2ACXX-LS-RSKActuator Remote Control System

* systems control one actuator; two actuators or more actuators in synchronously or independently available;* different remotes models and controller housing case for option. 1. Working Voltage: 10 ~14V DC 4. Controller Waterproof: IP66~IP67 2. Frequency: 433.92 Mhz 5. Max Current: 20 A 3. Working Teperature 6. Static Current 0.06mA INSTALLATION INSTRUCTIONS ---Remote Control System Series Kits (LS-RSK-2b) Jumper S1 Open, Jumper S2 ClosedIf the remotes lost, unavailable or broken, the switch on the board will be abutton for emergency.Press a time the actuators moving out, press 2 times quickly the actuatorsretracting back. A. New Remotes Program 3. Main Specifications: E-mail: [email protected] ; Tel: +86-20-3916 5188 / 3916 5268; Fax: +86-20-62351526-0291; No.1, Hongbafang Industrial Park, Shilian Road, Guanchong, Shiji, Panyu District, Guangzhou (511450), China -35 ~ 70 °C Jumper S1 Open, Jumper S2 OpenOpen the controller case and power the PCB to 12VDC, press the switch on the board and the LEDlighting; then press any button of the remote to theLED off.* At meanwhile, 2 remotes programmed at most.Andthe third programmed remote will erase the firstone...Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that maycause undesired operation.NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residentialinstallation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:-- Reorient or relocate the receiving antenna.-- Increase the separation between the equipment and receiver.-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.-- Consult the dealer or an experienced radio/TV technician for help. 1. Remotes & Connection Guide:2. Operation Instruction: B. Automatic Operation C. Manual Operation D. Emergecy Manual Operation Jumper S1 Open, Jumper S2 OpenPress"UP" a time, yellow and white wire output, actuatormoving out; press "UP" again to stop.Press"DN" a time, blue and green wire output, actuatorretract; press "DN" again to stop.If press "DN" when the actutor moving out,or if press "UP"when the actutor retracting back; then the actutor will berunning in reverse directly and immediately. Jumper S1 Closed, Jumper S2 OpenPressing and hold on the "UP" or "DN" button tocontrol the actuators moving out or retracking back.The actuators will not working if you not keep yourfinger pressing onto the button.
