2ADAU5003325WALL SWITCH TO MODULE INTERFACE BOARD

161014 610.INS INSTRUCTION MANUAL - 5003.325-A INTERFACE BOARD 1. PLUG INTERFACE BOARD INTO SIT MODULE. 2. CONNECT THE WIRE HARNESS AND COMMUNICATION CABLES SHOWN IN FIGURE A. FIG A 3. OPERATE AS PER THE FIREPLACE OPERATING INSTRUCTIONS. THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES AND INDUSTRY CANADA LICENSE- EXEMPT RSS STANDARD(S). OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. NOTE: THE GRANTEE IS NOT RESPONSIBLE FOR ANY CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. CET APPAREIL EST CONFORME AU 15 REGLES DE LA FCC ET D'INDUSTRIE CANADA EXEMPTS DE LICENCE STANDARD RSS (S). FONCTIONNEMENT EST SOUMIS AUX DEUX CONDITIONS SUIVANTES: (1) CET APPAREIL PEUT CAUSER DES INTERFERENCES NUISIBLES, ET (2) CET APPAREIL DOIT ACCEPTER TOUTE INTERFERENCE REÇUE, INCLUANT TOUTE INTERFERENCE POUVANT CAUSER UN FONCTIONNEMENT INDESIRABLE. REMARQUE: LE BENEFICIAIRE EST PAS RESPONSABLES DES EVENTUELLES MODIFICATIONS OU MODIFICATIONS NON EXPRESSEMENT APPROUVES PAR LA PARTIE RESPONSABLE DE LA CONFORMITÉ. CES MODIFICATIONS PEUVENT ANNULER LE DROIT DE L'UTILISATEUR À UTILISER L'APPAREIL. GAS VALVE CONNECTION CAT 5 CABLE TO WALL SWITCH CONNECT TO AIR PRESSURE SWITCH

19473 Fraser Way Pitt Meadows, BC Canada V3Y 2V4 ph. 604-527-8378 |fx. 604 527 8388 Electromagnetic Compatibility Test Report FCC CFR47, PART 15, SUBPART C Section 15.231,15.205 & RSS 210 issue 8, Annex 1 Report Reference No. .....................: E10657-1401 Rev 2.0 Date of issue ........................................: Oct-16-2014 Total number of pages. . . .. .. . ... . .. . ..: 30 Testing Laboratory........................ : Quality Auditing Institute Address................................................ : 16 – 211 Schoolhouse Street, Coquitlam, BC, V3K 4X9, Canada Accreditations (ISO 17025): Standard Council of Canada: Accredited Laboratory No. 743 International Accreditation Service Inc: Accredited Laboratory: No. TL-239 This report has been completed in accordance with the requirements of ISO/IEC 17025. Test results contained in this report are within QAI Laboratories ISO/IEC 17025 accreditation. QAI Laboratories authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for the use by the company’s employees only. Applicant’s name ..............................: Pacific Energy Fireplace Products Address......................................: 2975 Allenby Rd. Duncan, BC V9L 6V8 Contact.......................................: Mike Hollin, Email ...............: [email protected] Phone.........................................: (250)748-1184 Test Standard................................ : FCC CFR47, Part 15, Subpart C Section 15.231,15.205 & RSS 210 issue 8, Annex 1 Test item description................... : Interface Board 5003.325 Manufacturer ...................................: Pacific Energy Fireplace Products Model Number ................ .............: 5003.325 FCC ID ................................. ........: 2ADAU5003325 IC Certification No. ........................: 12377A-5003325 Client: Pacific Energy Fireplace Products Job No.: E10657-1401 Date: Oct 16, 2014 Page 2 of 30 Interface Board 5003.325 (EUT) Client: Pacific Energy Fireplace Products Job No.: E10657-1401 Date: Oct 16, 2014 Page 3 of 30 Revision History Date Report Number Rev # Details Authors Initials Sep-22-2014 E10657-1401 0.0 Draft Test Report JQ Oct-03-2014 E10657-1401 1.0 Final Test Report JQ Oct-16-2014 E10657-1401 2.0 Final Test Report with all the changes as per the TCB response. AJ All previous versions of this Report have been superseded by the latest dated Revision as listed in the above table. Please dispose of all previous electronic and paper printed revisions accordingly. Client: Pacific Energy Fireplace Products Job No.: E10657-1401 Date: Oct 16, 2014 Page 4 of 30 Index Section I: GENERAL TEST INFORMATION ...................................................................................... 5 EMC TEST SUMMARY....................................................................................................... 5 PRODUCT DESCRIPTION ................................................................................................. 6 EUT DESCRIPTION ........................................................................................................... 6 FACILITIES AND ACCREDITATION .................................................................................. 7 ENVIROMENTAL CONDITIONS: ....................................................................................... 7 TESTING METHODOLOGY ............................................................................................... 7 EUT TESTING CONFIGURATION ..................................................................................... 7 GENERAL TEST PROCEDURES ...................................................................................... 7 MEASUREMENT UNCERTAINTY ..................................................................................... 8 TEST EQUIPMENT LIST .................................................................................................... 8 Section II: Requirements for the US(FCC) & Canadia(IC) Market ....................................................... 9 Part 1 - AC Mains Conducted Emissions .......................................................................... 10 Part 2 - Radiated Emissions Testing ................................................................................. 19 Part 3 - Transmitter Radiated Spurious Emissions .......................................................... 21 Part 4 - Occupied Bandwidth ............................................................................................ 25 Part 5 - Transmitter Deactivates with in 5 seconds .......................................................... 27 Part 6 - Automatic Transmissions Not exceeding 2 secs/hour for transmitter ................. 28 Appendix A: Test Setup Pictures ........................................................................................................... 29 Client: Pacific Energy Fireplace Products Job No.: E10657-1401 Date: Oct 16, 2014 Page 5 of 30 Section I: GENERAL TEST INFORMATION EMC TEST SUMMARY The following tests demonstrate the testimony to “FCC & IC” Mark Electromagnetic compatibility testing for “Interface Board 5003.325” manufactured by Pacific Energy Fireplace Products. The testing was performed pursuant to FCC CFR47, Part 15, Subpart C Section 15.231, 15.205 & RSS 210 issue 8, Annex 1 Tests were conducted on a sample of the equipment as requested by Pacific Energy Fireplace Products for the purpose of demonstrating compliance with FCC CFR47, Part 15, Subpart C Section 15.231,15.205 & RSS 210 issue 8, Annex 1. Pacific Energy Fireplace Products is responsible for the tested product configuration, continued product compliance with these standards listed, and for the appropriate auditing of subsequent products, as required. Please note that this list of tests may only comprise a partial list of the tests that are required before a FCC or IC label can be produced by the manufacturer. This is to certify that the following report…

Text truncated - open the document above for the full version.

Test Setup Photos
