Version 1.1 - 23/06/15 Controlant ehf | www.controlant.com | [email protected] | Tel: +354-517-0630 Quick installation guide for CO 11.01 Gateway (1/3) 1. Before you begin please make sure that you have the following items at hand: A. Gateway B. 2 x antennas (long) C. 1 x antenna (short) D. Wall adapter E. GPS antenna (optional) 2. Fasten the all antennas (B C and E) to the gateway (A) and screw tight. 3. 4. Plug the wall adapter (D) and to an available wall socket (110/220 Vac). 5. Plug the wall adapter plug into the gateway (F). Version 1.1 - 23/06/15 Controlant ehf | www.controlant.com | [email protected] | Tel: +354-517-0630 Quick installation guide for CO 11.01 Gateway (2/3) 6. Turn the gateway ON (G). 7. Wait until the power light (H) lights green and blinks (turns off shortly) every 4 seconds. 8. Make sure that the gateway (A) is securely mounted with the antennas pointing upwards. For optimal functionality avoid mounting the transceiver on metal surface and try to have as few obstacles between the Transceiver and the wireless sensors as possible. 9. Please email or call our support desk for further information or assistance if needed. Version 1.1 - 23/06/15 Controlant ehf | www.controlant.com | [email protected] | Tel: +354-517-0630 Quick installation guide for CO 11.01 Gateway (3/3) FCC Regulatory notices Interference statement This device complies with Part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Wireless notice This equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled environment. The antenna should be installed and operated with minimum distance of 20 cm between the radiator and your body. FCC Class B digital device notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.
Document 75929314 Report 06 Issue 2 June 2015 Report On RF Exposure Assessment of the Controlant ehf. CO 11.01 Transceiver FCC ID: 2AD9RCO1101 IC: 5131a-HE910 TÜV SÜD Product Service, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuv-sud.co.uk Document 75929314 Report 06 Issue 2 Page 1 of 30 REPORT ON RF Exposure Assessment of the Controlant ehf. CO 11.01 Transceiver Document 75929314 Report 06 Issue 2 June 2015 PREPARED FOR Controlant ehf. Grensásvegi Reykjavik 108 Iceland PREPARED BY Sarah Jones Senior Engineer (Projects) APPROVED BY Simon Bennett Authorised Signatory DATED 26 June 2015 This report has been up-issued to Issue 2 to correct the FCC ID. Document 75929314 Report 06 Issue 2 Page 2 of 30 CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction .................................................................................................................................... 4 1.2 Regional Requirements ................................................................................................................. 5 1.3 Product Information ....................................................................................................................... 6 1.3.1 Technical Description .................................................................................................................... 6 1.3.2 Supported Features ....................................................................................................................... 6 1.3.3 Antennas ........................................................................................................................................ 6 1.4 Brief Summary of Results .............................................................................................................. 7 1.4.1 Configuration 1 - GSM 850 ............................................................................................................ 8 1.4.2 Configuration 2 - GSM 900 ............................................................................................................ 9 1.4.3 Configuration 3 - DSC 1800 ........................................................................................................ 10 1.4.4 Configuration 4 - PCS 1900 ......................................................................................................... 11 1.4.5 Configuration 5 - WCDMA 850 .................................................................................................... 12 1.4.6 Configuration 6 - WCDMA 900 .................................................................................................... 13 1.4.7 Configuration 7 - WCDMA 1900 .................................................................................................. 14 1.4.8 Configuration 8 - SRD 868........................................................................................................... 15 1.4.9 Configuration 9 - SRD 915........................................................................................................... 16 2 TEST DETAILS .......................................................................................................................... 17 2.1 Rationale for Assessment of the RF Exposure ........................................................................... 18 2.2 Test Result Details ....................................................................................................................... 19 2.2.1 Configuration 1 - GSM 850 .......................................................................................................... 19 2.2.2 Configuration 2 - GSM 900 .......................................................................................................... 20 2.2.3 Configuration 3 - DSC 1800 ........................................................................................................ 21 2.2.4 Configuration 4 - PCS 1900 ......................................................................................................... 22 2.2.5 Configuration 5 - WCDMA 850 .................................................................................................... 23 2.2.6 Configuration 6 - WCDMA 900 .................................................................................................... 24 2.2.7 Configuration 7 - WCDMA 1900 .................................................................................................. 25 2.2.8 Configuration 8 - SRD 868........................................................................................................... 26 2.2.9 Configuration 9 - SRD 915........................................................................................................... 27 3 DISCLAIMERS AND COPYRIGHT ............................................................................................ 29 3.1 Disclaimers and Copyright ........................................................................................................... 30 Document 75929314 Report 06 Issue 2 Page 3 of 30 SECTION 1 REPORT SUMMARY RF Exposure Assessment of the Controlant ehf. CO 11.01 Transceiver Document 75929314 Report 06 Issue 2 Page 4 of 30 1.1 INTRODUCTION The information contained in this report is intended to show verification of the RF Exposure Assessment of the Controlant ehf. CO 11.01 Transceiver to the requirements of the applied test specifications. Objective To perform RF Exposure Assessment to determine the Equipment Under Test's (EUT’s) compliance of the applied rules. Applicant Controlant ehf. Manufacturer Controlant ehf. Manufacturing Description Transceiver Model Number(s) CO 11.01 Test Specification/Issue/Date Council Recommendation 1999/519/EC CFR 47 Pt1.1310 Health Canada Safety Code 6 ARPANSA Radiation Protection Series No.3 …
Text truncated - open the document above for the full version.
Document 75929314 Report 02 Issue 2 June 2015 Report On Limited FCC Testing of the Controlant ehf. CO 11.01 Transceiver In accordance with FCC CFR 47 Part 15C COMMERCIAL-IN-CONFIDENCE FCC ID: 2AD9RCO1101 TÜV SÜD Product Service, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuv-sud.co.uk COMMERCIAL-IN-CONFIDENCE Document 75929314 Report 02 Issue 2 Page 1 of 44 COMMERCIAL-IN-CONFIDENCE REPORT ON Limited FCC Testing of the Controlant ehf. CO 11.01 Transceiver In accordance with FCC CFR 47 Part 15C Document 75929314 Report 02 Issue 2 June 2015 PREPARED FOR Controlant ehf. Grensásvegi Reykjavik 108 Iceland PREPARED BY Natalie Bennett Senior Administrator, Project Support APPROVED BY Simon Bennett Authorised Signatory DATED 26 June 2015 This report has been up-issued to Issue 2 to correct the FCC ID and remove results for 2PSK modulation ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Part 15C. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); G Lawler N Rousell Document 75929314 Report 02 Issue 2 Page 2 of 44 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Declaration of Build Status ........................................................................................................... 6 1.4 Product Information ...................................................................................................................... 7 1.5 Test Conditions ............................................................................................................................. 7 1.6 Deviations from the Standard ....................................................................................................... 7 1.7 Modification Record ...................................................................................................................... 7 2 TEST DETAILS ............................................................................................................................ 8 2.1 Frequency Hopping Systems - 20 dB Bandwidth and Channel Separation ................................. 9 2.2 Frequency Hopping Systems - Channel Dwell Time and Number of Hopping Channels .......... 14 2.3 Maximum Peak Conducted Output Power ................................................................................. 19 2.4 EIRP Peak Power ....................................................................................................................... 21 2.5 Spurious and Band Edge Emissions .......................................................................................... 25 3 TEST EQUIPMENT USED ......................................................................................................... 39 3.1 Test Equipment Used ................................................................................................................. 40 3.2 Measurement Uncertainty .......................................................................................................... 42 4 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 43 4.1 Accreditation, Disclaimers and Copyright ................................................................................... 44 Document 75929314 Report 02 Issue 2 Page 3 of 44 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY Limited FCC Testing of the Controlant ehf. CO 11.01 Transceiver In accordance with FCC CFR 47 Part 15C Document 75929314 Report 02 Issue 2 Page 4 of 44 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show the verification of Limited FCC Testing of the Controlant ehf. CO 11.01 Transceiver to the requirements of FCC CFR 47 Part 15C. Objective To perform Limited FCC Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Controlant ehf. Model Number(s) CO 11.01 Transceiver Serial Number(s) CMS 0100087E Number of Samples Tested 1 Test Specification/Issue/Date FCC CFR 47 Part 15C (2014) Incoming Release Date Declaration of Build Status 29 January 2015 Disposal Reference Number Date Held Pending Disposal Not Applicable Not Applicable Order Number Date Quotation Acceptance Form 30 January 2015 Start of Test 11 February 2015 Finish of Test 16 March 2015 Name of Engineer(s) G Lawler N Rousell J Hurley Related Document(s) ANSI C63.10: 2009 Document 75929314 Report 02 Issue 2 Page 5 of 44 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.2 BRIEF SUMMARY OF RESULTS A brief summary of the tests carried out in accor dance with FCC CFR 47 Part 15C is shown below. Section Spec Clause Test Description Result Comments/Base Standard Transmit 2.1 15.247 (a)(1) Frequency Hopping Systems - 20 dB Bandwidth and Channel Separation Pass 2.2 15.247 (a)(1)(iii) Frequency Hopping Systems - Channel Dwell Time and Number of Hopping Channels Pass 2.3 15.247 (b)(3) Maximum Peak Conducted Output Power Pass 2.4 15.247 (b)(4) EIRP Peak Power Pass 2.5 15.247 (d) Spurious and Band Edge Emissions Pass Document 75929314 Report 02 Issue 2 Page 6 of 44 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.3 DECLARATION OF BUILD STATUS Document 75929314 R…
Text truncated - open the document above for the full version.
FCC ID: R17HE910 IC: 5131a-HE910 Controlant ehf. CO 11.01 Transceiver 2015 Not to be reproduced, except in its entirety, Page 1 of 4 without the Permission of TÜV SÜD Product Service Reference: 75929719 PHOTOGRAPHS OF TEST SET UP FCC Part 15B Radiated Emissions 30 MHz to 1 GHz FCC ID: R17HE910 IC: 5131a-HE910 Controlant ehf. CO 11.01 Transceiver 2015 Not to be reproduced, except in its entirety, Page 2 of 4 without the Permission of TÜV SÜD Product Service Reference: 75929314 FCC Part 15B Radiated Emissions 1 GHz to 13 GHz FCC ID: R17HE910 IC: 5131a-HE910 Controlant ehf. CO 11.01 Transceiver 2015 Not to be reproduced, except in its entirety, Page 3 of 4 without the Permission of TÜV SÜD Product Service Reference: 75929314 FCC Part 15.247 Radiated Emissions 30 MHz to 1 GHz FCC ID: R17HE910 IC: 5131a-HE910 Controlant ehf. CO 11.01 Transceiver 2015 Not to be reproduced, except in its entirety, Page 4 of 4 without the Permission of TÜV SÜD Product Service Reference: 75929314 FCC Part 15.247 Radiated Emissions 1 GHz to 10 GHz
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 903 MHz - 927 MHz | 12.60 mW |

Ambient Temperature Logger
Equipment Class
DTS - Digital Transmission System
Ambient Temperature Logger
Equipment Class
DTS - Digital Transmission System
Ambient Temperature Logger
Equipment Class
DTS - Digital Transmission System
