2ADHI-BL-102HIVE WIRELESS SPEAKER

Product Development Department Page: 1/8 Product User Manual 1. Basic Parameters Amplifier: Input port (data): Bluetooth 2.4 G wireless digital transmission input Input port (imitation): Stereo L/R; 3.5mm Stereo Mini Plug Output power (trends): 2.5W x 2（1 kHz,1% THD） Output power (Maximum instantaneous): 3W x 2（1 kHz, 10% THD） AUX3.5mm Line input impedance：4.7kΩ Input sensitivity: 560mV Power supply: Built-in lithium polymer 3.7V 1500mAH Charging: USB interface, charge Current: 750mA, charge time: 3.5 hours Bluetooth play time: 6-8 hours Bluetooth Specification of Bluetooth： Version 2.1+EDR Online distance of Bluetooth: Appro.10M Type of Speaker: Stereo（ Passive radiation technology） Speaker Unit：4.5cm full-range tapered unit 4Ω 3W Frequency Response：90Hz-20kHz Separation Degree：≥45 dB Working temperature: +10～+40°C Routine Part Size ( Width * Height * Depth)：165 x 60 x 48.5mm Weight about 340 g Accessory: USB cable Main Characteristic Fashion and concise appearance, only a small unit, and nice sound performance Easy to be used, and it’s perfect to connect with portable computer, iPod/iPhone and other portable audio equipments. Passive radiation technology, shock bass expression force； Stereo Mini Plug, it will play after plug; 2. Functions • To connect by simple wireless Bluetooth. • To enjoy music by connect stereo mini plug • Rechargeable lithium-ion battery can supply power for speaker within a few hours. • List: Speaker USB Cable Product Development Department Page: 2/8 Product User Manual 4. TO activate system Initially, the battery is not full charged and it may be in protected or inactive mode. It needs to activate system and charge： To put the speaker on a stable surface. To plug USB cable to 3.5 DC Jack interface of speaker’s power supply It will charge for speaker after plug USB cable to connect USB with computer’s USB for charging. 5. How to use Power on/off ( Red/Green LED ) Turn on the Speaker by on/off- switch on lower right. Function key ( Bluetooth logo button ) Hold the function key about 5 seconds, the Red/Blue indicator LED on the front will flash. Then the Bluetooth module starts working. And pairing with your mobile can begin P.S. 10 minutes late, if no pairing or AUX not connect with any cable, unit will automatically into STANDBY model After inputting the password “0000”and choose for connecting “XXXXXX”, After pairing finished, front LED changes from Red/Blue flashing to only blue flashing P.S. some new devices will finish BT pairing automatically, no need password. Product Development Department Page: 3/8 Product User Manual Important notice： Above is the typical hands-free Bluetooth pairing instructions, and it may vary with different mobile phone models. For more information, please refer to the user manual or contact the mobile phone’s manufacturers. Play music by A2DP： Support the Advanced Audio specification A2DP. A2DP technology is a new music innovation, which allows wireless transfer between different devices like CD-quality stereo music. Remove stereo music over Bluetooth, cable winding. Therefore, if your phone supports A2DP, you can listen to music through the car stereo. View the following steps: Play music by mobile phone To open the phone’s music player after paring and connecting. Press the Bluetooth logo function key to pause music during playing music, and press again to resume. Important Notice： Some phones need to manually connect A2DP, in this case, you need to manually select the "Play via Bluetooth" ( with the difference of phone model. Please refer to the mobile phone user manual for accessing to music through A2DP). Answer a call: • In case of a call, the speaker will pause your music and your stereo will emit a ringing tone • The call can be answered by pressing the function button once Redial the last calling number: 1）No music, just press the key twice swiftly to redial the number; 2）if you’re playing music, press once to pause the music first, and press twice swiftly to redial. Ring off，press the key once to resume the music playing P.S. The LED will flash red if no any signal received from mobile phone after 3 minutes Product Development Department Page: 4/8 Product User Manual Play music by other audio devices： The device has a 3.5 mm audio input plug. It can be achieved from other similar MP3, iPod, CD players and other audio players to transmit audio signals. Only need to connect your audio player with the incidental audio cable simply. At this point the device can be connected to the maximum volume setting, and then use the system to adjust its volume buttons. Speaker’s volume controller • Press the +, - for volume control Vol - Vol + Use battery-powered If the system is set to 80％ volume, a fully charged battery sustainable supply for about 6-8 hours. However, the battery discharge rate is due to the music type and volume setting. Decrease the volume can greatly extend the battery life. Product Development Department Page: 5/8 Product User Manual 6. How to set up Standby in Bluetooth Mode and AUX mode Hold the function key will cycle the modes between standby and working. No need use the main Power switch on the right. Hold the function key about 5S, the LED indicator on front will go out, and the speak is automatically in standby mode. Continue in the same way to resume the working status. But if the system not use longer than 50 days, the system will enter the battery protection mode to protect the battery power. To resume working status, please turn off the main power switch on the right, and connect to a computer or any other standard USB port to activate it. ( see the picture as below ). When stocking it for a long time without use, please turn off the main power switch on the right, Then the system can not enter the battery protection mode. Remark: turn off the power if no use for a long time, Product Development Department Page: 6/8 Product User Manual 7. LED indicator Battery LED Two states: a) No USB-cable connected = L…

Text truncated - open the document above for the full version.

DONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LTD FCC Confidentiality Request Number: CF303 Version: V04 Date: 01-12-2011 (Permanent or also called long term confidentiality is the normal method to keep certain docuements confidential, and may apply to schematics, block diagrams, operational description and bill of materials. With Short term confidentiality, a period of max. 180 days on certain additional exhibits are possible, such as internal/external photos, user manual can test setup photosbet. After expiration of the confidentiality period, these additional exhibits for short term confidentiality become visible in the FCC database for the internet public.) To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company nameDONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LTD AddressJinDuoGang Development Zone, DaTang Village, DaLingShan Town, CityDongGuan City, GuangDong, CountryChina request for this certification filing under: Grantee CodeProduct Number FCC ID: to maintain permanent confidentiality for the following documents submitted within this application: (please cross what is applicable, or add other documents, provide the file name and description) ExhibitFile NameDescription XOperational Descriptionexplaining the functioning of the block diagram XBlock Diagramsshowing the systematic building blocks of the EUT XSchematics Diagramsshowing components, their values and interconnection no short term confidentiality requested for this application (remark: do not fill in exhibits below, please skip the table below). short term confidentiality is requested for 180 days for the following documents submitted within this application: (please cross what is applicable, or add other documents, provide the file name and description) ExhibitFile NameDescription Internal photospictures showing internal views of the EUT External photospictures showing external views of the EUT User ManualInstructions and information for the end-user Test Setup PhotosPhotos of conducted and radiated emission test setup Above materials crossed contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. The documents indicated as confidential above, are not publicly available elsewhere. Attestation: City and Country:Date:Name: (this must be a person) Function:Signature: (or official company stamp) DongGuan City, GuangDong, China Oct. 28,2014Carl XiangManager

DONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LTD FCC Authorization Letter Number: CF304 Version: V03 Date: 01-08-2011 We, (the approval holder) Company name DONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LTD Address JinDuoGang Development Zone, DaTang Village, DaLingShan Town, City DongGuan City, GuangDong, Country China declare that the following representative (agent): Name (person) KAIT CHEN Company name WST Certification & Testing (HK) Limited Address 12/F., San Toi Building,137-139 Connaught Road Central, City Hong Kong, Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description HIVE WIRELESS SPEAKER Type or Model(s) BL-102, KSHIVE, KSHIVEWH, KSHIVEBL, KSHIVEPI, KSHIVEPU, KSHIVEHL, KSHIVERE, KSHIVEGU, KSHIVEGD, KSHIVEYE Tradename or Brand(s) KS We also authorize Teleconformity (Mr. M. Koop, Manager Certification, Address: Rietven 31, 7534NH Enschede, the Netherlands) to apply and sign this application for certification, registration or filing on our behalf (as representative agent or certifier). Attestation: City and Country:Date:Name: (this must be a person) Function:Signature: (or official company stamp) DongGuan City, GuangDong, China Oct. 28,2014 Carl XiangManager

FCC ID LABEL: Label Location FCC ID: 2ADHI‐ BL‐102 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation.

3 XTAL_IN 4 XTAL_OUT 33 LED_1 32 LED_2 20 PIO_14 19 PIO_13 18 PIO_12 15 PIO_11 14 PIO_9 21 PIO_8 22 PIO_7 23 PIO_6 24 PIO_5 25 PIO_4 58 PIO_3 59 PIO_2 60 PIO_1 61 PIO_0 29 SPI_CLK 31 SPI_MISO 28 SPI_MOSI 30 SPI_CS# 9 UART_TX 10 UART_RX 11 UART_CTS 12 UART_RTS 7 AIO_0 6 AIO_1 5 LO_REF 27 TEST_EN 26 RST# 69 VSS_CNTR_PAD 8 NC 40 NC 41 NC 42 NC 43 NC 44 NC 49 NC 45 MIC_BIAS 50 MIC_B_N 48 MIC_B_P 52 MIC_A_N 51 MIC_A_P 56 SPK_A_N 57 SPK_A_P 54 SPK_B_P 53 SPK_B_N 55 AU_REF_DCPL 16 VDD_PADS 13 VDD_UART 62 VDD_PIO 47 VDD_AUDIO 46 VREGIN_L_AUDIO 68 VREGENABLE_L 35 VREGENABLE_H 38 BAT_P 39 VDD_CHG 36 VCC_BUCK_CORE 37 LX 1 VREGIN_L 2 VDD_ANA 34 VDD_CORE 17 VDD_CORE 63 VDD_RADIO 66 VDD_RADIO 67 VDD_LO 64 RF_P 65 RF_N U1 BLUE_TURNS_ROM BC57F687A05 6 BAL 4 BAL 2 DC 1 UNBAL 3 NC 5 GND 8 GND 7 GND U3 DBF81F104_CSR 1 E0 2 E1 3 E2 4 VSS 5 SCL 6 SDA 7 WC 8 VCC U2 M24C32-MFB5TG L3 22uH C2 15P L6 NF L1 15NH L2 15nH 1 ANT1 ANT_GENERAL C4 15P C3 15P C19 2u2 C18 22n C21 4u7 C14 2u2 C20 2u2 C17 2u2 C6 22n R4 2R2 C7 22n 1 2 3 4 TX TSX3225 26MHz C1 6P8 C5 18P R7 2K2 R8 2K2 R9 2K2 C12 100n C8 22n C15 2u2 C16 2u2 C10 100n C11 100n R3 1K R5 2K2 L5 0R C23 47n R6 2R2 L4 0R 1V5 1V5 1V5 1V5 V1.8 V1.8 1V5 VDD_CHG BAT POW 1V8 1V8 1V5_AUDIO 1V8 1V8 LED1LED2SW4SW3SW2SW1PIO1PIO2 1V8 SPI_CLKSPI_MISOSPI_MOSISPI_CS# RST MIC_BIAS SPANSPAPSPBPSPBN 1V5 JACK PART HIVE SCH1 REV1.0 5 6 2 3 7 1 4 8 U6 4558 C12 1uF C17 1uF C22 10uF C21 0.1uF C25 NC C24 NC C26 1uF C27 1uF R30 10K R31 10K R26 10K R2810K R33100K R 3 4 1 0 k R 3 5 1 0 k R2710K R2910K R32 100K C23 1uF C16 1uF C20 1uF R36 4.7K R37 4.7K 3 VOL+ 4 VOL- 5 UP 6 DOWN 7 PLAY/STOP 8 +1_8V 9 GND 10 BAT 11 LED1 12 LED2 13 MIC 14 SPBN 15 SPBP 16 SPAN 17 SPAP 18 GND_ 19 MOSI 20 CLK 21 CS# 2 PIO2 1 PIO1 22 MSIO 23 REST 24 CHG U1 F-3088 R2 10K R3 10K R4 10K R5 10K R6 10K D1 D2 RED_LED R7 1K R8 1K MIC1 MICROPHONE2 C 1 1 0 5 R9 1kR 1 CHRG 2 GND 3 BAT 6 PROG 5 LD 4 V_IN U2 TP4057 R10 1k C 2 1 0 5 D3DIODE R11 3.3K 1 COMP 2 FB 3 EN 4 GND 5 LX 6 VCC 7 FREQ 8 VSS U4 AX5510 R144.7R L 1 C3 103 C4 104R1515K R1647K R1733K C5101 R18 1M 12 J 3 C O N 2 1234567891 0 1 1 1 2 J5 CON12 2 1 3 6 4 5 SW1 D5 RED_LED D6 BLUE_LED Q2 9014 R19 1K R23 10R 1 PA0 10 PC3 11 PB3 24 VDD 12 PB2 23 PC6 22 GND 2 PA1 3 PA2 4 PA3 21 PC1 20 PC0 19 PB0 18 PB1 5 PA4 6 PA5 7 PA6 8 PA7 9 PC2 17 RES 16 PD1/TX 15 PD0/RX 14 PD3 13 PD4 U3 MG8F08A R 2 4 1 0 0 K R25 10k R38 100K R41 10K R44 1K R45 1K 1 A0 2 A1 3 NC 4 GND 5 SDA 6 SCL 7 WP 8 VCC U5 24C02 EC1 C 6 1 0 4 1 VDD 2 AGND 3 TREB_L 4 TREB_R 5 RIN 6 ROUT 7 LOUT_R 8 RIN4 9 RIN3 10 RIN2 11 RIN1 12 LOUT-L 13 LIN4 14 LIN3 28 REF 27 CLK 26 DATA 25 DGND 24 OUT_L 23 OUT_R 22 BOUT_R 21 BIN_R 20 BOUT_L 19 BIN_L 18 LOUT 17 LIN 16 LIN1 15 LIN2 U7 SC2314 C 7 1 0 4 R47 10R EC2 C8 272 C9 272 C10 225 C11 104 C13 225 C15 225 C19 225 C29 225 C31 104 C32 225 C33 104 C34 104 R48 5.6k C35 104 C36 104 R49 5.6k C37 NC C38 NC C39 226 1 OUTL- 2 PGND 3 OUTL+ 4 PVDD 5 MUTE 6 VDD 7 INL 8 VREF 16 OUTR- 15 PGND 14 OUTR+ 13 PVDD 12 SHDN 11 GND 10 INR 9 GND U8 MIX3001 L 3 EC3 C 4 1 1 0 4 C42 224 E C 5 C43 104 C44 10uF L 4 C 4 6 1 0 2 C 4 7 1 0 2 SP1 L 5 C45 10uF L 6 C 4 8 1 0 2 C 4 9 1 0 2 SP2 EC6 C 5 0 1 0 4 R500R C51 105 R5110K C52 105 R 5 2 1 0 K C 5 3 1 0 2 R5347K C54 104 R544.7K C55 105 R 5 5 1 0 K C 5 6 1 0 2 R5647K C57 104 C 5 8 1 0 2 R 5 7 2 2 K C 5 9 1 0 2 R 5 8 2 2 K R59 0R R 6 0 4 7 0 K R61100R R 6 2 4 7 0 K R 6 3 2 2 K R 6 4 2 2 K R65 4.7k R66 4.7k 12 D4 SS24 C62 10uF R 6 7 1 5 0 K L7 D13DIODE R68 10M R 6 9 2 M C 6 3 1 0 5 C64 106 123456789 1 0 1 1 1 2 J2 CON12 2 7 6 5 3 4 1 J4 PJ3530 2 1J1 DC_5V S1 PLAY S2 VOL- S3 VOL+ C 6 6 1 0 5 C65 104 Q5 9014 R7210K C 6 7 1 0 2 C 6 8 2 2 0 p R21 100K C69 10uF R22 1K R 4 2 1 K R20 1K C 7 0 1 0 3 C 7 1 1 0 3 R46 3.3K C72 105 C73 105 R1 10K R12 10K R13 10K R39 4.7R 2 VOUT 1 G N D 3 VIN U9 LDO-6206 AOM1 AOM AOL AOR BT_L_IN BT_R_IN VOL+/NEXT VOL-/PRE RFGND BAT BLUE_LED RED_LED AOR AOM AOL AOM1 BAT+_J J_GND J_GND J_GND J_GND J_GND AGND LINE_L_J_1 LINE_R_J_1 BAT +5V BAT CHRG B A T + _ J L I N E _ D E T L I N E _ L L I N E _ R B T - B L U E - L E D B T - R E D - L E D L O W - L E D J _ G N D BAT BAT+_J L I N E _ D E T L I N E _ L L I N E _ R B T - B L U E - L E D B T - R E D - L E D B A T D C 5 V L O W - L E D BAT BT-RED-LED SCL SDA SCL SDA +5V BT_R_IN LINE_R BT_L_IN LINE_L R L SCL SDA +5V RFGND PGNDPGND +5V PGND PGND MUTE LR LINE_L_J_1 LINE_R_J_1 LINE_L LINE_R VOL+ VOL- VOL- B A T D C 5 V AGND AGND B A T + _ J VSS VSS VSS VSS VSS VSSVSS AMP_MUTE VSS LOW-LED 3 . 3 V BAT DC5V D S Y L D S Y R DSYR DSYL VOL+ VOL- L O W - L E D BLUE_LED RED_LED LINE_DET BT-BLUE-LED BT-RED-LED MUTE LINE_DET BAT+_J CHRG BT-BLUE-LED MUTE 3.3V 3.3V 3.3V L PLAY_KEY VOL-/PRE VOL+/NEXT PLAY_KEY BAT+_J J_GND VSS B A T + _ J DC5V VOL+

3 X T A L _ I N 4 X T A L _ O U T 3 3 L E D _ 1 3 2 L E D _ 2 2 0 P I O _ 1 4 1 9 P I O _ 1 3 1 8 P I O _ 1 2 1 5 P I O _ 1 1 1 4 P I O _ 9 2 1 P I O _ 8 2 2 P I O _ 7 2 3 P I O _ 6 2 4 P I O _ 5 2 5 P I O _ 4 5 8 P I O _ 3 5 9 P I O _ 2 6 0 P I O _ 1 6 1 P I O _ 0 2 9 S P I _ C L K 3 1 S P I _ M I S O 2 8 S P I _ M O S I 3 0 S P I _ C S # 9 U A R T _ T X 1 0 U A R T _ R X 1 1 U A R T _ C T S 1 2 U A R T _ R T S 7 A I O _ 0 6 A I O _ 1 5 L O _ R E F 2 7 T E S T _ E N 2 6 R S T # 69 VSS_CNTR_PAD 8 NC 40 NC 41 NC 42 NC 43 NC 44 NC 49 NC 45 MIC_BIAS 50 MIC_B_N 48 MIC_B_P 52 MIC_A_N 51 MIC_A_P 56 SPK_A_N 57 SPK_A_P 54 SPK_B_P 53 SPK_B_N 55 AU_REF_DCPL 16 VDD_PADS 13 VDD_UART 62 VDD_PIO 47 VDD_AUDIO 46 VREGIN_L_AUDIO 68 VREGENABLE_L 35 VREGENABLE_H 38 BAT_P 39 VDD_CHG 36 VCC_BUCK_CORE 37 LX 1 VREGIN_L 2 VDD_ANA 34 VDD_CORE 17 VDD_CORE 63 VDD_RADIO 66 VDD_RADIO 67 VDD_LO 6 4 R F _ P 6 5 R F _ N U 1 B L U E _ T U R N S _ R O M B C 5 7 F 6 8 7 A 0 5 6 B A L 4 B A L 2 D C 1 U N B A L 3 N C 5 GND 8 GND 7 GND U 3 D B F 8 1 F 1 0 4 _ C S R 1 E 0 2 E 1 3 E 2 4 V S S 5 S C L 6 S D A 7 W C 8 V C C U 2 M 2 4 C 3 2 - M F B 5 T G L3 22uH C2 15P L6 NF L1 15NH L2 15nH 1 A N T 1 A N T _ G E N E R A L C4 15P C3 15P C19 2u2 C18 22n C21 4u7 C14 2u2 C20 2u2 C17 2u2 C6 22n R4 2R2 C7 22n 1 2 3 4 T X T S X 3 2 2 5 2 6 M H z C1 6P8 C5 18P R7 2K2 R8 2K2 R9 2K2 C12 100n C8 22n C15 2u2 C16 2u2 C10 100n C11 100n R 3 1 K R 5 2 K 2 L 5 0 R C23 47n R6 2R2 L 4 0 R 1 V 5 1 V 5 1 V 5 1 V 5 V 1 . 8 V1.8 1V5 VDD_CHG BAT POW 1 V 8 1 V 8 1 V 5 _ A U D I O 1 V 8 1 V 8 L E D 1 L E D 2 S W 4 S W 3 S W 2 S W 1 P I O 1 P I O 2 1 V 8 S P I _ C L K S P I _ M I S O S P I _ M O S I S P I _ C S # R S T M I C _ B I A S S P A N S P A P S P B P S P B N 1 V 5

Report No.: WST20141022004 WST Certification & Testing (HK) Limited Page 1 of 24 FCC TEST REPORT For DONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LTD HIVE WIRELESS SPEAKER Trade Name : KS Model No. : BL-102, KSHIVE, KSHIVEWH, KSHIVEBL, KSHIVEPI, KSHIVEPU, KSHIVEHL, KSHIVERE, KSHIVEGU, KSHIVEGD, KSHIVEYE All the model are the same circuit and RF module,except the appearance colour, this report only test mode name: BL-102 FCC ID : 2ADHI- BL-102 Frequency range : 2402-2480MHz Number of Channel : 79CH Type of antenna : Internal monopole Antenna Applicant : DONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LTD JinDuoGang Development Zone, DaTang Village, DaLingShan Town, DongGuan City, GuangDong, China Regulation : FCC Rules and Regulations Part 15 Subpart C Section 15.249 Prepared by : WST Certification & Testing (HK) Limited Address : 12/F., San Toi Building,137-139 Connaught Road Central, Hong Kong, China Report No.: : WST20141022004 Test Date : Oct. 22-28, 2014 Date of Report : Oct. 28, 2014 Report No.: WST20141022004 WST Certification & Testing (HK) Limited Page 2 of 24 TABLE OF CONTENT Description Page Test Report Declaration 1.1 TEST PROCEDURES AND RESULTS ..................................................................................... 4 1.2. Test Facility ......................................................................................................................................... 4 1. GENERAL INFORMATION ................................................................................................ 5 2.1. General Information ............................................................................................................................ 5 2. TEST INSTRUMENT USED ................................................................................................. 6 3. OPERATION OF EUT DURING TESTING ........................................................................... 7 4. CONDUCTED EMISSIONS TEST ....................................................................................... 9 4.1. Conducted Power Line Emission Limit ........................................................................................ 9 4.2. Test Setup ...................................................................................................................................... 9 4.3. Test Procedure ............................................................................................................................. 10 4.4. Test Result ................................................................................................................................... 10 5. RADIATED EMISSION TEST ........................................................................................... 11 5.1. Radiation Limit ............................................................................................................................ 11 5.2. Test Setup .................................................................................................................................... 11 5.3. Test Procedure ............................................................................................................................. 12 5.4. Test Result ................................................................................................................................... 13 6. BAND EDGE ......................................................................................................................... 17 6.1. Limits........................................................................................................................................... 17 6.2. Test Procedure ............................................................................................................................. 17 6.3. Test Result ................................................................................................................................... 17 7. OCCUPIED BANDWIDTH MEASUREMENT ................................................................ 20 7.1. Test Setup .................................................................................................................................... 20 7.2. Test Procedure ............................................................................................................................. 20 7.3. Measurement Equipment Used .................................................................................................... 20 7.4. Test Result ................................................................................................................................... 20 8. ANTENNA REQUIREMENT.............................................................................................. 22 9. PHOTOGRAPH OF TEST ..................................................................................................... 23 Report No.: WST20141022004 WST Certification & Testing (HK) Limited Page 3 of 24 TEST REPORT DECLARATION Applicant : DONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LTD Manufacturer : DONGGUAN CITY YUANYU ELECTRONIC TECHNOLOGY CO., LTD EUT Description : HIVE WIRELESS SPEAKER Model NO. : BL-102, PIE-V002, PIE-V003, PIE-V004, PIE-A001, PIE-A002 All the model are the same circuit and RF module,except the appearance colour, this report only test mode name: BL-102 Serial NO. : N/A Power Supply : DC 5V Measurement Procedure Used: FCC Rules and Regulations Part 15 Subpart C Section 15.249 ANSI C63.4:2009 The device described above is tested by WST Certification & Testing (HK) Limited to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 15 Subpart C Section 15.249 limits. The measurement results are contained in this test report and WST Certification & Testing (HK) Limited. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the Equipment Under Test (EUT) is to b…

Text truncated - open the document above for the full version.

1. PHOTOGRAPH OF TEST Radiated Emission Conducted Power Line Emission
