1 Quick Start Guide Watcher 2 INDEX Aboutourproducts -----------------------------------------3 Compatibility-----------------------------------------------3 Operation --------------------------------------------------3 Charging ---------------------------------------------------4 WatchMenudescription --------------------------------------4 FirmwareUpgrade-------------------------------------------- 7 ImportantProductInformation --------------------------------- -7 3 About our products: Watcher is an anti-lost smart watch. Just attach the accessory(pendant or card) to your valuables and pair it with the Watcher,and Watcher will keep track of them all the time.Your Watcher will be connected to iPhone or Android phone by Bluetooth,and the GPS location will also be recorded by Watcher app to help you recover your lost items. Once the accessory is out of communication range, your Watcher will vibrate to alert you.This will prevent you from losing or forgetting your phone, wallet, keys,etc. Compatibility: Watcher connects to your iPhone 4(and above) with iOS6(and above).Watcher connects to the Android devices that come with bluetooth4.0 running OS 4.3(and above) .The accessories are connected to your Watcher by RFID technology that is integrated within all of our products. Operation: To connect your Watcher to your smartphone, download and install the mobile app from www.elink-iot.com .After the mobile app is installed,you will be prompted to connect the smartphone to your Watcher.The time on Watcher will be automatically set.Once Watcher connects to your smartphone,Watcher will vibrate to notify you when you get SMS or a call from someone. 4 Watcher has four buttons.The left button is called the "back" button,which could return to the previous screen or enter into your watchface from the main menu.On the right side,the top and bottom buttons generally are used for scrolling through lists.The "Center"button is used to select an item in a list.You can scroll through the right side buttons to select the menu. The pendant and card each have one button that is used to pair up with Watcher.Once the RF is enabled on Watcher,scroll down on the menu and select the pair-up option, and press the select button on the pendant/card to connect to your Watcher immediately. Once Watcher connects to your accessories, it will display how much battery is left for each accessory.If you press the button on the accessories twice ,Watcher will get disconnected. They will automatically reset in 1 minute. Charging

The charger connects magnetically to the charging port on the left side of your Watcher and to two accessories.When your accessory is connected to Watcher, you can see when the accessory is charging on Belongings list. Watch Menu description
1.Belonging list 1.1 Belongings list Displays all the accessories that connected to your Watcher. 1.2 Reminder list 5 Lists all the communication records between your accessories and Watcher. 1.3 No disturb time You can set up a period of time when you don't want to get any alert from your Watcher. 1.4 Pair Pairs up Watcher with any accessory that is within range. 1.5 Delete Deletes any accessory connected to Watcher. 1.6 PowerAlert On Alerts you to the power level of your accessories. 1.7 LockAlert Off Turns off the vibrate reminder when Watcher connects to your accessories. 2. Sweet time When you and your partner both own Watcher and are within communication range, Watcher will automatically keep track of how much time is spent together.It also display how much time you’ve spent together in a daily,weekly or monthly basis.By making it work,one user should click Broadcast,the other user should click Pair,and they will connect with each other in couple seconds. 3.Thermometer Collects data from the thermometer that monitors the temperature of the baby. 3.1 History Data Displays the data collected before. 3.2 Fever Alarm Alert the user if the temperature is up to the fever level. 3.3 Abnormal Alarm Alert the user if the temperature is abnormal compared to the previous data. 4.Activity 4.1 History Data Displays the running data collected before. 4.2 Single test You can see your data for each test. 4.3 Settings Customize your own settings. 5.Find Phone 6 This function requires that Bluetooth is activated on Watcher and the smartphone. When the smartphone is beyond range ,Watcher will vibrate to alert you. 6.Settings The settings menu will allow you to customize Watcher's features.To access each of these settings,press the Select button when the item is highlighted in the list of settings. 6.1 RF To pair Watcher with your accessories,the RF must be "on". 6.2 Bluetooth To pair Watcher to your smartphone,the Bluetooth must be "On" .To disable Bluetooth,press the Select option when 'Bluetooth on' is highlighted. 6.3 Notifications You can enable or disable notifications.In sleep mode,you won't get any notifications. 6.4 Vibration This option enables you to manually decide how many times Watcher vibrates under three circumstances:receiving messages,incoming calls, when the your accessories are out of range. 6.5 Date&Time You can manually set the date and time on your Watcher. 6.6 Alarms You can set up to 3 alarms.. 6.7 Watchfaces Selects among different watchefaces . 6.8 Memo dates Sets alerts for important dates and times 6.9 Languages You can select the display language of your choice: English or Mandarin Chinese 6.10 Factory Reset Watcher can be restored to the original factory settings. Please note that this options removes any personalized settings 6.11 Shut Down Turns off your Watcher. In this mode, Watcher continues to keep time. To turn your Watcher on, press and hold any button for 3 seconds. 6.12 About This column contains Watcher hardware and software version information. 7 Firmware Upgrade: For more information about firmware upgrades, please go to www.elink-iot.com . Important Product Information: Elink-IOT Watcher 1 year limited Warranty Elink-IOT Technology C…
