2ADK3-9549Wooden Wireless Charging Pad

1. a. b. c. 2. a. b. c. * INSTRUCTIONS: Connect the provided Micro-USB cable to the USB plug adapter. Connect the Micro-USB tip to the input port on the charging pad. Insert corresponding charging cable into the Charging Pad USB port. Charging Mobile Devices: Ensure that your phone or tablet supports wireless charging. It will be listed in the the last page of this manual). Place the enabled device on the surface of the wireless charging pad. The device should display charging indicator. When completely charged, remove the device from the charging pad. Note: To charge devices, use only the accessory cable or the cable included with your own device by the manufacturer. FSC Bora Wooden Wireless Charging Pad Instruction Manual 7141-27 1 x Wireless Charging Pad 1 x USB to Micro-USB Charging Cable 1 x Instruction Manual Input power: 5V/2A MAX Wireless Output: 5W While device is charging LED will illuminate RED. 1. 2. 3. • • • Micro-USB Input Port LED Indicator Charging Pad Surface What’s included: Function: LED Indications *** KEEP OUT OF REACH OF CHILDREN*** SAFETY PRECAUTIONS: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation. Warning: approved by the party responsible for compliance could void the user’s authority to operate the equipment. (1) (2) * FCC Statement: WARNING-When using this product, basic precautions should always be followed: Read all the instructions before use. Never store or use this product in temperatures below 32°F (0°C) or above 115°F (45°C). Do not overcharge your phone. The unit may become hot under excessive use. Remove your phone once it is fully charged. Never charge your phone for more than 7 hours at a time. To reduce the risk of injury, close supervision is required when the product is used near children. • 1. 2. 3. 4. 5. Do not expose the device to moisture. Read all the instructions before using the product. 6. 7. 8. 9. 10. 11. 12. Do not use the device in excess of its output rating. Overload outputs above the Do not use the device if damaged or explosion or risk of injury. Do not disassemble the device. For repairs, Incorrect reassembly may result in a risk of or temperatures above 104°F (40°C) may result in explosion. To ensure product safety, ensure that identical replacement parts. Attachments on the back of your phone can impede the effectiveness of the wireless charger, and lead to overheating. Please remove attachments from the phone before charging on this device. Made in China 15.105 Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC RF Radiation Exposure Statement: 1.This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2.This equipment complies with RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

XING DA INTERNATIONAL ELECTRONICS LIMITED 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: XING DA INTERNATIONAL ELECTRONICS LIMITED Address: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Product Name: Wooden Wireless Charging Pad FCC ID: 2ADK3-9549 Model(s): XO-9549 2.911(d)(5)(i) Equipment Type We, [XING DA INTERNATIONAL ELECTRONICS LIMITED ] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Sam Shen Date: 2024-06-13 Title and Company name: Manager NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

XING DA INTERNATIONAL ELECTRONICS LIMITED 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: XING DA INTERNATIONAL ELECTRONICS LIMITED Address: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Product Name: Wooden Wireless Charging Pad FCC ID: 2ADK3-9549 Model(s): XO-9549 2.911(d)(5)(ii) Applicant filing We, [XING DA INTERNATIONAL ELECTRONICS LIMITED ] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: Sam Shen Date: 2024-06-13 Title and Company name: Manager NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

XING DA INTERNATIONAL ELECTRONICS LIMITED 2.911 (d)(7)USA Agent v1.2 Section 2.911(d)(7) USA Agent for Service of Process Company name: XING DA INTERNATIONAL ELECTRONICS LIMITED Address: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Product Name: Wooden Wireless Charging Pad FCC ID: 2ADK3-9549 Model(s): XO-9549 2.911(d)(7) USA Designated Agent for Service of Process We, [XING DA INTERNATIONAL ELECTRONICS LIMITED ] (“the applicant”) designate [THREE STONES MEDIA LLC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: THREE STONES MEDIA LLC Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 FRN: 0033401761 Contact Name: Sijie Zhang Telephone No: +1 267 909 3692 Email: [email protected] Applicant Company name: XING DA INTERNATIONAL ELECTRONICS LIMITED Address: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China FRN: 0024077448 FCC Grantee Code: 2ADK3 Contact Name: Sam Shen Telephone No: 0769-83454636 Email: [email protected] Signature: Title: Manager Signature: Title: Manager S俨沪� XING DA INTERNATIONAL ELECTRONICS LIMITED 2.911 (d)(7)USA Agent v1.2 Date: 2024-06-13 Date: 2024-06-13 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threat s-to-the-communications-supply-chain-through-the

XING DA INTERNATIONAL ELECTRONICS LIMITED Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-06-13 Subject; Request for Long Term Confidentiality FCC ID: 2ADK3-9549 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram BOM Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Sam Shen Title: Manager

Letter of Authorization Company: XING DA INTERNATIONAL ELECTRONICS LIMITED Address: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China Product Name: Wooden Wireless Charging Pad Model Number: XO-9549 FCC Identifier: 2ADK3-9549 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Sam Shen Date: 2024-06-13 Title: Manager

Model: XO-9549 External Model: XO-9549

Label&Location

Model: XO-9549 Internal Model: XO-9549 Model: XO-9549

Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 1 of 12 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China RF Exposure Report For Applicant Name: XING DA INTERNATIONAL ELECTRONICS LIMITED Address: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China EUT Name: Wooden Wireless Charging Pad Brand Name: N/A Model Number: XO-9549 Issued By Company Name: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Report Number: BTF240528R00302 Test Standards: 47 CFR Part 1 Subpart I Section 1.1310 FCC ID: 2ADK3-9549 Test Conclusion: Pass Test Date: 2024-05-28 to 2024-06-12 Date of Issue: 2024-06-12 Prepared By: Chris Liu / Project Engineer Date: 2024-06-12 Approved By: Ryan.CJ / EMC Manager Date: 2024-06-12 Note: All the test results in this report only related to the testing samples. Which can be duplicated completely for the legal use with approval of applicant; it shall not be reproduced except in full without the written approval of BTF Testing Lab (Shenzhen) Co., Ltd., All the objections should be raised within thirty days from the date of issue. To validate the report, you can contact us. Test Report Number: BTF240528R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 2 of 12 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Revision History Version Issue Date Revisions Content R_V0 2024-06-12 Original Note: Once the revision has been made, then previous versions reports are invalid. Test Report Number: BTF240528R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 3 of 12 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Table of Contents 1. Introduction ............................................................................................................................................................................................ 4 1.1 Identification of Testing Laboratory ................................................................................................................................. 4 1.2 Identification of the Responsible Testing Location ...................................................................................................... 4 1.3 Laboratory Condition ........................................................................................................................................................... 4 1.4 Announcement ....................................................................................................................................................................... 4 2. Product Information .............................................................................................................................................................................. 5 2.1 Application Information ....................................................................................................................................................... 5 2.2 Manufacturer Information .................................................................................................................................................... 5 2.3 Factory Information .............................................................................................................................................................. 5 2.4 General Description of Equipment under Test (EUT)................................................................................................... 5 3. Test Requirement ................................................................................................................................................................................. 6 3.1 Assessment Result ............................................................................................................................................................... 8 3.2 Test Set-up Photo .................................................................................................................................................................. 9 Test Report Number: BTF240528R00302 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 4 of 12 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China 1. Introduction 1.1 Identification of Testing Laboratory Company Name: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Phone Number: +86-0755-23146130 Fax Number: +86-0755-23146130 1.2 Identification of the Responsible Testing Location Test Location: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Description: All measurement facilities used to collect the measurement data are located at F101,201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China FCC Registration Number: 518915 Designation Number: CN1330 1.3 Laboratory Condition Ambient Temperature: 20°C to 25°C Ambient Relative Humidity: 45% to 55% Ambient Pressure: 100 kPa to 102 kPa 1.4 Announcement (1) The test report reference to the report template version v0. (…

Text truncated - open the document above for the full version.

Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 1 of 38 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China RF Test Report For Applicant Name: XING DA INTERNATIONAL ELECTRONICS LIMITED Address: #98 LiWu Swan Industrial District, Qiao Tou Town, Dong Guan, Guang Dong, China EUT Name: Wooden Wireless Charging Pad Brand Name: N/A Model Number: XO-9549 Issued By Company Name: BTF Testing Lab (Shenzhen) Co., Ltd. Address: F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Report Number: BTF240528R00301 Test Standards: 47 CFR Part 15 Subpart C FCC ID: 2ADK3-9549 Test Conclusion: Pass Test Date: 2024-05-28 to 2024-06-12 Date of Issue: 2024-06-12 Prepared By: Chris Liu / Project Engineer Date: 2024-06-12 Approved By: Ryan.CJ / EMC Manager Date: 2024-06-12 Note: All the test results in this report only related to the testing samples. Which can be duplicated completely for the legal use with approval of applicant; it shall not be reproduced except in full without the written approval of BTF Testing Lab (Shenzhen) Co., Ltd., All the objections should be raised within thirty days from the date of issue. To validate the report, you can contact us. Test Report Number: BTF231016R00701 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 2 of 38 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Revision History Version Issue Date Revisions Content R_V0 2024-06-12 Original Note: Once the revision has been made, then previous versions reports are invalid. Test Report Number: BTF231016R00701 Total or partial reproduction of this document without permission of the Laboratory is not allowed. Page 3 of 38 BTF Testing Lab (Shenzhen) Co., Ltd. F101, 201 and 301, Building 1, Block 2, Tantou Industrial Park, Tantou Community, Songgang Street, Bao'an District, Shenzhen, China Table of Contents 1. Introduction ............................................................................................................................................................................................ 4 1.1 Identification of Testing Laboratory ................................................................................................................................. 4 1.2 Identification of the Responsible Testing Location ...................................................................................................... 4 1.3 Laboratory Condition ........................................................................................................................................................... 4 1.4 Announcement ....................................................................................................................................................................... 4 2. Product Information .............................................................................................................................................................................. 5 2.1 Application Information ....................................................................................................................................................... 5 2.2 Manufacturer Information .................................................................................................................................................... 5 2.3 Factory Information .............................................................................................................................................................. 5 2.4 General Description of Equipment under Test (EUT)................................................................................................... 5 2.5 Technical Information........................................................................................................................................................... 6 3. Summary of Test Results .................................................................................................................................................................... 7 3.1 Test Standards ....................................................................................................................................................................... 7 3.2 Summary of Test Result ...................................................................................................................................................... 7 3.3 Uncertainty of Test ................................................................................................................................................................ 7 4. Test Configuration ................................................................................................................................................................................ 8 4.1 Environment Condition ........................................................................................................................................................ 8 4.2 Test Equipment List .............................................................................................................................................................. 8 4.3 Test Auxiliary Equipment .................................................................................................................................................... 9 4.5 Test Setup ............................................................................................................................................................................. 11 5. Test Items ...............................................................................…

Text truncated - open the document above for the full version.

线圈规 格 书 规格编号 A11-02 生效日期 2023-5-5 供应商 东莞市兴跃电子 Dongguan Xing Yue Electronic co., Ltd 产品类型无线充发射线圈 料号 客户料号 【 □ 新版发行 , □ 版本修订】 【 本规范含目录共3 页 】 【 RoHS Compliant Parts 】 编制审核批准 郑豪勇张甜甜许成瑞 地址 本承认书在客户收到30天内，请务必签章返回，逾期视为生产时按此承认书的标准 执行。 【客户核准】 日期: 承认状态： □完全承认 □条件承认 □拒绝承认 批准审核复检检查 说明: √√ 产 品 规 格 书 供应商 东莞市兴跃电子 Dongguan Xing Yue Electronic co., Ltd 客户料号 0 料号型号： A11-02 发行/修订记录 版本生效日期 变更内容/原因 核准 012023-5-5 新规格发行 编制审核批准 产 品 规 格 书 客户名称Dongguan Xing Yue Electronic co., Ltd客户料号 0 料号线圈型号 A11-02 版本 ♦、外形尺寸 (单位: mm) A## B## C## D## E## H## F## 磁片中间孔5 备注 (1) 线径 : 0.08*105P 丝包线 (2) 绕线圈数 :10TS (3) 起尾线是否交叉 : 是 (4) 线圈包 8mm 宽高温胶带 (5) 线圈与磁片需粘贴居中正贴 ♦、电气特性: 参数规格测试条件测试仪器 L06.3±10%μH100KHz/1V■TH1816B Q 50 min100KHz/1V■TH1816B DCR40mΩ@ 25°C■CH-502BC ♦、温度等级: 操作温度 -40°C~ 125°C ♦、材料清单: 序号品名材料规格供应商备注 1 磁片G50磁片PC40猛锌磁材新原料 2 热风绞线0.08*105P丝包线 3 高温胶带8MM环保胶 4 胶环保胶 5 锡107H千岛环保锡 6 胶黄胶环保胶 编制审核批准 天线频段Antenna frequency band: 110-205KHz 天线制造商Antenna manufacturer: Dongguan Xing Yue Electronic co., Ltd

Model: XO-9549 Radiated Emission (9 kHz -30MHz) Model: XO-9549 Radiated Emission (30MHz-1GHz) Conducted Emission (AC Mains)
