2ACZO-USR-EG828ARM based Computer

USR-IOT USR-EG828 ARM based Computer Linux Ubuntu20.044-core64-bitARM architectureCPU Rich InterfacePowerfuledge Computingapplication Node-REDPerfectHardwareDrivers Open source controller RobotControl FactoryAutomationEnergyManagement Introduction USR-EG828high-performanceopensourcegatewaycontroller,usingRK3568chip,4-core64-bit high-performanceARMarchitectureCPUdesign,mainfrequencyupto2.0G,hassupergeneral computingperformance,CPUintegratesAIneuralnetworkprocessorNPU,computingperformanceup to1.0TOPS,supportsavarietyofAIdevelopmenttoolsandinterfaces. Built-inLinuxUbuntu20.04system,supportdesktop,convenientdevelopmentanddesign.The producthardwareinterfaceisrich,thesupportingdriveisperfect,thestartisalreadyavailable.Built-in cellular4Gnetworking,twoEthernetinterfaceandoneWIFIinterface,realizingavarietyofnetworking functions,externaldesignofmulti-serialport,USB3.0interface,HDMIinterface,AI,DI,andDOand otheranalogacquisitionandswitchacquisitionandcontrolinterface,richinterfacedesigncanmeet theuseofdifferentscenariosoftheproduct.Theproductsupportstheinstallationofguiderailand hangingear,convenientandquick。 ProductFeatures RK3568,ARMarchitecturequad-core64-bitCPU,withafrequencyof2GHz,deliveringhigh performanceandfastoperation. DualnetworksupportwithparallelLTE4GandEthernet,ensuringstablenetworktransmission withoutdowntime.ItalsosupportsWiFicommunication,cateringtodifferentnetwork requirements. AbundantinterfacesincludingHDMIoutput,2*USB3.0ports,and1*CANinterface. Multipleserialports,includingtwoRS485andtwoRS232ports,maximizingcompatibilitywith externaldevices. MultipleIOinterfaces,including4*AI(AnalogInput),2*DO(RelayDigitalOutput),4*DI(Digital Input). StandardLinuxUbuntusystemwithagraphicalinterfaceformoreconvenientoperations. EmbeddedNode-REDgraphicaldesignmakesdevelopmentsimplerandfaster,allowingthe loadingofmoreprotocollibrariesforrapidprogramming. Powerfuledgegatewaycapabilities,supportingedgecollection,edgecomputing,grouped reporting,andcapableofcollecting2000actualpoints. Richcollectionprotocols,supportingstandardModbusandvariousmainstreamPLCprotocol collections,aswellascollectionsforvariousindustryprotocols. Jointcontrolsupportsmulti-pointlinkage,supportsjointSMSalarms,jointplatformalarms,joint pointcontrol,andjointDOcontrol. Multipleprotocolconversions,integratingvariousprotocolconversionssuchasModbusandOPC UA,Bacnet. ProductParameter SmartMedical SmartAgricultureSmartBuilding CPU RockchipRK3568 Quad-coreARMCortex-A5564bitCPU,upto2.0GHz GPU ARMG522EEGPU SupportOpenGLES1.1/2.0/3.2,OpenCL2.0,Vulkan1.1,embeddedhigh performance2Daccelerationhardware NPU 1.0TOPS@INT8 SupportCaffe/Mxnet/TensorFlow/TFLite/ONNX/Darknetmodels. operatingsystemLinuxUbuntu20.04 RAMDDR44GB MemoryeMMC32GB network Dual10/100Ethernetports 2.4GHzWi-Fi802.11b/g/n 4Gmobilenetwork GPS GPS,GLONASS,BDS,GalileoandQZSS Protocol:NMEA0183 Dataupdaterate:1Hzbydefault Sensitivity:-162dBm Receivefrequency:1575.42MHz AcquisitionAutonomous-146dBmTrackingAutonomous-157dBm Accuracy:Autonomous@opensky10m SIM1*SIMslotNano-SIM(4FF) Displays1*HDMIOUT2.0,4K60fps Audio1*Earoutput RTCBuilt-inreal-timeclockbattery,supportsscheduledpoweron/off. USB 1*USB3.0HOST 1*USB3.0OTG LED 1*PowerLED(RED),1*SystemLED(Blue,blinking) 2*DOLED 4*DILED Button1*upgradeforOTA,REC SerialPorts 2*RS232,2*RS485 IO 4*DI：dry/wetcontact --DIvoltagerange0-36V(Max.36V),High5-36V,Low0-2V 2*DO：Relay --DOMax.10A-277VAC/28VDCforNO,5A-250VACforNC 4*AI：Analogquantity --Voltagerange0-10v;AnaloginputCurrentrange4~20mA PowerInput DC12V/2A(Max.15V) Connector:JackBarrelTypeDC5.5*2.1mmRoundsocket WorkingTemperature-10-70°C StorageTemperature-20-70°C WorkingHumidity10%-80% Dimension160mm*85mm*28mm Multi-media Supportfor4K60fpsH.265/H.264Videodecoding Supportfor1080P100fpsH.265/H.264Videodecoding Supportfor8MISP,andsupportforHDR Language DefaultEnglish,andyoucandownloadotherlanguagesonline InputMethodStandardAndroidkeyboard,optionalthird-partyinputmethod(Chinese, Korean,Japanese,etc.) Dimensions&Details OrderingGuide ModelEthernetCellularRegionBands USR-EG828-G4 √ LTE Cat 4 China,Parts of SoutheastAsia LTE TDD ：Band 34 /38/39/40/41 LTE FDD ：Band 1/3/5/8 GSM ：900/1800MHz USR- EG828-GL√LTE Cat 4Global LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13/ B18/B19/B20/B25/B26/B28/B66 LTE-TDD:B34/B38/B39/B40/B41 WCDMA:B1/B2/B4/B5/B6/B8/B19 GSM: B2/B3/B5/B8 GPS ：GPS/GLONASS/BDS/Galileo/QZSS This product complies with the radio interference requirements of the European Community. Product name: ARM based Computer Product model: USR-EG828 Manufacturer: Jinan USR IOT Technology Limited Frequency Range: BT+BLE: 2402~2480MHz; WiFi 2.4G: 2412~2472MHz; GSM900: 880~915MHz; DCS1800: 1710~1785MHz; WCDMA Band I: 1920-1980 MHz; WCDMA Band VIII: 880-915MHz; FDD Band1: 1920~1980MHz; FDD Band3: 1710~1785MHz; FDD Band7: 2500~2570MHz; FDD Band8: 880~915MHz; FDD Band20: 832~862MHz; FDD Band28: 703-736 MHz; TDD Band34: 2010~2025MHz; TDD Band38: 2570-2620 MHz; TDD Band40: 2300-2400 MHz; GPS L1C/A: 1575.42MHz Max. Transmit Power: BT: 3.05dBm Max; BLE: 2.74dBm Max; WiFi 2.4G: 16.86dBm Max; GSM900: 31.23dBm Max; GSM1800: 23.93dBm Max; WCDMA Band I: 21.48dBm Max; WCDMA Band VIII: 22.69Bm Max; FDD Band1: 22.30dBm Max; FDD Band3: 22.42dBm Max; FDD Band7: 23.06dBm Max; FDD Band8: 22.33Bm Max; FDD Band20: 23.23dBm Max; FDD Band28: 23.06dBm Max; FDD Band34: 22.10dBm Max; FDD Band38: 21.52dBm Max; FDD Band40: 21.78dBm Max; SIMPLIFIED EU DECLARATION OF CONFORMITY The simplified EU declaration of conformity referred to in Article 10(9) shall be provided as follows: Hereby, Jinan USR IOT Technology Limited declares that radio equipment type USR-EG828 is in compliance with Directive 2014/53/EU, and this product is allowed to be used in all EU member states. This product can be used across EU member states. Adapter shall be installed near the equipment and shall be easily accessible. RF warning statement: The device has been evaluated to meet general RF exposure requirement. To maintain compliance with RF exposure requirement, use p…

Text truncated - open the document above for the full version.

ReportNo.:1812C40114912502Page1of32 FCCID:2ACZO-USR-EG828 FCCTestReport Applicant:JinanUSRIOTTechnologyLimited Address: FloorF1&PartofFloorF2,BuildingNo.9,Diya ShuangChuanglndustrialZone,No.2566, CenturyMainRoad,GaoxinDistrict,Jinan, Shandong,China ProductName:ARMbasedComputer ReportDate:Dec.11,2024 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:1812C40114912502Page2of32 FCCID:2ACZO-USR-EG828 Contents 1.GeneralInformation.................................................................................................................................6 1.1.ClientInformation...........................................................................................................................6 1.2.DescriptionofDevice(EUT)..........................................................................................................6 1.3.AuxiliaryEquipmentUsedDuringTest..........................................................................................7 1.4.Operationchannellist....................................................................................................................7 1.5.DescriptionofTestModes.............................................................................................................7 1.6.MeasurementUncertainty.............................................................................................................8 1.7.TestSummary................................................................................................................................8 1.8.DescriptionofTestFacility.............................................................................................................9 1.9.Disclaimer......................................................................................................................................9 1.10.TestEquipmentList...................................................................................................................10 2.Antennarequirement..............................................................................................................................12 2.1.Conclusion...................................................................................................................................12 3.ConductedEmissionatACpowerline..................................................................................................13 3.1.EUTOperation.............................................................................................................................13 3.2.TestSetup....................................................................................................................................13 3.3.TestData......................................................................................................................................14 4.6dBBandwidth.......................................................................................................................................16 4.1.EUTOperation.............................................................................................................................16 4.2.TestSetup....................................................................................................................................16 4.3.TestData......................................................................................................................................16 5.MaximumConductedOutputPower......................................................................................................17 5.1.EUTOperation.............................................................................................................................17 5.2.TestSetup....................................................................................................................................17 5.3.TestData......................................................................................................................................17 6.PowerSpectralDensity..........................................................................................................................18 6.1.EUTOperation.............................................................................................................................18 6.2.TestSetup....................................................................................................................................18 6.3.TestData......................................................................................................................................18 7.Emissionsinnon-restrictedfrequencybands.......................................................................................19 7.1.EUTOperation.............................................................................................................................19 7.2.TestSetup....................................................................................................................................19 7.3.TestData......................................................................................................................................19 8.Bandedgeemissions(Radiated)..........................................................................................................20 8.1.EUTOperation.............................................................................................................................20 8.2.TestSetup....................................................................................................................................21 8.3.TestData......................................................................................................................................22 9.Emissionsinfrequencybands(below1GHz).......................................................................................23 9.1.EUTOperation...................................................................................................................…

Text truncated - open the document above for the full version.

ProjectNo.:1812C401149125Page1of2 AppendixI--TestSetupPhotograph_RF ConductedEmissionatACpowerline Emissionsinfrequencybands(below1GHz) ProjectNo.:1812C401149125Page2of2 Emissionsinfrequencybands(above1GHz)

文档受控编号：JF-QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或深圳0755-23076842 1 承认书 SPECIFICATIONFORAPPROVAL 客户名称 CustomerName： 客户料号 CustomerP/N： 劲风料号 JingFengP/N：JF7767-7 规格描述 SpecificationDescription：SMA(Maleneedle)-RG174-Dualfrequency suckerantenna-L3000MM 制作日期 ProductionDate： 2024-05-18 出厂确认（FactoryConfirmation）： 部门 （Department） 审核 (CHECKEDBY) 批准 (APPROVEDBY) 射频部 (RFDepartment) ZhangYaYongWangShuo 结构部 (StructureDepartment) LiangSenWangShuo 品质部 (QualityDepartment) LiuXiaoJunWangShuo 客户确认（CustomerConfirmation）： 检查 (INSPECTION) 审核 (CHECKED) 批准 (APPROVED) 文档受控编号：JF -QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或 深圳0755-23076842 2 △ 文件制定、修改、废止记录(RecordOf DocumentFormulation,ModificationAnd Abolishment) 文件名称 (Filename) 日 期 (Date) 控制版次 （Control version） 关联内容 (Relatedcontent) 制 定 (Formulate) 批 准 (Approved) 样品承认书 (Sample Approved) 20 23 .05.18V1FirstLiangSenWangShuo Manufacturer: Beijing Jinfeng Technology Co.,LTD Address: 1701-8 Huaqiao Apartment, Yayuncun, Chaoyang District, Beijing, China. 文档受控编号：JF -QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或 深圳0755-23076842 3 目录 Contents 1、封面 /签字页面(CoverSignaturePage)..............................1 2、文本控制记录(TextControlRecord).................................2 3、目 录(Contents)............................................................3 4、产品性能参数(MainTechnicalSpecifications)..................4 5、产品结构图纸(ProductStructureDrawing)........................5 6、电气性能测试报告(ElectricalPerformanceTest Report)...............................................................6~10 文档受控编号：JF-QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或深圳0755-23076842 4 4、产品性能参数(Maintechnicalspecifications) 电气参数(ElectricalParameters) 频率范围FrequencyRange(MHZ) 2400-2500MHz 5150-5850MHz 输入阻抗Impedance(Ω)50Ω 驻波比VSWR≤2.0 增益PeakGain(dBi) 5±0.5dBi 功率容量PowerCapacity3W 耐压测试WithstandVoltageTest1KV 极化方式PolarizationLinear，Vertical 辐射方向RadiationOmni-Directional 连接方式ConnectorTypeSMA(maleneedle) 机械参数MechanicalParameters 外露尺寸Length(mm) L=3000±30MM 盐雾试验SaltSprayTest24H 同轴线类型CableTypeRG174Black 环境参数EnvironmentalParameters 工作温度OperatingTemp-20°C~+65°C 储存温度StorageTemp -30°C~+75°C 文档受控编号：JF -QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或 深圳0755-23076842 5 5、产品构图纸（Productdrawing） 文档受控编号：JF -QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或 深圳0755-23076842 6 6、电气性能测试报告（ElectricalPerformanceTestreport） VSWR ReturnLoss 文档受控编号：JF-QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或深圳0755-23076842 7 效率&增益（Efficiency&gain）： FreqEffiGain (MHz)(%)(dBi) 2400 56.085.12 2410 60.744.85 2420 51.664.93 2430 55.494.84 2440 58.414.81 2450 57.594.92 2460 61.175.07 2470 63.185.03 2480 55.944.81 2490 50.514.89 2500 52.514.84 FreqEffiGain (MHz)(%)(dBi) 5100 56.255.11 5200 56.474.73 5300 56.64.82 5400 57.024.93 5500 57.844.75 5600 57.025.11 5700 57.495.02 5800 58.255.26 5900 59.655.22 文档受控编号：JF -QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或 深圳0755-23076842 8 3D Radiationpattern： 文档受控编号：JF-QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或深圳0755-23076842 9 2DRadiationpattern： 文档受控编号：JF -QS-WJ-023.存档期：7年.文件涉及到相关项目技术设计参数，如有任何需要沟通的 信息可以联系公司电话：北京010-80257683或 深圳0755-23076842 10

ReportNo.:1812C40114912503Page1of36 FCCID:2ACZO-USR-EG828 FCCTestReport Applicant:JinanUSRIOTTechnologyLimited Address: FloorF1&PartofFloorF2,BuildingNo.9,Diya ShuangChuanglndustrialZone,No.2566, CenturyMainRoad,GaoxinDistrict,Jinan, Shandong,China ProductName:ARMbasedComputer ReportDate:Dec.11,2024 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:1812C40114912503Page2of36 FCCID:2ACZO-USR-EG828 Contents 1.GeneralInformation.................................................................................................................................6 1.1.ClientInformation...........................................................................................................................6 1.2.DescriptionofDevice(EUT)..........................................................................................................6 1.3.AuxiliaryEquipmentUsedDuringTest..........................................................................................7 1.4.Operationchannellist....................................................................................................................8 1.5.DescriptionofTestModes.............................................................................................................8 1.6.MeasurementUncertainty.............................................................................................................8 1.7.TestSummary................................................................................................................................9 1.8.DescriptionofTestFacility...........................................................................................................10 1.9.Disclaimer....................................................................................................................................10 1.10.TestEquipmentList....................................................................................................................11 2.Antennarequirement..............................................................................................................................13 2.1.Conclusion...................................................................................................................................13 3.ConductedEmissionatACpowerline..................................................................................................14 3.1.EUTOperation.............................................................................................................................14 3.2.TestSetup....................................................................................................................................14 3.3.TestData......................................................................................................................................15 4.6dBBandwidth.......................................................................................................................................17 4.1.EUTOperation.............................................................................................................................17 4.2.TestSetup....................................................................................................................................17 4.3.TestData......................................................................................................................................17 5.MaximumConductedOutputPower......................................................................................................18 5.1.EUTOperation.............................................................................................................................18 5.2.TestSetup....................................................................................................................................18 5.3.TestData......................................................................................................................................18 6.PowerSpectralDensity..........................................................................................................................19 6.1.EUTOperation.............................................................................................................................19 6.2.TestSetup....................................................................................................................................19 6.3.TestData......................................................................................................................................19 7.Emissionsinnon-restrictedfrequencybands.......................................................................................20 7.1.EUTOperation.............................................................................................................................20 7.2.TestSetup....................................................................................................................................20 7.3.TestData......................................................................................................................................20 8.Bandedgeemissions(Radiated)..........................................................................................................21 8.1.EUTOperation.............................................................................................................................21 8.2.TestSetup....................................................................................................................................22 8.3.TestData......................................................................................................................................23 9.Emissionsinfrequencybands(below1GHz).......................................................................................27 9.1.EUTOperation....................................................................................................................…

Text truncated - open the document above for the full version.

Page 1 of 59 AppendixTestData ReportNo:1812C40114912503TestSampleNO:1-2-2 StartTestDate：2024.10.31FinishTestDate:2024.10.31 TestEngineer:Auditor: Temperature:22.1 °C RelativeHumidity:56% Pressure:101kPa AppendixA:DTSBandwidth TestResult TestModeAntennaFrequency[MHz] DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11BAnt1241210.242406.842417.080.5PASS 11BAnt1243710.282431.842442.120.5PASS 11BAnt1246210.242456.842467.080.5PASS 11GAnt1241216.242403.722419.960.5PASS 11GAnt1243716.122428.922445.040.5PASS 11GAnt1246216.042453.842469.880.5PASS 11N20SISOAnt1241217.042403.442420.480.5PASS 11N20SISOAnt1243717.362428.362445.720.5PASS 11N20SISOAnt1246217.682453.122470.800.5PASS 11N40SISOAnt1242235.842404.002439.840.5PASS 11N40SISOAnt1243735.362419.642455.000.5PASS 11N40SISOAnt1245234.642434.162468.800.5PASS Page 2 of 59 TestGraphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS Page 3 of 59 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS Page 4 of 59 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS Page 5 of 59 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS Page 6 of 59 11N20SISO-Ant1-2462-PASS 11N40SISO-Ant1-2422-PASS Page 7 of 59 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS Page 8 of 59 AppendixB:OccupiedChannelBandwidth TestResult TestModeAntenna Channel Frequency[MHz] OCB [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict 11BAnt1241215.2652404.32772419.5924------ 11BAnt1243715.3052429.36762444.6723------ 11BAnt1246215.3052454.28772469.5924------ 11GAnt1241216.9832403.32872420.3117------ 11GAnt1243716.8232428.52852445.3516------ 11GAnt1246217.1432453.44862470.5914------ 11N20SISOAnt1241218.3022402.84922421.1508------ 11N20SISOAnt1243718.1422427.96902446.1109------ 11N20SISOAnt1246218.3422452.92912471.2707------ 11N40SISOAnt1242237.4032402.73932440.1419------ 11N40SISOAnt1243737.2432418.13892455.3816------ 11N40SISOAnt1245237.0032433.61842470.6214------ Page 9 of 59 TestGraphs 11B-Ant1-2412 11B-Ant1-2437 Page 10 of 59 11B-Ant1-2462 11G-Ant1-2412 Page 11 of 59 11G-Ant1-2437 11G-Ant1-2462 Page 12 of 59 11N20SISO-Ant1-2412 11N20SISO-Ant1-2437 Page 13 of 59 11N20SISO-Ant1-2462 11N40SISO-Ant1-2422 Page 14 of 59 11N40SISO-Ant1-2437 11N40SISO-Ant1-2452 Page 15 of 59 AppendixC:Maximumconductedoutputpower TestResultAverage Test Mode Antenna Frequency [MHz] Set Power Average power [dBm] Duty Cycle [%] DC Factor [dB] Result [dBm] Limit [dBm] Verdict 11BAnt12412NA17.9199.030.0417.95≤30.00PASS 11BAnt12437NA17.67100.000.0017.67≤30.00PASS 11BAnt12462NA17.6999.030.0417.73≤30.00PASS 11GAnt12412NA17.9894.860.2318.21≤30.00PASS 11GAnt12437NA17.6592.730.3317.98≤30.00PASS 11GAnt12462NA17.7293.580.2918.01≤30.00PASS 11N20SISOAnt12412NA17.8594.030.2718.12≤30.00PASS 11N20SISOAnt12437NA17.5092.200.3517.85≤30.00PASS 11N20SISOAnt12462NA17.5494.530.2417.78≤30.00PASS 11N40SISOAnt12422NA17.3286.920.6117.93≤30.00PASS 11N40SISOAnt12437NA17.2888.570.5317.81≤30.00PASS 11N40SISOAnt12452NA17.3687.040.6017.96≤30.00PASS Note： 1.Thecablelossarecompensatedinthegraph Page 16 of 59 TestGraphsAverage 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS Page 17 of 59 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS Page 18 of 59 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS Page 19 of 59 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS Page 20 of 59 11N20SISO-Ant1-2462-PASS 11N40SISO-Ant1-2422-PASS Page 21 of 59 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS Page 22 of 59 AppendixD:Maximumpowerspectraldensity TestResult TestModeAntenna Frequency [MHz] Reading Result [dBm/3kHz] DC Factor [dB] Result [dBm/3kHz] Limit [dBm/3kHz] Verdict 11BAnt12412-13.660.04-13.62≤8.00PASS 11BAnt12437-13.60.00-13.60≤8.00PASS 11BAnt12462-13.290.04-13.25≤8.00PASS 11GAnt12412-14.960.23-14.73≤8.00PASS 11GAnt12437-15.10.33-14.77≤8.00PASS 11GAnt12462-15.330.29-15.04≤8.00PASS 11N20SISOAnt12412-15.450.27-15.18≤8.00PASS 11N20SISOAnt12437-15.570.35-15.22≤8.00PASS 11N20SISOAnt12462-15.870.24-15.63≤8.00PASS 11N40SISOAnt12422-17.720.61-17.11≤8.00PASS 11N40SISOAnt12437-17.580.53-17.05≤8.00PASS 11N40SISOAnt12452-17.660.60-17.06≤8.00PASS Note: 1.Thecablelossarecompensatedinthegraph. Page 23 of 59 TestGraphs 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS Page 24 of 59 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS Page 25 of 59 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS Page 26 of 59 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS Page 27 of 59 11N20SISO-Ant1-2462-PASS 11N40SISO-Ant1-2422-PASS Page 28 of 59 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS Page 29 of 59 AppendixE:Bandedgemeasurements TestResult TestModeAntennaChName Frequency [MHz] RefLevel[dBm]Result[dBm]Limit[dBm]Verdict 11BAnt1Low24128.73-39.7≤-21.27PASS 11BAnt1High24627.96-52.88≤-22.04PASS 11GAnt1Low2412-1.40-32.36≤-31.4PASS 11GAnt1High24625.87-38.89≤-24.13PASS 11N20SISOAnt1Low2412-0.45-31.15≤-30.45PASS 11N20SISOAnt1High24624.32-37.29≤-25.68PASS 11N40SISOAnt1Low2422-3.93-34.61≤-33.93PASS 11N40SISOAnt1High24523.06-30.68≤-26.94PASS Page 30 of 59 TestGraphs 11B-Ant1-2412-PASS 11B-Ant1-2462-PASS Page 31 of 59 11G-Ant1-2412-PASS 11G-Ant1-2462-PASS Page 32 of 59 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2462-PASS Page 33 of 59 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2452-PASS Page 34 of 59 AppendixF:ConductedSpuriousEmission TestResult TestModeAntennaFrequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11BAnt124120~Reference5.995.99---PASS 11BAnt1241230~10005.99-56.93≤-24.01PASS 11BAnt124121000~265005.99-42.95≤-24.01PASS 11BAnt124370~Reference8.118.11---PASS 11BAnt1243730~10008.11-56.86≤-21.89PASS 11BAnt124371000~265008.11-44.01≤-21.89PASS 11BAnt124620~Reference4.904.90---PASS 11BAnt1246230~10004.90-57.11≤-25.1PASS 11BAnt124621000~265004.90-44.24≤-25.1PASS 11GAnt124120~Reference3.983.98---PASS 11GAnt1241230~10003.98-55.84≤-26.02PASS 11GAnt124121000~265003.98-43.65≤-26.02PASS 11GAnt124370~Reference3.743.74---PASS 11GAnt1243730~10003.74-56.89≤-26.26PASS 11GAnt124371000~265003.74-43.34≤-26.26PASS 11GAnt124620~Reference3.463.46---PASS 11GAnt1246230~10003.46-55.69≤-26.54PASS 11GAnt124621000~265003.46-43.34≤-26.54PASS 11N20SISOAnt124120~Reference4.534.53---PASS 11N20SISOAnt1241230~1000…

Text truncated - open the document above for the full version.

Page 1 of 33 AppendixTestData ReportNo:1812C40114912502TestSampleNO:1-2-2 StartTestDate：2024.11.1FinishTestDate:2024.11.1 TestEngineer:Auditor: Temperature:22.7 °C RelativeHumidity:51% Pressure:101kPa AppendixA:DTSBandwidth TestResult TestModeAntennaFrequency[MHz] DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict BLE_1MAnt124020.652401.672402.320.5PASS BLE_1MAnt124400.722439.622440.340.5PASS BLE_1MAnt124800.692479.652480.340.5PASS BLE_2MAnt124021.342401.312402.650.5PASS BLE_2MAnt124401.392439.292440.680.5PASS BLE_2MAnt124801.142479.402480.540.5PASS Page 2 of 33 TestGraphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Page 3 of 33 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Page 4 of 33 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Page 5 of 33 AppendixB:OccupiedChannelBandwidth TestResult TestModeAntennaFrequency[MHz] OCB [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict BLE_1MAnt124021.0152401.48852402.5035------ BLE_1MAnt124401.0352439.47252440.5075------ BLE_1MAnt124801.0392479.47252480.5115------ BLE_2MAnt124022.0462400.98102403.0270------ BLE_2MAnt124402.052438.97302441.0230------ BLE_2MAnt124802.0622478.97302481.0350------ Page 6 of 33 TestGraphs BLE_1M-Ant1-2402 BLE_1M-Ant1-2440 Page 7 of 33 BLE_1M-Ant1-2480 BLE_2M-Ant1-2402 Page 8 of 33 BLE_2M-Ant1-2440 BLE_2M-Ant1-2480 Page 9 of 33 AppendixC:Maximumconductedoutputpower TestResultPeak TestModeAntennaFrequency[MHz] ConductedPeak Power[dBm] Conducted Limit[dBm] Verdict BLE_1MAnt12402-0.43≤30PASS BLE_1MAnt12440-1.29≤30PASS BLE_1MAnt12480-2.24≤30PASS BLE_2MAnt12402-0.51≤30PASS BLE_2MAnt12440-1.33≤30PASS BLE_2MAnt12480-2.24≤30PASS Page 10 of 33 TestGraphsPeak BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Page 11 of 33 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Page 12 of 33 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Page 13 of 33 AppendixD:Maximumpowerspectraldensity TestResult TestModeAntennaFrequency[MHz]Result[dBm/3kHz]Limit[dBm/3kHz]Verdict BLE_1MAnt12402-17.51≤8.00PASS BLE_1MAnt12440-18.42≤8.00PASS BLE_1MAnt12480-19.31≤8.00PASS BLE_2MAnt12402-20.24≤8.00PASS BLE_2MAnt12440-21.03≤8.00PASS BLE_2MAnt12480-21.96≤8.00PASS Page 14 of 33 TestGraphs BLE_1M-Ant1-2402-PASS BLE_1M-Ant1-2440-PASS Page 15 of 33 BLE_1M-Ant1-2480-PASS BLE_2M-Ant1-2402-PASS Page 16 of 33 BLE_2M-Ant1-2440-PASS BLE_2M-Ant1-2480-PASS Page 17 of 33 AppendixF:Bandedgemeasurements TestResult TestModeAntennaChName Frequency [MHz] RefLevel[dBm]Result[dBm]Limit[dBm]Verdict BLE_1MAnt1Low2402-2.28-47.76≤-22.28PASS BLE_1MAnt1High2480-3.64-46.41≤-23.64PASS BLE_2MAnt1Low2402-4.78-38.02≤-24.…

Text truncated - open the document above for the full version.
