2ADKU-02069FM Transmitter with car charger-Hastings

User Manual FM Transmitter with car charger-Hastings Overview Operating instructions Listen music on your car radio system Step1: power on the FM transmitter Step2: Insert the FM transmitter 3.5mm jack connector into the 3.5mm audio socket on your audio device, such as MP3,MP4,Ipod, which has no RF transmitting function. Step3: Tune the frequency of this devices same as your car radio. Step4: Play your music and enjoy it via car stereo Pick up a call on your car stereo system Step1: Connect your phone to the transmitter Step2: Answer the call when the phone rings, then talk handsfree via the car stereo. (For optimal voice clarity, distance of 30-60cm between the user and the transmitter is advised) Note: Please charge the FM transmitter for 3-4 hours when you get it, in order to make it work better. please do not charge to long time in order to prolong the life of the battery It can not work while the phone is wearing a protect case. Features Full frequency range, memory for last frequency Powered by rechargeable built-in lithium battery, no need to consume your cellphone’s power. Included a cable to charge this device via PC or other car charger, input:5v/1A FAQ: 1. If the FM transmitter can not get charged, please make sure the micro usb cable was connected to the FM transmitter tightly, or please use your other micro usb cable to charge it if possible. 2. If the FM signal is interrupted, please reset the car radio and this device to another clear frequency (Blank frequency no local radio used ) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help.

March 30, 2015 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2ADKU-02069___ _ Product Name: FM Transmitter with car charger-Hastings Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics Long-term confidential  Block diagram Long-term confidential  Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this March 30, 2015 Agency agreement expiration date: Usually Give 8 - 12 Months By: Robert Chen Signature Printed Title: Manager On behalf of : (Company Name) National Entertainment Collectibles Associat ion (NECA) Telephone: 908-686-3300

March 30, 2015 Nemko Canada Inc 303 River Road Ottawa, Ontario, Canada K1V 1H2 Attn: Director of Certification Authority to Act as Agent On our behalf, I appoint Shenzhen Alpha Product Testing Co., Ltd. Address: Building B, East Area of Nanchang Second Industrial Zone, Gushu 2nd Road, Bao'anDistrict, Shenzhen 518126,P.R.China Person: Mark Zhu (Name and address，person). to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with National Entertainment Collectibles Association (NECA) . Address: 603 Sweetland Avenue Hillside, NJ 07205 USA ( applicant name and address). Signature: Name Robert Chen Position Manager Company Name National Entertainment Collectibles Association (NECA) Address 603 Sweetland Avenue Hillside, NJ 07205 USA Tel 908-686-3300 Fax 908-686-0301 Email [email protected]

20mm 7mm FCC ID: 2ADKU-02069

Label location

Antenna

Shenzhen Alpha Product Testing Co., Ltd. TEST REPORT FCC ID: 2ADKU-02069 Applicant : National Entertainment Collectibles Association (NECA) Address : 603 Sweetland Avenue Hillside, NJ 07205 USA Equipment under Test (EUT): Name : FM Transmitter with car charger-Hastings Model : 02069 Standards : FCC PART 15, SUBPART C : 2014 (Section 15.239) Report No. : A1850161 01 Date of Test: March 18- March 25, 2015 Date of Issue: March 25, 2015 Test Result : PASS * *In the configuration tested, the EUT complied with the standards specified above Authorized Signature (Mark Zhu) General Manager The manufacture should ensure that all the products in series production are in conformity with the product sample detailed in this report. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of Shenzhen Alpha Product Testing Co., Ltd. Or test done by Shenzhen Alpha Product Testing Co., Ltd. Approvals in connection with, distribution or use of the product described in this report must be approved by Shenzhen Alpha Product Testing Co., Ltd. Approvals in writing. Page 2 of 31 Report No.:A1850161 01 TABLE OF CONTENT Description Page 1 General Information ----------------------------------------------------------------------------------- 3 1.1 Description of Device (EUT) ---------------------------------------------------------------- 3 1.2 Description of Test Facility ------------------------------------------------------------------ 3 2 EMC Equipment List ------------------------------------------------------------------------------- 4 3 Test Procedure ---------------------------------------------------------------------------------------- 5 4 Summary of Measurement ------------------------------------------------------------------------ 6 4.1 Summary of test result ----------------------------------------------------------------------- 6 4.2 Test mode -------------------------------------------------------------------------------------- 6 5 POWER LINE CONDUCTED EMISSION --------------------------------------------------- 8 5.1 Conducted Emission Limits(15.209&249) ------------------------------------------------ 8 5.2 Test Setup -------------------------------------------------------------------------------------- 8 5.3 Test Procedure --------------------------------------------------------------------------------- 9 5.4 Test Results ------------------------------------------------------------------------------------ 9 6 Radiation Emission -------------------------------------------------------------------------------- 10 6.1 Radiation Emission Limits(15.209&249 (a)) -------------------------------------------- 10 6.2 Test Setup ------------------------------------------------------------------------------------- 11 6.3 Test Procedure -------------------------------------------------------------------------------- 12 6.4 Test Equipment Setting For emission test. ----------------------------------------------- 13 6.5 Test Condition -------------------------------------------------------------------------------- 13 6.6 Test Result ------------------------------------------------------------------------------------ 13 7 Occupied bandwidth ------------------------------------------------------------------------------- 17 7.1 Test limit -------------------------------------------------------------------------------------- 17 7.2 Method of measurement -------------------------------------------------------------------- 17 7.3 Test Setup ------------------------------------------------------------------------------------- 17 7.4 Test Results ----------------------------------------------------------------------------------- 17 8 Band Edge Check ---------------------------------------------------------------------------------- 20 8.1 Test limit -------------------------------------------------------------------------------------- 20 8.2 Test Procedure -------------------------------------------------------------------------------- 20 8.3 Test Setup ------------------------------------------------------------------------------------- 20 8.4 Test Result ------------------------------------------------------------------------------------ 20 9 Antenna Requirement ----------------------------------------------------------------------------- 23 9.1 Standard Requirement ----------------------------------------------------------------------- 23 9.2 Antenna Connected Construction ---------------------------------------------------------- 23 9.3 Result ------------------------------------------------------------------------------------------ 23 10 Photographs of Test Setup ------------------------------------------------------------------------ 24 11 Photographs of EUT ------------------------------------------------------------------------------- 25 Page 3 of 31 Report No.:A1850161 01 1 General Information 1.1 Description of Device (EUT) EUT : FM Transmitter with car charger-Hastings Trade Name : N/A Model No. : 02069 Type of Antenna : Integrated Antenna, Max. Gain: 0dBi Operation Frequency : 88.1-107.9MHz Channel number : 199 Modulation type : FM Power Supply : DC 5.0V From car charger for charge or DC 3.7V from battery Applicant : National Entertainment Collectibles Association (NECA) Address : 11-11 44 th Drive,Long Island, New York,United States Manufacturer : C-STAR INDUSTRIAL LIMITED Address : 4F, C11 block, Fuyuan Industrial Area, Jiuwei, Xixiang, Bao’an, Shenzhen, China 1.2 Description of Test Facility Shenzhen Alpha Product Testing Co., Ltd. Building B, East Area of Nanchang Second, Industrial Zone, Gushu 2nd Road, Bao'an, Shenzhen, China August 11, 2014 File on Federal Communication Commission Registration Number: 203110 Page 4 of 31 Report No.:A1850161 01 2 EMC Equipment List Equipment Manufacture Model No. Serial No. Cal. Due day Cal Interval 3m Semi-Anechoic ETS-LINDGRENN/A SEL…
