FCC Software Configuration Control Declaration Rev1.0.docx Winner Wave Limited FCC Software Configuration Control Declaration Date: Dec. 30, 2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Product: Pocket Model No.: R-1 Regarding FCC Country Code Selection guidelines identified in KDB 594280 D01 v02r01. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Date: Dec. 30, 2022 Name: Stan Chen Title: Product Director Signature of applicant

Winner Wave Limited Agent Authorization Company: Winner Wave Limited Address: Unit 1615 Peninsula Tower,538 Castle Peak Road, Lai Chi Kok Kowloon, Hong Kong Product Name: Pocket Model Number(s): R-1 Product Description: Pocket We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Dec. 30, 2022 Name: Stan Chen Title: Product Director Company: Winner Wave Limited

Winner Wave Limited Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Dec. 30, 2022 Subject; Request for Confidentiality FCC ID: 2ADFS-POCKET-R-1 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirement In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Stan Chen Title: Product Director

Annex A External Photos Report No.: HK2211105048-1E/2E Page 1 of 4 Report No.: HK2211105048-1E/2E Page 2 of 4 Report No.: HK2211105048-1E/2E Page 3 of 4 Report No.: HK2211105048-1E/2E Page 4 of 4

FCC ID LABEL: Ca. 10mm x 20mm label location FCC ID: 2ADFS-POCKET-R-1

Annex B Internal Photo Report No.: HK2211105048-1E/2E Page 1 of 4 Report No.: HK2211105048-1E/2E Page 2 of 4 Report No.: HK2211105048-1E/2E Page 3 of 4 Report No.: HK2211105048-1E/2E Page 4 of 4 Antenna

MPE ESTIMATION FCC ID: 2ADFS-POCKET-R-1 1, Limit for General Population/ Uncontrolled Exposures Frequency Power density (mW/ cm 2 ) Averaging time(minutes) 300MHz----1.5GHz F/1500 30 1.5GHz---100GHz 1.0 30 2, Estimation Result For 2.4G/5.2 WIFI: Mode Max PK Output power(dBm) Tune Up Power(dBm) Max Tune Up power(mW) Antenna Gain(dBi) Antenna Gain (linear) MPE (mW/cm²) 2.4G WIFI 1.81 1±1(2) 1.58 3.04 2.01 0.00063 5.2G WIFI 12.24 12±1(13) 19.95 2.22 1.67 0.00663 Note: Note: The estimation distance is 20cm Note: PK Output power= conducted power. Conducted power see the test report HK2211105048-1E/2E . 2.4G WIFI antenna gain=3.04dBi 5.2G WIFI antenna gain=2.22dBi when the minimum test separation distance is >20 cm, a distance of 20 cm is applied to determine RF Exposure test exclusion. The test exclusion threshold is 0.00663mW/cm² which is< 1.0mW/cm², RF Exposure testing is not required. Note: the device could not transmit simultaneously in 2.4G and 5G -------The End-------

Page 1 of 53 Report No.: HK2211105048-2E FCC TEST REPORT Test report On Behalf of Winner Wave Limited For Pocket Model No.: R-1 FCC ID: 2ADFS-POCKET-R-1 Prepared For : Winner Wave Limited Unit 1615 Peninsula Tower, 538 Castle Peak Road, Lai Chi Kok Kowloon, Hong Kong Prepared By : Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Nov. 10, 2022 ~Dec. 26, 2022 Date of Report: Dec. 26, 2022 Report Number: HK2211105048-2E Page 2 of 53 Report No.: HK2211105048-2E TEST RESULT CERTIFICATION Applicant’s name .................. : Winner Wave Limited Address .................................. : Unit 1615 Peninsula Tower, 538 Castle Peak Road, Lai Chi Kok Kowloon, Hong Kong Manufacture's Name ............. : Actions Microelectronics Co., Ltd. Address .................................. : 201, No.9 Building, Software Park, KeJiZhongEr Road, GaoXinQu, NanShan, Shenzhen, China Product description Trade Mark: EZCast Product name ............................ : Pocket Model and/or type reference . : R-1 Standards .............................. : FCC Rules and Regulations Part 15 Subpart E Section 15.407 ANSI C63.10: 2013 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of performance of tests ............. : Nov. 10, 2022 ~Dec. 26, 2022 Date of Issue ........................................... : Dec. 26, 2022 Test Result ............................................... : Pass Prepared by: Project Engineer Reviewed by: Project Supervisor Approved by: Technical Director Page 3 of 53 Report No.: HK2211105048-2E TABLE OF CONTENTS 1. TEST RESULT SUMMARY ........................................................................ 5 1.1. TEST PROCEDURES AND RESULTS ............................................................................................... 5 1.2. INFORMATION OF THE TEST LABORATORY ................................................................................ 5 1.3. MEASUREMENT UNCERTAINTY ..................................................................................................... 6 2. EUT DESCRIPTION ................................................................................... 7 2.1. GENERAL DESCRIPTION OF EUT ................................................................................................... 7 2.2. OPERATION FREQUENCY EACH OF CHANNEL ............................................................................ 8 2.3. OPERATION OF EUT DURING TESTING .......................................................................................... 8 2.4. DESCRIPTION OF TEST SETUP ....................................................................................................... 9 3. GENERA INFORMATION ........................................................................ 10 3.1. TEST ENVIRONMENT AND MODE ................................................................................................. 10 3.2. DESCRIPTION OF SUPPORT UNITS .............................................................................................. 11 4. TEST RESULTS AND MEASUREMENT DATA ...................................... 12 4.1. CONDUCTED EMISSION ................................................................................................................. 12 4.2. MAXIMUM CONDUCTED OUTPUT POWER ................................................................................... 16 4.3. 6DB EMISSION BANDWIDTH .......................................................................................................... 19 4.4. 26DB BANDWIDTH AND 99% OCCUPIED BANDWIDTH .............................................................. 20 4.5. POWER SPECTRAL DENSITY ........................................................................................................ 25 4.6. BAND EDGE ..................................................................................................................................... 30 4.7. SPURIOUS EMISSION ..................................................................................................................... 39 4.8. FREQUENCY STABILITY MEASUREMENT ................................................................................... 47 4.9. ANTENNA REQUIREMENT ............................................................................................................. 50 5. PHOTOGRAPHS OF TEST SETUP ......................................................... 51 6. PHOTOS OF THE EUT ............................................................................ 53 Page 4 of 53 Report No.: HK2211105048-2E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release Dec. 26, 2022 Jason Zhou Page 5 of 53 Report No.: HK2211105048-2E 1. TEST RESULT SUMMARY 1.1. TEST PROCEDURES AND RESULTS Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Maximum Conducted Output Power §15.407(a) PASS 6dB Emission Bandwidth §15.407(e) N/A 26dB Emission Bandwidth& 99% Occupied Bandwidth §15.407(a) PASS Power Spectral Density §15.407(a) PASS Band edge §15.407(b)/15.209/15.205 PASS Radiated Emission §15.407(b)/15.209/15.205 PASS Frequency Stability §15.407(g) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 1.2. INFORMATION OF THE …

Text truncated - open the document above for the full version.

产品规格书 PRODUCT SPECIFICATION Customer: 深圳市炬力北方微电子有限公司 Customer’s part number: RBT-WIFI-524-004-2P5-L Product description: 2.4G/5G 铁皮天线 1、产品技术指标（PRODUCT TECHNICAL SPECIFICATION） 电性能指标Electrical Specifications 频率范围Frequency Range (MHz) 2400-2500/5150-5350/5700-5850 频带宽度Bandwidth (MHz) 2.4G：100 5G：350 输入阻抗Input Impendence (Ω) 50 电压驻波比V.S.W.R ≤2.0 增益Gain (dBi) 2.4G：<3.04 5.1G：<2.22 5.8G： <2.12 极化形式Polarization Type 垂直Vertical 机械指标Mechanical Specifications 天线长度Antenna Length (mm) 21.5*2.5*4.5mm 辐射体Radiator 钢片镀镍 连接器型号Connect Type DIP 工作温度Working Temp(°C) -20~85 储藏温度Storage Temperature(°C) -40~90 外壳颜色Radome Color 银色 重量Weight (g) 0.5 产品简介 该天线是专为无线内置天线设备设计生产的，天线具有外形美观，结 构小巧，安装方便的优点。材质使用不锈钢镀镍，硬度足够。 2、产品图片（PRODUCT PICTURE） 3、产品规格图(PRODUCT SPECIFICATION CHART) 4、驻波图（STATIONARY WAVE PATTERN） 5.增益效率值： 6.场型图
