2ADE9XU20CLHamster Pro Duo CL

PCSC User Guide Page 1 Hamster Pro Duo CL™ PCSC User Guide Hamster Pro Duo CL™ PCSC User Guide Table of Contents 1. General Description ................................................................................................................................................... 2 2. USING PCSC.EXE ................................................................................................................................................... 3 3. TESTING THE MIFARE CARD .............................................................................................................................. 5 4. TESTING THE SAM CARD .................................................................................................................................... 7 5. TESTING THE SAM AND MIFARE CARD ........................................................................................................... 9 Copyright © SecuGen Corporation. All rights reserved. Information in the document is subject to change at any time without prior notice. PCSC User Guide Page 2 Hamster Pro Duo CL™ PCSC User Guide 1. General Description Hamster Pro Duo CL™ is a combination fingerprint reader and contactless smart card reader that supports the USB (Universal Serial Bus) 1.1 and 2.0 interface, utilizes the Plug & Play architecture, and is hot swappable. The Hamster Pro Duo CLC is RoHS compliant and is compatible with the Hamster Pro 20™ fingerprint reader (model HU20) with regard to fingerprint functionality. The smart card reader in the device is 100% compatible with the ACS ACR1251U USB smart card reader. The PCSC application is designed to continuously test the functionality of both the contact (SAM) card reader and the contactless (MIFARE) card reader in the Hamster PRO DUO. PCSC User Guide Page 3 Hamster Pro Duo CL™ PCSC User Guide 2. USING PCSC.EXE PCSC.EXE must be invoked in a command prompt so that the necessary command-line arguments can be specified 2.1 Invoking PCSC with no command-line arguments When the PCSC.EXE utility is invoked without command-line arguments, the available smart card readers will be displayed as shown below. PCSC User Guide Page 4 Hamster Pro Duo CL™ PCSC User Guide Two readers should be enumerated: 1. ACS ACR1251 1S CL Reader PICC 0 – This is the contactless card reader. The MIFARE 1K card is used with this reader 2. ACS ACR1251 1S CL Reader SAM 0 – This is the SAM reader. The ACOS6-SAM card will be used with this reader PCSC User Guide Page 5 Hamster Pro Duo CL™ PCSC User Guide 2.2 PCSC Command-line Arguments PCSC is invoked with three command-line arguments; PCSC.EXE <reader> <delay> <test> <reader> - The number of the enumerated reader <delay> - The number of milliseconds to delay between smart card commands. This must be an integer value greater than or equal to zero. <test> - They type of card test to be performed. M = Mifare and must be run with the PICC reader S = SAM and must be run with the SAM reader There is a special set of command-line arguments to be used in the case where both readers are to be tested at the same time PCSC.EXE 0 <delay> B Reader=0 – Both readers will be tested Test=B – Both SAM and MIFARE tests will be executed 3. TESTING THE MIFARE CARD 3.1 Place the MIFARE 1K card on the device. PCSC User Guide Page 6 Hamster Pro Duo CL™ PCSC User Guide 3.2 Invoke PCSC.EXE with the correct command-line options 3.3 The test will start. The Answer-to-Reset (ATR) of the card will be reported and then the test will proceed with repetitive read and write operations to the card. PCSC User Guide Page 7 Hamster Pro Duo CL™ PCSC User Guide 3.4 Press <Ctrl>-C to end the test. 4. TESTING THE SAM CARD 4.1 Insert the SAM Card in the receiver. 4.2 Invoke PCSC.EXE with the correct command-line options 4.3 The test will start. The Answer-to-Reset (ATR) of the card will be reported and then the test will proceed with repetitive formatting, read and write operations to the card. PCSC User Guide Page 8 Hamster Pro Duo CL™ PCSC User Guide PCSC User Guide Page 9 Hamster Pro Duo CL™ PCSC User Guide 4.4 Press <Ctrl>-C to end the test. 5. TESTING THE SAM AND MIFARE CARD 5.1 Place the SAM and MIFARE 1K cards as described in sections 3 and 4 above. 5.2 Invoke PCSC.EXE with the correct command-line options 5.3 The test will start. The tests described in section 3 and 4 will be performed iteratively with both MIFARE and SAM tests being executed. PCSC User Guide Page 10 Hamster Pro Duo CL™ PCSC User Guide PCSC User Guide Page 11 Hamster Pro Duo CL™ PCSC User Guide 5.4 Press <Ctrl>-C to end the test.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 3 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (current) 3.0 4.0 May-23-2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 3 Rev 4.0 Oct. 21, 2014 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Secugen Corporation hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Hamster Pro Duo CL, XU20CL) FCC ID: 2ADE9XU20CL Sincerely, Seungwhan Rhee Principal Hardware Engineer Secugen Corporation 2065 Martin Ave Suite 108, Santa Clara California 95050 United States

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 3.0 Oct. 21, 2014 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADE9XU20CL We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title : Seungwhan Rhee / Principal Hardware Engineer Contact information / address: 408-727-7787 / 2065 Martin Ave Suite 108, Santa Clara California 95050 United States SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 3.0 Oct. 21, 2014 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: 2ADE9XU20CL To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days (please check one). - e.g. User Manual - e.g. Ext Photo - e.g. Int Photo - e.g. Test Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature : Client’s name / title : Seungwhan Rhee / Principal Hardware Engineer Contact information / address: 408-727-7787 / 2065 Martin Ave Suite 108, Santa Clara California 95050 United States

Secugen Corporation 2065 Martin Ave Suite 108, Santa Clara California 95050 United States Date: Oct. 21, 2014 SIEMIC 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Letter of Authorization We, the undersigned, hereby authorize Harvey Sung of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCCID: 2ADE9XU20CL including signing of all documents relating to these matters. Any and all acts carried out by Harvey Sung of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Secugen Corporation “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Seungwhan Rhee Principal Hardware Engineer

FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Page 1 / 3 View 1 FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Page 2 / 3 View 2 FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Page 3 / 3 View 3

FCC ID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase Label locate bottom side - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label. - The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the user's manual. 절단SecuGen Corporation FCC ID: 2ADE9XU20CL MODEL NAME:Hamster Pro Duo CL MODEL No.: XU20CL INPUT: 5V 450mA MADE IN KOREA RoHS Compliant 바 코 드 자 리 S/N: SERIAL NUMBER 자리 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation

FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Page 1 / 5 View 1 FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Page 2 / 5 View 2 FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Page 3 / 5 View 3 FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Page 4 / 5 View 4 FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Page 5 / 5 View 5

FCCID: 2ADE9XU20CL DTNC1409-04158 Report No.: DRTFCC1410-1321 TRF-RF-203(03)140422 Page 2 / 16 Copyright ○ C 2014, DT&C Co., Ltd. Test Report Version Test Report No. Date Description DRTFCC1410-1321 Oct. 21. 2014 Initial issue FCCID: 2ADE9XU20CL DTNC1409-04158 Report No.: DRTFCC1410-1321 TRF-RF-203(03)140422 Page 3 / 16 Copyright ○ C 2014, DT&C Co., Ltd. CONTENTS 1. Equipment information ............................................................. 4 1.1 Equipment description ............................................................ 4 1.2 Ancillary equipment ................................................................ 4 2. Information about test items .................................................... 5 2.1 Test mode ............................................................................... 5 2.2 Auxiliary equipment ................................................................ 5 2.3 Tested frequency .................................................................... 5 2.4 Tested environment ................................................................ 5 2.5 EMI Suppression Device(s)/Modifications .............................. 5 3. ANTENNA REQUIREMENTS ..................................................... 5 3. Test report ................................................................................. 6 3.1 Summary of tests ................................................................... 6 3.2 Transmitter requirements........................................................ 7 3.2.1 Occupied bandwidth ........................................................... 7 3.2.2 In-band emissions .............................................................. 8 3.2.3 Out-of-band emissions ....................................................... 9 3.2.4 Frequency Stability............................................................ 11 3.2.5 AC Line Conducted Emissions ......................................... 12 APPENDIX ................................................................................... 15 FCCID: 2ADE9XU20CL DTNC1409-04158 Report No.: DRTFCC1410-1321 TRF-RF-203(03)140422 Page 4 / 16 Copyright ○ C 2014, DT&C Co., Ltd. 1. Equipment information 1.1 Equipment description FCC Equipment Class Low Power Communications Device Transmitter(DXX) Equipment type Hamster Pro Duo CL Equipment model name XU20CL Equipment add model name NA Equipment serial no. Identical prototype Frequency band 13.56MHz Modulation type ASK Channel 1 Power DC 5V(USB) Antenna type Loop Antenna 1.2 Ancillary equipment Equipment Model No. Serial No. Manufacturer Note - - - - - - - - - - FCCID: 2ADE9XU20CL DTNC1409-04158 Report No.: DRTFCC1410-1321 TRF-RF-203(03)140422 Page 5 / 16 Copyright ○ C 2014, DT&C Co., Ltd. 2. Information about test items 2.1 Test mode Test mode1 Continuous transmitting mode Test mode2 - Note: For this test mode, a test program was supported by manufacturer. 2.2 Auxiliary equipment Equipment Model No. Serial No. Manufacturer Note Notebook Computer CQ62-207AU CNF0327B7P HP DoC AC Adapter PPP009D 608425-003 HP DoC 2.3 Tested frequency TX Frequency(MHz) RX Frequency(MHz) Lowest Channel 13.56 13.56 Middle Channel - - Highest Channel - - 2.4 Tested environment Temperature : 24~ 25 o C Relative humidity content : 47 ~ 48 % R.H. Details of power supply : DC 5V 2.5 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None 3. ANTENNA REQUIREMENTS “An intentional radiator antenna shall be designed to ensure that no antenna other than that furnished by the responsible party can be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section.” The antenna is attached to the internal PCB. Therefore this E.U.T Complies with the requirement of §15.203 FCCID: 2ADE9XU20CL DTNC1409-04158 Report No.: DRTFCC1410-1321 TRF-RF-203(03)140422 Page 6 / 16 Copyright ○ C 2014, DT&C Co., Ltd. 3. Test report 3.1 Summary of tests FCC part section(s) RSS section(s) Parameter Limit Test condition Status Note 1 2.1049 RSS-Gen [ 4.6.1 ] Occupied bandwidth NA Radiated C 15.225 (a) RSS-210 [ A2.6 (a) ] In-band emissions 15,848㎶/m @ 30m 15.553 – 13.567 MHz C 15.225 (b) RSS-210 [ A2.6 (b) ] In-band emissions 334㎶/m @ 30m 13.410 – 13.553 MHz 13.567 – 13.710 MHz C 15.225 (c) RSS-210 [ A2.6 (c) ] In-band emissions 106㎶/m @ 30m 13.110 – 13.410 MHz 13.710 – 14.010 MHz C 15.225 (d) 15.205 15.209 RSS-210 [ A2.6 (d) ] RSS-Gen [ 7.2.2 & 5 ] Out-of band emissions Emissions outside of the specified band (13.110-14.010 MHz) must meet the radiated limits detailed in 15.209 C 15.225 (e) RSS-210 [ A2.6 ] Frequency stability ±0.01% of operating frequency Conducted C 15.207 RSS-Gen [ 7.2.4 ] AC conducted emissions FCC Part 15.207 AC Line Conducted C 15.203 - Antenna requirements FCC Part 15.203 - C Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable The sample was tested according to the following specification: ANSI C-63.10-2009 FCCID: 2ADE9XU20CL DTNC1409-04158 Report No.: DRTFCC1410-1321 TRF-RF-203(03)140422 Page 7 / 16 Copyright ○ C 2014, DT&C Co., Ltd. 3.2 Transmitter requirements 3.2.1 Occupied bandwidth - Procedure: The 20dB Bandwidth is measured with a spectrum analyzer connected via a receive antenna placed near the EUT while the EUT is operating in transmission mode. - Measurement Data: Comply - Minimum Standard: NA FCCID: 2ADE9XU20CL DTNC1409-04158 Report No.: DRTFCC1410-1321 TRF-RF-203(03)140422 Page 8 / 16 Copyright ○ C 2014, DT&C Co., Ltd. 3.2.2 In-band emissions - Procedure: The EUT was placed on a 0.8m high wooden table inside a 10m semi anechoic chamber. An antenna was placed at 3 m distance from the EUT Measurements were performed with the EUT oriented in 3 orthogonal axis and rotated 360 degrees to determine worst-case orientation for maximum emissions. A loop antenna was used for this test…

Text truncated - open the document above for the full version.

FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup photographs EUT Position: X-axis EUT Position: Y-axis EUT Position: Z-axis FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (0.009 ~ 30MHz) FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup Photo of Radiated Measurement (below 1000MHz) FCCID: 2ADE9XU20CL Copyright Ⓒ 2014, DT&C Co., Ltd. Test Setup photo of Conducted Emissions
