2AD7HT928Portable Digital Radio

USER MANUAL Model name:T928 Brand name: TIETONG FCC Caution. SAFETYTRAINING INFORMATION Your TIETONG Electronics(Group) radio generates RF electromagnetic energy during transmit mode. This radio is designed for and classified as “Occupational Use Only”, meaning it must be used only during the course of employment by individuals aware of the hazards, and the ways to minimize such hazards. This radio is NOT intended for use by the “General Population” in an uncontrolled environment. This radio has been tested and complies with the FCC RF exposure limits for “Occupational Use Only”. In addition, your TIETONG Electronics(Group) radio complies with the following Standards and Guidelines with regard to RF energy and electromagnetic energy levels and evaluation of such levels for exposure to humans: 1. FCC OET Bulletin 65 Edition 97-01 Supplement C, Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields. 2. American National Standards Institute (C95.1-1992), IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. 3. American National Standards Institute (C95.3-1992), IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields– RF and Microwave. Electromagnetic Interference/Compatibility During transmissions, your TIETONG Electronics(Group) radio generates RF energy that can possibly cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, aircraft, and blasting sites. Occupational/Controlled Use The radio transmitter is used in situations in which persons are exposed as consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. 4.The antennas, batteries, belt clips, speaker-microphone, and other accessories that are listed in "OPTIONS" of the INSTRUCTIONS sheet, are authorized for use with this product. Use of accessories other than those specified may result in RF exposure levels exceeding the FCC requirements for wireless RF exposure. To ensure that your expose to RF electromagnetic energy is within the FCC allowable limits for occupational use, always adhere to the following guidelines: . DO NOT operate the radio without a proper antenna attached, as this may damaged the radio and may also cause you to exceed FCC RF exposure limits. A the antenna supplied with this radio by the manufacturer or antenna specifically authorized by the manufacturer for use with this radio. .DO NOT transmit for more than 50% of total radio use time ("50% duty cycle"). Transmitting can cause FCC RF exposure compliance requirements to be exceeded. The radio is transmitting when the LED indicator lights red. You can cause the radio to transmit by pressing the"PTT"switch. .ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the body when transmitting and only use the Icom belt-clips listed in "OPTIONS" of the INSTRUCTIONS sheet when attaching the radio to your belt, etc., to ensure FCC RF exposure compliance requirements are not exceeded. To provide the recipients of your transmission the best sound quality, hold the antenna at least 5 cm (2inches) from your mouth, and slightly off to one side. proper antenna is more than 50% of the time The information listed above provides the user with the information needed to make him or her aware of RF exposure and what to do to assure that this radio operates with the FCC RF exposure limits of this radio.

TIETONG Electronics(Group) No.13 zihua Street Jiangnan Hi-tech，Industrial area, Licheng District, QuanZhou, China Tel: 0755 36886281 Fax: 0755 36886277 Attestation letter FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir/Madam, We, TIETONG Electronics(Group) hereby declare that our product: Digital Transceiver; FCC ID: 2ADWKT928 is capable of supporting a voice channel. DMR interphone’s bandwidth is 12.5 kHz, and it has a double time slot, one is the speech time slot. . Sincerely, TIETONG Electronics(Group) Contact Person: Yue Chu 2015-04-10

FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name TIETONG Electronics(Group) Addresss No.13 zihua Street Jiangnan Hi-tech Industrial area Licheng District City QuanZhou Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: 2AD7H T928 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams x Part List Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) China 2015-04-10 Yue Chu Manager

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 11 Photo 12 Photo 13 Photo 14 Photo 15 Photo 16

ATTENTION! Restricted to occupational use to satisfy FCC RF exposure limits.See user manual for operating requirements.

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9

Ref : ACR.262.1.14.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA SATIMO COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 17/14 EP221 Calibrated at SATIMO US 2105 Barrett Park Dr. - Kennesaw, GA 30144 09/01/2014 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in SATIMO USA using the CALISAR / CALIBAIR test bench, for use with a SATIMO COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 2/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 9/19/2014 Checked by : Jérôme LUC Product Manager 9/19/2014 Approved by : Kim RUTKOWSKI Quality Manager 9/19/2014 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 9/19/2014 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 3/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 4/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer Satimo Model SSE5 Serial Number SN 17/14 EP221 Product Condition (new / used) New Frequency Range of Probe 0.4 GHz- 6 GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.179 M Dipole 2: R2=0.167 M Dipole 3: R3=0.178 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION Satimo’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – Satimo COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 4.5 mm Maximum external diameter 8 mm Probe Tip External Diameter 5 mm Distance between dipoles / probe extremity 2.7 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 5/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid,…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1412052H01 Issued for TIETONG Electronics(Group) No.13 zihua Street Jiangnan Hi-tech Industrial area Licheng District QuanZhou City Fujian Province Product Name: Portable Digital Radio Brand Name: TIETONG Model No.: T928 Series Model: T906,T908,T916,T828,T816,TT-820,TT-810 FCC ID: 2AD7HT928 Test Standard: IEEE 1528:2003; ANSI/IEEE C95.1-1999 IEC 62209-2: 2010 Max. SAR (1g): Head:2.884 W/kg Body:6.709 W/kg S T L A B S Page 2 of 57 Report No.: STS1412052H01 Test Report Certification Applicant’s name ................. : TIETONG Electronics(Group) Address ................................. : No.13 zihua Street Jiangnan Hi-tech Industrial area Licheng District QuanZhou City Fujian Province Manufacture's Name ............ : TIETONG Electronics(Group) Address ................................. : No.13 zihua Street Jiangnan Hi-tech Industrial area Licheng District QuanZhou City Fujian Province Product description Product name ........................ : Portable Digital Radio Trademark ............................ : TIETONG Model and/or type reference : T928 Serial Model： T906,T908,T916,T828,T816,TT-820, TT-810 Standards ............................. : IEEE 1528:2003; ANSI/IEEE C95.1-1999 IEC 62209-2: 2010 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ............................................ : Date (s) of performance of tests ............. : 27/03/2015 Date of Issue ........................................... : 30/03/2015 Test Result ............................................... : Pass Testing Engineer : (Allen Chen) Technical Manager : (John Zou) Authorized Signatory : (Bovey Yang) Page 3 of 57 Report No.: STS1412052H01 TABLE OF CONTENS 1. General Information 4 1.1 EUT Description 4 2 Test Environment 5 2.1 Environmental conditions 5 2.2 Test Facility 5 2.3 TEST ENVIRONMENT 5 2.4 Equipments Used during the Test 6 3. SAR Measurement System 7 3.1 SAR Measurement Set-up 7 3.2 DASY5 E-field Probe System 8 3.3 Phantoms 9 3.4 Device Holder 10 4. Scanning Procedure 10 4.1 Data Storage and Evaluation 11 4.2 Tissue Dielectric Parameters for Head and Body Phantoms 13 4.3 Dielectric Performance 14 4.4 System Check 14 4.5 Measurement Procedures 16 5. TEST CONDITIONS AND RESULTS 21 5.1 Conducted Power Results 21 5.2 SAR Measurement Results 21 5.3 Measurement Uncertainty 22 5.4 System Check Results 23 5.5 SAR Test Graph Results 25 6 Calibration Certificate 31 6.1 Probe Calibration Certicate 31 6.2 D450V3 Dipole Calibration Certicate 42 6.3 DAE4 Calibration Certicate 50 7. Test Setup Photos 53 8. EUT Photos 55 Page 4 of 57 Report No.: STS1412052H01 1. General Information 1.1 EUT Description Equipment: Portable Digital Radio Brand Name: TIETONG Model No.: T928 Serial Model: T906,T908,T916,T828,T816,TT-820, TT-810 FCC ID: 2AD7HT928 Model Difference: The appearance of different Adapter: Input: AC100-240V, 0.5 A, 50/60 Hz Output: DC 12V, 1.0A Battery: Model Name: T928 Rated Voltage: 7.4V Capacity: 2000mAh Rated Power: UHF: 4W/1W Hardware Version: T928V01 Software Version: T928V02 Frequency Range: 400-470MHz Channel Spacing: 12.5KHz Max. Reported SAR(1g): with 50% duty cycle 12.5KHz: Head: 2.884 W/kg; Body: 6.709 W/kg Modulation Type: 4FSK/FM Test channel: 406.1MHz – 435.325MHz –469.975MHz Exposure Category: Occupational/Controlled Exposure Page 5 of 57 Report No.: STS1412052H01 2 Test Environment 2.1 Environmental conditions Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 22~23 Humidity (%RH) 30-70 55~65 2.2 Test Facility The Testing and Technology Center for Industrial Products of Shenzhen Entry-Exit Inspection and Quarantine Bureau Add. : No.289, 8th Industry Road, Nanshan District, Shenzhen, Guangdong, China 2.3 TEST ENVIRONMENT No. Identity Document Title 1 IEEE 1528:2003 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 2 ANSI/IEEE C95.1-1999 standard for safety levels with respect to human exposure to radio frequency electromagnetic fields, 3 KHz to 300 GHz. 3 IEC62209-2 Human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices – Human models, instrumentation, and procedures –Part 2: Procedure to determine the Specific Absorption Rate (SAR) in the head and body for 30MHz to 6GHz Handheld and Body-Mounted Devices used in close proximity to the body. This device belongs to portable device category because its radiating structure is allowed to be used within 20 centimeters of the body of the user. Limit for Occupational/Controlled Exposure should be applied for this device, it is 8.0 W/kg as averaged over any 1 gram of tissue. NOTE GENERAL POPULATION/UNCONTROLLED EXPOSURE PARTIAL BODY LIMIT 8.0 W/kg Page 6 of 57 Report No.: STS1412052H01 2.4 Equipments Used during the Test Test Equipment Manufacturer Type/Model Serial Number Calibration Last Calibration Calibration Interval Data Acquisition Electronics DAEx SPEAG DAE4 1315 2014/07/22 1 E-field Probe SPEAG EX3DV4 3842 2014/06/06 1 System Validation Dipole D450V3 SPEAG D450V3 1079 2014/02/28 3 Network analyzer Agilent 8753E US37390562 2014/10/26 1 Signal generator IFR 203…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC TEST REPORT Report No: STS1412052F01 Issued for TIETONG Electronics(Group) No.13 zihua Street Jiangnan Hi-tech Industrial area Licheng District QuanZhou City Fujian Province Product Name: Portable Digital Radio Brand Name: TIETONG Model No.: T928 Series Model: T906,T908,T916,T828,T816,TT-820, TT-810 FCC ID: 2AD7HT928 Test Standard: FCC Part 90 Rules S T L A B S Page 2 of 47 Report No.: STS1412014F02 Testing Engineer : (Tony Liu) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) TEST RESULT CERTIFICATION Applicant’s name .................... : TIETONG Electronics(Group) Address .................................... : No.13 zihua Street Jiangnan Hi-tech Industrial area Licheng District QuanZhou City Fujian Province Manufacture's Name .............. : TIETONG Electronics(Group) Address .................................... : No.13 zihua Street Jiangnan Hi-tech Industrial area Licheng District QuanZhou City Fujian Province Product description Product name ........................... : Portable Digital Radio Band name ............................... : TIETONG Model and/or type reference ..... : T928, T906,T908,T916,T828,T816,TT-820,TT-810 Standards ................................ : FCC Part 90 Rules Test procedure ............................... : ANSI C 63.4: 2014; TIA/EIA 603 and FCC CFR 47 Rules of 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057. This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................. : Date of performance of tests ................... : 01 Jan. 2015 ~09 Jan . 2015 Date of Issue ........................................... : 10 Jan . 2015 Test Result ............................................... : Pass Page 3 of 47 Report No.: STS1412014F02 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2. GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 EUT OPERATION MODE 9 2.3 DESCRIPTION OF TEST MODES 10 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 11 2.5 DESCRIPTION OF SUPPORT UNITS 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3. EMISSION TEST 14 3.1 RADIATED RECEIVE AND OUT-OF-BAND SPURIOUS EMISSION 14 3.1.1 RADIATED RECEIVE EMISSION LIMITS 14 3.1.2 OUT-OF-BAND SPURIOUS EMISSION MEASUREMENT LIMITS 14 3.1.3 TEST PROCEDURE 14 3.1.4 DEVIATION FROM TEST STANDARD 15 3.1.5 TEST SETUP BLOCK DIAGRAM 16 3.1.6 RADIATED RECEIVE EMISSION TEST RESULTS BELOW 30MHZ 17 3.1.7 OUT-OF-BAND SPURIOUS TEST RESULTS ABOVE 30MHZ 18 3.2 EMISSION MASK PLOT 21 4. FREQUENCY TOLERANCE 24 4.1 DESCRIPTION OF SUPPORT UNITS 24 4.2 MEASUREMENT PROCEDURE 24 4.2.1 FREQUENCY STABILITY VERSUS ENVIRONMENTAL TEMPERATURE 24 4.2.2 FREQUENCY STABILITY VERSUS INPUT VOLTAGE 24 4.3 TEST SETUP BLOCK DIAGRAM 24 4.4 TEST RESULT 25 5. EMISSION BANDWIDTH 29 5.1 PROVISIONS APPLICABLE 29 5.2 MEASUREMENT PROCEDURE 29 5.3 TEST SETUP BLOCK DIAGRAM 29 5.4 MEASUREMENT RESULT: 30 6. MODULATION CHARACTERISTICS 34 6.1 PROVISIONS APPLICABLE 34 6.2 PROVISIONS APPLICABLE 34 Page 4 of 47 Report No.: STS1412014F02 Table of Contents Page 6.2.1 MODULATION LIMIT 34 6.2.2 AUDIO FREQUENCY RESPONSE 34 6.3 TEST SETUP BLOCK DIAGRAM 34 6.4 MEASUREMENT RESULT 35 7. AUDIO LOW PASS FILTER RESPONSE 38 7.1 PROVISIONS APPLICABLE 38 7.1.1 LIMITS 38 7.2 METHOD OF MEASUREMENTS 38 7.3 TEST DATA 39 8. TRANSMITTER FREQUENCY BEHAVIOR 41 8.1 PROVISIONS APPLICABLE 41 8.2 TEST METHOD 41 8.3 DESCRIBE LIMIT LINE OF RANSMITTER FREQUENCY BEHAVIOR 41 8.4 MEASURE RESULT 43 9. MAXIMUMN TRANSMITTER POWER (CONDUCTED OUTPUT POWER) 44 9.1 PROVISIONS APPLICABLE 44 9.2 TEST PROCEDURE 44 9.3 TEST CONFIGURATION 44 9.4 TEST RESULT 45 PHOTOS OF TEST SETUP 47 Page 5 of 47 Report No.: STS1412014F02 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: Emission Standard Item Result Remarks §90.210 Radiated Receive And Out-Of-Band Spurious Emission Measurement PASS §90.205 Maximum Transmitter Power PASS §90.207 Modulation Characteristic PASS §90.242 Audio Low Pass Filter Response PASS §90.209 Occupied Bandwidth PASS §90.210 Emission Mask PASS §90.213 Frequency Tolerance PASS §90.214 Transient Frequency Behavior PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 47 Report No.: STS1412014F02 1.1 TEST FACILITY Shenzhen STS Test Services Co., Ltd. Add.: 1/F, Building 2, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China. FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 RF power,conducted ±0.70dB 2 Spurious emissions,conducted ±1.19dB 3 Spurious emissions,radiated((>1G) ±2.83dB 4 Spurious emissions,radiated(<1G) ±3.01dB 5 Temperature ±0.5°C 6 Humidity ±2% Page 7 of 47 Report No.: STS1412014F02 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product: Portable Digital Radio Brand Name: TIETONG Model Number: T928 Series Model Name: T906,T908,T916,T828,T816,TT-820, TT-810 Series Model Difference description: Onl…

Text truncated - open the document above for the full version.

Setup photo Radiated Measurement Photos 30MHz- 1GHz Above 1GHz
