets of equipment at the same time Voice quality: HD Audio(16KHZ) Weight: 5g ACCESSORIES: We have supplied you with 3 different size earbuds. Try all the size and pick the one that is most comfortable and fit for you. RB-T1 have equipped with 3 ear cap, to fit a new earbud, position the earbud over the speaker housing and gently press down on the earbud. CALL INSTRUCTIONS : A. Power on: In the state of shutdown, press &hold the button for 2 seconds until the white light is on, “power on”&“Bluetooth connected ”voice prompt will be heard. B. Standby: White light blinks once every 7 seconds, after 5 min connectionless mode, RB-T1 will be power off automatically. C. Power off: Press & Hold Button for 2 seconds, the headset is power off and the red light go on for 1 second. D. Answer a call: when incoming call, please just press power button one time. E. Hang Up a call: Tap Talk button once while on call. F. Transfer a call: When you are talking, Press & Hold Button for 1 second, release the button after tone, which can switch between the Headset and mobile phone call at the moment. G. Reject a call: Press & Hold Button for 2 seconds, release the button after tone. H. Redial: while in connect standby mode, press & Hold button for 2seconds, redial last number. Chinese voice prompt will be heard. I. Low power prompt: when the Bluetooth is low power, there is "low battery" voice prompt. J.Language switch: In the state of charging, Press button until the white light flashes twice, then Voice from the Chinese into English or from English into Chinese. PAIRING INSTRUCTIONS: Open smart phone Bluetooth setting, Click “Add” or “Search “Bluetooth devices, select the "paired device: RB-T1" (if ask for a password, please enter “0000” ), then you can connect smart phone to Bluetooth Headset, pairing time is 90 seconds, if fail to pair, 90 seconds later, it will return back to the connectionless state. PS: In the process of Bluetooth Headset and smart phone Bluetooth pairing, the white light is in flashing fast state. B. Pairing two phones 1. Matching with the first mobile phone by paring method 1; 2. Turn off the Bluetooth Headset after paring successfully, keep connecting with the 1st paired mobile phone. 3. Turn on Bluetooth Headset, press the talk key until the white light flashes quickly. Bluetooth Headset enter pairing state again. 4. Open the Bluetooth setting of the 2nd device, and connect the Bluetooth headset. 5. Keep the paring mode of the 2nd device, find the Bluetooth headset in the first smart phone Bluetooth menu,click “connect”, then these two devices will connect the Bluetooth headset. ADJUST VOLUME: Adjust the REMAX RB-T1 Speaker Volume Press + to increase the speaker’s volume Press- to decrease the speaker’s volume OTHER FUNCTIONS: Under the pairing mode RB-T1 will deactivate the mode if th-ere is no connection in 90 seconds (LED flash red light). Auto power off: After 5 min connectionless mode, RB-T1 will auto power off. Power display: Battery capacity on Phone shows up automatically after it is connected with the IOS system or part of the Android system. VOICE PROMPT: RB-T1 is provided with two language voice prompt- Chinese and English, and the default prompt for English speech. In the charging state, Press & Hold Button until the white light flashes twice, then can switch the two languages between Chinese and English, the following table for Chinese /English voice prompts and their implications. The voice prompt function: default English CHARGING: A. Use the included USB cable to connect Bluetooth to PC to charging B. Use the included USB cable to connect Bluetooth to the matching charger to charging COMMON PROBLEMS & SOLUTIONS: A. Can not turn on the Bluetooth Headset: Check whether the Headset is power shortage, or due to the misoperation, resulting in Headset program error, use charger to recharge it, then problem will be solved. B. Cannot search Bluetooth Headset: Check whether the Bluetooth Headset is in normal state of starting, or smart phone Bluetooth application procedures can be normal used. C. Noise in the headset: Please confirm whether the audio signal is connected well or not, RB-T1 and smart phone should be placed on the same side. D.Headset no sound: Check whether the RB-T1 Bluetooth Headset and mobile phone connection pairing.If you have Headset connected with Bluetooth pairing, still no sound, you may refer to the Bluetooth Headset pairing instructions partially repairing connection. E.Unable to use or the smart phone can't display RB-T1 power: Please confirm that whether the smart phone supports these functions, refer smart phone specification to obtain relevant information. FCC STATEMENT: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or reloc…

Text truncated - open the document above for the full version.

ShenzhenRemaxCo.,Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: August 11, 2014 Subject; Request for Confidentiality FCC ID: 2ACXFRB-T1 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure indefinitely. •Schematic Dia gram •Block Diagram • Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company andwould give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission' s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant shot-term confidentiality request on the following attachment(s) for 180 days after the grant as outlined in Public Notice DA 04-1705. •External Photos •Internal Photos •Test Setup Photos •Use rManual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: ShenQun Title:Sales

ShenzhenRemaxCo.,Ltd. Letter of Authorization Company: Shenzhen Remax Co., Ltd. Address:3/F, B1 Building, Mingjun Industrial Park, Huarong Rd., Bao'an Area, Shenzhen, China. Product Name: REMAX Bluetooth Headset Model Number: RB-T1, RB-T2, RB-T3, RB-T4, RB-T5, RB-TT, RB-M1, RB-M2, RB-M3, RB-M5, RB-MAX We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. This shall include the following: •Testin g •Approval applications (includes complete product documentation package, including Confidential information) and procedures •Pa yment of approval fees We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Shen Qun Date: August 11, 2014 Title: Sales Signature of applicant:

FCC ID: 2ACXFRB-T1 Label size: L*W= 15*5mm . Label location FCC ID: 2ACXFRB-T1

The results detailed in this test report relate only to the specific sample(s) tested. It is the Application’s responsibility to ensure that all production units are manufactured with equivalent EMC characteristics. This report is not to be reproduced except in full, without written approval from Shenzhen POCE Technology Co., Ltd.. FCC ID TEST REPORT Prepared for...............................: Shenzhen Remax Co., Ltd. Address.....................................: 3/F, B1 Building, Mingjun Industrial Park, Huarong Rd., Bao'an Area, Shenzhen, China Equipment Under Test(E.U.T.): REMAX Bluetooth Headset Model................................................: RB-T1 FCC ID.............................................: 2ACXFRB-T1 Applicable Standards........................: FCC CFR Title 47 Part 15 Subpart C Section 15.247:2013 KDB 558074 D01 DTS Meas Guidance v03r01 Test Date...................................: 01 August 2014 to 12 August 2014 Issued Date...............................: 12 August 2014 Report Number.........................: POCE14080537PRF Test Engineer............................: Reviewed By.............................: Prepared By...............................: Shenzhen POCE Technology Co., Ltd. H Building, Hongfa Science and Technology Park, Tangtou, Shiyan, Bao’an District, Shenzhen, China Tel: 86-755-2911 3252 Fax: 86-755-2911 3135 Shenzhen POCE Technology Co., Ltd. Report No.: POCE14080537PRF FCC ID: 2ACXFRB-T1 H Building, Hongfa science and Technology Park, Tangtou, Shiyan, Bao’an District, Shenzhen, China Tel: +86-755-2911 3252 Fax: +86-755-2911 3135 http://www. poce-cert.com Page 2 of 31 Table of Contents 1.0 General Information......................................................................................................................................................4 1.1 Client Details............................................................................................................................................................4 1.2 Test Lab Details........................................................................................................................................................4 1.3 Description of E.U.T. ...............................................................................................................................................5 1.4 AE used during the test ............................................................................................................................................5 2.0 Test Summary.................................................................................................................................................................6 3.0 E.U.T. Modification........................................................................................................................................................6 4.0 Measurement Uncertainty.............................................................................................................................................6 5.0 Antenna Requirement....................................................................................................................................................7 5.1 Standard Applicable .................................................................................................................................................7 5.2 Antenna Specification ..............................................................................................................................................7 6.0 Power Line Conducted Emission Test..........................................................................................................................8 6.1 Test Equipment.........................................................................................................................................................8 6.2 Test Method and test Procedure ...............................................................................................................................8 6.3 Block diagram of Test setup .....................................................................................................................................8 6.4 E.U.T. Operating Condition .....................................................................................................................................8 6.5 Power line conducted Emission Limit according to Paragraph 15.207....................................................................8 6.6 Test specification......................................................................................................................................................8 6.7 Test Result ................................................................................................................................................................8 7.0 Maximum Peak Output Power................................................................................................................................... 11 7.1 Test Equipment....................................................................................................................................................... 11 7.2 Test configuration................................................................................................................................................... 11 7.3 Limits of Maximum Peak Output Power ............................................................................................................... 11 7.4 Test Procedure ........................................................................................................................................................ 11 7.5 Test Result .............................................................................................................................................................. 11 8.0 6dB Bandwidth Measurement...................................................................…

Text truncated - open the document above for the full version.
