2ADJ2TXMremote control

remote control MANUAL MODEL TXMULTI English – Programming Instructions 1. Locate the selector switch in the back of the remote. Use a paper clip or small object to pry up the rubber cover to expose the selector switch. 2. Set your selector switch for the desired manufacture. See Chart Below 3. The remote is ready to be used, please refer to your receiver’s user manual. Note: To programming BFT, MUTANCODE and ERREKA- Hidden button (beside the switches) will be necessary. Español – Instrucciones de programación. 1. Localice los DIP switches en la parte trasera del mando. Use un clip o un objeto pequeño para retirar la goma protectora que da acceso a los DIP switches. 2. Seleccione la combinación correspondiente de DIP switches de acuerdo a la marca deseada. Véase la tabla a continuación. 3. El mando está listo para usarse. Por favor, diríjase al manual de usuario de su receptor. Nota: Para BFT, MUTANCODE y ERREKA, será necesaria la utilización del Botón semilla (junto a los DIPS). Batt. Open remote control TX MULTI Num DIP SWITCHES R/F Brand Marca Marque Original Comments Comentarios Commentaires 1 Rolling Code Compatible DEA (KING SISTEM) GENIE GENIE GREEN GENIE WOOD MIO TR-2 315 MHZ 2 Rolling Code Compatible BFT MITTO 315 MHZ NEED HIDDEN BUTTON 3 Rolling Code Compatible Genie 315 MHZ 4 Rolling Code Compatible FAAC XT 433 RC 315 Mhz Red LED LED rojo LED rouge 5 Fixed Code Compatible DITEC GOL4 GOL4C BIXLP2 315 Mhz TX Multi 6 Encrypted Code Compatible NICE FLOR-S 315 MHZ 7 Fixed Code Compatible LIFTMASTER BILLIONCODE 315 MHZ 8 Encrypted Code Compatible Liftmaster Chamberlain Motorlift 700 Lobas Raynor Orion 315 MHZ 9 Encrypted Code Compatible Liftmaster Chamberlain Lobas 315 MHZ 10 Rolling code SOMMER 315 MHZ 11 Encrypted Code MARANTEC 315 MHZ TXMR315 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Rolling Code Limited FCC Confidentiality Request Number: CF303 Version: V01 Date: 01-02-2010 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Rolling Code Limited Addresss 21/F C C WU BLDG, 302-308 HENNESSY RD WANCHAI, City HONG KONG Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: 2ADJ2 TXM of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) hongkong 2014.11.03 Mario Conejo Chacon Manager

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

FCC ID: 2ADJ2TXM

Photo 8 Photo 9

FCC RADIO TEST REPORT FCC ID: 2ADJ2TXM Product： remote control Trade Name： N/A Model Name： Tx Multi Mhz Serial Model： N/A Prepared for remote control 21/F C C WU BLDG, 302-308 HENNESSY RD WANCHAI, HONG KONG Prepared by Shenzhen SCT-CERT Technology Co., Ltd 2F, 18BLD, Internet industry base, Xixiang Street Bao’an District, Shenzhen P.R. China Tel:+86-0755-36932168 Fax:+86-0755-27849355 SCT2014110259 ` TEST RESULT CERTIFICATION Applicant’s name................. : remote control Address ................................. : 21/F C C WU BLDG, 302-308 HENNESSY RD WANCHAI, HONG KONG Manufacture's Name............ : remote control Address ................................. : 21/F C C WU BLDG, 302-308 HENNESSY RD WANCHAI, HONG KONG Product description Product Name ........................... : remote control Model and/or type reference : Tx Multi Mhz Serial Model： N/A Standards............................. : FCC Part15.231:2012 Test procedure .............................. ANSI C63.4-2003 This device described above has been tested by ATT, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of ATT, this document may be altered or revised by ATT, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: Nov. 01 2014 ~Nov. 09 2014 Date of Issue...........................................: Nov. 09 2014 Test Result...............................................: Pass Testing Engineer: (Jack xie) Technical Manager : (Jemes liu) Authorized Signatory : (Amanda mei) SCT2014110259 ` Table of Contents Page 1 . SUMMARY OF TEST RESULTS 4 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2 . GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 7 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 8 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3 . ANTENNA REQUIREMENT 11 3.1 STANDARD REQUIREMENT 11 3.2 EUT ANTENNA 11 3.3 CONDUCTED EMISSION MEASUREMENT 12 3.3.1 POWER LINE CONDUCTED EMISSION LIMITS 12 3.3.2 TEST PROCEDURE 13 3.3.3 DEVIATION FROM TEST STANDARD 13 3.3.4 TEST SETUP 13 3.2.5 TEST RESULT 14 3.4 RADIATED EMISSION MEASUREMENT 15 3.4.1 RADIATED EMISSION LIMITS 15 3.4.2 TEST PROCEDURE 16 3.4.3 DEVIATION FROM TEST STANDARD 16 3.4.4 TEST SETUP 17 3.4.5 TEST RESULTS (BELOW 30MHZ) 19 3.4.6 TEST RESULTS (BETWEEN 30 – 1000 MHZ) 20 4 . BANDWIDTH TEST 22 4.1 TEST PROCEDURE 22 4.2 DEVIATION FROM STANDARD 22 4.3 TEST SETUP 22 4.4 TEST RESULTS 23 5 . TRANSMITTER TIMEOUT 24 5.1 REQUIREMENTS 24 6 . EUT TEST PHOTO 26 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS SCT2014110259 ` 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15, Subpart C (15.231) Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A Note(1) 15.203 Antenna Requirement Pass 15.231 Radiated Spurious Emission Pass 15.231 Occupied Bandwidth Pass 15.231 Transmitter Timeout Pass NOTE: (1) ” N/A” denotes test is not applicable in this Test Report. SCT2014110259 ` 1.1 TEST FACILITY Shenzhen STONE Testing Technology Co.,Ltd. Add.: F/6, Bldg.12, Zhongxing Industrial City, Chuangye Rd., Nanshan District Shenzhen P.R. China FCC Registration No.: 323508; IC Registration No.: 11043A 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% SCT2014110259 ` 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment remote control Trade Name N/A Model Name Tx Multi Mhz Serial Model N/A Model Difference N/A Product Description The EUT is a remote control Product Type Remote Control Operation Frequency: 315MHz Modulation Type: FSK Number Of Channel 1CH. Antenna Designation: Printed antenna Antenna Gain(Peak) 0 dBi Output Power: 74.03 dBuV/m (AV Max.) Channel List N/A Adapter N/A Battery DC 3V Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Table for Filed Antenna Ant . Brand Model Name Antenna Type Connector Gain (dBi) NOTE 1 N/A N/A PCB Antenna NA 0 Antenna SCT2014110259 ` 2.2 DESCRIPTION OF TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 TX For Conducted Emission Final Test Mode Description Mode 1 N/A For Radiated Emission Final Test Mode Description Mode 1 TX Note： (1) The EUT used new battery during the measurement. (2) After The pre-test All button will not affect the emission frequency, modulation mode and power. So only one result recorded. SCT2014110259 ` 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED Radiated Spurious Emission Test E-1 EUT SCT2014110259 ` 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Item Equipment Mfr/Brand Model/Type No. Series No. Note E-1 remote control N/A Tx Multi Mhz N/A EUT Item Shielded Type Ferrite Core Len…

Text truncated - open the document above for the full version.

` 6. EUT TEST PHOTO Radiated Measurement Photos
