M104A Tab l e t PC User manual Instruction Manual 1 What's Included The following components are included with your purchased product: - Tablet PC - Power Adapter - USB Cable - Instruction Manual 2 Getting Started Before operating your Tablet PC for the first time, please read this manual carefully and follow the instructions as below. 3 Battery charging The tablet is equipped with a built-in rechargeable Lithium battery. It is suggested to fully charge the battery before use. We strongly recommend to use the power adapter included in the packaging, using other adapter may damage the tablet and void the warranty. Charging Process - Connect the power adapter to your tablet, and plug the power adapter to the nearest electrical outlet. - Users can still use the tablet while it is being charged. 4 Appearance and buttons 4.1 Front Camera 4.2 Rear Camera 4.3 HOME Tapping on HOME button will return to the main interface. 4.4 Volume + 4.5 Volume- Press on the Volume +,Volume - buttons to increase or decrease the sound volume. 4.6 Speaker 4.7 Headphone Socket 3.5 mm standard earphone jack 4.8 Micro USB Micro USB port: you can use it to connect to PC for data transmission, charging or connection with external USB devices. 4.9 TF Card Slot Micro SD card slot 4.10 Micro USB Mini USB port: you can use it to connect to U disk and key board for data transmission, 4.11 HDMI output interface HDMI output interface 4.12 Power Socket 4.13 Power Switch Turn on/off tablet 5 Turn ON/OFF Tablet 5.1 Turn On: after the battery has been fully charged, press & hold the power switch for around 3 seconds to turn on the device. Screen lock will be showed after starting up. 5.2 Turn Off: When the tablet is ON, press & hold the power switch for around 3 seconds and the system will popup out power off option, tap on it to turn the tablet off. 5.3 Lock screen: quickly press Power Switch and release to lock screen. 5.4 Unlock screen: slide the lock icon rightward onto the unlock icon to unlock the screen and go to main interface; Slide the lock icon leftward onto the camera icon to open camera. Remarks: - When battery power has been used up, the tablet will shut down itself automatically. - If you illegally turn off the device, restart will scan and restore the disk, it may take longer time to enter into system. 6 Connection with PC 6.1 Use the USB cable provided to connect the tablet with PC, device will pop up the USB connection window, click “Turn on USB storage” to connect to PC, in the connection mode, you can copy or delete the file on the device or the file on the memory device. 7 Tablet Operation Interface 7.1 After starting up, you will enter into below main screen interface 7.2 In the main interface, you can manage main interface software icons: press the icon and hold it for 3 seconds, then you can drag anywhere in the main interface. 7.3 Delete icons: press the icon and hold it for 3 seconds, and drag the icon onto the “Remove” icon, then you can delete that icon from Desktop. 7.4 Touch the screen and hold for around 4 seconds, the dialog box “Choose wallpaper from” will pop out as shown below: You can choose the wallpaper from different sources and change the Wallpaper 7.5 Status Bar Descriptions From left to right: Back to previous interface, Back to main interface, Display the Apps performed previously, Menu key, USB connected, USB connected, USB debugging connected,TF-card information, Current time, battery charge icons, current time. 7.6 Quick Guide For Touch Operations - No matter which interface you are on the screen, you can go back to main screen by tapping the key located at the left bottom corner of the main screen. [Attention] The key functions as back to main screen interface. - During options, by tapping the back key at the left bottom corner of the touch screen, you can return to previous screen interface. - Click to see all history of Apps performed previously. - In the main interface, you can touch the icon to see all the APPS, tap on any App icon and hold it for around 3 seconds, you can drag that App icon onto main screen interface. 8 Basic Settings 8.1 WIRELESS & NETWORKS - Wi-Fi Ta p o n setting icon, then ap on the “OFF” to open Wi-Fi, All available Wi-Fi networks will be listed, tap on your Wi-Fi network and start to connect. If the Wi-Fi network does not need a password, tap "connect" to start the connection. If the Wi-Fi network needs a password, then input the password and tap “connect” to start the connection. If the Wi-Fi network has been successfully connected before, that information will be stored. Connection will be done automatically. Once your tablet connects to Wi-Fi successfully, the Wi-Fi icon will appear on the status bar at the below of the screen. - Bluetooth Select to turn on/off of Bluetooth, connect with Key board or mobile phone. - Data Usage Select to turn on/off Mobile data, Set mobile data limit. - More... Select to turn on/off Airplane mode, to setup Ethernet connection, VPN and Mobile networks. 8.2 DEVICE - Sound Settings on Volume, Ringtone & Notifications, you can also tick to select or untick to unselect for Vibrate and ring,Touch sounds, Screen lock sound and Vibrate on touch. - Display Settings on LCD Panel brightness,Wallpaper, Auto-rotate screen, sleep, Font size, Accelerometer coordinate system, Screen adaption. - Storage To view the available storage space, Erase SD card(format the internal memory) and select the option of enabling media scanning of external SD card or external USB devices [Remarks]: 1. If you want to safely remove the Micro SD card or USB flash drive, please tap on the option “Unmount SD card”, and confirm the selection, after this, you can safely remove SD card/USB host. 2. Make sure to tick the option of “Enable media scanning on extsd” and “Enable media scanning on usbhost 1”, this way, your tablet can scan and display the files in the external TF card and USB devices. - Battery To know the battery usage information - Apps To Manage …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 Zhongshan Seiyo Electronic Technology CO., LTD. 2014/8/12 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____ Zhongshan Seiyo Electronic Technology CO., LTD. _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： TABLET PC Trade Name： N/A Model Name： M104A Serial Model： N/A FCC ID： 2ACYO-M104A Sincerely, Signature Name: guiziduan Title: Manager Address: NO.77 Yugangwan Garden NO.106 Zhongshangan Road Huoju Development Zone Zhongshan City, Guangdong, China SCS-F18: Project and Product Certification Representative Authorization Letter Page 3 of 3 Rev 4.0 Zhongshan Seiyo Electronic Technology CO., LTD. 2014/8/14 To: SIEMIC, Inc. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, ____ Zhongshan Seiyo Electronic Technology CO., LTD._ __hereby authorize SIEMIC, Inc. to act as Certification Body for certifying for the following project(s): Product： TABLET PC Trade Name： N/A Model Name： M104A Serial Model： N/A FCC ID： 2ACYO-M104A We affirm that between SIEMIC, Inc. and _____ Zhongshan Seiyo Electronic Technology CO., LTD.__, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature Name: guiziduan Title: Manager Address: NO.77 Yugangwan Garden NO.106 Zhongshangan Road Huoju Development Zone Zhongshan City, Guangdong, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 Zhongshan Seiyo Electronic Technology CO., LTD. 2014/8/14 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ACYO-M104A We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Name: guiziduan Title: Manager Address: NO.77 Yugangwan Garden NO.106 Zhongshangan Road Huoju Development Zone Zhongshan City, Guangdong, China

Zhongshan Seiyo Electronic Technology CO., LTD. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2014/8/14 SUBJECT: FCC Application for (FCC ID: 2ACYO-M104A) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Name: guiziduan Title: Manager Address: NO.77 Yugangwan Garden NO.106 Zhongshangan Road Huoju Development Zone Zhongshan City, Guangdong, China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

FCC ID LABELING AND LOCATION FCC ID Label TABLET PC Model NO.: M104A FCC ID:2ACYO-M104A Zhongshan Seiyo Electronic Technology CO., LTD. Made in China This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 WiFi&BT Antenna Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID : 2ACYO-M104A RF EXPOSURE EVALUATION METHOD FCC ID: 2ACYO-M104A SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Maximum measured transmitter power. WIFI: TX 802.11b Mode Frequency Maximum Peak Conducted Output Power（PK） Maximum Peak Conducted Output Power（AV） Maximum Peak Conducted Output Power （AV） Te s t Channe (MHz) (dBm) (dBm) (mW) CH01 2412 12.64 9.67 9.268 CH06 2437 12.57 9.61 9.141 CH11 2462 12.42 9.65 9.226 TX 802.11g Mode CH01 2412 11.82 8.77 7.534 CH06 2437 11.79 8.74 7.482 CH11 2462 11.72 8.67 7.362 TX 802.11n(20) Mode CH01 2412 10.88 8.61 7.261 CH06 2437 10.76 8.48 7.047 CH11 2462 10.72 8.44 6.982 TX 802.11n(40) Mode CH03 2422 9.99 7.62 5.781 CH06 2437 9.94 7.57 5.715 CH09 2452 9.88 7.51 5.636 FCC ID : 2ACYO-M104A BT3.0: 1Mbps Test Channel Frequency (MHz) Peak Output Power (dBm) Peak Output Power (mW) CH00 2402 4.32 2.704 CH39 2441 4.77 2.999 CH78 2480 4.88 3.076 2Mbps CH00 2402 3.79 2.393 CH39 2441 4.20 2.630 CH78 2480 4.35 2.723 3Mbps CH00 2402 3.77 2.382 CH39 2441 4.20 2.630 CH78 2480 4.31 2.698 BT 4.0 Frequency Maximum Conducted Output Power Maximum Conducted Output Power Te s t Channe (MHz) (dBm) mW CH01 2402 -3.14 0.485 CH20 2440 -2.83 0.521 CH39 2480 -2.63 0.546 Remark: The best case gain of the antenna is 2.5dBi. 2.5 dBi logarithmic terms convert to numeric result is nearly 1.78 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)] FCC ID : 2ACYO-M104A WIFI: Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [√f(GHz)] Result Limit 802.11b CH01 9.268 5 2.412 2.88 3 CH06 9.141 5 2.437 2.85 3 CH11 9.226 5 2.462 2.90 3 802.11g CH01 7.534 5 2.412 2.34 3 CH06 7.482 5 2.437 2.34 3 CH11 7.362 5 2.462 2.31 3 802.11n(20) CH01 7.261 5 2.412 2.26 3 CH06 7.047 5 2.437 2.20 3 CH11 6.982 5 2.462 2.19 3 802.11n(40) CH03 5.781 5 2.422 1.80 3 CH06 5.715 5 2.437 1.78 3 CH09 5.636 5 2.452 1.77 3 BT3.0: Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [√f(GHz)] Result Limit 1Mbps CH00 2.704 5 2.402 0.838 3 CH39 2.999 5 2.441 0.937 3 CH78 3.076 5 2.480 0.969 3 2Mbps CH00 2.393 5 2.402 0.742 3 CH39 2.630 5 2.441 0.822 3 CH78 2.723 5 2.480 0.858 3 3Mbps CH00 2.382 5 2.402 0.738 3 CH39 2.630 5 2.441 0.822 3 CH78 2.698 5 2.480 0.850 3 FCC ID : 2ACYO-M104A BT4.0: Mode [(max. power of channel, including tune-up tolerance, mW) (min. test separation distance,mm)] [√f(GHz)] Result Limit 1Mbps CH00 0.485 5 2.402 0.150 3 CH19 0.521 5 2.440 0.163 3 CH39 0.546 5 2.480 0.172 3 The test Result is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Conclusion: No SAR is required.

FCC RADIO TEST REPORT-BT 3.0 FCC ID: 2ACYO-M104A Product： TABLET PC Trade Name： N/A Model Name： M104A Serial Model： N/A Report No.： NTEK-2014NT07311258F2 Prepared for Zhongshan Seiyo Electronic Technology CO., LTD. NO.77 Yugangwan Garden NO.106 Zhongshangan Road Huoju Development Zone Zhongshan City, Guangdong, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 66 Report No.:NTEK-2014NT07311258F2 TEST RESULT CERTIFICATION Applicant’s name................. Zhongshan Seiyo Electronic Technology CO., LTD. Address ................................. NO.77 Yugangwan Garden NO.106 Zhongshangan Road Huoju Development Zone Zhongshan City, Guangdong, China Manufacture's Name............ Zhongshan Seiyo Electronic Technology CO., LTD. Address ................................. NO.77 Yugangwan Garden NO.106 Zhongshangan Road Huoju Development Zone Zhongshan City, Guangdong, China Product description Product name ...........................TABLET PC Model and/or type reference M104A Serial Model： N/A Standards............................. FCC Part15.247 01 Oct. 2013 Test procedure .......................... ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: 31 July 2014 ~11 Aug. 2014 Date of Issue...........................................: 12 Aug. 2014 Test Result...............................................: Pass Testing Engineer : (Denny Huang) Technical Manager : (Brown Lu) Authorized Signatory : (Bill Yao) Page 3 of 66 Report No.:NTEK-2014NT07311258F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 23 4 . NUMBER OF HOPPING CHANNEL 24 4.1 APPLIED PROCEDURES / LIMIT 24 4.1.1 TEST PROCEDURE 24 4.1.2 DEVIATION FROM STANDARD 24 4.1.3 TEST SETUP 24 4.1.4 EUT OPERATION CONDITIONS 24 4.1.5 TEST RESULTS 25 5 . AVERAGE TIME OF OCCUPANCY 26 5.1 APPLIED PROCEDURES / LIMIT 26 Page 4 of 66 Report No.:NTEK-2014NT07311258F2 Table of Contents Page 5.1.1 TEST PROCEDURE 26 5.1.2 DEVIATION FROM STANDARD 26 5.1.3 TEST SETUP 27 5.1.4 EUT OPERATION CONDITIONS 27 5.1.5 TEST RESULTS 28 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 34 6.1 APPLIED PROCEDURES / LIMIT 34 6.1.1 TEST PROCEDURE 34 6.1.2 DEVIATION FROM STANDARD 34 6.1.3 TEST SETUP 34 6.1.4 EUT OPERATION CONDITIONS 34 6.1.5 TEST RESULTS 35 7 . BANDWIDTH TEST 41 7.1 APPLIED PROCEDURES / LIMIT 41 7.1.1 TEST PROCEDURE 41 7.1.2 DEVIATION FROM STANDARD 41 7.1.3 TEST SETUP 41 7.1.4 EUT OPERATION CONDITIONS 41 7.1.5 TEST RESULTS 42 8 . PEAK OUTPUT POWER TEST 48 8.1 APPLIED PROCEDURES / LIMIT 48 8.1.1 TEST PROCEDURE 48 8.1.2 DEVIATION FROM STANDARD 48 8.1.3 TEST SETUP 48 8.1.4 EUT OPERATION CONDITIONS 48 8.1.5 TEST RESULTS 49 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 55 9.1 DEVIATION FROM STANDARD 55 9.2 TEST SETUP 55 9.3 EUT OPERATION CONDITIONS 55 9.4 TEST RESULTS 56 10 . ANTENNA REQUIREMENT 64 10.1 STANDARD REQUIREMENT 64 10.2 EUT ANTENNA 64 11 . EUT TEST PHOTO 65 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 66 Report No.:NTEK-2014NT07311258F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 66 Report No.:NTEK-2014NT07311258F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 66 Report No.:NTEK-2014NT07311258F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment TABLET PC Trade Name N/A Model…
