2ACXG60003Remote control

INSTRUCTIONS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC ID: 2ACXG60003

775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD ( 2014/08/10) To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, __ HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD __hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name) Product： Remote control Model Name： 60003 Trade name: KAITE, FCC ID： 2ACXG60003 Sincerely, Date: 2014/08/10 Name: BaofengFang Title: Manager Tel: +86-571-58317205 Company: HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD Address: Sandu Town ,Industrial Zone, Jiande City, Hangzhou, Zhejiang SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD (2014/08/10) To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ___ HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD ___hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): (Product description, model name) Product： Remote control Model Name： 60003 Trade name: KAITE, FCC ID： 2ACXG60003 We affirm that between SIEMIC, Inc. and ___ HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD__, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Date: 2014/08/10 Name: BaofengFang Title: Manager Tel: +86-571-58317205 Company: HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD Address: Sandu Town ,Industrial Zone, Jiande City, Hangzhou, Zhejiang SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0

HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD 2014/08/10 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACXG60003 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Signature Date: 2014/08/10 Name: BaofengFang Title: Manager Tel: +86-571-58317205 Company: HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD Address: Sandu Town ,Industrial Zone, Jiande City, Hangzhou, Zhejiang SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0

Top View Bottom View Rear View Left View Right View Front View

Label: FCC ID: 2ACXG60003

Label: Label Location FCC ID: 2ACXG60003

To p Vi e w Bottom View Antenna

FCC RADIO TEST REPORT FCC ID: 2ACXG60003 Product： Remote control Trade Name： KAITE, Model Name： 60003 Serial Model： N/A Report No.： BZT-2014NT0801142F Prepared for HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD Sandu Town ,Industrial Zone, Jiande City, Hangzhou, Zhejiang Prepared by Shenzhen BZT Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Page 2 of 28 Report No.: BZT-2014NT0801142F TEST RESULT CERTIFICATION Applicant’s name ................. : HANGZHOU KAITE ELECTRICAL APPLIANCE CO., LTD Address ................................. : Sandu Town ,Industrial Zone, Jiande City, Hangzhou, Zhejiang Manufacturer........................ Shenzhen Lighting Delight Electronics Development Co., Ltd Address.............................. 4th floor, Bldg B1, Tianrui Industrial Park, Fuyuan 1st Road, Bao ́an district, Shenzhen Product description Product name ........................... : Remote control Model and/or type reference : 60003 Serial Model： N/A Rating(s) ................................ : DC 12V from battery Standards ............................. : FCC Part15.231 Test procedure .............................. ANSI C63.4-2 003 This device described above has been tested by BZT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of BZT, this document may be altered or revised by BZT , personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 02 August. 2014 ~07 August. 2014 Date of Issue ........................................... : 08 August. 2014 Test Result ............................................... : Pass Testing Engineer : (Lynn Chen) Technical Manager : (Carlen Liu) Authorized Signatory : (To m m y zhang) ` Page 3 of 28 Report No.: BZT-2014NT0801142F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . ANTENNA REQUIREMENT 11 3.1 STANDARD REQUIREMENT 11 3.2 EUT ANTENNA 11 3.3 CONDUCTED EMISSION MEASUREMENT 12 3.3.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.3.2 TEST PROCEDURE 13 3.3.3 DEVIATION FROM TEST STANDARD 13 3.3.4 TEST SETUP 13 3.2.5 TEST RESULT 14 3.3.5 TEST RESULTS 14 3.4 RADIATED EMISSION MEASUREMENT 15 3.4.1 RADIATED EMISSION LIMITS 15 3.4.2 TEST PROCEDURE 16 3.4.3 DEVIATION FROM TEST STANDARD 16 3.4.4 TEST SETUP 17 3.4.5 TEST RESULTS (BELOW 30MHZ) 19 3.4.6 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 20 4 . BANDWIDTH TEST 24 4.1 TEST PROCEDURE 24 4.2 DEVIATION FROM STANDARD 24 4.3 TEST SETUP 24 4.4 TEST RESULTS 25 5 . TRANSMITTER TIMEOUT 26 5.1 REQUIREMENTS 26 6 . EUT TEST PHOTO 28 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS ` Page 4 of 28 Report No.: BZT-2014NT0801142F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.231) Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.203 Antenna Requirement Pass 15.231 Radiated Spurious Emission Pass 15.231 Occupied Bandwidth Pass 15.231 Transmitter Timeout Pass NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. ` Page 5 of 28 Report No.: BZT-2014NT0801142F 1.1 TEST FACILITY BZT Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.: 701733 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% ` Page 6 of 28 Report No.: BZT-2014NT0801142F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Remote control Trade Name KAITE, Model Name 60003 Serial Model N/A Model Difference N/A Product Description The EUT is a Remote control Product Type Low Power Communication Device Transmitter Operation Frequency: 315MHz Modulation Type: FSK Number Of Channel 1CH. Antenna Designation: internal Antenna Antenna Gain(Peak) 1dBi Output Power: 76.64 dBuV/m (AV Max.) More details of EUT technical specification, please refer to the User's Manual. Channel List N/A Adapter N/A Battery DC 12V Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A internal Antenna N/A 1 Antenna ` Page 7 of 28 Report No.: BZT-2014NT0801142F 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 TX For Conducted Emission Final Test Mode Description Mode 1 TX For Radiated Emission Final Test Mode Description Mode 1 TX Note: (1) The EUT use new battery. (2) The EUT is set to Continuous emission by short sensor. ` Page 8 of 28 Report No.: BZT-2014NT0801142F 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED Radiated Spurious…

Text truncated - open the document above for the full version.

Radiated Emission Test Setup in Chamber
