2ADB5-TRACKER1Pro-tracker The Ultimate Tracking Device

Tracker 1 User Manual Module description Programming port interface description Down Loading code description Exclusive Application Platform Description for Module Transfer protocol RF General Information CC Debugger Connector GndVCC CLK Data Reset SPI ProgrammingPins Programming port interface description Move mouse to upper right corner icon to click it , and then Flash Programmer will appear. Next, move the mouse to Flash programmer Anti ‐ white area and click the mouse, then enter the programming Screen.. Down Loading code description Select programming file Check the box Fill in four Fill in 1000 97 98 99 9A 9B 9C 9D 9E 9F A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 AA AB AC AD AE AF B0 B1 ... ......... . . Transmitter ID Click “Perform actions” Programming OK Programming screen C:\Transmit_20140627_2.HEX 1000 Battery V+V ‐ After installing the battery, move magnet away, then turn on the power to send out information move magnet close, turn off the power module only used for Pro ‐ Tracker platform Exclusive Application Platform Description for Module • Transfer protocol • Baud Rates : 2.4K Start First 30 minutes 12 seconds on to sending information 6 seconds off After 30 minutes 10 seconds on to sending information 6 seconds off After 1 hour 8 seconds on to sending information 6 seconds off After 1 hours 8 seconds on to sending information 8 seconds off • RF General Information • Frequency Range : 902 ‐ 928 MHz • Modulation : FSK • Ch. Frequency : 905 ‐ 927.25 Mhz • Bandwith : 250 KHz • Channel Number : 89 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module. Appropriate measurements (e.g. 15 B compliance) and if applicable additional equipment authorizations (e.g. Verification , Doc) of the host device to be addressed by the integrator/manufacturer. LABEL OF THE END PRODUCT: The final end product must be labeled in a visible area with the following " Contains TX FCC ID: 2ADB5-TRACKER1 ".

Confidentiality Request Letter Federal Communications Commission Authorization and Evaluation Division FCC ID : 2ADB5-TRACKER1 Permanent Confidentiality Request Date: 2014/1 0/22 Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosu~e of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Applicant's company name Applicant's company address Signature Job Title and Dept. E-mail Tel. Pro-Tracker LLC 6010 South 400 West Rexburg Idaho 83440 USA gary@pro-tracker. com 801-608-0190

Limited Module Approval Request LeHer Subject: Limited Module Approval Date: ~i.ZU FCCID:2ADB~TRACKER1 Dear Reviewer, We, Pro-Tracker LLC would request Pro-tracker The Ultimate Tracking Device approved under limited module approval authorization. The application of this module is specified to portable or mobile host equipment. The requirements regulated in 15.212 have been fulfilled and clearly explained below. 1. The requirement of RF shielding: The module dces not have its own RF shielding and will be integrated in Pro-Tracker model: Tracker X (X can be 0-9, A-Z or blank) host. Pro-Tracker LLC will retain control over all final installations of the device into its product, and therefore can assure the compliance of the end product to the tested results. 2. The requirement of buffered inputs: Buffered data inputs stage has been integrated in chip (CC 111 0). 3. The requirement of power supply regulation: The part number of the power regulator is (CL-2025). 4. The requirements of section 15.203 and 15.204(C): The requirements of antenna connector and spurious emission have been fulfilled. Please reference the exhibition Test Report. 5. The requirement of stand-alone test configuration: Please reference exhibition Test Configuration Photo for the stand-alone test configuration. 6. The requirement of labeling: The instruction on the labeling rule of the end product has been stated in the user's manual of this module. Please also see the exhibition Label Sample. 7. The requirement of compliance on specific rule or c;>perating requirements: The required FCC rule has been fulfilled and all the instructions for maintaining compliance has been clearly stated in the Users Manual. 8. The requirement of RF exposure: The module only radiates very low power levels; it complies with RF exposure requirement. Please do not hesitate to contact me for any questions of this request letter. Thank you. Applicant's company name Pro-Tracker LLC Applicant's company address 6010 South 400 West Rexburg Idaho 83440 USA Signature Job Title and Dept. E-mail [email protected] Tel. 801-608-0190

Federal Communications Commission 7 435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Product Certification Representative Authorization Letter FCCID:2ADB~TRACKER1 Product name: Pro-tracker The Ultimate Tracking Device To whom it may concern: Date: 2014/10/22 We the undersigned, hereby authorize following person to act as our agent in the preparation of an application for equipment authorization of model Tracker 1 to the FCC Rules and Regulations. Sporton International Inc. Address Name Job Title e-mail No. 52, Hwa Ya 1st Road., Kwei-Shan Hsiang, TaoYuan Hsien Taiwan R.O.C. Kevin Liang Vice Manager [email protected] We further certifies that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002(b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 835(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Applicant Address Signature Name and Job Title. E-mail Tel. Pro-Tracker LLC 6010 South 400 West Rexburg Idaho 83440 USA Gary Chrisfensen I President [email protected] 801-608-0190
