Huadoo V4 Intelligent Three-Proof Mobile Phone Quick Guide Thank you for your purchase of V4 Huadoo Mobile Phone. Please read this manual carefully, so that you can use your mobile phone in the best way. User Instructions The Company ́s products have approved the third-party certification and the water-proof test before leaving the factory. Non-artificial damage,one year warranty. If there are water drops on the screen, the sensitivity of the touch screen will be affected, thus causing malfunction. Please wipe the water drops off, before resuming the use. Exception Clause If allowed by the applicable laws, the Company shall neither compensate for any special, incidental, indirect and secondary damage due to the use of products covered and described in this Manual, nor for any loss of profits, data, goodwill or expected savings. The maximum liability for the loss is limited to the payment you have made for your product (except that compensation for damage shall be made in accordance with applicable laws in case of personal injury). Violators will be prosecuted. For errors in printing and out of date information in this manual, we will make timely corrections. These corrections will be included in the latest manual without prior notice. Huadoo Bright Group Limited reserves the right of final interpretation. The pictures in this Manual are for reference only. If the pictures are not the same as the physical objects, then the objects shall prevail; please refer to physical objects for mobile phone structure and other relevant parameters of the battery and the charger. The accessories attached to your mobile phone may vary from the model and the function of the product you have purchased. For the accessories, the physical objects in the packaging shall prevail. Safety Matters and Environmental Protection If you are going to make or answer a phone call while driving, please use earphones or park your car properly before using your mobile phone. Please turn off the device near medical devices or medical locations that are marked “no wireless devices”. Please turn off the mobile phone on the plane, and confirm the cancellation of the alarm clock or auto power-on setting, so as to avoid auto power-on. Waste battery should be put into the battery recycling bin rather than be discarded in household garbage. Avoid using the mobile phone at excessively high or low temperature and do not expose the mobile phone to strong sunlight or high humidity. When using water to flush the exterior of your mobile phone, please make sure that the battery cover, the lock catch, the screw hole rubber plug, the earphones and USB rubber plug port of the mobile phone are properly sealed, only then can the mobile phone be water-proof and dust-proof. Never use the device around a gas station, fuels or chemicals. Avoid interference with blasting: turn off the device at the site of blasting and comply with any relevant provisions. To ensure the best performance, please use original accessories and battery instead of connecting to incompatible products. Do not disassemble the mobile phone and please visit the designated professional services for maintenance if necessary. Please use the mobile phone within network coverage. In the case of an emergency, you may use the mobile phone to call 112 directly to seek service from your local phone network. Your device is a radio transmitter and receiver. Its design complies with the radio wave radiation limit suggested by the international standard (ICNRP). The standard is formulated by the independent science organization (ICNIRP) and contains certain safety coefficients, so as to ensure the safety of users of each age group with different health conditions. Please backup important information stored in the device, to avoid loss thereof. User Guide 1.1 Schematic Diagram of Appearance and Description on Keys 1. Earphone Jack 3. Volume + 5. Receiver 7. Distance/Light Sensor 9. Option Key 11. Return Key 13. Power Key 15. Rear Camera 17. Screw Lock 2. USB Charge Jack 4. Volume - 6. Front Camera 8. Touch Screen 10. Return to Main Interface 12. Microphone 14. Flash/Alternate to Flashlight 16. Loudspeaker 1.2 Installation and Removal of SIM Card/Micro SD-Card/Battery Charge 1. Open the rear cover: buckle the screw at the battery cover by an unlocking hang tag (or coin), rotate the screw at the left until the screw is loosened, and then remove the rear cover and the battery. Turn the screw lock to the left on the battery cover till it loosens 2. Insert the sheet metal of the SIM Card and Micro-SD Card face down, into the corresponding card slot and lock it. 3. First match the lower part of the battery with the mobile phone metal part in the direction of Arrow 1 and then press the battery into the battery slot in the direction of Arrow 2. 4. Close and lock the rear cover. Turn the screw lock to the right on the battery cover till it locks. 5. Charge. 6. Use the shortcut key to turn the power display on and off and press on the power key to turn the mobile phone on/off. Press on the power key. Please make sure that the battery cover, the lock catch of the battery cover, the screw hole rubber plug, the earphones and USB rubber plug port of the mobile phone are properly sealed, only then can the mobile phone be water-proof and dust-proof. This point will not be covered again. When you install or remove a SIM Card, please turn off and cut off all power connected to the mobile phone first. ■ 1.3 Specification Parameters of Mobile Phones Type of mobile phone Three-proofmobilephone,3Gmobile phone,smart phone Operating system Android 4.4.2 System GSM：850/900/1800/1900 WCDMA：850/1900/2100 Size (154*84*16.8) mm Weight 283 g Chip MTK6582 Quad-core (1.3GHz) Default memory capacity of mobile phone ROM :8GB RAM : 1GB Maximum memory capacity of Micro-SD Card: 32G Display screen OGS 5.0`` QHD（540*960） Dual SIM Dual Standby Dual SIM Dual Standby Network type WCDMA/GPRS/EDGE/WAP Battery capacity 3600mAh Operat…

Text truncated - open the document above for the full version.

Shenzhen Huadoo Bright Group Limited Date: 7 January, 2015 To : Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Shenzhen Huadoo Bright Group Limited, the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen BALUN Technology Co.,Ltd., to act on the behalf of the Shenzhen Huadoo Bright Group Limited solely in matters relating to the application for an FCC equipment authorization for FCC ID # 2ACXS-V4 including the signing of documents in connection with this Application. Necessary acts carried out by Shenzhen BALUN Technology Co., Ltd. on our behalf of the Shenzhen Huadoo Bright Group Limited in connection with the Application shall have the same effect as acts of the Shenzhen Huadoo Bright Group Limited. The Shenzhen Huadoo Bright Group Limited also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, Terry Yuan [email protected] Shenzhen Huadoo Bright Group Limited

Shenzhen Huadoo Bright Group Limited Date: 14 Oct, 2014 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Shenzhen Huadoo Bright Group Limited FCC ID: 2ACXS-V4 FCC Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Shenzhen Huadoo Bright Group Limited requests that the following documents regarding this submission for FCC ID: 2ACXS-V4 be kept confidential: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Circuit Diagram.pdf Operational Description circuit description for fcc.pdf Part list BOM.pdf Tune-Up-Procedure Tune up procedure.pdf Those documents contain detailed system and equipment description and related information about the product which Shenzhen Huadoo Bright Group Limited considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Shenzhen Huadoo Bright Group Limited considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours Sincerely, Terry Yuan [email protected] Shenzhen Huadoo Bright Group Limited

Date: January 7, 2015 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: 2ACXS-V4 label location justification Gentlemen: Shenzhen Huadoo Bright Group Limited requests acceptance of the labeling proposal described below for Smart Phone bearing FCC identifier 2ACXS-V3 The subject Smart Phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 22H&24E for mobile services. Figure 1 Because the majority of the cell phone housing is composed of display, speaker, operating controls and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, Shenzhen Huadoo Bright Group Limited proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. Figure 2 The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), Infinity System S.L. will add the FCC identifier "2ACXS-V4 " to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter. Yours Sincerely, Wu Xuewen Certification manager Shenzhen BALUN Technology Co., Ltd.

Report No.: BL-SZ14C0012-604 ANNEX C TEST SETUP PHOTOS C.1 Appearance of the EUT THE FRONT OF EUT THE BACK OF EUT Report No.: BL-SZ14C0012-604 THE LEFT OF EUT THE RIGHT OF EUT Report No.: BL-SZ14C0012-604 THE UP OF EUT THE DOWN OF EUT Report No.: BL-SZ14C0012-604 CHARGER USB CABLE Report No.: BL-SZ14C0012-604 EARPHONE

Label and Label Location Label: Label Location:

Report No.: BL-SZ14C0012-604 C.2 Inside of the EUT EUT UNCOVER VIEW 1 EUT UNCOVER VIEW 2 Report No.: BL-SZ14C0012-604 EUT UNCOVER VIEW 3 EUT UNCOVER VIEW 4 GSM Antenna Report No.: BL-SZ14C0012-604 EUT UNCOVER VIEW 5 EUT UNCOVER VIEW 6 BT/WIFI Antenna GPS Antenna NFC Antenna Report No.: BL-SZ14C0012-604 EUT UNCOVER VIEW 7 BATTERY WIFI/BT Antenna Feed Point GPS Antenna Feed Point Report No.: BL-SZ14C0012-604 MAIN BOARD TOP VIEW 1 MAIN BOARD TOP VIEW 2 GSM Antenna Feed Point Report No.: BL-SZ14C0012-604 MAIN BOARD BACK VIEW 2 MAIN BOARD TOP VIEW 3 Report No.: BL-SZ14C0012-604 MAIN BOARD BACK VIEW 3 MAIN BOARD TOP VIEW 4 Report No.: BL-SZ14C0012-604 MAIN BOARD BACK VIEW 4 MAIN BOARD TOP VIEW 5 WIFI/BT Antenna Feed Point GPS Antenna Feed Point Report No.: BL-SZ14C0012-604 MAIN BOARD BACK VIEW 5 MAIN BOARD TOP VIEW 6
