2ADDXRF001WIRELESS REMOTE BATTERY PACKS

SAVE THESE INSTRUCTIONS HOW TO USE Charger: 1. Plug the adapter unit into an available AC outlet. The adapter works with most 100-240V AC power outlets. 2. Charger LED only for charger power indication. 3. The adapter can charge two RF battery by the split cord at the same time Note: For 240V, use appropriate country adapter. 4. Do not try to charge battery pack by other company. RF Battery pack: Press button holding for 3 seconds to activate Press button to select output setting and to power off 4 level Output Settings 25%-50%-75%-100% 1 light ON=25% output (during discharging) 4 lights ON=100% highest setting RF remote controller: The remote can control two RF battery to activate at the same time Press “ON” button holding for 3 seconds to activate in two metre Press “ON” button to select output setting and to power off 4 level Output Settings 25%-50%-75%-100% 1 light ON=25% output (during discharging) 4 lights ON=100% highest setting Press “OFF” button to power off directly This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTON: 1. Burn hazard, fire hazard and explosion hazard associated with mishandling of the battery 2. To avoid possible hazards, do not crush, disassemble, dispose of in fire, or similar actions 3. Risk of Fire and Burns. Do Not Open, Crush, Heat Above 65°C 4. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

FCC ID: 2ADDXRF001 EXTERIOR PHOTOGRAPHS

Label & Label Location Label: Label Location: FCC ID: 2ADDXRF001 Model no.: RF001 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in China Label Location

FCC ID: 2ADDXRF001 INTERIOR PHOTOGRAPHY

FCC ID：2ADDXRF001 Report No.: EA1410010F 01001 1 of 19 DongGuan Anci Electronic Technology Co., Ltd No. A222, Building A, Shifu Hardware Plaza, Changan Town, Dongguan City, Guangdong Pr., China. Phone: 86-769- 8507 5888; Fax: 86-769- 8507 5898 E-mail: [email protected] Rev. 1.0 TEST REPORT FCC TEST REPORT Under FCC 15 Subpart B Report Reference No. .......................: EA1410010F 01001 Engineer (name + signature) ............: Kelly Wu ...................................................... Approved by (name + signature) ......: Joe Long ...................................................... Date of issue .....................................: Oct. 23, 2014 Testing Laboratory ............................: Dong Guan Anci Electronic Technology Co., Ltd. Address .............................................: No. A222, Building A, Shifu Hardware Plaza, Changan Town, Dongguan City, Guangdong Pr., China. Applicant’s name ..............................: Luen Ming Electric Works CO., Ltd. Address .............................................: Flat G, 2F. & 10F., Wah Hing lndustrial Mansions, 36 Tai Yau Street, San Po Kong, Kowloon, Hong Kong Manufacturer .....................................: Shen Zhen Luen Ming Hing Plastic & Electric Technology Co.,Ltd. Address .............................................: No. 103, Ao Yi Road, Heng Gang, Long Gang Town, Shen Zhen City, Guang Dong, China Test specification: Test item description .........................: WIRELESS REMTOTE BATTERY PACKS Trade Mark ........................................: N/A Model/Type reference .....................: RF001 Ratings ..............................................: DC 3V 20mA FCC ID：2ADDXRF001 Report No.: EA1410010F 01001 2 of 19 DongGuan Anci Electronic Technology Co., Ltd No. A222, Building A, Shifu Hardware Plaza, Changan Town, Dongguan City, Guangdong Pr., China. Phone: 86-769- 8507 5888; Fax: 86-769- 8507 5898 E-mail: [email protected] Rev. 1.0 Table of Contents Page 1 GENERAL INFORMATION 4 1.1 CERTIFICATE 4 1.2 GENERAL PRODUCT INFORMATION 5 1.3. NORMATIVE REFERENCES 5 2. SUMMARY OF TEST RESULTS 6 2.1 MEASUREMENT UNCERTAINTY 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 7 2.4 DESCRIPTION OF SUPPORT UNITS 7 2.5 EUT SYSTEM OPERATION 7 3. EMISSION TEST 8 3.1 CONDUCTED EMISSION MEASUREMENT 8 3.1.1 LIMITS OF CONDUCTED EMISSION (MAINS PORT) 8 3.1.2 MEASUREMENT INSTRUMENTS LIST 8 3.1.4 DEVIATION FROM TEST STANDARD 9 3.1.5 TEST SETUP 9 3.1.6 EUT OPERATING CONDITIONS 9 3.1.7 TEST RESULTS 9 3.2 RADIATED EMISSION MEASUREMENT 10 3.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT 10 3.2.2 MEASUREMENT INSTRUMENTS LIST 11 3.2.3 TEST PROCEDURE 11 3.2.4 DEVIATION FROM TEST STANDARD 11 3.2.5 TEST SETUP 12 3.2.6 EUT OPERATING CONDITIONS 12 3.2.7 TEST RESULTS 13 3.3 20dB OCCUPIED BANDWIDTH MEASUREMENT 14 3.3.1 LIMITS 14 3.3.2 MEASUREMENT INSTRUMENTS LIST 14 3.3.3 TEST PROCEDURE 14 3.3.4 DEVIATION FROM TEST STANDARD 14 3.3.5 TEST SETUP 14 3.3.6 EUT OPERATING CONDITIONS 14 3.3.7 TEST RESULTS 15 FCC ID：2ADDXRF001 Report No.: EA1410010F 01001 3 of 19 DongGuan Anci Electronic Technology Co., Ltd No. A222, Building A, Shifu Hardware Plaza, Changan Town, Dongguan City, Guangdong Pr., China. Phone: 86-769- 8507 5888; Fax: 86-769- 8507 5898 E-mail: [email protected] Rev. 1.0 Table of Contents Page 3.4 DWELL TIME MEASUREMENT 16 3.4.1 LIMITS 16 3.4.2 MEASUREMENT INSTRUMENTS LIST 16 3.4.3 TEST PROCEDURE 16 3.4.4 DEVIATION FROM TEST STANDARD 16 3.4.5 TEST SETUP 16 3.4.6 EUT OPERATING CONDITIONS 16 3.4.7 TEST RESULTS 17 FCC ID：2ADDXRF001 Report No.: EA1410010F 01001 4 of 19 DongGuan Anci Electronic Technology Co., Ltd No. A222, Building A, Shifu Hardware Plaza, Changan Town, Dongguan City, Guangdong Pr., China. Phone: 86-769- 8507 5888; Fax: 86-769- 8507 5898 E-mail: [email protected] Rev. 1.0 1 GENERAL INFORMATION 1.1 CERTIFICATE Testing Laboratory ........................... : Dong Guan Anci Electronic Technology Co., Ltd. Address ............................................ : No. A222, Building A, Shifu Hardware Plaza, Changan Town, Dongguan City, Guangdong Pr., China. Applicant’s name.............................. : Luen Ming Electric Works CO., Ltd. Address ............................................ : Flat G, 2F. & 10F., Wah Hing lndustrial Mansions, 36 Tai Yau Street, San Po Kong, Kowloon, Hong Kong Manufacturer .................................... : Shen Zhen Luen Ming Hing Plastic & Electric Technology Co.,Ltd. Address.................................: No. 103, Ao Yi Road, Heng Gang, Long Gang Town, Shen Zhen City, Guang Dong, China Factory..................................: Shen Zhen Luen Ming Hing Plastic & Electric Technology Co.,Ltd. Address.................................: No. 103, Ao Yi Road, Heng Gang, Long Gang Town, Shen Zhen City, Guang Dong, China Test specification: Test item description ........................ : WIRELESS REMTOTE BATTERY PACKS Trade Mark ....................................... : N/A Model/Type reference .................... : RF001 Te s t S a m p l e : RF001 Ratings ............................................. : DC 3V 20mA Standards ....................................... : 47 CFR FCC Part 15 Subpart C: 2014 ANSI C63.4: 2009 The device described above was tested by Dong Guan Anci Electronic Technology Co., Ltd. to determine the maximum emission levels emanated from the device and severity levels of the device endure and its performance criterion. The measurement results are contained in this test report and Dong Guan Anci Electronic Technology Co., Ltd. assumes full responsibility for the accuracy and completeness of these measurements. This report shows the EUT is technically compliance with the above official standards. This report applies to the above sample only and shall not be reproduced in part without written approval of Dong Guan Anci Electronic Technology Co., Ltd. FCC ID：2ADDXRF001 Report No.: EA1410010F 01001 5 of 19 DongGuan Anci Electronic Techn…

Text truncated - open the document above for the full version.

FCC ID: 2ADDXRF001 TEST SETUP PHOTOGRAPHY Radiation Emission Below 1GHz Above 1GHz
