Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 2 | 15E | 5.75 GHz - 5.83 GHz | 20.20 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesSingle Modular Approval.. Device is an 802.11a/n/ac/ax device in a 2x2 MIMO configuration as described in this filing. Output power listed is conducted. Grantee is responsible for providing specific testing instructions to host manufacturers for additional testing to verify compliance as a composite system. This includes retesting of transmitter module per part 15.31(h) and (k) and verification of compliance with FCC RF Exposure requirements. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This device complies with the Dynamic Frequency Selection (DFS) requirements of KDB 905462 D03 as a Client only without Radar Detection. The device contains 20MHz, 40MHz and 80MHz bandwidth.
