2ADAR504006Vibratissimo Cinque

[Vibratissimo ] Amor Gummiwaren GmbH August‐Rost‐Straße 4 99310 Arnstadt, Germany +49 (0)3628 / 66287 – 5 +49 (0) 06328 / 66287 ‐59 www.vibratissimo.com User Manual Product description  Intended Use  Initial Operations  Operating Instructions General Safety Instructions  Safety instructions  Health protection  Handling and storage  Disposal advice Technical Data  Electrical Characteristics Rev. A‐ 2014‐11‐18 VIBRATISSIMO Cinque FCC ID: 2ADAR504006 IC: 12372A‐504006 Read these operating instructions carefully before using your Vibratissimo, and follow the instructions! Non‐adherence to these instructions can lead to damage to the device and/or other damage to property and/or personal injury. Clean your Vibratissimo before use! Find out about regular news about Vibratissimo at www.vibratissimo.com! Please note! Control via Smartphone only works with operating systems from Android 4.3 (upwards) or Apple I‐Phone 4S (upwards)! Please note that Bluetooth only works with Vibratissimo within a range of max. 10m! Intended Use: Vibratissimo can be used for selective massaging as well as for blood‐flow stimulating, vitalizing massaging of larger body surface areas. It is made of materials that are non‐hazardous for health. The gliding behaviour can be improved by applying a water‐soluble lubricant. Initial operations: Get your Vibratissimo ready for use Please clean the vibrator before the first and every new use, with running water and soap or TOY CLEANER from the Vibratissimo series, in a switched off and closed state. Charge the battery: Only use the charging cable supplied for charging. When using other parts, no guarantee can be made that these parts are compatible. Do not charge the vibrator during a storm. In case of a storm, disconnect the power supply from the mains, if you have the Vibratissimo connected to the mains outside of charging times. Before you start charging, check whether all parts (vibrator and charging cable) are undamaged, clean and dry. Particularly check the 2 contact points on the charging cable and the 2 small magnetic points on the handle of the vibrator. The magnetic points on the handle of the vibrator and the surrounding area must be free from soap residues or other residues. You can find instructions for cleaning in these operating instructions under "Safety instructions". The removal cord has a USB plug (type A). Plug this into the USB terminal of your PC, laptop or tablet, etc. Then connect the other end of the charging cable to the vibrator. Place the 2 contact points on the charging cable exactly on the 2 magnetic points on the handle of the vibrator. Never connect the power supply, charging cable and vibrator differently, because with a different arrangement the battery will not charge, and to rule out all risks which may arise from such an incorrect connection. Check all connections again before you finally connect the power supply with the socket. A completely discharged battery requires approx. 6 hours charging time. Do not put the vibrator into operation and/or use it during the charging process! When the charging process is completed, first remove the power supply from the socket, then loosen the other connections. In doing so, always pull on the plug and not the charging cable. You do not always need to completely charge the battery. However, a minimum charge level of approx. 70% should always be aimed at, amongst other things to ensure that your Vibratissimo is always completely efficient. Charge the battery after every use of the vibrator. Charge the battery at least once a month if you have not used the vibrator for a long time, or if it will not be used for a long time. Even in this case, a charge level of 70% is optimum. Now your Vibratissimo is ready for operation, and you can operate it by hand, or control it via your Smartphone. To get the Vibratissimo‐App: Start "Google play" or "AppStore" directly on your Smartphone and enter Vibratissimo in the search engine. Load the App onto your Smartphone. App started? Then simply enter any nickname and a password and log in with them. Operating instructions: How your Vibratissimo works ‐ manual operation with the setting wheel When you turn the setting wheel, the vibrator begins to vibrate in the first pre‐installed programme. You can adjust the vibration strength by turning the setting wheel up and down. You can get to the next vibration programme by moving the setting wheel into the desired position. You can get to the programme after next in the same way, etc. To switch off, turn the setting wheel in the direction that reduces the vibration strength, until it stops. ‐ via Smartphone: Switch on the vibrator manually with the setting wheel. Also activate the Smartphone, i.e. start the App. Please note that the Bluetooth in the Vibratissimo only works within a range of max. 10m. As soon as you have logged in, you will see the Vibratissimo desktop with 4 buttons. Connect to your Vibratissimo device via the "MyToys" button. As soon as you have pressed this button, the available connections will be shown. Select your device and connect it. As soon as the connection is established, you can determine the status of your device via "ToyInfo", e.g. charge status, battery status, temperature of the device. You can find an intuitive remote control via the Smartphone under "ToyControl". Move your finger over the surface of your smartphone to control the intensity, rhythm, and strength. Under "MyVibes" you can find additional functions, e.g. you can record and save your own vibration programmes there, download saved programmes, etc. Safety instructions: ‐ for your health: Please consult your doctor before use during or after pregnancy, after medical operations or other health problems. Your Vibratissimo is intended for individual use, i.e. it should only ever be used by the same person. ‐ for your safety: A damaged Vibratissimo must not be used. Do not use the parts if you perceive unusual odours, if the part…

Text truncated - open the document above for the full version.

External Photos page 1 Model No.:Cinque FCC ID: 2ADAR504006 IC: 12372A-504006 Project No.: G0M-1409-4154

Internal Photos page 1 Model No.:Cinque FCC ID: 2ADAR504006 IC: 12372A-504006 Project No.: G0M-1409-4154

Test Report No.: G0M-1409-4154-TFC093PE-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 12 RF-EXPOSURE ASSESSMENT REPORT FCC 47 CFR Part 2.1093 Industry Canada RSS-102 RF-Exposure evaluation of portable equipment Report Reference No. ..................... : G0M-1409-4154-TFC093PE-CINQUE-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Amor Gummiwaren GmbH Address............................................. : August-Rost-Straße 4 99310 Arnstadt GERMANY Test specification: Standard ........................................... : 47 CFR 1.1310 / 47 CFR 2.1091 / 47 CFR 2.1093 OET Bulletin 65:1997 KDB 447498 D01 v05r01:2013-05-28 RSS-102, Issue 4:2010 Safety Code 6:2009 Equipment under test (EUT): Product description electric device Model No. CINQUE Additional Model(s) None Brand Name(s) Vibratissimo Hardware version V2.0 Firmware / Software version BLE-Stack SD110 V6.0.0 FCC-ID: 2ADAR504006 IC: 12372A-504006 Test result Passed Test Report No.: G0M-1409-4154-TFC093PE-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 12 Version History Version Issue Date Remarks Revised by 01 2015-01-19 Initial Release Test Report No.: G0M-1409-4154-TFC093PE-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 12 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Reference Documents 6 1.2 Radiation Sources 7 2 RESULT SUMMARY 8 3 RF-EXPOSURE CLASSIFICATIONS 9 4 ASSESSMENT 10 4.1 SAR Exemption Assessment –FCC KDB447498 / RSS-102 10 Test Report No.: G0M-1409-4154-TFC093PE-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 12 1 Equipment (Test item) Description Description electric device Model CINQUE Additional Model(s) None Brand Name(s) Vibratissimo Serial number None Hardware version V2.0 Software / Firmware version BLE-Stack SD110 V6.0.0 FCC-ID 2ADAR504006 IC 12372A-504006 Equipment type End product Test Report No.: G0M-1409-4154-TFC093PE-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 12 1.1 Reference Documents Document type Document No. Issued by Date Test report G0M-1409-4154-TFV247BL- CINQUE -V01 Eurofins Product Service GmbH 2015-01-19 Test Report No.: G0M-1409-4154-TFC093PE-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 12 1.2 Radiation Sources Mode # Description Bluetooth Low Energy Frequency range [MHz] 2402 – 2480 Channels 40 Modulations GFSK Maximum conducted power [dBm] 2.39 Maximum transmission duty cycle [%] 100 (worst case) Test Report No.: G0M-1409-4154-TFC093PE-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 12 2 Result Summary FCC 47 CFR Part 2.1093, KDB447498, IC RSS-102 Product Specific Standard Section Requirement Result Remarks 47 CFR 2.1093 KDB447498 SAR evaluation exemption : Bluetooth PASS RSS-102 2.5.1 SAR evaluation exemption : Bluetooth PASS Remarks: Test Report No.: G0M-1409-4154-TFC093PE-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 12 3 RF-Exposure Classifications Device Types Fixed A fixed device is defined as a device physically secured at one fixed location and cannot be easily re-located. Mobile A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. (47 CFR 2.1091) Portable A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. (47 CFR 2.1093) Exposure Categories Occupational / Controlled Limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. General population / uncontrolled Exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. Test Report No.: G0M-1409-4154-TFC093PE-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 12 4 Assessment 4.1 SAR Exemption Assessment –FCC KDB447498 / RSS-102 Low Power Exclusion acc. to FCC KDB447498 / IC RSS-102 Verdict: PASS Assessment according to reference Reference Method KDB447498 & 2.1093 / RSS-102 & Safety Code 6 Device type portable Exposure category General population FCC/IC SAR Limits Region Occupational SAR values [W/kg] General public SAR values [W/kg] Whole-body SAR averaging mass = entire body 0.4 0.08 Partial-body SAR averaging mass = 1g 8.0 1.6 Hands, Wrists, Feet and Ankles SAR averaging mass = 10g 20 4 FCC SAR test exclusion Excerpt from KDB 447498: Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, …

Text truncated - open the document above for the full version.

Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 36 EMC TEST REPORT FCC 47 CFR Part 15B Industry Canada RSS-Gen Electromagnetic compatibility - Unintentional radiators Report Reference No. .................... : G0M-1409-4154-EF0115B-V01 Testing Laboratory ........................ : Eurofins Product Service GmbH Address ............................................ : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation .................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ........................... : Amor Gummiwaren GmbH Address ............................................ : August-Rost-Straße 4 99310 Arnstadt GERMANY Test specification: Standard ........................................... : 47 CFR Part 15 Subpart B RSS-Gen, Issue 3, 2010-12 ANSI C63.4:2009 Equipment under test (EUT): Product description electric device Model No. Cinque Additional Models None Hardware version V2.0 Firmware / Software version BLE-Stack SD110 V6.0.0 FCC-ID: 2ADAR504006 IC: 12372A-504006 Test result Passed Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 36 Version History Version Issue Date Remarks Revised by V01 2014-12-23 Initial Release Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 36 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Photos – Equipment external 6 1.2 Photos – Equipment internal 8 1.3 Supporting Equipment Used During Testing 10 1.4 Input / Output Ports 10 1.5 Operating Modes and Configurations 11 1.6 Test Equipment Used During Testing 12 1.7 Sample emission level calculation 13 2 RESULT SUMMARY 14 3 TEST CONDITIONS AND RESULTS 15 3.1 Test Conditions and Results – Radiated emissions 15 3.2 Test Conditions and Results – AC power line conducted emissions 33 Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 36 1 Equipment (Test item) Description Description electric device Model Cinque Additional Models None Serial number None Hardware version V2.0 Software / Firmware version BLE-Stack SD110 V6.0.0 FCC-ID 2ADAR504006 IC-ID 12372A-504006 Power supply 3.7 V rechargeable LiIon battery AC/DC-Adaptor Model : FW7713 Manufacturer : FRIWO Gerätebau GmbH Input : 100-240VAC / 50-60Hz Output : 5VDC / 1.0A Manufacturer Amor Gummiwaren GmbH August-Rost-Straße 4 99310 Arnstadt GERMANY Highest emission frequency Fmax [MHz] = 2540 Device classification Class B Equipment type Tabletop Number of tested samples 1 Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 36 1.1 Photos – Equipment external EUT EUT Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 36 EUT – AC/DC Adaptor Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 36 1.2 Photos – Equipment internal EUT PCB Top EUT PCB Bottom Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 36 Photos – Test setup Test Setup : Radiated Emissions Test Setup : Conducted Emissions Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 36 1.3 Supporting Equipment Used During Testing Product Type* Device Manufacturer Model No. Comments AE smart phone LG G2 *Note: Use the following abbreviations: AE : Auxiliary/Associated Equipment, or SIM : Simulator (Not Subjected to Test) CABL : Connecting cables 1.4 Input / Output Ports Port # Name Type* Max. Cable Length Cable Shielded Comments 1 AC Power AC - no *Note: Use the following abbreviations: AC : AC power port DC : DC power port N/E : Non electrical I/O : Signal input or output port TP : Telecommunication port Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 36 1.5 Operating Modes and Configurations Mode # Description 1 charging + Bluetooth communication 2 vibrating + Bluetooth communication Configuration # EUT Configuration 1 EUT connected to charger 2 EUT without charger Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 12 of 36 1.6 Test Equipment Used During Testing Measurement Software Description Manufacturer Name Version EMC Test Software Dare Instruments Radimation 2014.1.15 Radiated emissions Description Manufacturer Model Identifier Cal. Date Cal. Due Biconical Antenna R&S HK 116 EF00012 2013-02 2016-02 LPD-Antenne R&S HL 223 EF00187 2014-03 2017-03 Horn antenna Schwarzbeck BBHA 9120D EF00018 2013-09 2016-09 EMI Test Receiver R&S ESU26 EF00887 2014-01 2015-01 Conducted emissions Description Manufacturer Model Identifier Cal. Date Cal. Due AMN R&S ESH2-Z5 EF00182 2014-11 2016-11 EMI Test Receiver R&S ESCS 30 EF00295 2014-10 2015-10 Test Report No.: G0M-1409-4154-EF0115B-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 13 of 36 1.7 Sample emission level calculation The following is a description of terms and a sample calculation, as appears in the radiated emissions data table. The numbers used in the calculation are for example only. There is no direct correlation to the specific data taken for the product described in this document: Reading: This is the reading obtained on the spectrum analyzer in dBμV. Any external preamplifiers used are taken into account through internal analyzer settings. A.F.: This is the antenna factor for t…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 79 FCC TEST REPORT FCC 47 CFR Part 15C Industry Canada RSS-210 Digital transmission systems operating within the 2400 – 2483.5 MHz band Report Reference No. ..................... : G0M-1409-4154-TFC247BL-CINQUE-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Amor Gummiwaren GmbH Address............................................. : August-Rost-Straße 4 99310 Arnstadt GERMANY Test specification: Standard ........................................... : 47 CFR Part 15C KDB Publication No. 558074 RSS-210, Issue 8, 2010-12 RSS-Gen, Issue 4, 2014-11 ANSI C63.4:2009 Test scope.............. ........................ : complete Radio compliance test Equipment under test (EUT): Product description electric device Model No. CINQUE Additional Model(s) None Brand Name(s) Vibratissimo Hardware version V2.0 Firmware / Software version BLE-Stack SD110 V6.0.0 FCC-ID: 2ADAR504006 IC: 12372A-504006 Test result Passed Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 79 Version History Version Issue Date Remarks Revised by 01 2015-01-19 Initial Release Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 79 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Photos – Equipment External 6 1.2 Photos – Equipment internal 7 1.3 Photos – Test setup 8 1.4 Supporting Equipment Used During Testing 9 1.5 Test Modes 10 1.6 Test Equipment Used During Testing 11 1.7 Sample emission level calculation 13 2 RESULT SUMMARY 14 3 TEST CONDITIONS AND RESULTS 15 3.1 Test Conditions and Results – Occupied Bandwidth 15 3.2 Test Conditions and Results – 6 dB Bandwidth 19 3.3 Test Conditions and Results – Maximum peak conducted power 23 3.4 Test Conditions and Results – Power spectral density 24 3.5 Test Conditions and Results – AC power line conducted emissions 25 3.6 Test Conditions and Results – Band edge compliance 28 3.7 Test Conditions and Results – Conducted spurious emissions 31 3.8 Test Conditions and Results – Transmitter radiated emissions 35 3.9 Test Conditions and Results – Receiver radiated emissions 38 ANNEX A Transmitter radiated spurious emissions 40 ANNEX B Receiver radiated spurious emissions 72 Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 79 1 Equipment (Test item) Description Description electric device Model CINQUE Additional Model(s) None Brand Name(s) Vibratissimo Serial number None Hardware version V2.0 Software / Firmware version BLE-Stack SD110 V6.0.0 FCC-ID 2ADAR504006 IC 12372A-504006 Equipment type End product Radio type Transceiver Radio technology Bluetooth 4.0 Low Energy Operating frequency range 2402 - 2480 MHz Assigned frequency band 2400 - 2483.5 MHz Main test frequencies F LOW 2402 MHz F MID 2442 MHz F HIGH 2480 MHz Spreading Frequency Hopping Modulations GFSK Number of channels 40 Channel spacing 2MHz Number of antennas 1 Antenna Type integrated Model printed inverted F antenna Manufacturer unspecified Gain +2.75 dBi (manufacturer declaration) Manufacturer Amor Gummiwaren GmbH August-Rost-Straße 4 99310 Arnstadt GERMANY Power supply V NOM 3.7 VDC V MIN N/A V MAX N/A AC/DC-Adaptor Model FW7713 Vendor Friwo Input 100-240V AC, 50/60 Hz, 150 mA Output 5.0 VDC, 100 mA Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 79 1.1 Photos – Equipment External EUT Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 79 1.2 Photos – Equipment internal EUT PCB TOP EUT PCB BOTTOM Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 79 1.3 Photos – Test setup SETUP AC-Power line SETUP Radiated Spurious Emission Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 79 1.4 Supporting Equipment Used During Testing Product Type* Device Manufacturer Model No. Comments AE Laptop DELL Latitude D 630 - AE AC/DC adaptor FRIWO Gerätebau GmbH FW7713 - AE : Auxiliary/Associated Equipment Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 79 1.5 Test Modes Mode # Description Transmit General conditions: EUT powered by internal battery. Radio conditions: Mode = standalone transmit Spreading = Hopping stopped (single hopping channel) Modulation = GFSK Data rate = 1 Mbps Bandwidth = 2 MHz Duty cycle = 100 % Power level = Maximum Receive General conditions: EUT powered by internal battery. Radio conditions: Mode = standalone receive (scan mode) Spreading = FHSS Modulation = GFSK AC-Powerline General conditions: EUT charged by AC/DC adaptor Radio conditions: Mode = Radio “OFF” during charging Test Report No.: G0M-1409-4154-TFC247BL-CINQUE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 79 1.6 Test Equipment Used During Testing Measurement Software Description Manufacturer Name Version EMC Test Software Dare Instruments Radimation 2014.1.15 Occupied Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum analyzer R&S FSW43 EF00896 2014-02 2015-…

Text truncated - open the document above for the full version.

TSup Photos page 1 Model No.:Cinque FCC ID: 2ADAR504006 IC: 12372A-504006 Project No.: G0M-1409-4154
