Label Location On EUT Label Product Name: QuattroPod Model No.: LT01 FCC ID: 2ADFS-LT01 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2ADFS-LT01

Winner Wave Limited Declaration concerning Antenna Specification It is hereby declared that the product Model No.: LT01 FCC ID: 2ADFS-LT01 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: LT01 Type of antenna: Columnar Antenna Gain of the antenna: 1.8 dBi Frequency range: 5180MHz~5240MHz (5.1G) Gain of the antenna: 1.54 dBi Frequency range: 5745MHz~5825MHz (5.8G) The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Winner Wave Limited Address: 4F-5, No.736, Jhongjheng Road, Jhonghe Dist., New Taipei City, Taiwan City: Taipei ZIP / Postal code: N/A Country: China Place: China Date: 2020-06-08 Signature: version01

RF EXPOSURE EVALUATION According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b) FCC ID: 2ADFS-LT01 EUT Specification EUTQuattroPod Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.24GHz WLAN: 5.745GHz ~ 5.825GHz Others: 2.402GHz~2.480GHz (BLE) Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Exposure classificationOccupational/Controlled exposure (S = 5mW/cm2) General Population/Uncontrolled exposure (S=1mW/cm2) Antenna diversitySingle antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power5.1GHz WIFI: 12.15dBm (0.0164W) 5.8GHz WIFI: 13.34dBm (0.0216W) Antenna gain (Max)5.1GHz WIFI: 1.8 dBi 5.8GHz WIFI: 1.54 dBi Evaluation appliedMPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure(MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) Average Time (A) Limits for Occupational/Control Exposures 300-1500----F/3006 1500-100000----56 (B) Limits for General Population/Uncontrol Exposures 300-1500----F/15006 1500-100000----130 Friis transmission formula: Pd=(Pout*G)\(4*pi*R2) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result 5.1GHz &5.8GHz WiFi: Operating Mode Channel Frequency Measured Power Tune up tolerance Max. Tune up Power Antenna Gain Power density at 20cm Power density Limits (mW/cm2 ) (MHz)(dBm)(dBm)(dBm)(dBi)(mW/ cm2 ) 802.11a 51809.949.94±110.941.80.00371 520010.3410.34 ± 111.341.80.00411 524011.9311.93 ± 112.931.80.00591 802.11n20 518010.3310.33±111.331.80.00411 520010.9210.92 ± 111.921.80.00471 524012.1112.11 ± 113.111.80.00621 802.11ac20 518010.5310.53±111.531.80.00431 520010.9010.90 ± 111.901.80.00471 524012.1512.15 ± 113.151.80.00621 802.11n40 519010.7010.70±111.701.80.00451 523011.9111.91 ± 112.911.80.00591 802.11ac40 519010.2010.20 ± 111.201.80.00401 523011.6311.63±112.631.80.00551 802.11ac80 521011.2911.29 ± 112.291.80.00511 802.11a 574511.9311.93 ± 112.931.540.00561 578513.3413.34±114.341.540.00771 582513.0813.08 ± 114.081.540.00731 802.11n20 574511.1611.16 ± 112.161.540.00471 578512.0212.02±113.021.540.00571 582512.3812.38 ± 113.381.540.00621 802.11ac20 574511.7211.72 ± 112.721.540.00531 578512.4012.40±113.401.540.00621 582512.5012.50 ± 113.501.540.00631 802.11n40 575511.1911.19 ± 112.191.540.00471 579511.7211.72±112.721.540.00531 802.11ac40 575511.1211.12 ± 112.121.540.00461 579511.7211.72 ± 112.721.540.00531 802.11ac80 577511.3911.39±112.391.540.00491

Report No.: 18220WC00038701FCC ID: 2ADFS-LT01Page 1 of 78 Code:AB-RF-05-a FCC Test Report Client Name: Winner Wave Limited Address: 4F-5, No.736, Jhongjheng Road, Jhonghe Dist., New Taipei City, Taiwan Product Name: QuattroPod Date: Jun. 08 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00038701FCC ID: 2ADFS-LT01Page 2 of 78 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 5 1.1. Client Information ....................................................................................................................................... 5 1.2. Description of Device (EUT) ..................................................................................................................... 5 1.3. Auxiliary Equipment Used During Test ................................................................................................... 6 1.4. Description of Test Modes ........................................................................................................................ 6 1.5. List of channels ........................................................................................................................................... 7 1.6. Description Of Test Setup ......................................................................................................................... 8 1.7. Test Equipment List .................................................................................................................................... 9 1.8. Measurement Uncertainty ....................................................................................................................... 10 1.9. Description of Test Facility ...................................................................................................................... 10 2. Summary of Test Results ................................................................................................................................... 11 3. Conducted Emission Test ................................................................................................................................... 12 3.1. Test Standard and Limit .......................................................................................................................... 12 3.2. Test Setup .................................................................................................................................................. 12 3.3. Test Procedure .......................................................................................................................................... 12 3.4. Test Data .................................................................................................................................................... 12 4. Radiation Spurious Emission and Band Edge ................................................................................................ 17 4.1. Test Standard and Limit .......................................................................................................................... 17 4.2. Test Setup .................................................................................................................................................. 17 4.3. Test Procedure .......................................................................................................................................... 18 4.4. Test Data .................................................................................................................................................... 19 5. Maximum Peak Output Power Test .................................................................................................................. 38 5.1. Test Standard and Limit .......................................................................................................................... 38 5.2. Test Setup .................................................................................................................................................. 38 5.3. Test Procedure .......................................................................................................................................... 38 5.4. Test Data .................................................................................................................................................... 38 6. Occupy Bandwidth Test ...................................................................................................................................... 40 6.1. Test Standard ............................................................................................................................................ 40 6.2. Test Setup .................................................................................................................................................. 40 6.3. Test Procedure .......................................................................................................................................... 40 6.4. Test Data .................................................................................................................................................... 40 7. Power Spectral Density Test .............................................................................................................................. 56 7.1. Test Standard and Limit .......................................................................................................................... 56 7.2. Test Setup .................................................................................................................................................. 56 7.3. Test Procedure .......................................................................................................................................... 56 7.4. Test Data ....…
