2AD2Q-SPFDQ01Smart searching & anti-lost device

Users Manual Product Name: Smart searching & anti-lost device Tips: Small and exquisite, Easy to carry. Easy to use anywhere, anytime on any occasion. Product Size: mainframe 56*42*14mm . Auxiliary :48*33*14mm Weight: 39.58g Packing list: 1: one each of mainframe and Auxiliary 2: Two Button batteries, Battery model : CR2032 With 2 Batterries. 3: two Pendants 4: one Instructions Scope of application ： Easy To find your Luggage Wallet, bags anti-theft Carry-on items Anti forgotten elderly, children Anti-lost Pets Anti-lost Introduction of the product function : 1: Smart Anti-lost Searching is Composed by mainframe and Auxiliary , The mainframe is a Shield shape , Auxiliary is a small Rectangle . 2:The Smart Anti-lost searching have 3 functions : Smart luggage tag Sensor of losing and Anti-lost device L represent Smart luggage tag Mode . A represent Sensor of losing mode Turn both the mainframe and auxiliary device to according position go in Smart luggage tag mode or Anti-lost device mode . 2：Anti-lost device mode ：function of searching things . Put the button of the Auxiliary once on the mode of Smart luggage tag enter . Unable to enter on other mode . Need to turn it off and reselect when switch to other mode again . 3. there has a warning voice of di di di di on the mainframe . No warning voice of Auxiliary . the function of Smart luggage tag and Sensor of losing : Used in the corresponding scene ,hang on the mainframe in the Luggage/items . Follow the voice of di di di , can quickly know your luggage has arrived or easily to search your things . the function of Anti-lost device : adult or host carry the mainframe . because need to get the alarm quickly . the mainframe should be carried with the adult or host . the Auxiliary is more small and light , Suitable for The elderly, children . or hang on the pets Cell phone computer or something Important items . FCC STATEMENT: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date FromTo Initial Release (obsolete)1.01.0Nov-14-2006 Revised wording (obsolete)1.02.0Sept–25-2007 Updated company template (obsolete)2.03.0Jan-31-2012 Updated letter information (obsolete)3.04.0May-23-2014 Added FCC ID field (current)4.05.0Sept 16 2014

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 (JIAOZUO AEGIS SCIENCE&TECHNOLOGY CO., LTD) (2015-01-19) To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AD2Q-SPFDQ01 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Fang Qin / Deputy General Manager Company Name: JIAOZUO AEGIS SCIENCE&TECHNOLOGY CO., LTD Address: The 3rd Floor, No.2 Plant, Incubation Center Of High Tech Zone, Jiaozuo City, Henan Province, China Email: [email protected]

Figure 1 The EUT-Top View Figure 2 The EUT-Bottom View Figure 3 The EUT-Front View Figure 4 The EUT-Back View Figure 5 The EUT-Left View Figure 6 The EUT-Right View

Product Name: Smart searching & anti-lost device Model No.: SP-FDQ01 FCC ID: 2AD2Q-SPFDQ01

Label Location On EUT

Figure 7 The EUT-Inside View Figure 9 PCB of the EUT-Front View Antenna Figure 10 PCB of the EUT-Back View

Shenzhen Anbotek Compliance Laboratory Limited FCC ID: 2AD2Q-SPFDQ01 Page 1 of 23 Report No.: R011412803E Shenzhen Anbotek Compliance Laboratory Limited Tel:(86)755-26066544 Fax:(86)755-26014772 www.anbotek.com FCC TEST REPORT for JIAOZUO AEGIS SCIENCE&TECHNOLOGY CO., LTD Smart searching & anti-lost device Model No.: SP-FDQ01 Report Number : R011412803E Date of Test : Dec. 29, 2014~ Jan. 19, 2015 Date of Report : Jan. 19, 2015 Prepared for : JIAOZUO AEGIS SCIENCE&TECHNOLOGY CO., LTD Address : The 3rd Floor, No.2 Plant, Incubation Center Of High Tech Zone, Jiaozuo City, Henan Province, China Prepared By : Shenzhen Anbotek Compliance Laboratory Limited Address : 1/F., Building 1, SEC Industrial Park, No.0409 Qianhai Road, Nanshan District, Shenzhen, Guangdong, China Tel: (86) 755-26066544 Fax: (86) 755-26014772 Shenzhen Anbotek Compliance Laboratory Limited FCC ID: 2AD2Q-SPFDQ01 Page 2 of 23 Report No.: R011412803E Shenzhen Anbotek Compliance Laboratory Limited Tel:(86)755-26066544 Fax:(86)755-26014772 www.anbotek.com TABLE OF CONTENTS Description Page Test Report 1. GENERAL INFORMATION ......................................................................................................... 4 1.1. Description of Device (EUT) .................................................................................................................... 4 1.2. Description of Test Facility ...................................................................................................................... 5 1.3. Description of Test Facility ...................................................................................................................... 5 1.4. Measurement Uncertainty ......................................................................................................................... 5 1.5. Test Summary ........................................................................................................................................... 6 2. MEASURING DEVICE AND TEST EQUIPMENT .................................................................... 7 3. TEST PROCEDURE ....................................................................................................................... 8 4. RADIATION INTERFERENCE ................................................................................................... 9 4.1. Requirements (15.231): ............................................................................................................................ 9 4.2. Test Procedure .......................................................................................................................................... 9 4.3. Test Results ............................................................................................................................................... 9 5. 20DB BANDWIDTH ..................................................................................................................... 12 5.1. Requirements (15.231): .......................................................................................................................... 12 5.2. EUT Setup .............................................................................................................................................. 12 5.3. Test Results ............................................................................................................................................. 12 6. DUTY CYCLE ............................................................................................................................... 14 6.1. EUT Setup .............................................................................................................................................. 14 6.2. Test Procedure ........................................................................................................................................ 14 6.3. Requirements & Result ........................................................................................................................... 14 7. ANTENNA APPLICATION ......................................................................................................... 17 7.1. Antenna Requirement ............................................................................................................................. 17 7.2. Result ...................................................................................................................................................... 17 8. TEST PHOTO ................................................................................................................................ 18 8.1. Photo of Radiation Emission Test .......................................................................................................... 18 APPENDIX I (EXTERNAL PHOTOS) ........................................................................................... 19 APPENDIX II(INTERNAL PHOTOS) ......................................................................................... 22 Shenzhen Anbotek Compliance Laboratory Limited FCC ID: 2AD2Q-SPFDQ01 Page 3 of 23 Report No.: R011412803E Shenzhen Anbotek Compliance Laboratory Limited Tel:(86)755-26066544 Fax:(86)755-26014772 www.anbotek.com TEST REPORT Applicant : JIAOZUO AEGIS SCIENCE&TECHNOLOGY CO., LTD Manufacturer : JIAOZUO AEGIS SCIENCE&TECHNOLOGY CO., LTD EUT : Smart searching & anti-lost device Model No. : SP-FDQ01 Serial No. : N.A. Rating : DC 3V Trade Mark : SUNPOPO Measurement Procedure Used: FCC Part15 Subpart C, Paragraph 15.231 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of…
