1 of 23 20150120 ver.1 44” Electric Smoker Model Number: SC21874XX-YY-ZZ Assembly, Care and Use Manual This Product is for outdoor use only  This instruction manual contains important information necessary for the proper assembly and safe use of the appliance.  Read and follow all warnings and instructions before assembling and using the appliance.  Follow all warnings and instructions when using the appliance.  Keep this manual for future reference.  Failure to follow these instructions could result in fire or explosion which could cause property damage, personal injury or death. Should you encounter any problem, CALL US FIRST. DO NOT return product to the retail store!! WE CAN HELP. For assistance, contact customer service at [email protected] or at (888) 837-1380, Mon to Fri, 8:00am – 5:00pm Pacific Standard time CSA CERTIFIED TO UL STANDARD 1026 2 of 23 20150120 ver.1 WARNING CARBON MONOXIDE HAZARD  Burning wood chips gives off carbon monoxide, which has no odor and can cause death.  DO NOT burn wood chips inside homes, vehicles, tents, garages or any enclosed areas.  Use only outdoors in a well-ventilated space. WARNING Important Safety Instructions When using electrical appliances, basic safety precautions should always be followed, including the following: 1. This appliance is for outdoor use only. Do NOT operate in an enclosed area. 2. Do NOT touch the hot surfaces. 3. To protect against electric shock, wear protective gloves such as oven mitts at all times when using appliance. Do not immerse cord, plugs or control panel in water or other liquid. 4. Do NOT expose the appliance to rain or water at any time. 5. Do NOT place the appliance on or near gas or other flammable liquid. 6. Keep children and pets away from the appliance at all times. Do NOT allow children to use this appliance. 7. Do NOT plug in the appliance until fully assembled and ready for use. 8. Do NOT move the appliance during use. Allow to cool down completely before moving or storing. 9. Unplug the appliance from outlet when not in use or before cleaning. Allow appliance to cool down before putting on or taking off parts, and before cleaning. 10. Use this appliance only on a level, stable surface to prevent tipping. 11. The appliance MUST be on the ground. Do NOT locate it on tables or counters. Do NOT move it across uneven surfaces. 12. Use only approved and grounded electrical outlet. 13. Do NOT operate the appliance with a damaged cord or plug, or after appliance malfunctions or has been damaged in any manner. Return appliance to our customer service c enter for examination, repair or adjustment. 14. Do NOT let cord touch hot surfaces. 15. Keep a fire extinguisher accessible while using the appliance. 16. Do NOT use fuel, such as charcoal briquettes or heat pellets for in this appliance. 17. Do NOT use this appliance as a heater (READ CARBON MONOXIDE HAZARD ABOVE). 18. Be careful when removing food from the appliance. All surfaces are HOT and may cause burns. 19. Do NOT allow anyone to conduct activities around the appliance during or following its use until the unit has cooled. 20. Do NOT use appliance when under the influence of alcohol, prescription or non-prescription drugs. 3 of 23 20150120 ver.1 WARNING GENERAL WARNINGS AND SAFETY INFORMATION 1. Do not cover cooking racks with metal foil. This will trap heat and damage the appliance. 2. Drip tray is only used at bottom of the drawer. Do not put it on the cooking racks and this may damage the appliance. 3. Wood chip tray is HOT when the appliance is in operation. Use caution when adding wood chips. 4. For disconnection, press “OFF” button on control panel then remove the plug from the outlet. 5. Make sure to unplug the appliance when not in use or before cleaning. Let the appliance cool completely before adding/removing racks or trays. 6. Dispose cold ashes by placing them in aluminum foil and soaking with water then discarding in a non-combustible container. 7. Do not store the appliance with HOT ashes inside. Store it only when all surfaces are cool. 8. Do not use accessory attachments which are not supplied by appliance manufacturer. 9. Do not use the appliance other than its intended purpose. This unit is not for commercial use. 10. Always use the appliance in accordance with all applicable local, state and federal fire codes. 11. Longer detachable power-supply cords or extension cords are available and may be used with care. 12. An extension cord is used: 1. The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance; and 2. The cord should be arranged so that it will not be pulled or cause a trip hazard. 13. Extension cord must be a grounding type, 3-wire cord. 14. Outdoor extension cords must be used with this appliance and be marked with suffix “W” and with the statement “Suitable for Use with Outdoor Appliances”. 15. To reduce the risk of electric shock, keep extension cord connection dry and off the ground. WARNING Combustion by-products produced when using this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. 4 of 23 20150120 ver.1 WARNING 1. This appliance is for OUTDOOR USE ONLY. 2. This appliance is used for slow cooking. Please allow sufficient time for cooking. 3. Pre-season smoker prior to first use. Please refer to page 14. 4. Before loading food, pre-heat the appliance for 30 to 45 minutes at maximum temperature. 5. Do not cover racks with aluminum foil as this will cause inappropriate heat circulation. 6. Do not overload the appliance with food. Excess amount of food may trap heat. It will extend the cooking time and cause uneven cooking. Keep enough space between foods on racks to ensure proper heat circulation. The weight limit of each cooking rack is 15 pounds (6.8 kg) maximum. If use cooking pan, place the pan at center of rack to obtain even cooking performance. 7. Keep ai…
