2AD2L-XRSLEDRRemote Controller

oscillator frequency:13.56MHz SYNF115

FCC ID Label The FCC ID and IC code are marked on the back of Remote controller by Laser etching.

Technical Description Part 1: Wireless transmitter, the low frequency digital signal is converted to high frequency signal, the signal is output to the signal amplification part and emit via antenna. Part 2: Encoding part, it encodes the data input from key and covert to digital signal and send to Part 1, it is powered by 3 AAA battery. Part 3: Port. Antenna Used: An integral antenna has been used.

1 2 34 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 27-Feb-2015 Sheet of File: C:\Do cument s an d Set tin gs \zjb 00 4\ 桌面 \REMOT E led.dd b Drawn By: BATTERY 1 14 2 13 3 12 4 11 5 10 6 9 7 8 U1 RESET DOWN UP COLOR AUTO ON/OFF R1 100K C1 0.1uF ANT 433MHZ 3V 433MHZ ZY156-TX PAOUT 1 ASK 6 VSS 2 XTLIN 5 VDD 3 XTLOUT 4 U2 SYNF115 Y1 13.560MHZ C1433p C1333p C510p C75p C101uF C1100p R2100K L4 56nH L1 470nH R7 1K REMOTE LIGHT--TX A0

Report No.: 150109032GZU-001 Issued: 2015-2-28 FCC ID: 2AD2L-XRSLEDR Page 2 of 22 CONTENT TEST REPORT ........................................................................................................................................................... 1 CONTENT ................................................................................................................................................................... 2 1.0 Summary of Test............................................................................................................................................ 3 2.0 General Description ....................................................................................................................................... 4 2.1 Product Description ........................................................................................................................ 4 2.3 Test Methodology .......................................................................................................................... 5 2.4 Test Facility .................................................................................................................................... 5 3.0 System Test Configuration ............................................................................................................................ 6 3.1 Justification .................................................................................................................................... 6 3.2 EUT Exercising Software ............................................................................................................... 7 3.3 Special Accessories ........................................................................................................................ 7 3.4 Measurement Uncertainty .............................................................................................................. 7 3.5 Equipment Modification ................................................................................................................. 7 3.6 Support Equipment List and Description ....................................................................................... 7 4.0 Measurement Results ..................................................................................................................................... 8 4.1 Antenna Requirement: .................................................................................................................... 8 4.2 Radiated Emissions ........................................................................................................................ 9 4.3 Occupied Bandwidth .................................................................................................................... 17 4.4 Dwell Time: .................................................................................................................................. 19 4.5 Conducted Emission Test ............................................................................................................. 21 5.0 Test Equipment List ..................................................................................................................................... 22 Report No.: 150109032GZU-001 Issued: 2015-2-28 FCC ID: 2AD2L-XRSLEDR Page 3 of 22 1.0 Summary of Test TEST TEST REQUIREMENT TEST METHOD RESULT Radiated Emission FCC PART 15 section 15.231(b) ANSI C 63.10: Clause 6.4, 6.5 and 6.6 PASS Occupied Bandwidth FCC PART 15 section 15.231(c) ANSI C 63.10: Clause 6.9 PASS Dwell Time FCC PART 15 section 15.231(a) FCC PART 15: Section 15.231(a) PASS Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radio Frequency. ANSI C63.10: the detail version is ANSI C63.10:2009 in the whole report. Report No.: 150109032GZU-001 Issued: 2015-2-28 FCC ID: 2AD2L-XRSLEDR Page 4 of 22 2.0 General Description 2.1 Product Description Operating Frequency 433.92 MHz Type of Modulation: ASK modulated by internal signal Antenna Type Integral Antenna gain: 0 dBi Function: Wireless control with 433.92 MHz as carrier. Power Supply: DC 3 V for remote controller Power cord: Power by battery Report No.: 150109032GZU-001 Issued: 2015-2-28 FCC ID: 2AD2L-XRSLEDR Page 5 of 22 2.3 Test Methodology Radiated emission measurement was performed in semi-anechoic chamber and conducted emission measurement was performed in shield room. For radiated emission measurement, preliminary scans and final tests were performed in the semi-anechoic chamber to determine the worst case modes. All radiated tests were performed at an antenna to EUT distance of 3 meters, unless stated otherwise. 2.4 Test Facility All of the tests are performed at: Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Block E, No.7-2 Guang Dong Software Science Park, Caipin Road, Guangzhou Science City, GETDD Guangzhou, China. This test facility and site measurement data have been fully placed on file with the FCC, test firm registration number is 549654. Report No.: 150109032GZU-001 Issued: 2015-2-28 FCC ID: 2AD2L-XRSLEDR Page 6 of 22 3.0 System Test Configuration 3.1 Justification For emissions testing, the equipment under test (EUT) setup to transmit continuously to simplify the measurement methodology. Care was taken to ensure proper power supply voltages during testing. During testing, it was powered by DC 3V supply. The signal is maximized through rotation and placement in the three orthogonal axes. The antenna height and polarization are varied during the search for maximum signal level. The antenna height is varied from 1 to 4 meters. Radiated emissions are taken at three meters unless the signal level is too low for measurement at that distance. If necessary, a pre-amplifier is used and/or …
