2ADFV-5E902029FCCTransponder Reader Kit Mifare USB

FCC and IC 1 1 FCC and IC B&R products satisfy EMC requirements for operation in the USA and Canada and are compliant with FCC and IC regulations. Corresponding "Radio Frequency Interference Statements" for the USA and Canada: USA: Federal Communi- cations Commission (FCC) This device complies with Part 15 of the FCC Rules and with Industry Canada li- censeexempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Canada: Industry Canada (IC) Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux ap- pareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. If products are equipped with an additional RFID read/write device, it must be approved for operation in the USA and Canada. These types of products are identified by a sticker with Contains FCC ID and Contains IC ID on the RFID read/write device. In addition to the sticker for products with an RFID read/write device, the following requirements also apply: Information: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Information: This equipment has been tested and found to comply with the limits for a Class B digital device, pur- suant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television re- ception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help.

Request for Confidentiality Date: 2014-12-03 Subject: Confidentiality Request for: FCC ID:2ADFV-5E902029FCC IC ID:12444A-5E902029FCC Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual B & R Industrial Automation Inc. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___180___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details.

CSA Group Bayern GmbH  Ohmstrasse 1 - 4  94342 Strasskirchen  GERMANY Telefon: +49 (0) 9424 9481-0  Telefax: +49 (0) 9424 9481-430  E-Mail: [email protected]  Web: www.csagroup.org Geschäftsführer: Dieter Fröhlich  Günter Mikes  Magali Depras  Ash K. Sahi  Robert J. Falconi Amtsgericht Straubing HRB 11130  USt.-Id. Nr.: DE 814 397 903 Raiffeisenbank Straubing: Kto: 5 580 080 BLZ: 742 601 10 IBAN: DE27 7426 0110 0005 5800 80 SWIFT (BIC): GENODEF1SR2 UniCredit Bank AG Straubing: Kto: 345 753 540 BLZ: 742 200 75 IBAN: DE70 7422 0075 0345 7535 40 SWIFT (BIC): HYVEDEMM452 FCC ID: 2ADFV5E902029FCC Model Number: 5E9020.29 Date: 24.11.2014 Subject: Request for a Limited Modular Approval - FCC ID: 2ADFV5E902029FCC Dear Examiners, Limited Modular Approval is being requested for this device. Not all eight requirements that the device must meet for full modular approval can be met in this case! The following paragraphs detail these requirements and the manner in which the device meets them. 1. The modular transmitter must have its own RF shielding No, it hasn't an own shielding. 2. The modular transmitter must have buffered modulation/data inputs The module has a memory management unit inside of the IC. It buffers the data inputs from the serial peripheral interface 3. The modular transmitter must have its own power supply regulation The application that uses the RFID module has to provide a power supply voltage from USB port with 5 V DC with the given rated voltage. The end application includes the provided power supply. 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204c The transmitter shall only be used with the tested integral antenna or with an antenna that has less antenna gain. Requirements are specified in the test report. Only antennas specified in the test report / Operational description will be used later with the host equipment! American Certification Body Inc. 6731 Whittier Ave, Suite C110 McLean, VA22101 CSA Group Bayern GmbH  Ohmstrasse 1 - 4  94342 Strasskirchen 5. The modular transmitter must be tested in a stand-alone configuration The EUT was tested in a stand-alone configuration. For setup of the test configurations, only a test board was connected to the module. 6. The modular transmitter must be labelled with its own FCC ID number The EUT will be labelled with its own FCC ID number. The label is specified in the attached file named “Label”. If the module is installed inside of an end-product, the label will not be visible. In this case the company Bernecker & Rainer will label the hosts respectively! 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The EUT is compliant with all applicable FCC rules. Detail instructions are given in the products Operating Description and Manual ! 8. The modular transmitter must comply with any applicable RF exposure requirements. Due to the low power and the resulting expected low hazard is no RF exposure require. Please contact us if you have any additional questions. Yours sincerely, Thomas Ring Manager Certification CSA Group Bayern GmbH Ohmstr. 1-4, 94342 Strasskirchen, Germany

CSA Group Bayern GmbH  Ohmstrasse 1-4  D-94342 Strasskirchen  Tel:+49-9424-9481-0  Fax:+49-9424-9481-440 Internal Views: CSA Group Bayern GmbH  Ohmstrasse 1-4  D-94342 Strasskirchen  Tel:+49-9424-9481-0  Fax:+49-9424-9481-440 CSA Group Bayern GmbH  Ohmstrasse 1-4  D-94342 Strasskirchen  Tel:+49-9424-9481-0  Fax:+49-9424-9481-440

FCC ID:2ADFV ‐ 5E902029FCC IC ID: 12444A ‐ 5E902029FCC Model: 5E902029

Draft Label B&R for „End Product”

CSA Group Bayern GmbH  Ohmstrasse 1-4  D-94342 Strasskirchen  Tel:+49-9424-9481-0  Fax:+49-9424-9481-440 Internal Views: CSA Group Bayern GmbH  Ohmstrasse 1-4  D-94342 Strasskirchen  Tel:+49-9424-9481-0  Fax:+49-9424-9481-440 CSA Group Bayern GmbH  Ohmstrasse 1-4  D-94342 Strasskirchen  Tel:+49-9424-9481-0  Fax:+49-9424-9481-440

FCC ID: 2ADFV-5E902029FCC CSA Group Bayern GmbH File No. T38693-00-00HU, page 1 of 31 Ohmstrasse 1-4  94342 Strasskirchen Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 EMI − T E S T R E P O R T - FCC Part 15.225 - Test Report No. : T38693-00-00HU 18. November 2014 ______________________________________________________________________________________________ Date of issue Type / Model Name : 5E9020.29-FCC Product Description : Transponder Reader Kit Mifare USB Applicant : B&R Industrieelektronik GmbH Address : B&R Strasse 1 A-5142 Eggelsberg Manufacturer : B&R Industrieelektronik GmbH Address : B&R Strasse 1 A-5142 Eggelsberg Licence holder : B&R Industrieelektronik GmbH Address : B&R Strasse 1 A-5142 Eggelsberg Test Result according to the standards listed in clause 1 test standards: POSITIVE The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permission of the test laboratory. FCC ID: 2ADFV-5E902029FCC CSA Group Bayern GmbH File No. T38693-00-00HU, page 2 of 31 Ohmstrasse 1-4  94342 Strasskirchen Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 Contents 1 T E S T S T A N D A R D S 3 2 S U M M A R Y 4 3 E Q U I P M E N T U N D E R T E S T 5 3.1 PHOTO DOCUMENTATION OF THE EUT 5 3.2 POWER SUPPLY SYSTEM UTILISED 5 3.3 SHORT DESCRIPTION OF THE EQUIPMENT UNDER TEST (EUT) 5 4 T E S T E N V I R O N M E N T 6 4.1 ADDRESS OF THE TEST LABORATORY 6 4.2 STATEMENT REGARDING THE USAGE OF LOGOS IN TEST REPORTS 6 4.3 ENVIRONMENTAL CONDITIONS 6 4.4 STATEMENT OF THE MEASUREMENT UNCERTAINTY 6 4.5 MEASUREMENT PROTOCOL FOR FCC, VCCI AND AUSTEL 7 5 T E S T C O N D I T I O N S A N D R E S U L T S 8 5.1 CONDUCTED EMISSIONS 8 5.2 FIELD STRENGTH OF THE FUNDAMENTAL WAVE 18 5.3 SPURIOUS EMISSIONS (MAGNECTIC FIELD) 9 KHZ – 30 MHZ 20 5.4 RADIATED EMISSIONS (ELECTRIC FIELD) 30 MHZ – 1 GHZ 22 5.5 FREQUENCY TOLERANCE OF THE CARRIER 24 5.6 EMISSION BANDWIDTH 26 5.7 TRANSMITTER SPECTRUM MASK 28 6 U S E D T E S T E Q U I P M E N T A N D A C C E S S O R I E S 31 FCC ID: 2ADFV-5E902029FCC CSA Group Bayern GmbH File No. T38693-00-00HU, page 3 of 31 Ohmstrasse 1-4  94342 Strasskirchen Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15, Subpart A - General (October, 2014) Part 15, Subpart A, Section 15.31 Measurement standards Part 15, Subpart A, Section 15.33 Frequency range of radiated measurements Part 15, Subpart A, Section 15.35 Measurement detector functions and bandwidths Part 15, Subpart A, Section 15.207 AC Line conducted emissions FCC Rules and Regulations Part 15, Subpart C - Intentional Radiators (October, 2014) Part 15, Subpart C, Section 15.203 Antenna requirement Part 15, Subpart C, Section 15.204 External radio frequency power amplifiers and antenna modifications Part 15, Subpart C, Section 15.205 Restricted bands of operation Part 15, Subpart C, Section 15.209 Radiated emission limits, general requirements Part 15, Subpart C, Section 15.225 Operation within the band 13.110-14.010 MHz ANSI C63.4: 2009 Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. ANSI C95.1:1992 IEEE Standard for Safety Levels with respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz CISPR 16-4-2: 2003 Uncertainty in EMC measurement FCC ID: 2ADFV-5E902029FCC CSA Group Bayern GmbH File No. T38693-00-00HU, page 4 of 31 Ohmstrasse 1-4  94342 Strasskirchen Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 2 S U M M A R Y GENERAL REMARKS: The EuT is working at frequency of 13.56 MHz. The EuT has a Data connection via USB to a PC. FINAL ASSESSMENT: The equipment under test fulfills the EMI requirements cited in clause 1 test standards. Date of receipt of test sample : acc. to storage records Testing commenced on : 25. August 2014 Testing concluded on : 28. August 2014 Checked by: Tested by: Klaus Gegenfurtner Teamleader Radio Markus Huber FCC ID: 2ADFV-5E902029FCC CSA Group Bayern GmbH File No. T38693-00-00HU, page 5 of 31 Ohmstrasse 1-4  94342 Strasskirchen Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 3 E Q U I P M E N T U N D E R T E S T 3.1 Photo documentation of the EuT 3.2 Power supply system utilised Power supply voltage : Primary: 115 V / 60 Hz / 1 Secondary: USB 5.0 V / DC 3.3 Short description of the Equipment under Test (EuT) The EuT is a RFID reader which will be built in an engine for industrial use. Number of tested samples: 1 Serial number: Prototype EuT operation mode: The equipment under test was operated during the measurement under the following conditions: - Tag reading mode at 13.56 MHz - EuT configuration: The following peripheral devices and interface cables were connected during the measurements: - USB cable male type A Model : Supplied by manufacturer Fujitsu LapTop Supplied by CSA - Model : Power Supply CASIO, Model: AD-C53U Supplied by CSA - Model : - Model : - Model : - Model : - customer specific cables FCC ID: 2ADFV-5E902029FCC CSA Group Bayern GmbH File No. T38693-00-00HU, page 6 of 31 Ohmstrasse 1-4  94342 Strasskirchen Tel.:+49(0)9424-94810  Fax:+49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 4 T E S T E N V I R O N M E N T 4.1 Address of the test laboratory CSA Group Bayern GmbH Ohmstrasse 1-4 94342 STRASSKIRCHEN GERMANY 4.2 Statement regarding the usage of logos in test reports The accreditation and notification body logos displayed in this test report are only valid for standards listed in the accreditation or notification scope of CSA Group Bayern GmbH. 4.3 Environmental conditions During the measurement the environmental conditions were within the listed ranges: Temperature: 15-35 ° C Humidity: 30-60 % Atmospheric pressure: 86-106 kPa 4.4 Statement of the measurement uncertai…

Text truncated - open the document above for the full version.

Setupn Photos Setupn Photos Setupn Photos Setupn Photos
